- Page 1 User Manual CYC MOTOR support@cycmotor.com +952 3690 8938...
- Page 2 General Safety ............................ 2 Before the Ride ........................... 2 Installation & Use ..........................3 Disclaimer ............................3 Description ............................4 General Specifications ........................4 Features .............................. 5 Package Inclusions ..........................5 Dimensions ............................6 Required Tools ........................... 6 Operating Notice ..........................6 Strapping on battery pack .........................
- Page 3 Kindly read through the entire user manual. This manual contains important information to reduce user risk as well as instructions for this product’s proper use. Do not discard the manual but keep it for reference. Note that the user’s personal safety remains the user’s responsibility and that the user must contact CYCMOTOR LTD or their official product dealer directly for any further guidelines or assistance.
- Page 4 Follow the installation guidelines provided in this manual to fit your battery pack securely to your bicycle frame. This product is manufactured to be used as an electric bicycle battery pack for powering the CYCMOTOR LTD mid-drive motor product line. Using this battery for anything other than its intended use, is not recommended and will not be supported by CYCMOTOR LTD.
- Page 5 Charge Current Weight of 2.2 kg 2.9 kg 2.9 kg 4.3 kg 4.3 kg Battery Pack Weight of 0.1 kg 0.2 kg 0.2 kg 0.3 kg 0.3 kg Battery Mount ***Compatible with all CYC motor systems © 2023 CYCMOTOR LTD...
- Page 6 • High discharge BMS with short circuit protection • Secure & versatile dual-mounting solution • Original high-quality Samsung 21700 cells • Stealthy & compact bag-like design • Ice-blue battery level indicators • Quick removal for portability • Weather & impact resistant •...
- Page 7 • 3mm Allen Key / Hex Key RIGHT-HAND and LEFT-HAND sides are determined by the bike handle; Right-hand corresponds to the right handle. © 2023 CYCMOTOR LTD...
- Page 8 1. Select a mounting position on your bike frame that will provide 3-point support for the straps. 2. Thread 2x 25*350mm straps through the mounting bracket & 1x 20*250mm through the side bracket. Note that the above image is for reference only. Straps can be placed as needed.
- Page 9 1. Select a mounting position on your bike frame that fits over the bottle cage mount inserts. 2. Unscrew the 4x M5 mounting bracket bolts with a 3mm Allen Key. 3. Secure the battery mount into position by fastening the bottle cage mount insert screws. 4.
- Page 10 Battery Connector: XT-90 (female) Wire: 10 AWG (red wire to positive pole & black wire to negative pole) © 2023 CYCMOTOR LTD...
- Page 11 1. Plug the charger into the wall socket. 2. Connect the battery to the charger at the XT90 connector side. 3. Leave until fully charged (approx. 2-4 hours from empty) 4. Unplug after fully charged for safety precautions. B-36 B-52 B-52L Charge Type 36V 4A XT90...
- Page 12 • Please place the battery pack in a cool and dry environment if you do not use it for a long time; charge for 2 hours every month when stored. • Use the designated lithium battery charger when charging. • Keep away from children •...
- Page 13 Monday to Friday 9AM – 6PM (Hong Kong Time HKT) +852 3690 8938 Kindly download the display & mobile app user manuals in our Downloads page (www.cycmotor.com/cycmotor-downloads) or scan the QR code. All materials listed below are freely available to download on website.
