  • Page 1 Electric Vehicle Charging Station Model EVC80-310-001 Installation Guide FastFind Links Before You Start Types of Installations Installation Instructions Using the Web Interface Fact Sheet Specifications...
  • Page 2 4.2 Using the Menus......................34 Showing the Firmware Version ...............35 Updating Your Password ................36 Resetting the Unit ...................37 Checking Network Settings for the LAN ............38 EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 2 of 46 Document version: 1.0 May 11, 2023...
  • Page 3 Checking the Wi-Fi Hotspot for Accessing the Point Network ......40 Checking Sf. LTE Settings for Wireless Broadband Communication Network .40 Logging Out ....................41 EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 3 of 46 Page 3 of 45 Document version: 1.0...
  • Page 4 Be sure to use standard regulation fuses for switches and do not use copper/steel  wire. Do not use faulty or malfunctioning cables or breakers on this product.  EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 4 of 46 Document version: 1.0 May 11, 2023...
  • Page 5 When transporting the product, handle with care. Do not drag it or step on it or  subject it to any strong force. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 5 of 46 Document version: 1.0 May 11, 2023...
  • Page 6 Connections between the Harmonic equipment and other equipment must be made in a manner that is consistent with maintaining compliance with FCC radio frequency emission EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 6 of 46 Document version: 1.0...
  • Page 7 The purpose of this manual is to provide you with information necessary to safely install, operate and maintain this equipment. Keep this manual for future reference. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 7 of 46 Document version: 1.0...
  • Page 8 120V. Some list the phase-to-phase voltage in which case this is referred to as 240/120 single phase. Figure 2-1. Single-Phase 120V/240V Installations Using 240V (L-L) EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 8 of 46 Document version: 1.0...
  • Page 9 120VAC. This may also be designated as 120/208VAC, 120/208 WYE, 208/120 WYE, 4-wire WYE or 120/208Y. Figure 2-2. Three-Phase WYE Installations Using Any L-L EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 9 of 46 Document version: 1.0...
  • Page 10 Warning: Do not use high leg and make sure that 120V is measured from L1/L2 to GND. Figure 2-3. Three-Phase 240V High Leg Delta Installation EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 10 of 46 Document version: 1.0...
  • Page 11 Note: The cable hole must be sealed properly to keep the terminal cabinet watertight. Caution: To reduce the risk of fire, connect only to a circuit with appropriately sized conductors and branch circuit. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 11 of 46 Document version: 1.0 May 11, 2023...
  • Page 12 (M8 x 1.25 x 40mm x D18 x H1 .2) Mounting template This manual 2. Keep the packaging material for possible future transportation or storage. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 12 of 46 Document version: 1.0 May 11, 2023...
  • Page 13 Table 3-2. User-Supplied Tools and Parts Description Figure Phillips screwdriver (PH#4) Torx screwdriver x2 (T20 & T45) Hole saw cutter (2") Allen wrench (4 mm) EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 13 of 46 Document version: 1.0 May 11, 2023...
  • Page 14 2. Hold and lift the cover from the bottom end. 3. Set aside the screw and cover in a safe place. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 14 of 46 Document version: 1.0...
  • Page 15 2. Remove the cabinet cover. 3. Set aside the five screws and the cover together in a safe place. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 15 of 46 Document version: 1.0 May 11, 2023...
  • Page 16  Choose either method and drill the corresponding hole, as shown in the following figures. From the bottom From the top back EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 16 of 46 Document version: 1.0 May 11, 2023...
  • Page 17 To access to the back panel from inside: 1. Using an M4 Philips screwdriver, unscrew the four Philips screws to release the electrical box. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 17 of 46 Document version: 1.0 May 11, 2023...
  • Page 18 You drilled the input cable hole and the mounting holes on your charger (see  sections 3.2.3 and 3.2.4). The installation height is at least 60 cm as shown in the following figure.  EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 18 of 46 Document version: 1.0 May 11, 2023...
  • Page 19 Note: This device is considered to be a “continuous load” device. As such, the branch circuit must be rated for 125% of the operating current. Table 3-3 shows the available options and required (125%) breaker sizes. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 19 of 46 Document version: 1.0...
  • Page 20 10 AWG 8 AWG 8 AWG 8 AWG 8 AWG 6 AWG 6 AWG 4 AWG 4 AWG 100A 2 AWG 2 AWG EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 20 of 46 Document version: 1.0 May 11, 2023...
  • Page 21 Secure the three wires to the corresponding terminals, as shown in the following figure. Note: The cable hole must be sealed properly to keep the terminal cabinet watertight. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 21 of 46 Document version: 1.0 May 11, 2023...
  • Page 22 “Table 3-4 – Minimum Required Conductor Size,” and using branch circuit rating as defined in “Table 3-3 – Current Selection and Branch Circuit Rating.” EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 22 of 46 Document version: 1.0...
