MH EDS O 2 D1-2G
Electronic Digital Pulse-Demand
Aviation Oxygen Delivery System
INSTRUCTION MANUAL
Thank you for purchasing the MH EDS O 2 D1-2G
Pulse-Demand Oxygen Controller. The MH EDS
O 2 D1-2G (O2D1) is patented oxygen control tech-
nology that allows you and your co-pilot to fly with
safety and comfort, knowing it will automatically
give the oxygen required at the various altitudes.
THE EDS O 2 D1-2G IS DESIGNED FOR
EASY OPERATION, PLEASE CAREFULLY
READ THIS INSTRUCTION MANUAL
BEFORE USE.
INTRODUCTION ....................................2
FEATURES .............................................2
BASIC SAFETY ......................................2
GETTING STARTED ...............................3
THE BATTERIES .....................................4
REMOVING THE TUBING ......................4
STORING THE O2D1 .............................4
MOUNTING THE O2D1 .........................4
MODE CONTROL SWITCH SETTINGS
AND MODES OF OPERATION ..............5
ALARMS AND ALERTS .........................6
THIRD PARTY REGULATOR ..................6
TROUBLE-SHOOTING ...........................7
WARRANTY ..........................................7
MAINTENANCE QUESTIONS ................8
KNOW ABOUT OXYGEN ......................9
AUTO COMPENSATION ......................11
O2D1-2G SPECIFICATIONS ................12
5MD10-0002-00$b 2015-10-01
Single Person
TM
CONTENTS
Advertisement
Table of Contents
Related Manuals for MH Pulse-Demand MH EDS O2D1-2G
Summary of Contents for MH Pulse-Demand MH EDS O2D1-2G
-
Page 1: Table Of Contents
Electronic Digital Pulse-Demand Aviation Oxygen Delivery System INSTRUCTION MANUAL Thank you for purchasing the MH EDS O 2 D1-2G Pulse-Demand Oxygen Controller. The MH EDS O 2 D1-2G (O2D1) is patented oxygen control tech- nology that allows you and your co-pilot to fly with safety and comfort, knowing it will automatically give the oxygen required at the various altitudes. -
Page 2: Introduction
INTRODUCTION The patented MH EDS-O2D1-2G (O2D1) is an aviation oxygen delivery device for one person. It is designed to deliver aviation oxygen in the most efficient, comfortable and convenient way possible. With its user-selectable settings, apnea alarm and small size, the O2D1 is the most portable and flexible electronic digital oxygen delivery system in the world. -
Page 3: Getting Started
(approx.1/8 inch). Then connect the other end of the tube to AA Batteries (Qty 2) Tote Bag your regulator. If you are using a MH single port regulator Cannulas 3M Dual-Lock™ Tape (XCR), use the red tube that came with the regulator in place 1 standard, 1 flared tip of the tube that came with your O2D1. -
Page 4: Inserting & Removing The Batteries
INSERTING AND REMOVING THE BATTERIES Remove the battery door by pressing down gently on the battery cover flange then slide the door out and away from the unit. The O2D1 unit uses two (2) standard AA alkaline batteries. Insert the batteries as shown on the label inside the battery compartment (they will be a tight fit), then replace the door by slid- ing the door into place until it snaps in place. -
Page 5: And Modes Of Operation
The F-Mode settings augment the amount of oxygen needed to compensate for the additional dead-space plenum associated with face masks. They also can be used with the MH cannula in situations where more oxygen may be required over the normal ‘N’ and ‘D’ set- tings. -
Page 6: Alarms And Alerts
Time before Apnea event is ~30 ~35 seconds. This typically occurs for the following reasons: (1) The user has quit breathing for 30 - 45 seconds or the cannula/face mask is improperly worn. (2) The outlet tube from the MH EDS- O2D1 to the mask or cannula has become disconnected. -
Page 7: Trouble-Shooting
Mountain High Equipment & Supply Company warrants your MH EDS-O2D1-2G unit against defects in materials and workmanship for two (2) years from date of purchase invoice. The warranty is non-transferable. Should any part of the MH EDS-O2D1-2G become defective within the warranty period, contact our Service Department (service@MHoxygen.com) to request a RMA (Return Materials Authorization). -
Page 8: Maintenance Questions
Portable Systems: ™ I have one of your portable MH-EDS PULSE DEMAND™ units. It seems to be operating just fine, should I send it in for any type of routine service or testing? Yes. Even though your pulse-demand unit will generally let you know if there is a problem and has been designed to be relatively maintenance free except for batteries, it should be sent in on a regular basis for performance inspection and service. -
Page 9: What Every Pilot Should Know About Oxygen
WHAT EVERY PILOT SHOULD KNOW ABOUT OXYGEN What Is Air? The air surrounding us is a mixture of gases consisting of 78% nitrogen and 21% oxygen. The remaining 1% is made up of argon, carbon dioxide, and traces of rare gases. What Is Oxygen? Under normal conditions, pure oxygen is a colorless, tasteless, odorless, non-combustible gas. - Page 10 How Should An Oxygen System Or Equipment Be Selected? Your MH Sales Engineer can help you at 800-468-8185. He or she can assist the pilot in selecting the system best suited to the specific airplane and the pilot’s special needs.
-
Page 11: Auto Compensation
AUTO COMPENSATION INFORMATION EDS O2D1-2G Auto-compensation Altitude compensated breathing sensor Because absolute atmospheric pressure lessens as a function of altitude, breathing efforts assert less pressure upon breath- ing sensors to the point at which they may not properly detect breathing while at higher altitudes. Additionally, as the partial pressure of CO2 drops below a normalized point with altitude, one’s breathing efforts also diminish. -
Page 12: O2D1-2G Specifications
SPECIFICATIONS The O2D1 Specifications, performance standards and limits are derived from actual units tested, characterized or calculated. Specifications are subject to change without notice. Allowable respiration rates: Adaptive: up to 43 bpm. And down to ~ 5 bpm. Apnea time-out envelope: Adaptive: ~40 sec Pa. 0-12 K ft., ~30 sec. Pa. 13-18 K ft., 20 Sec. at and above Pa. 18 K ft. Apnea alarm does not respond if in any of the ‘D’...
