- Page 1 Hardware Manual ANM88 audac.eu...
- Page 2 This manual is put together with much care, and is as complete as could be on the publication date. However, updates on the specifications, functionality or software may have occurred since publication. To obtain the latest version of both manual and software, please visit the Audac website @ audac.eu. ANM88 - Quick Start Manual...
- Page 3 Updating the system ................12 Technical specifications Notes ANM88 - Quick Start Manual...
- Page 4 ANM88 - Quick Start Manual...
- Page 5 Dante™/AES67 networked audio module with 8x8 license for LUNA-U The ANM88 is a hardware extension card that makes a LUNA-U audio matrix processor a Dante™/AES67 enabled device. It comes with 8x8 Dante™/AES67 channels and can be expanded with additional software extension SL-NAC8 for additional networked audio channels. The LUNA-U is limited to a maximum of 32x32 channels.
- Page 6 This will make sure that it will be recycled in an environmentally friendly manner, and will help to protect the environment in which we all live. ANM88 - Quick Start Manual...
- Page 7 ANM88 - Quick Start Manual...
- Page 8 Network settings STANDARD NETWORK SETTINGS DHCP: ON IP Address: Depending on DHCP Subnet Mask: 255.255.255.0 (Depending on DHCP) Gateway: 192.168.0.253 (Depending on DHCP) DNS 1: 8.8.4.4 (Depending on DHCP) DNS 2: 8.8.8.8 (Depending on DHCP) ANM88 - Quick Start Manual...
- Page 9 Make sure that the slot whereto the module should be installed is open and ready for installation. The corresponding slot can be reached by releasing the four screws on the cover panel located on top of the LUNA-U. ANM88 - Quick Start Manual...
- Page 10 Step 3: Align both edges of the module with the slot and carefully insert the module into the slot. It should slide into the slot without any considerable resistance when well positioned into the guide rail. ANM88 - Quick Start Manual...
- Page 11 Step 4: Fasten the cover panel using the four screws. Once the module is installed into the slot correctly, the system can be powered-on and the module functionality will be automatically discovered. ANM88 - Quick Start Manual...
- Page 12 Thanks to the OTA feature of the LUNA series, the device automatically checks the latest version whenever the device is on the network. On this screen, the device can be updated to available software by holding the rotary function dial for 5 seconds. ANM88 - Quick Start Manual...
- Page 13 Audio Buffering Up to 2000 samples per channel Onboard word clock or external word Clocking clock Dimensions (W x D) 45 x 60 mm Power 3.3VDC @ 2W max Physical Connector Mini-PCI Compatible device LUNA-U ANM88 - Quick Start Manual...
- Page 14 Notes ANM88 - Quick Start Manual...
- Page 15 Notes ANM88 - Quick Start Manual...
- Page 16 Discover more on audac.eu...