  • Page 23 4. Using an M4 Philips screwdriver, unscrew the four Philips screws, as shown in the following figure, to release the electrical box. Raise the bottom side of the box and you can find the cable gland. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 23 of 46 Document version: 1.0...
  • Page 24 If necessary, insert an RJ-45 cable using the following instructions. 1. Unscrew the outer cap. 2. Pull out the pin. 3. Pull out the plug. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 24 of 46 Document version: 1.0 May 11, 2023...
  • Page 25 5. Thread the RJ45 head through the outer cap, plug, and gland. 6. Make sure the plug has been inserted firmly into the cable gland. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 25 of 46 Document version: 1.0...
  • Page 26 Note: You will need to drill a hole to let the cable go into the charging station. For example, see the following figure. From lower right corner From the bottom EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 26 of 46 Document version: 1.0 May 11, 2023...
  • Page 27 3.4 Installing the Micro SIM Card 1. Locate the micro SIM card slot. 2. Insert the card into the slot in the direction shown in the following figure. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 27 of 46 Document version: 1.0...
  • Page 28 Using a T20 Torx screwdriver, unscrew the eight Phillips screws, as shown below. b. Open the box cover as shown in the following figure. Note: There are cables connected to the cover. Open the cover with care. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 28 of 46 Document version: 1.0...
  • Page 29 3. Install the electrical box cover back into its place. Note: If the front cover of the inner box needs to be removed, see section 3.3.3.4 for instructions on removing and replacing the cover. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 29 of 46 Document version: 1.0...
  • Page 30 1. 3. After the unit connects to the access point, point a browser to https://10.0.0.1. 4. When the following page appears, press Advanced. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 30 of 46 Document version: 1.0...
  • Page 31 5. At the next page, press Accept the Risk and Continue. 6. At the following prompt, use these credentials to log in: Username: admin  Password: password  EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 31 of 46 Document version: 1.0 May 11, 2023...
  • Page 32 7. Press the Connect button or press Enter. 8. At your first login, the system recommends you change your password. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 32 of 46 Document version: 1.0 May 11, 2023...
  • Page 33 9. Enter your new password and save your change. Wait for the confirmation message to appear. Tip: Keep your password in a safe location for future logins. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 33 of 46 Document version: 1.0...
  • Page 34 Configuration: Updates the Network, OCPP, WIFI Client, Wi-Fi Hotspot, or LTE  settings. Settings: Updates your password, shows the available firmware, and resets the  unit. Logout: Disconnects from the interface.  EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 34 of 46 Document version: 1.0 May 11, 2023...
  • Page 35 4.2.1 howing the Firmware Version Under Settings, click the exclamation mark at the right side of the Configuration text. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 35 of 46 Document version: 1.0 May 11, 2023...
  • Page 36 4.2.2 pdating Your Password 1. Under Settings, enter your new password in both text boxes. 2. Click the Save button. 3. Wait for confirmation. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 36 of 46 Document version: 1.0 May 11, 2023...
  • Page 37 1. Under Settings, press the Reset button. 2. Confirm your selection or cancel it. 3. If you choose reset again, a message appears. Wait for the reset to finish. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 37 of 46 Document version: 1.0...
  • Page 38 4. After changing the settings, a menu at the bottom of the display prompts you to save changes, discard changes, or reboot the unit to apply the changes. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 38 of 46 Document version: 1.0...
  • Page 39 3. After changing the settings, a menu at the bottom of the display prompts you to save changes, discard changes, or reboot the unit to apply the changes. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 39 of 46 Document version: 1.0...
  • Page 40 3. After changing the settings, a menu at the bottom of the display prompts you to save changes, discard changes, or reboot the unit to apply the changes. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 40 of 46 Document version: 1.0...
  • Page 41 4.2.9 ogging Out Press the LOGOUT button to disconnect from the unit. Press CANCEL to stay connected to the unit. EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 41 of 46 Document version: 1.0 May 11, 2023...
  • Page 42 APPENDIX A - Fact Sheet EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 42 of 46 Document version: 1.0 May 11, 2023...
  • Page 43 EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 43 of 46 Document version: 1.0 May 11, 2023...
  • Page 44 Specification Model EVC80-310-001 Wireless Network 2.4GHz Wi-Fi (802.11 b/g/n) Wide Area Network 4G LTE (optional) LAN 10/100 RFID Reader ISO 15693, 14443NB EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 44 of 46 Document version: 1.0 May 11, 2023...
  • Page 45 Operating Humidity up to 85% @ +50°C (122°F) non- condensing Non-Operating Humidity up to 95%@ +50°C (122°F) non- condensing Warranty (yr) 2 (optional) EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 45 of 46 Document version: 1.0 May 11, 2023...
  • Page 46 9700 W 74th Street Eden Prairie, MN 55344 888-653-0160 evochargesupport@phillipsandtemro.com evocharge.com EVC80-310-001 80A Electric Vehicle Charging Station Installation Guide Page 46 of 46 Document version: 1.0 May 11, 2023...
  • Page 48 42-015P227XXX 42-015P227XXX...
