Volvo S60 TWIN ENGINE Owner's Manual

Hide thumbs Also See for S60 TWIN ENGINE:

Owner's manual (694 pages)

page of 645

/ 645
Bookmarks

Advertisement

Quick Links

Download this manual

S60

T W I N E N G I N E

O W N E R ' S MA N UAL

Advertisement

Need help?

Need help?

Do you have a question about the S60 TWIN ENGINE and is the answer not in the manual?

Questions and answers

Summary of Contents for Volvo S60 TWIN ENGINE

Page 1 T W I N E N G I N E O W N E R ' S MA N UAL...
Page 3 VÄLKOMMEN! We hope your Volvo will give you many years of happy motoring. The manual. The owner's manual is also available as a mobile app (Volvo vehicle is designed for the safety and comfort of you and your passen- Manual) and on Volvo Cars support page (support.volvocars.com).
Page 4 Safety Owner's Manual in the center display Volvo ID Safety during pregnancy Navigate in the Owner's Manual in Creating and registering a Volvo ID Occupant safety the center display Drive-E ‒ purer driving pleasure Reporting safety defects Owner's manual in mobile devices IntelliSafe –...
Page 5 DISPLAYS AND VOICE CONTROL Top tether anchors Instruments and controls in left-hand Handling messages saved from the drive vehicles instrument panel Lower child seat attachment points Instrument panel Center display overview ISOFIX/LATCH lower anchors Instrument panel settings Handling the center display Detailed information for child seat manufacturers Fuel gauge...
Page 6 LIGHTING WINDOWS, GLASS AND MIRRORS Resetting user data when the vehicle Lighting control and panel Windows, glass and mirrors changes owners Adjusting light functions via the cen- Pinch protection for windows and Resetting center display settings ter display sun curtains Table of settings in the center display Adjusting the headlight pattern Reset procedure for pinch protection...
Page 7 SEATS AND STEERING WHEEL CLIMATE CONTROL Manual front seats Climate Activating and deactivating the heated steering wheel* Power* front seats Climate zones Activating and deactivating automatic Climate control sensors Adjusting the power* front seats steering wheel heating* Perceived temperature Storing positions for seats, mirrors Activating auto climate control and head-up display* Climate control system voice commands...
Page 8 KEY, LOCKS AND ALARM Activating and deactivating precondi- Lock indication Locking and unlocking from inside tioning timer the vehicle Lock confirmation settings Deleting preconditioning timer settings Unlocking the trunk lid from inside Remote key the vehicle Climate comfort retaining function Locking and unlocking using the Opening the trunk lid from inside the Starting and switching off the cli-...
Page 9 DRIVER SUPPORT Driver support systems Switching between Cruise Control City Safety parameters and sub-functions 306 and Adaptive Cruise Control* Speed-dependent steering wheel Setting a warning distance for City Safety 308 resistance Symbols and messages for Adaptive Detecting obstacles with City Safety Cruise Control* Electronic Stability Control City Safety in crossing traffic...
Page 10 Lane Keeping Aid symbols and mes- Starting the Park Assist Camera Road Sign Information* sages Activating/deactivating Road Sign Park Assist Camera symbols and Lane Keeping Aid symbols in the messages Information* instrument panel Park Assist Pilot* Road Sign Information and sign displays* Steering assistance at risk of collision Types of parking with Park Assist Pilot* Road Sign Information and Sensus...
Page 11 HYBRID INFORMATION STARTING AND DRIVING General information about Twin Engine Starting the vehicle Using the steering wheel paddles* to shift Charging the hybrid battery Switching off the vehicle Shiftlock Charging current Ignition modes The kickdown function Charge cable Selecting ignition mode All Wheel Drive (AWD) Charging cable residual current device Brake functions...
Page 12 AUDIO, MEDIA AND INTERNET ® Overheating of engine and transmission Audio, media and Internet SiriusXM Travel Link * - Notifications ® Battery drain Sound settings SiriusXM Travel Link * - Fuel Jump starting using another battery Sound experience* ® SiriusXM Travel Link * - Sports Driving with a trailer Apps...
Page 13 WHEELS AND TIRES Connecting the vehicle to the Inter- Tires Android Auto* net via a phone (Wi-Fi) Tire direction of rotation Using Android Auto* Connecting the vehicle to the Inter- Tread wear indicator Settings for Android Auto* net via vehicle modem (SIM card) Tire terminology Tips for using Android Auto* Vehicle modem settings...
