Roland RH-IE3 Owner's Manual

SPECIFICATIONS

Type of Const ruction Closed type; dynamic
Driver 11.5 mm in diameter
Sensitivity 100 dB/mW
Maximum Input 250 mW (JEITA)
Frequency Response 10–24,000 Hz
Impedance 18
Weight 8 g (without cord)
Cord 4' (1.2 m)/OFC litz wire
Plug Stereo mini (gold-plated)
Accesso ries Extension cord (6' (1.8 m))
Plug adaptor
(mini plug 1/4 inch phone plug)
Earpieces (S, M, L)
Car
* In the interest of product improvement, the specifications and/or
appearance of this unit are subject to change without prior notice.
Concerning the fit of the earpieces
The sound quality you'll experience can vary depending on how well the earpieces of
this device are fitted with your ears during use. In order to enjoy the sound as it should
be heard, please wear the earpieces so that they fit snugly into your ears.
If the earpieces do not fit your ears, exchange them with either the L or S sized ones,
which are included. (When shipped from the factory, the M sized ones are attached.)
To remove an earpiece, grasp the body of the unit and gently pull the tip of the
earpiece.
About the slide tube
The slide tube is used to adjust the cable separation. Adjust it to the appropriate location
so that the cable will not get in your way as you play your instrument.
For EU Countries
Owner's Manual
rying pouch
* 0 4 8
All rights reserved. No part of this publication may be reproduced in any form without the
WARNING
Before using this unit, make sure to read the instructions below, and the Owner's Manual.
In the interest of personal and public safety, never wear the earphones while operating any type
of vehicle.
Do not use the earphones in a location where safety requires that you be able to hear the sounds
around you (such as on a train platform, at a railroad crossing, in a factory, or along a busy
road).
CAUTION
Using earphones for an extended time at high volume may damage your ears or negatively
impact your hearing. Such use will also strain the earphones themselves, so please enjoy them at
an appropriate volume.
When using earphones while on public transportation or in a public place, please be aware of
the possibility of annoyance to people around you.
Always handle either the earphones themselves or the plug, not the cord. This will help in
maintaining the electrical integrity of the cord by preventing any damage to it.
When connecting the earphones, always have the volume on the unit you are connecting them to
turned down to the minimum. Damage to the earphones may occur otherwise.
Protect the unit from strong impact.
(Do not drop it!)
Do not expose the unit to direct sunlight, place it near devices that radiate heat, leave it inside an
enclosed vehicle, or otherwise subject it to temperature extremes. Excessive heat can deform or
discolor the unit.
When the earphones need cleaning, wipe them with a soft, dry cloth.
Be sure to keep the included and removed earpieces out of the reach of small children to prevent
any child from accidentally swallowing these items.
If you experience any abnormality in the skin area contacted by the earphones, immediately stop
using them.
9 3 5 6 7 - 0 1 *
Copyright ©2007 ROLAND CORPORATION
written permission of ROLAND CORPORATION.
04893567 07-08-1AT
