- Page 1 Recreation Series 9- or 11-Foot Screen/5” Speakers Instruction Booklet...
- Page 3 Setting Up Your Screen 1. Open the tripod stands by loosening the lower knob and separate the legs until fully extended. Tighten the lower knob to secure. Repeat this step for the second stand and position it approximately 10 feet away from the first stand. 2.
- Page 4 Setting Up Your Screen =Twist Stakes =Tie Down Straps Close-Up View of Bottom Bungee Cord and Top Eyebolt with Straps Placement...
- Page 5 Setting Up Your Speakers and Projection Station 1. Attach the brackets to the speakers using the provided twist caps. Attach the speakers to the tripod stands by inserting the hex bolt through the top hole in the speaker bracket. Then insert the hex bolt through the tripod stand. Using the twist knob from the parts bag, tighten the hex bolt in place.
- Page 7 Run Into Trouble? Read These Super Helpful Hints! Using Rear Projection 1. Use only the white stretch screen without the black backdrop. 2. Set Up the projector station behind the screen, shooting the image through the white screen instead of on top of it from the front. 3.
- Page 8 952-513-7764 www.outdoortheatersystem.com info@outdoortheatersystem.com...
