Metal Fusion MO12 Assembly Instructions And Use And Care Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
English
OUTDOOR COOKERS
MO12
ASSEMBLY INSTRUCTIONS
AND
USE AND CARE MANUAL
__________
MODEL/SERIAL #
THE INSTRUCTION MANUAL CONTAINS IMPORTANT INFORMATION NECESSARY
FOR THE PROPER ASSEMBLY AND SAFE USE OF THE APPLIANCE.
READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS BEFORE ASSEMBLING
AND USING THE APPLIANCE. FOLLOW ALL WARNINGS AND INSTRUCTIONS WHEN
USING THE APPLIANCE.
KEEP THIS MANUAL FOR FUTURE REFERENCE.
METAL FUSION, INC.
712 St. George Avenue.
Jefferson, LA 70121
If you have any problems or questions
Call Us Toll Free at
1-800-783-3885
7:30 A.M. to 3:30 P.M. CST • Monday through Friday
(504) 736-0201
www.kingkooker.com
FAILURE TO FOLLOW THESE INSTRUCTIONS
AND WARNINGS COULD RESULT IN FIRE, EXPLOSION, BURN HAZARD OR CARBON
MONOXIDE POISONING WHICH COULD CAUSE PROPERTY DAMAGE,
PERSONAL INJURY OR DEATH.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MO12 and is the answer not in the manual?

Questions and answers

Related Manuals for Metal Fusion MO12

Summary of Contents for Metal Fusion MO12

  • Page 1 READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS BEFORE ASSEMBLING AND USING THE APPLIANCE. FOLLOW ALL WARNINGS AND INSTRUCTIONS WHEN USING THE APPLIANCE. KEEP THIS MANUAL FOR FUTURE REFERENCE. METAL FUSION, INC. 712 St. George Avenue. Jefferson, LA 70121 If you have any problems or questions...

  • Page 2: Warnings

    DANGER FOR YOUR SAFETY If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. If odor continues, keep away from the appliance and immediately call your Fire Department. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN FIRE OR EXPLOSION WHICH COULD CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
  • Page 3 Check all cooker fittings for leaks before each use. Do not use a flame to check for gas leaks. Keep the fuel supply hose away from any heated surfaces. Only the LP hose/regulator assembly specified by Metal Fusion, Inc. should be used with this appliance.
  • Page 4 13) Introduction of water or ice from any source into the oil/grease may cause overflow and severe burns from hot oil and water splatter. When frying with oil/ grease, all food products MUST be completely thawed and towel dried before being immersed in the fryer.

  • Page 5: Table Of Contents

    READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE USING YOUR MR. OUTDOORS® PRODUCT TABLE OF CONTENTS Warnings ..........................2-4 Table of Contents .

  • Page 6: Warranty

    Metal Fusion, Inc., or when it has been abused or misused, or when it has been used other than in accordance with the manufacturer’s operating instructions, including, without limitation, any damage to the consumer’s pots because they were placed on a lit cooker...

  • Page 7: Owner's Registration

    OWNER’S REGISTRATION Dear Customer, Thank you for purchasing a Mr. Outdoors®! Please take a moment to fill out your registration form and return it to us. We are always happy to hear suggestions and comments from our customers about our products. Completion of this registration allows us to contact you if the need arises.
  • Page 8 TAPE HERE FOLD ________________________ ________________________ Place Stamp ________________________ Here METAL FUSION, INC. 712 St. George Avenue Jefferson, LA 70121 FOLD...

  • Page 9: Section I - Mr. Outdoors® Outdoor Cooker Assembly

    Required Parts Lists: Cooker Stand, Cast Burner, LP Hose and Regulator, Thermometer If any of the above parts are missing, contact Metal Fusion, Inc. at 1-800-783-3885 between the hours of 7:30 a.m. and 3:30 p.m. CST Monday through Friday for replacements.

  • Page 10: Outdoor Cooker Assembly Instructions

    ASSEMBLY INSTRUCTIONS * Model May Vary From Picture CONTENTS Shroud (1) Bottom Ring with Welded (3) Legs Top Ring (1) Flat Bar Casting Support Bracket (1) Shroud with Welded Top Ring (1) Casting/Air Shutter (1) Heat Plate (1) Hose/Regulator Flat Bar (13) Bolts, Lockwashers and Nuts Casting Support Bracket...

  • Page 11: Hose Assembly Instructions

    HOSE ASSEMBLY INSTRUCTIONS 1/8 MALE PIPE THREAD ADJUSTABLE WITH ORIFICE AIR SHUTTER REGULATOR VENTURI TUBE TYPE 1 CONNECTION * Model May Vary From Picture Tighten the hose fitting into the venturi with a torque wrench, up to a torque of 95 to 105 lb./in. Alternatively, hand tighten securely and then, using a wrench, tighten an additional 1-1 1/2 turns.