Page 14 LOADING, STORAGE AND MAINTENANCE AND SERVICE PASSENGER COMPARTMENT Tire sealing system Volvo's service program Passenger compartment interior Using the tire sealing system Data transfer between vehicle and workshop over Wi-Fi Tunnel console Inflate tires with the compressor included in the tire sealing system...
Page 15 SPECIFICATIONS Fuses in the engine compartment Touching up minor paint damage Type designations Fuses under the glove compartment Color codes Dimensions Fuses in the trunk Replacing windshield wiper blades Weights Cleaning the interior Windshield wipers in the service position Towing capacity and tongue weight Cleaning the center display Filling washer fluid Engine specifications...
Page 16 INDEX Index...
Page 17 OWNER'S INFORMATION...
Page 18 Owner's Manual is available on the vehicle's contains information on fuses to visual navigation with exterior center display, as a mobile app and on Volvo and specifications as well as a Cars' support website. There is also a Quick and interior images of the vehi-...
Page 19 Top menu. important that the vehicle is operated, main- The digital Owner's Manual can be accessed tained and serviced according to Volvo's rec- from Top view and in certain cases, the contex- ommendations provided in the owner's infor- tual Owner's Manual can also be accessed from mation.
Page 20 OWNER'S INFORMATION Navigate in the Owner's Manual in Related information Contextual Owner's Manual the center display • Navigate in the Owner's Manual in the center display (p. 18) The digital Owner's Manual can be accessed from the center display's Top view. The contents •...
Page 21 OWNER'S INFORMATION Opening the menu in the Top menu Quick Guide 2. Tap a hotspot. Tap the symbol to go to a page > The title of a relevant article will be dis- – in the upper list in the Owner's with links to a selection of use- played.
Page 22 Play. This QR code will take gle Play. you directly to the app. You can • Using the Owner's Manual (p. 21) also search for "Volvo manual" Related information in the App Store or Google • Using the Owner's Manual (p. 21) Play.
Page 23 Volvo On Call, the naviga- get the most out of everything your Volvo has to tion system* and apps. Videos and step-by-step offer. Pay particular attention to the safety warn- instructions explain various procedures, such as ings provided in the Owner's Manual.
Page 24 Ignoring a warning of standard and which is an option or accessory, this type could result in serious injury or death. please contact your Volvo retailer. Risk of damage White ISO symbols and white text/image on a Decals black message field.
Page 25 • Owner's Manual in the center display (p. 17) • Owner's manual in mobile devices (p. 20) • Volvo Cars support site (p. 21) Related information Drive-E ‒ purer driving pleasure (p. 27) •...
Page 27 YOUR VOLVO...
Page 28 Volvo ID. Use the following contact information if you Volvo ID is a personal ID that gives you access would like to get in touch with Volvo in the Uni- to a range of services using a single username Related information ted States or Canada.
Page 29 Registering your Volvo ID to the vehicle If your Volvo ID was created using the Volvo On A Volvo ID can be created in two ways. If your Volvo is committed to the well-being of its cus- Call app, follow these steps to register the ID to Volvo ID was created with the Volvo On Call tomers.
Page 30 Avoid heating the entire When you drive a Volvo, you become our partner safer, prevent accidents and protect passengers passenger compartment, which reduces the in the work to lessen the vehicle's impact on the and other road users.
Page 31 YOUR VOLVO • Road Sign Information* NOTE • Electronic Stability Control Read the individual parts about each system • Roll Stability Control to fully understand the functions and be noti- fied of important warnings. • Speed Limiter* • Cruise control Related information •...
Page 32 YOUR VOLVO Sensus - connection and Information when it's needed, where it's Sensus provides an intelligent interface and entertainment Internet connection to the digital world. An intui- needed tive navigation structure offers access to relevant The vehicle's displays present the right informa-...
Page 33 YOUR VOLVO Different types of information are shown in different displays depending on how the information should be prioritized. Instrument panel Head-up display* and navigation messages*. Road sign information and incoming phone calls are also shown in the head-up display. These can be handled using the right-side steering wheel keypad or the center display.
Page 34 YOUR VOLVO currently playing. It is controlled using the steer- Voice control system ing wheel keypads. The voice control system ena- bles the driver to control certain Center display vehicle functions without taking their hands off the wheel. The system can understand natural speech.
