Aetechron T1000 Instruction Sheet

— INSTRUCTION SHEET —
Application
The AE Techron T1000 Magnetic-Field
Susceptibility Transformer was designed
to exceed the AF Magnetic Field sus-
ceptibility test requirements of DO 160
Section 19 and Boeing D6-16050-5
Section 7.2.
It may also be used as 10-to-1 step-down
transformer for output currents of up to
100 A .
RMS
Description
The T1000 transformer provides up to
300 A-m and is able to generate up to
100A . The turns ratio provides a
RMS
ten-to-one step down to the secondary
winding.
The T1000 provides convenient input
connectors via binding posts. Standard
0.75-inch spacing of binding posts allows
use of standard plugs. Output is via 150A
feed-through terminal block connectors.
The connectors accept up to 1/0 AWG
wire.
T1000 Transformer Instructions
97-8002536 - 6-20-2023
T1000 Transformer
for Magnetic-Field
Susceptibility Testing
Features
• Up to 100 A
• Exceeds AF Magnetic Field test
requirements of DO 160 Section 19
and Boeing D6-16050-5 Section 7.2
• Circuit breaker protected from
over-current
• Durable steel and high-density poly-
ethylene case for impact resistance
A 12-amp circuit breaker protects the
unit against over-current conditions. A
rugged, impact-resistant case and robust
design protects the transformer from
accidental damage.
The T1000 transformer is for use by
experienced staff.
Unit Setup
Safety First
Throughout these instructions, special
emphasis is placed on good safety
practices. The LIGHTNING FLASH
and EXCLAIMATION POINT graphics
are used to highlight certain topics that
require extra precaution.
Watch for These Symbols:
The lightning flash with the
arrowhead symbol within an
equilateral triangle is intended to
alert the user to the presence of "danger-
page 1
secondary current
RMS
Information subject to change.
