- Page 1 Hardware Manual LUNA-F & LUNA-U audac.eu...
- Page 2 This manual is put together with much care, and is as complete as could be on the publication date. However, updates on the specifications, functionality or software may have occurred since publication. To obtain the latest version of both manual and software, please visit the Audac website @ audac.eu. LUNA-F & LUNA-U - Quick Start Manual...
-
Page 3: Table Of Contents
Updating the system ................12 Technical specifications Notes LUNA-F & LUNA-U - Quick Start Manual... - Page 4 LUNA-F & LUNA-U - Quick Start Manual...
-
Page 5: Introduction
LUNA-F includes 8 Mic/Line Inputs, 8 flex channels that can be switched between 8 Mic/Line Inputs or Line level output, and 8 Line level outputs. Additionally, up to 64x64 Dante™/AES67 I/O Channels are available with primary and secondary ethernet ports, allowing the integration of the system with any Dante™/AES67 compatible audio over IP I/O units with redundancy. -
Page 6: Precautions
This will make sure that it will be recycled in an environmentally friendly manner, and will help to protect the environment in which we all live. LUNA-F & LUNA-U - Quick Start Manual... - Page 7 The fuse (T2AL/250V) provides a safeguard function to the device. When replacing the fuse, make sure that the value of the replacement matches the value of the original fuse. Identification of a suitable replacement component or substitute shall be done by qualified technicians. LUNA-F & LUNA-U - Quick Start Manual...
-
Page 8: Network Settings
Chapter 1 Connections CONNECTION STANDARDS The in- and output connections for AUDAC audio equipment are performed according to international wiring standards for professional audio equipment. RJ45 (Network, PoE) Network connections Pin 1 White-Orange Pin 2 Orange Pin 3 White-Green Pin 4... - Page 9 3-Pin Terminal block: For balanced line output connections. Left: Signal - Signal + Right: Ground Center: For balanced line output connections. For unbalanced line input connections. LUNA-F & LUNA-U - Quick Start Manual...
-
Page 10: Overview Front Panel
The LUNA series has two USB Type-C connections, one on the front and one on the rear. These ports can be used for uploading files (e.g. voice messages) or to use a connected device as external storage. LUNA-F & LUNA-U - Quick Start Manual... -
Page 11: Overview Rear Panel
GPIO LUNA-F has 24 flex inputs/outputs which can be configured in all possible ways. On the other hand, LUNA-U has fixed 12 GPI and 12 GPO ports. LUNA series GPIO ports are not only edge but also configurable threshold level triggered. - Page 12 3rd party devices that the LUNA is integrated into. Primary and Secondary Dante Ports (only LUNA-F) The LUNA-F can establish a redundant Dante™/AES67 system through its primary and secondary Dante™ ports. In a non-redundant system, in split mode, the primary Dante™...
-
Page 13: User Interface And Configuration
The home screen of the LUNA series indicates if there is a signal or clipping on analogue inputs or outputs (or on flex input and outputs of LUNA-F). This screen also shows the time, date, and installed project name. Clicking on the rotary function dial shows the menu for connections, devices, and settings. -
Page 14: Audac Touch Tm
From audio processing to sequenced third-party integration. You can also create custom user dashboards without even needing to write a single line of code to offer full system control. AUDAC Touch™ is available for freely downloadable for all major OS. - Page 15 Inputs The inputs block is the inputs section of the overview page. Available inputs are direct, flex (only LUNA-F), Dante (optional for LUNA-U), OS, and generator. Gain Manually adjustable pre-gain for microphone/line level adjustment is available for physical inputs (-6/0/34/40 dB) and gain is available for all input channels with a range of -35 and 35 dB.
- Page 16 A compressor/limiter is an automated volume control tool with the setting of maximum volume to avoid any clipping caused by the signal dynamics or peaks. Threshold and ratio indicate how much the signal is going to be attenuated. LUNA-F & LUNA-U - Quick Start Manual...
-
Page 17: Updating The System
Thanks to OTA feature of the LUNA series, the device automatically checks the latest version whenever the device is on the network. On this screen, the device can be updated to available software by holding the rotary function dial for 5 seconds. LUNA-F & LUNA-U - Quick Start Manual... -
Page 18: Technical Specifications
100 ~ 240 V AC / 50 ~ 60 Hz 24 V DC Dimensions (W x H x D) 482 x 44 x 335 mm Mounting 19” Unit height 1 HE Construction Steel Colours Black (RAL9005) LUNA-F & LUNA-U - Quick Start Manual... -
Page 19: Notes
Notes LUNA-F & LUNA-U - Quick Start Manual... - Page 20 Discover more on audac.eu...