Page 35 Data recording personal data (e.g., name, gender, age, and crash location) are recorded. However, other parties, So that you as a Volvo customer shall have the As part of Volvo's commitment to safety and such as law enforcement, could combine the...
Page 36 • Whether the driver and passenger seat belts have occurred in the vehicle. The recorded infor- were tightened/buckled; mation is also needed to enable Volvo to fulfill legal and other regulatory requirements. Informa- • The driver's use of the accelerator/brake tion registered in the vehicle is stored in its com- pedal;...
Page 37 Terms & Conditions for Services Customer Privacy Policy Important information on accessories and extra equipment Volvo offers services to help make driving your Volvo respects and safeguards the personal pri- Volvo as safe and comfortable as possible. vacy of everyone who visits our websites.
Page 38 Accessory installation NOTE WARNING We strongly recommend that Volvo owners use Do not export your Volvo to another country Certain components of this vehicle such as air only genuine, Volvo-approved accessories, and bag modules, seat belt tensioners, adaptive before investigating that country's applicable...
Page 39 NOTE vehicle's data link connector genuine accessories. Volvo Cars takes no responsibility for the con- Incorrectly connected or installed software or Related information sequences of connecting non-authorized diagnostic tools may have an adverse effect on •...
Page 40 > The vehicle identification number will be Related information dures to keep your Volvo at peak operating con- displayed. • Important information on accessories and dition.
Page 41 Related information collision. This energy absorption system including, • Data recording (p. 33) Your new Volvo is, or can be, equipped with fea- but not limited to, structural components such as ture-rich entertainment and communication sys- bumper reinforcement bars, bumper energy tems.
Page 42 YOUR VOLVO WARNING • Never use a hand-held cellular telephone while driving. Some jurisdictions prohibit cellular telephone use by a driver while the vehicle is moving. • If your vehicle is equipped with a naviga- tion system, set and make changes to your travel itinerary only with the vehicle parked.
Page 43 SAFETY...
Page 44 Volvo recommends contacting an authorized activate different safety systems, such as the air- Volvo workshop for repairs as soon as possi- ble. bag system and seat belt tensioners. Depending on the specific conditions of the accident, e.g.
Page 45 Our concern for safety dates back to 1927 when Related information Seat belt the first Volvo rolled off the production line. • Safety (p. 42) Three-point seat belts (a Volvo invention), safety cages, and energy-absorbing impact zones were •...
Page 46 Keep your windshield and headlights clean. become involved in individual problems • Replace wiper blades when they start to between you, your retailer, or Volvo Car leave streaks. USA, LLC. To contact NHTSA, you may • Take into account the traffic, road, and...
Page 47 Please check with • Viewing the Vehicle Identification Number your local retailer or Volvo Car USA, Volvo customers in Canada (VIN) (p. 38) For any questions regarding open recalls for your LLC if your vehicle is covered under vehicle, please contact your authorized Volvo these conditions.
Page 48 Do not attempt to alter or repair the seat or designed to help reduce the risk of whiplash- • Reporting safety defects (p. 44) WHIPS on your own. Volvo recommends con- type injuries. The system consists of energy tacting an authorized Volvo workshop. •...
Page 49 SAFETY Seat belts • Rear Collision Warning (p. 320) WARNING Seat belts should always be worn by all occu- Do not squeeze box-like cargo between the pants in your vehicle. Children should be prop- rear seat cushion and the front seat backrest. erly restrained using an infant seat, adjustable If the rear seat backrests are folded down, child seat or booster cushion as determined by...
Page 50 Never repair the belt yourself. Repairs not twisted or damaged. their seat belts before starting to drive. should only be performed by a trained and qualified Volvo service technician. NOTE • Any device used to induce slack into the The seat belt is equipped with a seat belt...
Page 51 SAFETY 2. Buckle the seat belt by pushing the latch 3. The height of the seat belts in the front seats plate into the receptacle. can be adjusted. > A distinct "click" indicates that the belt is locked into place. WARNING Always insert the seat belt latch plate into the belt buckle on the correct side.