  • Page 12: Section Ii - Use And Care Of Mr. Outdoors® Outdoor Cookers And Accessories

    When the cooking is complete and the cooker has been turned off, allow the temperature of the oil to fall below 100°F(38°C) before moving the pot, cooking oil, or cooker. e. Please call Metal Fusion, Inc. at (800) 783-3885 with any questions concerning the use or operation of the thermometer.

  • Page 13: Determining Proper Fill Levels For Cooking Vessels

    DETERMINING PROPER FILL LEVELS FOR COOKING VESSELS Never overfill the cooking vessel with oil, grease or water. Never fill a pot beyond the maximum fill line. If the pot being used does not have a maximum fill line, follow these instructions to determine the amount of cooking liquid to be used: a.

  • Page 14: Connection Instructions

    1/2 turn). If bubbles are seen, indicating a leak, turn off the cylinder and tighten the leaking connection until a further leak test shows no leaks. If tightening the connection does not stop the leak, call Metal Fusion, Inc. (800) 783-3885, for assistance.

  • Page 15: Placement Instructions

    5. Center the pot over the burner on the cooker. Do NOT use any pot larger than the recommended size for your cooker as listed below: Model # Maximum Pot Size Pot - Height/Diameter MO12 10 qt. (9.46 L) pot 5.12” X 11.73” (13 cm X 29.8cm) CLEAR OVERHEAD WIND DIRECTION (.61m)

  • Page 16: Lighting And Operating Instructions

    LIGHTING AND OPERATING INSTRUCTIONS THE COOKER MUST NOT BE LIT UNTIL THE PRECEDING PLACEMENT INSTRUCTIONS HAVE BEEN COMPLETELY FOLLOWED. Check the cooker to make sure that it is set up as per the diagram (Figure 1). Make certain that the regulator control is turned to OFF by turning it counterclockwise until it reaches the stop. Open cylinder control valve by turning it counterclockwise as per the diagram (Figure 2).

  • Page 17: Turning Off And Storing The Cooker After Use

    TURNING OFF AND STORING THE COOKER AFTER USE NEVER MOVE THE COOKER OR POT WHILE IN USE OR STILL HOT [ABOVE 100°F (38°C)]. After each use turn OFF the Mr. Outdoors® at the regulator first, then at the gas cylinder valve. Check to make sure there is no flame and all valves are off.

  • Page 18: Maintenance Of Outdoor Cookers And Accessories

    Assemble and light the cooker again as per the instruction manual. If this does not resolve the problem, please call Metal Fusion, Inc. at (800) 783-3885. Always use the LP Hose/Regulator assembly supplied with the appliance. Before each use of the appliance check the LP Hose for evidence of abrasion, wear, cuts or leaks.

  • Page 19: Caring For Aluminum And Cast Iron Cookware

    TIPS FOR CARING FOR ALUMINUM FRY PANS AND BOILING POTS It is not necessary to season aluminum pots before cooking with them. Wash with a liquid dish washing detergent and towel dry. After cooking, wash aluminum pots and fry pans in hot, sudsy detergent. If grease or black soot has cooked to the outside of the pot while cooking with your outdoor cooker, scrub the outside of the pot with a steel wool scouring pad.

  • Page 20: Section Iii - Recipes

    SECTION III RECIPES Fried Seafood Wash and drain seafood. Remove any excess moisture. This will reduce splashing and popping in hot oil. Thoroughly coat seafood with King Kooker Seasoned Fish Fry. Place in oil or shortening at ® 325 - 350°F (163- 177°C) and cook until golden brown on all sides. Heavier breading may be obtained by dipping seafood in a mixture of egg and milk before coating with seasoned fish fry.

  • Page 21: Fried Onion Rings

    Fried Onion Rings Ingredients: Colossal onions (if available), 2 beaten eggs, 1/2 cup milk, flour, Onion Mum Seasoning. Cut onions into rings, wash and drain. Blend eggs and milk in a bowl for dipping. Dip each onion ring into egg and milk mixture, then into flour. Dip onion ring again in the egg and milk mixture, then coat with Onion Mum Seasoning.

  • Page 22: Section Iv - Frequently Asked Questions

    If this does not solve the problem refer to Maintenance Instruction items #3 and #4, page 18. If you have questions please call Metal Fusion, Inc. at (800) 783-3885. IF YOU HAVE A QUESTION WE HAVE NOT ADDRESSED IN THIS MANUAL PLEASE SEND US AN E-MAIL AT info@kingkooker.com OR CALL 1-800-783-3885...
  • Page 23 NOTES...
  • Page 24 , the KING KOOKER ® logo, THE KING ® THE KING OF OUTDOOR COOKING ® , MR. OUTDOORS ® , and WATCHDOG OUTDOOR COOKER SERIES ® are trademarks of Metal Fusion, Inc., 712 St. George Avenue, Jefferson, LA 70121 Rev. 04/2018-E...
