Aetechron T2000 Instruction Sheet

— INSTRUCTION SHEET —

Application

The AE Techron T2000 Audio-Bandwidth
Transformer was designed to meet or ex-
ceed the LF conducted susceptibility test
requirements of DO 160 Section 18. The
T2000 is used to apply the required test
signals to the lines under test for ripple
voltage tests and continuous or transient
conducted immunity tests.
It may also be used as a 2-to-1 step-
down transformer. The secondary can
support up to 40 A

Description

The T2000 transformer supports up to
200W and is able to pass up to 40A
the secondary. The turns ratio provides a
two-to-one step down.
The T2000 provides convenient input
connectors via binding posts. Standard
0.75-inch spacing of binding posts allows
use of standard plugs. Output is via Multi
Contact 125A plugs.
T2000 Transformer Instructions
97-8002537 - 3-17-2017
.
P
T2000 Transformer
for Low-Frequency
Conducted Susceptibility Testing

Features

• Frequency response – 10 Hz to 250 kHz
• Turns ratio – 2:1 step down
• Audio power – 200W
• Meets the LF Conducted Susceptibility
test requirements of DO 160 Section 18
• Circuit breaker protected from
over-current on secondary
• Durable steel and high-density poly-
ethylene case for impact resistance
A thermal breaker protects the unit
against over-current conditions on the
primary. A 35A
unit against over-current conditions on
the secondary. A rugged, impact-resis-
tant case and robust design protects the
transformer from accidental damage.
The T2000 transformer is for use by
experienced staff.

Unit Setup

Safety First

Throughout these instructions, special
emphasis is placed on good safety
practices. The LIGHTNING FLASH
on
P
and EXCLAIMATION POINT graphics
are used to highlight certain topics that
require extra precaution.

Watch for These Symbols:

The lightning flash with the
arrowhead symbol within an equi-
lateral triangle is intended to alert
page 1
breaker protects the
RMS
Information subject to change.
