Technical Data
MAXIMUM RECOMMENDED MOUNTING HEIGHT: 3.0m
RANGE: Cone-shaped detection pattern, diameter (at floor level) = 2.4 x mounting height
2.5m
6.0m
OPERATING VOLTAGE: 230V 50Hz (UK & Europe)
o
ta = 0 - 50 C
CAPACITY: Total load must not exceed 2 AMPS, up to 4 Ballasts MAX
Electronic, high-frequency ballasts ONLY
INTERCONNECT CABLE TEMPERATURE RATING:
COLOUR: White or silver bezel (DHW = White, DHS = Silver)
MATERIAL: UV stabilised polycarbonate (DHW/DHS)
Flame retardant PC/ABS (MSM2000A)
IP RATING: 20
DIMENSIONS: See diagrams overleaf
WEIGHT: 32g (DHW/DHS)
48g (MSM2000A)
Ex-Or
Haydock Lane, Haydock, Merseyside WA11 9UJ
Tel: +44 (0)1942 719229
Fax: +44 (0)1942 272767
Email: technicalsales.ex-or@honeywell.com
www.ex-or.com
o
60 C
At the end of their useful life
the packaging and product
should be disposed of via a
suitable recycling centre.
Do not dispose of with normal
household waste.
Do not burn.
W4206G
LightSpot Digital Luminaire Controllers
MSM2000A - Control Module
DHW/DHS - Mini Detector Head
for use with Analogue 1-10V and Fixed-Output
Electronic High-frequency Ballasts
Installation and Commissioning
Instructions
Note: HP2000 or HP10 required for commissioning
