  • Page 1 OWNER’S MANUAL Lexicon BOB-32 ® 32 Channel Digital to Analog Breakout Box Signal/Clip Channel Professional Audio Equipment...
  • Page 2 IMPORTANT SAFETY INSTRUCTIONS WARNING FOR YOUR PROTECTION READ THE FOLLOWING: READ THESE INSTRUCTIONS. KEEP THESE INSTRUCTIONS. HEED ALL WARNINGS. FOLLOW ALL INSTRUCTIONS. The symbols shown above are internationally accepted symbols that warn of potential hazards with electrical products. The lightning flash with arrowpoint in DO NOT USE THIS APPARATUS NEAR WATER.
  • Page 3 European Contact: Your local Lexicon Professional Sales and Service Office or WARNING: IF THE GROUND IS DEFEATED, CERTAIN FAULT CONDITIONS IN THE UNIT OR IN THE Harman Signal Processing SYSTEM TO WHICH IT IS CONNECTED CAN RESULT IN FULL LINE VOLTAGE BETWEEN CHASSIS AND EARTH GROUND.
  • Page 4 CONSIGNES DE SÉCURITÉ IMPORTANTES AVERTISSEMENT POUR VOTRE SÉCURITÉ LIRE ATTENTIVEMENT: LIRE CES CONSIGNES. CONSERVER CES CONSIGNES. RESPECTER TOUS LES AVERTISSEMENTS. SUIVRE TOUTES LES CONSIGNES. Les symboles illustrés ci-dessus sont des symboles acceptés NE PAS UTILISER CET APPAREIL PRÈS DE L’EAU. internationalement qui avertissent des dangers potentiels relatifs à...
  • Page 5 VERT/JAU VERT Contact en Europe: votre revendeur Lexicon local et le bureau d’assistance de: Harman Signal Processing ATTENTION: UN DÉFAUT DE MISE À LA TERRE PEUT PROVOQUER CERTAINS 10653 South River Front Parkway DYSFONCTIONNEMENTS DE L’APPAREIL OU DU SYSTÈME AUQUEL IL EST RELIÉ, POUVANT SE TRADUIRE PAR UNE TENSION COMPOSÉE ENTRE LA MASSE ET LA PRISE DE TERRE.
  • Page 6 BOB-32 The Lexicon BOB-32 breakout box converts up to 32 channels of the BLU link digital audio bus to analog audio. This device is ideal for use with Lexicon’s QuantumLogic Immersion processor (QLI-32). ™ Lexicon’s BOB-32 is easily configured by DIP switches located on the rear of the device.
  • Page 7 DIP Switches Adjust the red DIP switches to select the group of channels required using the table below. BLU link OFF RAMP Output Connector Pinout G − + G − + G − + G − + G − + G − + G − + G − + + - POSITIVE −...
  • Page 8 Questions or comments? Email us at: customer@lexiconpro.com or visit us online at www.lexiconpro.com Part# 5059582 Copyright 2023 Lexicon Professional ®...
