Summary of Contents for Victorian Plumbing Cruze WH-8801
- Page 1 WH-8801 User manual...
-
Page 2: Table Of Contents
Contents Important safety warning Product specifications Preparation before first use Other fu nctiona I description Overall sketch Operation Cleaning Warm air drying Key Flush Lamp control Water temperature adjustment Drying temperature adjustment Seat temperature adjustment Night light Remote button function Remote control operation protection Maintenance and cleaning Troubleshooting... -
Page 3: Important Safety Warning
Important safety warning Save these instructions. Warning: Risk of electric shock, fire, or injury to life. This product must be grounded safely. Connect to a dedicated 220-230V AC.50Hz.10A. In a circuit with a ground fault circuit breaker or an earth leakage protector. Warning: Risk of electric shock or product damage. - Page 4 When using electrical products, especially when there are children, basic safety protection should be observed included the following: Danger - Reduce the risk of electric shock: □ Do not touch the toilet that has been sprayed with water. Warning - Reduce the risk of low burns, electric shock, fire or personal injury: □...
-
Page 5: Product Specifications
Product specifications Water supply pressure (dynamic 0.7kgf/cm2~ 7. Skgf/cm2 (0.07Mpa. ~ pressure) 0.74M pa.) 50 Hz 220~230V Specification 1600W (cold water temperature ° < Power cord length About lm Use environment 0~40°C Hip rinse/ female rinse 0.42~1.2L/min (three grades adjustable)) Water Laxative flushing 0.42~1.2L/min (three grades adjustable)) -
Page 6: Preparation Before First Use
Product Specifications (continued) Remote control Set various functions Health Nozzle self-cleaning Have. Antibacterial material Seat, nozzle Auxiliary Button nob On the side of the body Other Sitting sensor. Located inside the seat Functions Night light One blue LED light Preparation before first use □... -
Page 7: Overall Sketch
Overall sketch Button Button control: The front spine is cleaned, the female is cleaned after the rotation, and the cleaning is stopped by pressing. (Note: The above smart toilet is one of the toilet models, which is subject to the actual product. ) -
Page 8: Cleaning
Female cleaning Operational function of the toilet. -stop -start up Press the button and hear a "beep'' After the spin button, you hear a "beep'' and start the female cleaning. to stop the female cleaning. The cleaning will automatically stop after approximately three minutes of continuous cleaning. Cleaning Operational function of the toilet. -
Page 9: Warm Air Drying
Warm air-drying Operation function operation of the toilet. -start up -stop “beep" Press the button and hear a Press the button again and hear a "beep.” to start the warm air arch. stop the warm air drying. After 6-7s, automatically stop after approximately three minutes of continuous drying. Drying will Lamp control... -
Page 10: Water Temperature Adjustment
Water temperature adjustment When cleaning: -Warming -Desuperheat The button is continuously rotated forward 2 The button is continuously rotated backwards two times, and when the "beep" is heard, the times, and when the sound is heard, the water water temperature rises by one step. temperature is lowered by one step. -
Page 11: Seat Temperature Adjustment
Seat temperature adjustment Operational function of the toilet: -Warming -Desuperheat The button rotates forward two times in a row, The button is continuously rotated backwards two and when "beep" is heard, the seat times, and when "beep" is heard, the seat temperature rises by one step' temperature is lowered by one step. -
Page 12: Remote Button Function
Remote button function Note: For the first time, if the remote control does not respond to use, you need to re code. (Refer to the coding method on the following page) Pulsate Power Stop Flush Dryer Rear Front Water Seat Wind Press this button to perform the drying Press this button to perform... -
Page 13: Remote Control Operation Protection
Remote control operation protection A The remote control communicates with the body. The remote control controls the body by sending wireless signal. The closer signal is, the stronger the signal is. Please choose the installation location. B Remote control signal pair code If the remote control is lost or damaged, need to pair the signal with the appliance with a new remote control. -
Page 14: Maintenance And Cleaning
Maintenance and cleaning Avoid rough surface materials: use soft, wet sponges or cotton cloth, do not use rough surface, materials to clean the surface, such as brushes, scour pads, etc. Scrub: Immediately after adding the cleaner, wipe the surface with a damp cloth and wipe off the detergent and dirt sprayed onto the surface. - Page 15 Maintenance and cleaning Seat cover and seat cleaning: It is not recommended that the user disassemble the seat cover and the seat to clean the dirt in the corners, so as not to damage the internal connecting wires and electrical components. Please contact a qualified electrician to disassemble and replace the cover and seat.
- Page 16 Maintenance and cleaning • Maintenance when not in use for extended periods of time are not going to use the smart toilet cover for a long time, be sure to close the water stop valve. • Turn off the power. •...
- Page 17 Troubleshooting (continued) Cleaning function Symptoms Possible reason Recommended measures A. The water supply valve has been closed. A. Open the water supply value. water flow B. Check the active seat information in the "Usage B. The drop sensor does not detect the user.
-
Page 18: Troubleshooting
Troubleshooting (continued Remote control Symptoms Possible reason Recommended measures The battery is exhausted, or the battery A. Please replace the battery, please insert polarity is reversed. the battery correctly. The remote control is in the water. B. Take out the battery in time and then dry it. Remote control does not The remote control is broken. - Page 19 Size Dimension drawing of floor mounted toilet installation...
