Nokia TA-1047 Get Started

Get Started
Nokia x
TA-1047 TA-1060 EN-EU
1. Insert the SIM and memory
card
1. Open the back cover: insert your fingernails in
the seam between the cover and display, and bend
the cover open.
2.If the battery is in the phone, lift it out.
PKFRT55001A V1.0
Camera
Flash
Loudspeaker
USB connector
3.Slide the nano-SIM in the SIM slot face down. If
you have a dual SIM phone, slide the second SIM in
the SIM2 slot.
4.Slide the memory card in the memory card slot
face down.
Use only original nano-SIM cards. Use of incompati-
ble SIM cards may damage the card or the device,
and may corrupt data stored on the card.
Use only compatible memory cards approved for
use with this device. Incompatible cards may dam-
Headset connector
Microphone
age the card and the device and corrupt data stored
on the card.
Note: On dual SIM capable devices, both SIM1
and SIM2 slots support 4G networks. However, if
your SIM1 and SIM2 are both LTE SIM cards, the
primary SIM supports 4G/3G/2G networks, while
the secondary SIM can only support 2G. For more
information on your SIM cards, contact your service
provider.
Earpiece
Volume keys
Power/Lock key
2. Charge the battery and switch
the phone on
Plug a compatible charger into a wall outlet, and
connect the cable to your phone. Your phone
supports the USB micro-B cable. You can also
charge your phone from a computer with a USB
cable, but it may take a longer time.
If the battery is completely discharged, it may take
several minutes before the charging indicator is
displayed.
To switch your phone on, press and hold the power
key until the phone vibrates. The phone guides you
through the setup.
For an online user guide and troubleshooting help,
go to www.nokia.com/mobile-support.