Page 52 SAFETY Seat belt tensioners Related information WARNING • Seat belts (p. 47) The vehicle is equipped with standard and elec- Never use a seat belt for more than one tric* seat belt tensioners that can help tension • Seat belt tensioners (p. 50) occupant.
Page 53 1. Stop the vehicle in a safe location. Never attempt to alter or repair the seat belt 2. Unbuckle the seat belt and then rebuckle it. on your own. Volvo recommends contacting an authorized Volvo workshop. > The seat belt and the electric seat belt tensioner will be reset.
Page 54 The reminder will inspected by a trained and qualified Volvo stop when the seat belt has been rebuckled. service technician as soon as possible.
Page 55 Volvo recommends towing the There may therefore be accident situations in vehicle directly to an authorized Volvo work- which only one (or none) of the airbags are shop. deployed. The sensors monitor the impact of...
Page 56 SAFETY sors that activate the gas generators, causing the certain non-frontal collisions where rapid WARNING airbags to be inflated with nitrogen gas. deceleration occurs. • The airbags in the vehicle are designed to • The airbag system's sensors, which trigger As the movement of the seats' occupants com- be a SUPPLEMENT to-not a replacement the front airbags, are designed to determine...
Page 57 SRS system, please contact a trained and at partial capacity. If the impact is more qualified Volvo service technician or Volvo cus- severe, the airbags are triggered at full tomer support: capacity.
Page 58 Never try to open the airbag cover on the Passenger's side airbag decal. steering wheel or the passenger's side dashboard. This should only be done by a WARNING trained and qualified Volvo service techni- cian. • Children must never be allowed in the •...
Page 59 In this case, the SRS present in a booster seat, system and Occupant Weight Sensor should be inspected by a trained and qualified Volvo • a front passenger takes his/her weight off of service technician as soon as possible.
Page 60 This indicates limitations in OWS classification Volvo recommends that children always be properly restrained in appropriate child restraints in the rear seats. Do not assume capability. It does not indicate OWS malfunction.
Page 61 SAFETY WARNING WARNING WARNING • No objects that add to the total weight on • Keep the following points in mind with • Do not place any type of object on the the seat should be placed on the front respect to the OWS system.
Page 62 Volvo recommends only using seat covers approved by Volvo. Other seat covers could prevent the side airbags from functioning properly. The side airbags are located in the front seats'...
Page 63 This could impair the intended protective WARNING properties. Volvo recommends only using Never attempt to restart the vehicle if you Volvo original parts that are approved for Safety smell fuel fumes when the message placement in these areas. mode See Owner's manual is displayed in the instrument panel.
Page 64 It should Safety mode See Owner's If the message be towed from the site on a tow truck. Volvo attempt to start the engine. manual is still displayed, the vehicle should recommends towing the vehicle directly to an authorized Volvo workshop.
Page 65 It should systems for all occupants including children. be towed from the site on a tow truck. Volvo ing how and where children should be carried in Remember that, regardless of age and size, a recommends towing the vehicle directly to an a vehicle.
Page 66 Child seats should always be registered. Volvo's recommendations Why does Volvo believe that no child should sit in the front seat of a vehicle? It's quite simple really. A front airbag is a very powerful device designed,...
Page 67 Airbags are a SUPPLEMENTAL safety Child restraint systems device which, when used with a three-point seat belt can help reduce serious injuries during certain types of accidents. Volvo rec- ommends that you do not disconnect the air- bag system in your vehicle. •...
Page 68 A small child's head represents a consid- erable part of its total weight and its neck WARNING is still very weak. Volvo recommends that Do not use child safety seats or child booster children up to age 4 travel, properly cushions/backrests in the front passenger's restrained, facing rearward.
Page 69 SAFETY Infant seats Related information • Child safety (p. 63) Suitable child restraints should always be used when children (depending on their age/size) are • Infant seats (p. 67) seated in the vehicle. • Convertible seats (p. 69) Securing an infant seat with a seat belt •...
Page 70 SAFETY WARNING NOTE A child seat should never be used in the front The locking retractor will automatically passenger seat of any vehicle with a front release when the seat belt is unbuckled and passenger airbag - not even if the "Passenger allowed to retract fully.
