Safety Instructions • Position on a flat, stable surface. • A service agent/qualified technician should carry out installation and any repairs if required. Do not remove any components or service panels on this product. • Consult Local and National Standards to comply with the following: - Health and Safety at Work Legislation - BS EN Codes of Practice...
• POLAR recommend that this appliance should be periodically tested (at least annually) by a Competent Person. Testing should include, but not be limited to: Visual Inspection, Polarity Test, Earth Continuity, Insulation Continuity and Functional Testing. • POLAR recommend that this product is connected to a circuit protected by an appropriate RCD (Residual Current Device).
Installation Lock/Unlock the Doors A lock is fitted to the doors to ensure foodstuffs are kept secure within your POLAR appliance. Note: Not for use in vans or trailers, food trucks or similar vehicles. Use the keys provided to lock/unlock the doors. Note: If the unit has not been stored or •...
Operation Storing Food To get the best results from your POLAR appliance, follow these instructions: • Only store foodstuffs in the appliance when it has reached the correct operating temperature. • Do not place uncovered items as below inside the appliance, as this can lead to a damaged and leaking evaporator, and thus void your warranty: hot food, hot liquids, acidic fluids, acidic products.
Note: Due to our continuing program of research and development, the specifications herein may subject to change without notice. Model Voltage Power Current Dimensions H x W x D mm Weight (kg) UA025 220-240V~ 50Hz 600W 3,5A 2000 x 680 x 810 Compartment Temp. Range Net usable capacity (Ltr)
Troubleshooting A qualified technician must carry out repairs if required. Fault Probable Cause Solution The appliance is not The unit is not switched on Check unit is plugged in correctly and working switched on Plug or lead is damaged Replace plug or lead Fuse in the plug has blown Replace the fuse Mains power supply fault...
Electrical Wiring POLAR appliances are supplied with a 3 pin BS1363 plug and lead. The plug is to be connected to a suitable mains socket. POLAR appliances are wired as follows: • Live wire (coloured brown) to terminal marked L •...
Page 9
Veiligheidstips • Plaatsen op een vlakke en stabiele ondergrond. • De installatie en eventuele reparaties zijn door een servicetechnicus/vaktechnicus uit te voeren. Verwijder geen componenten of servicepanelen van dit product. • Raadpleeg en volg de plaatselijke en nationale regelgeving op m.b.t.
Page 10
• Indien de stroomkabel beschadigd raakt, dient men deze door een Polar technicus of een aanbevolen vaktechnicus te laten vervangen om gevaarlijke situaties te verhinderen. • Polar beveelt aan dat dit apparaat periodiek (minstens jaarlijks) door een bevoegd persoon wordt getest. Tests moeten omvatten, maar zijn niet beperkt tot: visuele inspectie, polariteit, aardings continuïteit (klasse I-apparatuur), isolatie continuïteit en functionele test.
Page 11
Installatie Vergrendelen/ontgrendelen van deuren De deuren zijn voorzien van een slot om de Niet voor gebruik in bestelwagens of levensmiddelen veilig te bewaren in uw Polar aanhangwagens, foodtrucks of soortgelijke product. voertuigen. Gebruik de meegeleverde sleutels om de deuren te Indien het apparaat niet in een vergrendelen/ontgrendelen.
Bediening Opslag van levensmiddelen Volg de volgende aanwijzingen voor de beste resultaten met uw Polar product: • Bewaar uitsluitend levensmiddelen in het product wanneer het product de juiste gebruikstemperatuur heeft gereikt. • Plaats geen onbedekte voorwerpen zoals hieronder vermeld in het toestel, aangezien dit kan leiden tot een beschadigde en lekkende verdamper, waardoor uw garantie vervalt: heet voedsel, hete vloeistoffen, zure vloeistoffen, zure producten.
Afmetingen Gewicht Model Voltage Vermogen Stroom h x b x d mm (kg) UA025 220-240V~ 50Hz 600W 3,5A 2000 x 680 x 810 Compartiment Temperatuurbereik Net bruikbare capaciteit (Ltr) Bruto volume (Ltr) Koelmiddel Bovenste 2°C ~ 8°C...
