smart-me Pico Quick Start Manual

Pico
Art. 232070
Riedstrasse 18 | 6343 Rotkreuz | Switzerland
support@smart-me.com | +41 (0) 41 511 09 70
www.smart-me.com
smart-me wiki: dok.smart-me.com
This document was last edited on: 2023-05-23
Installation & Configuration Guide
EN- Scan the QR Code to find the Installation and Configuration guide as well as
additional information
DE- Scanne den QR-Code, um die Installations- und Konfigurationsanleitung sowie
weitere Informationen zu erhalten.
https://web.smart-me.com/232070-qr/

Declaration of Conformity

smart-me AG, Riedstrasse 18, CH-6343 Rotkreuz hereby declares that the smart-me Pico
EV-Charger complies with the following guidelines:
Measuring lnstruments Directive (MID) 2014/32/EU
●
Low voltage directive 2014/35/EU
●
EMC Directive 2014/30/EU
●
EMC standard for radio equipment and services
●
Radio Equipment Directive 2014/53/EU
●
RoHS directive 2011/65/EU
●
The CE-symbol confirms that this product conforms with the
above mentioned norms and regulations
Number of quality system approval certificate. Notified Body.
CH-MI003-23043 (MID) METAS-Cert (Nr. 1259), Lindenweg 50, CH-3003 Bern-Wabern
Find the full-length version by scanning the QR Code on this page.
EN- Safety instructions
The safety instructions must be observed under all circumstances:
Installation, maintenance, repair, commissioning:
Read the entire manual carefully before installing and operating the product.
●
Danger to life due to high electrical voltage. Never make any changes to components,
●
software or connecting cables without being de-energised. Therefore, remove the
appropriate fuses and store them in such a way that other persons cannot reinsert
them unnoticed.
The product may only be installed, repaired or maintained by an authorised electrician.
●
All applicable local, regional and national regulations for electrical installations must
be observed.
The product requires a serial RCD type-A to comply with national installation
●
standards.
Installation must not be carried out near flammable, explosive media, flooded areas
●
(underground car park) or areas where there is a risk of flowing water.
The product must be installed in a permanent location. The connections on the pico
●
and back plate are designed for a limited number of mating cycles.
The product must be installed on a wall or structure with sufficient load-bearing
●
capacity.
The terminals in the backplate are live when the circuit is closed and must never be
●
brought into direct contact or into contact with anything other than the Pico
electronics.
Depending on the type of installation, approvals may be required before installation,
●
e.g. if the house connection is increased.
The charging station must be registered with the grid operator.
●
The screws of the cable connections should be tightened with a torque of 3 Nm. The
●
maximum diameter of the cable with ferrule is 6.5mm.

Intended use:

This product is intended exclusively for charging electrically powered vehicles which
●
are equipped with non-gassing batteries. The product may only be used with a
charging cable according to IEC 62196. Uses other than those specified here are not
permitted.
The unit is intended for indoor and outdoor use.
●

Operation:

Never use or touch the product if it is damaged or not working properly. In the event
●
of an emergency (smoke, fire, sparks or other malfunction), switch off the product
immediately using the RCD switch and contact customer support.
Do not extinguish the product with water or clean it with running water.
●
Do not immerse the product in water or other liquids.
●
This product is not intended for use by persons with reduced physical, mental or
●
sensory capabilities (including children) or persons who do not understand the
product.
Ensure that children do not play with the product.
●
Never touch the contacts of the type 2 charging socket and do not insert any foreign
●
objects into the product.
Never use the charging cable if it is damaged or if the connectors are wet or dirty.
●
Do not use extension cables or unauthorised adapters in combination with the
●
product.
Never kink the charging cable, drive over it or expose it to high heat.
●
Only pull the charging cable out of the charging cradle by the plug.
●
Do not place the charging cable in the path of other road users and always position it
●
so that there is no risk of tripping.
Protect the charging cable from the effects of the weather such as direct sunlight,
●
wind, rain, humidity and moisture and never connect it with wet or damp hands.
Do not use the product near strong electromagnetic fields or in the direct vicinity of
●
radio telephones.