Page 71 SAFETY Convertible seats WARNING Suitable child restraints should always be used It should not be possible to move the child when children (depending on their age/size) are restraint more than 2.5 cm (1 in.) in any direc- seated in the vehicle. tion along the seat belt path.
Page 72 The locking retractor will automatically able part of its total weight and its neck is release when the seat belt is unbuckled and still very weak. Volvo recommends that allowed to retract fully. children up to age 4 travel, properly restrained, facing rearward.
Page 73 SAFETY Booster cushions Related information WARNING • Child restraints (p. 65) Suitable child restraints should always be used It should not be possible to move the child when children (depending on their age/size) are • Infant seats (p. 67) restraint more than 2.5 cm (1 in.) in any direc- seated in the vehicle.
Page 74 3. Fasten the seat belt by inserting the latch plate into the buckle (lock) until a distinct • Child restraints (p. 65) Your Volvo is equipped with child restraint top click is audible. tether anchorages for all three seating positions •...
Page 75 • Volvo recommends that the top tether 3. Attach the strap for the lower tether anchors anchors be used when installing a for- in the lower ISOFIX/LATCH attachment ward-facing child restraint.
Page 76 SAFETY Lower child seat attachment points ISOFIX/LATCH lower anchors Related information • Child restraints (p. 65) The rear seats are equipped with lower child Lower anchors for ISOFIX/LATCH-equipped seat attachment points. child seats are located in the rear, outboard • Top tether anchors (p.
Page 77 WARNING tethers whenever possible. that is positioned in the center seating position. When securing a child restraint Volvo's ISOFIX/LATCH anchors conform to in the center seating position, use only FMVSS/CMVSS standards. Always refer to the vehicle's center seat belt. the child restraint system's manual for weight and size ratings.
Page 78 SAFETY Detailed information for child seat manufacturers The table provides detailed information for child seat manufacturers on what locations in the vehi- cle are suitable for what types of child seats. Seat positions in right-hand drive cars. Seat positions in left-hand drive cars. 2 (with deactivated air- 2 (with activated airbag, Seat position...
Page 79 SAFETY 2 (with deactivated air- 2 (with activated airbag, Seat position bag, only rear-facing only forward-facing child B, C B, C child seats) seats) Largest suitable forward-facing fixture (F1/F2/F2x/F3/No) Largest suitable booster fixture (B2/B3/No) In accordance with illustration. The seat cushion extension must always be retracted for the installation of child seats. Child seats with support legs can be used here.
Page 81 DISPLAYS AND VOICE CONTROL...
Page 82 DISPLAYS AND VOICE CONTROL Instruments and controls in left- Horn hand drive vehicles Left-side steering wheel keypad The overviews show the location of the vehicle's displays and controls. Hood open Steering wheel and dashboard Display lighting, trunk lid unlock/open, halo- gen headlight height adjustment Ceiling console Center display...
Page 83 DISPLAYS AND VOICE CONTROL Memory for power front seat settings*, door mirrors and head-up display* Central locking Power windows, door mirrors, electric child safety locks* Controls for front seat Related information • Manual front seats (p. 180) • Adjusting the power* front seats (p. 181) •...
Page 84 Consult a workshop immedi- on the equipment, settings and functions cur- ately. Volvo recommends an authorized Volvo workshop. rently active. The instrument panel is activated as soon as a WARNING door is opened, i.e.
Page 85 DISPLAYS AND VOICE CONTROL Left side In the center Right side – Navigation system map* Current fuel consumption – Phone App menu (activated using steering wheel keypad) – Voice Control – Depends on selected drive mode. Total distance. Dynamic symbol •...
Page 86 DISPLAYS AND VOICE CONTROL Instrument panel settings Settings via center display System System Languages and 2. Tap Display settings for the instrument panel can be Units System Language Selecting type of information to select lan- set via the instrument panel's app menu and via Settings guage.
Page 87 DISPLAYS AND VOICE CONTROL Fuel gauge Hybrid gauge Indicates the power level when the internal combustion engine starts. A The fuel gauge in the instrument panel shows In Hybrid and Pure drive modes, the instrument solid symbol indicates that the internal the fuel level in the tank.