Oplossen van problemen Indien nodig moet een gekwalificeerde technicus reparaties uitvoeren. Probleem Mogelijke oorzaak Handeling Het apparaat Het apparaat staat uit Controleer of de stroomkabel van het werkt niet apparaat is aangesloten en of het apparaat is ingeschakeld Stekker en kabel zijn beschadigd Vervang stekker of kabel Storing netvoeding Controleer netvoeding...
Elektrische bedrading Men dient de stekker op een geschikt stopcontact aan te sluiten. De bedrading van dit apparaat is als volgt: • Stroomkabel (bruin) naar de aansluitklem gemarkeerd met L • Neutraalkabel (blauw) naar de aansluitklem gemarkeerd met N • Aardekabel (groen/geel) naar de aansluitklem gemarkeerd met E Dit apparaat moet worden geaard.
Conseils de sécurité • Placez l’appareil sur une surface plane, stable. • L’installation et les éventuelles réparations doivent être confiées à un dépanneur / technicien qualifié. Ne retirez aucun composant ou cache de ce produit. • Consultez les normes locales et nationales pour vous conformer aux : - lois sur l’hygiène et la sécurité...
• Un cordon d’alimentation endommagé doit être remplacé par un agent POLAR ou un technicien qualifié recommandé, pour éviter tout danger. • POLAR recommande de faire tester régulièrement cet appareil (une fois par an au minimum) par une personne compétente. Le test devrait inclure, entre autres : inspection visuelle, test de polarité, la continuité...
Installation Verrouillage / déverrouillage des portes Ne pas utiliser dans des camionnettes ou Les portes sont munies d’un verrou qui vous des semi-remorques, dans des camions- permet d’enfermer les aliments dans votre appareil restaurants ou véhicules similaires. Polar. Remarque : Dans les cas où l’appareil a été Le verrouillage / déverrouillage de l’appareil stocké...
Fonctionnement Stockage des aliments Suivez ces consignes pour profiter au mieux de votre appareil POLAR : • Ne stockez des aliments dans l’appareil que lorsqu’il a atteint la bonne température de fonctionnement. • Ne placez pas d’articles non couverts comme ceux mentionnés ci-dessous à l’intérieur de l’appareil, car cela pourrait entraîner un évaporateur endommagé...
Remarque : en raison de notre programme continu de recherche et de développement, les spécifications du présent document peuvent être modifiées sans préavis. Modèle Tension Puissance Courant Dimensions h x l x p mm Poids (kg) UA025 220-240V~ 50Hz 600W 3,5A 2000 x 680 x 810 Compartiment Plage de température Capacité Nette (L) Volume brut (L) Réfrigérant...
Dépannage Un technicien qualifié doit effectuer les réparations si nécessaire. Dysfonctionnement Cause probable Intervention L'appareil ne L'appareil n'est pas allumé Vérifier que l'appareil est bien branché et fonctionne pas allumé La fiche ou le câble est endommagé Remplacez la fiche ou le câble Défaut d’alimentation secteur Vérifier l’alimentation secteur L'appareil s'allume,...
Raccordement électrique La prise doit être reliée à la prise secteur qui convient. Cet appareil est câblé comme suit : • Fil conducteur (brun) à la borne marquée L • Fil neutre (bleu) à la borne marquée N • Fil de terre (vert / jaune) à la borne marquée E Cet appareil doit être mis à...
Page 23
Sicherheitshinweise • Auf eine flache, stabile Fläche stellen. • Alle erforderlichen Montage- und Reparaturarbeiten sollten von Wartungspersonal oder einem qualifizierten Techniker durchgeführt werden. Keine Bauteile oder Bedienflächen von diesem Produkt entfernen. • Für folgende Normen und Vorschriften sind die lokalen und nationalen Normen heranzuziehen: - Arbeitsschutzvorschriften - BS EN Verhaltenspraktiken...
