  • Page 3: Included Items

    Thank you for buying the Ritron J Series business band radio. For almost 30 years, Ritron has been a leader in providing cost- effective, on-site communication equipment for businesses. The J Series radio will provide cost-effective communication for schools, retail stores, manufacturing, warehousing, construction sites, property management, hotel and motel management and many more.
  • Page 4: Table Of Contents

    Range utton © 2005 - 2007 Ritron, Inc. All rights reserved. Ritron, Patriot, Jobcom, OutPost, GateGuard, RadioNexus, Quiet Call and Quick Assist are registered trademarks of Ritron, Inc. Quick Talk, Liberty are trademarks of Ritron, Inc. Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com...
  • Page 5: Fcc R Egulations , L Icensing

    To get a FCC license for VHF or UHF frequencies, submit FCC application Form 600 as indicated in the block at right. Your Ritron dealer can help you with this process. SAFETy STANdARdS —...
  • Page 6: Ow Btain Fcc R Adio Bout His Ser Uide

    Emergency Call Feature Voice Scrambler VOX Capability * Per FCC regulations certain frequencies (see frequency listing) are pre-set to operate at 2 Watt maximum. Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com J-V110 J-U410 5/2 * 4/2 *...
  • Page 7: R Adio C Ontrols

    See additional notes on page 11. 7. Microphone 8. Speaker 9. Antenna Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com FIG. - 2: 10. Accessory Connector Connects headsets, remote speaker/ microphones and other accessories. Replace attached dust cap when not in use.
  • Page 8: Radio Buttons & Controls

    Radio Buttons & Controls FIG.-1 9 Antenna 2 PTT Button 3 Up / Down Scroll Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com FIG.-2 10 Accessory Connector 1 Volume Knob 4 TX/RX LED 5 LCD Display FIG.-3...
  • Page 9: Display Icons

    Keypad Lock – Appears when keypad lock is ON. Bell – Appears when keypad tones are Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com Symbol Name/Function Battery Level Indicator: 3 Bars = full charge...
  • Page 10: Attaching The Battery

    Press the top part of the battery towards the radio until both latches firmly attach to the radio. Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com Removing the Battery Turn off the radio.
  • Page 11: J Series Audio Accessories

    J Series Audio Accessories Ritron offers a wide range of audio accessories and headsets to help customize your J Series radio for your application. All J Series audio accessories include a durable, injection molded strain relief. The strain relief keeps the audio accessory firmly attached to the J Series radio during use and attaches to the radio using 2 Phillips head screws (provided).
  • Page 12 DS-CB Swivel attachment, fits LH-D Leather Holster NH-C Nylon Carry Holster with Fixed Metal Belt Clip BC-G6X/J 6-unit 110/220 VAC, 12 VDC Charger BC-G6X/J (SLX and J Series only) Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com...
  • Page 13: Fast Rate Dual Slot Drop-In Charger (Bc-Jx)

    (see slots for battery only) Status Charging Green Complete Amber Waiting Indicator Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com Front Slot LED Rear Slot LED Indicator * Use only a Ritron approved 110 VAC adapter. * Do not attempt to repair.
  • Page 14: Attaching The Antenna

    1. Do not use radio or activate transmitter unless antenna is securely fastened to radio. NOTE: 2. Do not use any portable radio that has a damaged antenna. Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com ON/OFF and Volume Control To turn the radio ON, turn the knob clockwise.
  • Page 15: Operating The Radio

    Keypad lock feature prevents accidental activation of the buttons on the front of the radio (the PTT button, P1 and P2 keys do not lock). Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com Emergency Call Feature (Default P1 KEy-orange button) The Emergency Call feature allows the radio user to immediately notify all other radios on the same channel.
  • Page 16: Noaa W Eather R Adio

    Service frequency. When you’ve programmed the NOAA WX feature into your radio, [NOAA WX] will appear as the last channel programmed in your radio. Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com You may select from the National Weather Service frequencies listed below:...
  • Page 17: H Ow To R Ead - Out F Requency

    Note: If no Tone Code is programmed, the display will read: [ T 4 4 2T X ] 44 = No Tone * If no 2-Tone Code is programmed, display will read: [ 2T X ]. 2-Tone feature not available in all J Series models. Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com Frequency...
  • Page 18: H Ow To

    Display will then show current setting of the selected option. Step 7. Buttons to scroll option sub-list; e.g. [FREQ] codes or [TONE] code lists. Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com Table #4 Code NONE button to SAVE selection. Display will show Step 8.
  • Page 19: Radio Programming

    151.7000 12.5 151.7600 12.5 152.7000 ^ By FCC rule these frequencies are limited to 2 Watt maximum power output. Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com RADIO PROGRAMMING UHF Business Band Code Color Band Width NONE * 467.7625...
  • Page 20: Able Rogrammable Requency Able Nterference Liminator Rogrammable Odes

    467.8875 467.9125 469.4875 469.5125 469.5375 469.5625 ^ By FCC rule these frequencies are limited to 2 Watt maximum power output. Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com Code No. Band Width 12.5 12.5 12.5 12.5 12.5 12.5...
  • Page 21: How To Program Radio-Wide Features

    Step 3. Press for the current setting of the selected Radio-Wide feature. Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com to find frequency of NOAA Weather Broadcast for your area. Step 4. buttons to scroll sub-list setting options such as;...
  • Page 22: H Ow To A Ssign A F Unction To A P K

    P KEy you have selected. * NOTE: Certain frequencies are limited by the FCC to 2 Watt maximum output. See pages 15 &16. Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com FIG. 3 transmit power of selected Step 4.
  • Page 23: How To Delete A Channel

    Press to select [FREQ]. Display will then show current frequency code for the channel; e.g. [F C_ _ ]. Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com Step 7. buttons to scroll to [NONE] button to SAVE [NONE] selection.
  • Page 24: Rf Energy Exposure Awareness And Control Information

    COMPLIANCE WITH RF EXPOSURE STANDARDS Your Ritron J Series 2-way radio is designed and tested to comply with a number of national and international standards and guidelines (listed below) for human exposure to radio frequency electromagnetic energy. This radio complies with the IEEE and...
  • Page 25: Contact Information

    Antenna should be kept away from eyes. Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com • When worn on the body, always place the radio in a Ritron approved clip, holder, holster, case, or body harness for this product. Using approved body-worn accessories is important because the use of Ritron or other manufacturer’s non-approved accessories may result in exposure levels,...
  • Page 26: Itron Imited Arranty

    Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com RITRON, INC. LIMITED WARRANTy What RITRON has agreed to do above is your sole and exclusive remedy. No person is authorized to make any other warranty to you on behalf of RITRON. Warranties implied...
  • Page 27 Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com...
  • Page 28 505 West Carmel Drive • Carmel, IN 46032 • USA P. O. Box 1998 • Carmel, IN 46082-1998 • USA Ph: 317-846-1201 • Fax: 317-846-4978 • Email: Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com JMX Series Portables Small but sturdy 2-way radios permit an ef- ficient mobile command center for an array of commercial uses.