Page 88 DISPLAYS AND VOICE CONTROL Hybrid battery gauge For example: The hybrid battery gauge shows how much cur- rent is left in the hybrid battery. The vehicle is generating current to recharge the battery, e.g. during light braking or engine braking on a down- The vehicle has been started, but is stationary and no slope.
Page 89 DISPLAYS AND VOICE CONTROL Trip computer Symbols in the hybrid battery gauge • Tourist - alternative speedometer The vehicle's trip computer registers data while Unit standards for distance, speed, etc. can be driving such as mileage, fuel consumption and changed via system settings in the center display. average speed.
Page 90 This may vary if your driving style changes. other factors that affect the range of electric the one shown in the vehicle's gauges. motors, Volvo uses a starting value when the When used, the digital speed is displayed in the An economical driving style will generally vehicle is fully charged.
Page 91 DISPLAYS AND VOICE CONTROL Displaying trip data in the Related information 1. Open the app menu in the instrument panel instrument panel by pressing (1). • Trip computer (p. 87) Data recorded and calculated by the trip com- (The App menu cannot be opened while •...
Page 92 DISPLAYS AND VOICE CONTROL Resetting the trip odometer Displaying trip statistics in the center display Resetting the trip odometer using the left-side steering wheel lever. Trip computer statistics can be displayed graphi- cally in the center display, providing an overview that facilitates more fuel-efficient driving.
Page 93 DISPLAYS AND VOICE CONTROL Trip statistics settings Date and time zone will then be automatically set to the vehi- cle's location. In some navigation systems, the Trip statistics settings can be reset or adjusted. The clock is displayed in both the instrument current location must also be set to determine panel and the center display.
Page 94 DISPLAYS AND VOICE CONTROL Ambient temperature sensor Indicator symbols in the instrument Related information panel • Instrument panel (p. 82) The ambient temperature is shown in the instru- ment panel. The indicator symbols alert the driver that a func- • Changing system units of measurement tion has been activated, that a system is running, (p.
Page 95 The brakes hold the vehicle at a trol system. Have the vehicle standstill after it has stopped. checked by a workshop. Volvo rec- This symbol lights up in white when ommends contacting an authorized the active high beams are off.
Page 96 DISPLAYS AND VOICE CONTROL Related information Symbol Meaning Symbol Meaning • Instrument panel (p. 82) Active high beams off Stability system, Sport mode • Warning symbols in the instrument panel This symbol lights up in white when This symbol illuminates when Sport (p.
Page 97 Add oil if message in the instrument panel. necessary. If the symbol illuminates WARNING Volvo recommends contacting an and the oil level is normal, contact The red warning symbol illuminates authorized Volvo workshop. a workshop. Volvo recommends...
Page 98 OTHERWISE, ARISING FROM, OUT OF OR IN tions specified in the agreement. The following REGENTS AND CONTRIBUTORS ``AS IS'' AND CONNECTION WITH THE SOFTWARE OR THE text is Volvo's agreement with the manufacturer ANY EXPRESS OR IMPLIED WARRANTIES, USE OR OTHER DEALINGS IN THE or developer.
Page 99 DISPLAYS AND VOICE CONTROL BSD 3-clause "New" or "Revised" License SERVICES; LOSS OF USE, DATA, OR PROFITS; OR CONTRIBUTORS BE LIABLE FOR ANY OR BUSINESS INTERRUPTION) HOWEVER DIRECT, INDIRECT, INCIDENTAL, SPECIAL, Copyright (c) 2011-2014, Yann Collet. CAUSED AND ON ANY THEORY OF LIABILITY, EXEMPLARY, OR CONSEQUENTIAL DAMAGES Redistribution and use in source and binary WHETHER IN CONTRACT, STRICT LIABILITY,...
Page 100 DISPLAYS AND VOICE CONTROL FreeType Project License provided that all warranty or liability claims IN NO EVENT WILL ANY OF THE are assumed by the product vendor. Legal AUTHORS OR COPYRIGHT HOLDERS BE 1. 1 Copyright 1996-1999 by David Turner, Terms 0.
Page 101 DISPLAYS AND VOICE CONTROL on the FreeType code, not just the Libpng License libpng versions 0.97, January 1998, through unmodified files. If you use our work, you 1.0.6, March 20, 2000, are Copyright (c) 1998, This copy of the libpng notices is provided for must acknowledge us.
Page 102 DISPLAYS AND VOICE CONTROL For the purposes of this copyright and license, 3. This Copyright notice may not be removed or sublicense, and/or sell copies of the Software, "Contributing Authors" is defined as the following altered from any source or altered source and to permit persons to whom the Software is set of individuals: distribution.