Page 24
• Verpackungsmaterial außerhalb der Reichweite von Kindern aufbewahren und gemäß den lokalen Vorschriften entsorgen. • POLAR empfiehlt, dass dieses Gerät regelmäßig (wenigstens jährlich) von einem Fachmann überprüft wird. Die Überprüfung sollte beinhalten, ohne darauf beschränkt zu sein: Visuelle Überprüfung, Polaritätstest, Erdungskontinuität (Klasse-1- Geräte), Isolationskontinuität und Funktionalitätsprüfung.
Montage Ver-/Entriegeln der Türen Um sicherzustellen, dass Nahrungsmittel in Ihrem Hinweis: Nicht zur Verwendung in Polar-Gerät sicher aufbewahrt werden, ist an den Lieferwagen oder Anhängern, Transportern Türen ein Schloss angebracht. oder ähnlichen Fahrzeugen. Mit den Schlüsseln im Lieferumfang können Sie die Hinweis: Wenn das Gerät nicht aufrecht Türen ver- bzw.
Betrieb Lagerung von Nahrungsmitteln Sie erzielen die besten Ergebnisse mit Ihrem POLAR-Gerät, wenn Sie folgende Anweisungen beachten: • Nahrungsmittel dürfen erst nach Erreichen der korrekten Betriebstemperatur im Gerät gelagert werden. • Legen Sie keine unbedeckten Gegenstände wie die folgenden in das Gerät, da dies zu einem beschädigten und undichten Verdampfer führen kann und somit Ihre Garantie erlischt: heiße Lebensmittel, heiße Flüssigkeiten, säurehaltige Flüssigkeiten, säurehaltige Produkte.
Hinweis: Aufgrund unseres kontinuierlichen Forschungs- und Entwicklungsprogramms können sich die hier aufgeführten Spezifikationen ohne vorherige Ankündigung ändern. Abmessungen Modell Spannung Leistung Stromstärke Gewicht (kg) h x b x t mm UA025 220-240V~ 50Hz 600W 3,5A 2000 x 680 x 810 Abteil Temperaturbereich Nutzinhalt (Liter) Bruttoinhalt (Liter) Kühlmittel...
Störungssuche Falls erforderlich, muss ein qualifizierter Techniker Reparaturen durchführen. Störung Vermutliche Ursache Lösung Das Gerät Das Gerät ist nicht eingeschaltet Prüfen, ob der Netzstecker in die funktioniert nicht Steckdose gesteckt wurde und das Gerät eingeschaltet ist Stecker und Kabel sind beschädigt Stecker oder Leitung ersetzen Fehler Netzstromversorgung Prüfe Netzstromversorgung...
Page 29
Elektroanschlüsse Der Stecker muss in eine geeignete Steckdose gesteckt werden. Das Gerät ist wie folgt verdrahtet: • Stromführender Leiter (braun) an Klemme L • Neutralleiter (blau) an Klemme N • Erdleiter (grün/gelb) an Klemme E Dieses Gerät muss geerdet sein. Bei Fragen wenden Sie sich bitte an einen qualifizierten Elektriker.
Suggerimenti per la sicurezza • Posizionare su una superficie piana e stabile. • L’installazione e le eventuali riparazioni devono venire eseguite da un agente/tecnico qualificato. Non rimuovere i componenti o i pannelli di accesso dell’apparecchio. • Verificare la conformità alle normative locali e nazionali di quanto segue: - Normativa antinfortunistica sul lavoro - Linee guida BS EN...
• Se danneggiato, il cavo di alimentazione deve venire sostituito da un agente POLAR o da un tecnico qualificato al fine di prevenire eventuali rischi. • POLAR raccomanda che questo apparecchio venga periodicamente testato (almeno una volta all’anno) da una persona competente.
Installazione Blocco/sblocco dei portelli Una serratura è montata sui portelli per assicurasi Nota: Non per l’uso in furgoni o rimorchi, che i cibi siano conservati al sicuro all’interno camion per il trasporto del cibo o veicoli dell’apparecchio Polar. simili. Nota: se l’apparecchio è stato Utilizzare le chiavi fornite per bloccare/sbloccare i immagazzinato o spostato in posizione non portelli.