Page 103 DISPLAYS AND VOICE CONTROL App menu in instrument panel zlib License documentation files (the "Software"), to deal in The zlib/libpng License Copyright (c) <year> the Software without restriction, including without The application menu (App menu) in the instru- <copyright holders> limitation the rights to use, copy, modify, merge, ment panel provides quick access to commonly publish, distribute, sublicense, and/or sell copies...
Page 104 DISPLAYS AND VOICE CONTROL Handling the App menu in the Opening and closing the app menu Functions instrument panel Tap open/close (1). – Trip com- Select a trip odometer, change The App (application) menu in the instrument > The App men opens/closes. puter instrument panel display set- panel is controlled using the right-side steering...
Page 105 DISPLAYS AND VOICE CONTROL Messages in the instrument panel Related information Service messages • App menu in instrument panel (p. 101) The following table lists a selection of important The instrument panel shows messages in certain service messages and what they mean. circumstances to inform or assist the driver.
Page 106 App view in the center display. The message of the problem. Vehicle message stored in Car Status app An authorized Volvo workshop is recommended. will simultaneously appear in the center display. Related information Examples of messages in the instrument panel and the Related information •...
Page 107 Saved messages in the app are automatically appear in the center display. Owner's Manual. deleted each time the engine is started. Market dependent. Volvo ID and selected workshop also need to be registered...
Page 108 DISPLAYS AND VOICE CONTROL Related information • Messages in the instrument panel (p. 103) • Handling messages in the instrument panel (p. 104) • Messages in the center display (p. 138)
Page 109 DISPLAYS AND VOICE CONTROL Center display overview Many of the vehicle's functions can be con- trolled from the center display. The center dis- play and its possibilities are presented below.
Page 110 DISPLAYS AND VOICE CONTROL Three of the center display's basic views. Swipe to the right/left to access Function or App view Function view ‒ vehicle functions that can be is the Camera. Settings for the head-up dis- functions, called "trigger functions", open activated or deactivated with one tap.
Page 111 DISPLAYS AND VOICE CONTROL Fourth tile ‒ most recently used apps or adjusted using the right-side steering wheel • Changing system language (p. 130) keypad. vehicle functions not associated with the • Changing system units of measurement other tiles. Tap the tile to expand it. Home view ‒...
Page 112 DISPLAYS AND VOICE CONTROL Handling the center display ent views, mark objects, scroll in a list and move CAUTION apps by touching the screen in various ways. Many of the vehicle's functions and features can Do not use sharp objects on the screen as be controlled and adjusted from the center dis- An infrared light curtain just above the surface of this could cause scratches.
Page 113 DISPLAYS AND VOICE CONTROL Procedure Gesture Result Drag Moves between screen views or scrolls in a list, text or a view. Press and hold to drag apps or points on a map. Drag horizontally or vertically over the screen. Swipe Moves between screen views or scrolls in a list, text or a view.
Page 114 DISPLAYS AND VOICE CONTROL Returning to Home view from another • drag the control to the desired temperature, view − • to raise or lower the temperature 1. Briefly press the home button below the cen- by degrees, or ter display. •...
Page 115 DISPLAYS AND VOICE CONTROL Activating and deactivating the Navigating in the center display's 1. Press and hold the button beneath the center display views screen. > The screen will go dark (the climate bar The center display can be temporarily switched There are five different basic views in the center will remain visible).
Page 116 DISPLAYS AND VOICE CONTROL Top view view when an app (e.g. navigation) is being NOTE used. In Home view's standard mode – short press Navigation • Contextual Owner's Manual (e.g. on the Home button. An animation describing Manual ). Access articles in the digital access to the various views is shown on the Owner's Manual related to the content screen.
Page 117 DISPLAYS AND VOICE CONTROL App view Function view Tap an app to open it. It will then be opened in its Media associated tile, e.g. Depending on the number of apps, it is possible to scroll down in App view. This is done by sweeping/dragging from the bottom upwards.
Page 118 DISPLAYS AND VOICE CONTROL If there are many functions, you can also scroll downward through the view. This is done by sweeping/dragging from the bottom upwards. Unlike in App view, where you tap an app to open it, in Function view, tapping a function activates or deactivates it.