Funzionamento Conservazione dei cibi Per ottenere i migliori risultati dall’apparecchio POLAR, osservare le seguenti istruzioni: • Conservare i cibi nell’apparecchio solo quando esso ha raggiunto la corretta temperatura di esercizio. • Non collocare all’interno dell’apparecchio oggetti non coperti come quelli indicati di seguito, in quanto ciò...
Nota: a causa del nostro continuo programma di ricerca e sviluppo, le specifiche qui riportate possono essere soggette a modifiche senza preavviso. Modello Tensione Alimentazio Corrente Dimensioni h x l x p mm Peso (kg) UA025 220-240V~ 50Hz 600W 3,5A 2000 x 680 x 810 Scomparto Intervallo di temperatura Capacità netta (litri)
Risoluzione dei problemi Se necessario, un tecnico qualificato deve eseguire le riparazioni. Guasto Probabile causa Azione L'apparecchio non L'apparecchio non è acceso Controllare che l'apparecchio sia funziona correttamente collegato e acceso La presa e il cavo sono danneggiati Sostituire la spina o il cavo Guasto alimentazione di rete Controllare l’alimentazione di rete L'apparecchi si...
Cablaggi elettrici La spina deve venire collegata a una presa di rete appropriata. L’apparecchio ha i seguenti cablaggi: • Filo sotto tensione (colore marrone) a terminale L • Filo del neutro (colore blu) a terminale N • Filo di terra (colore verde/giallo) a terminale E Questa apparecchiatura deve essere collegata a terra.
Consejos de Seguridad • Colóquela sobre una superficie plana y estable. • Un agente del servicio técnico cualificado debería llevar a cabo la instalación y cualquier reparación si se precisa. No retire ningún componente ni panel de servicio de este producto. •...
• POLAR recomienda que este aparato debe ser periódicamente probado (al menos anualmente) por una Persona Competente. La prueba debe incluir, pero no debe estar limitado a: Inspección visual, Prueba de polaridad, Toma a tierra, continuidad de aislamiento y prueba Funcional. Precaución: Riesgo de Incendio •...
Instalación Abrir y cerrar las puertas con llave Se incorpora una cerradura en las puertas para Nota: No debe utilizarse en furgonetas garantizar que los alimentos se mantengan seguros o remolques, camiones de alimentos o dentro de su aparato Polar. vehículos similares.
Funcionamiento Almacenamiento de comida Para obtener los mejores resultados de su aparato POLAR, siga estas instrucciones: • Guarde alimentos en el aparato sólo cuando haya alcanzado la temperatura de funcionamiento correcta. • No coloque en el interior del aparato objetos que no estén cubiertos como los que se indican a continuación, ya que esto puede hacer que el evaporador se dañe y tenga fugas, anulando así...
Nota: Debido a nuestro continuo programa de investigación y desarrollo, las especificaciones aquí expuestas pueden estar sujetas a cambios sin previo aviso. Modelo Tensión Potencia Corriente Dimensiones a x a x p mm Peso (kg) UA025 220-240V~ 50Hz 600W 3,5A 2000 x 680 x 810 Compartimiento Margen de Temperaturas Capacidad Neta (l) Volúmen Bruto (l)
Resolución de problemas Un técnico calificado debe realizar las reparaciones si es necesario. Fallo Causa probable Acción El aparato no El aparato no está conectado Compruebe que el aparato esté enchufado funciona correctamente y conectado El enchufe y el cable están dañados Reemplace el enchufe o el cable Fallo de la fuente de alimentación Compruebe la fuente de alimentación de de red...
Cableado Eléctrico El enchufe tiene que conectarse a una toma eléctrica adecuada. Este aparato está conectado de la forma siguiente: • Cable cargado (de color marrón) al terminal marcado como L • Cable neutro (de color azul) al terminal marcado como N •...
Equipment Type • Uitrustingstype • Type d'équipement • Gerätetyp Model • Modèle • Modell • Modello • Tipo di apparecchiatura • Tipo de equipo • Modelo U-Series Fridge Freezer UA025 (& -E) Application of Territory Legislation & Machinery Directive 2006/42/EC Council Directives(s) Supply of Machinery (Safety) Regulations 2008...