Page 119 DISPLAYS AND VOICE CONTROL Handling tiles in the center display Navigation Home view consists of four tiles: Media Phone and a fourth tile. These views can be expanded.
Page 120 DISPLAYS AND VOICE CONTROL Expanding a tile from standard mode Standard mode and expanded mode of a tile in the center display.
Page 121 DISPLAYS AND VOICE CONTROL Related information Expanding a tile: In expanded mode, open the app in full-screen mode. Tap • Handling the center display (p. 110) Navigation Media Phone For tiles – the symbol. • Activating and deactivating the center display Tap the screen anywhere in the tile.
Page 122 DISPLAYS AND VOICE CONTROL Function view in the center display Different types of buttons to Function view by swiping from left to right over the screen There are three different types of buttons for Function view, which is one of the center dis- vehicle functions;...
Page 123 DISPLAYS AND VOICE CONTROL Button modes The function is deactivated when the LED indica- tor light is switched off. When a function or parking button's LED indica- tor is green, the function is activated (on). For some functions, an additional text explaining the function will be shown when the function is ini- tially activated.
Page 124 DISPLAYS AND VOICE CONTROL Moving apps and buttons in the Symbols in the center display status NOTE center display Hide the apps that are rarely or never used by The apps and buttons for vehicle functions can Overview of symbols displayed in the center dis- moving them far down, outside of the visible be moved and organized in the App and Func- play status bar.
Page 125 DISPLAYS AND VOICE CONTROL • Internet-connected vehicle* (p. 494) Symbol Meaning • Connecting a device via the USB port Vehicle modem activated. (p. 477) • Phone (p. 484) USB sharing active. • Date and time (p. 91) Action in progress. Timer for preconditioning active.
Page 126 DISPLAYS AND VOICE CONTROL Using the center display keyboard You can use the keyboard in the center display to enter characters or to switch to handwriting mode to "write" letters and characters on the screen. The keyboard can be used to enter characters (letters, numbers, symbols, etc.) to e.g.
Page 127 DISPLAYS AND VOICE CONTROL The illustration shows an overview of some of the buttons that may be shown on the keyboard. The appearance may vary depending on language settings and the context in which the keyboard is used.
Page 128 DISPLAYS AND VOICE CONTROL Variants of letters or characters Row showing suggestions for words or char- uppercase letter. In text fields intended for passwords, website addresses or email acters . The suggested words change as addresses, all letters will automatically be new letters are entered.
Page 129 DISPLAYS AND VOICE CONTROL Changing keyboard language in the Entering characters, letters and To toggle between keyboard languages from the center display words by hand in the center display list: In order to toggle between keyboard languages, Characters, letters and words can be entered in 1.
Page 130 DISPLAYS AND VOICE CONTROL Suggestions for characters/letters/words/ Handwriting characters/letters/words Erasing/changing handwritten characters/ parts of words. You can scroll through the letters 1. Write a character, a letter, a word or parts of list. a word in the field for handwritten letters (1). Write the word or part of the word vertically Space bar.
Page 131 DISPLAYS AND VOICE CONTROL Changing the appearance of the Turning off and adjusting the New lines in free-text fields in handwriting center display volume of the center display system mode sounds The appearance of the center display can be changed by selecting a different theme. The volume of the center display system sounds can be adjusted or turned off completely.
Page 132 DISPLAYS AND VOICE CONTROL Changing system units of Changing system language Changing settings in the center measurement display's Top view Settings Language settings are adjusted in the Settings menu in the center display. You can change settings and information for Unit settings are adjusted in the menu many of the vehicle's functions via the center...
Page 133 Third-party apps are apps that are not factory- installed in the vehicle's system, but can be A sub-category in the Settings menu with various possi- Volvo ID downloaded, e.g. . Settings for these ble settings; has a multi-selection button and radio but- apps are changed in the apps themselves, not in tons.
Page 134 It is also important to change the Reset Personal Settings • - erases personal view (p. 130) owner of the Volvo On Call service. data and resets personalized settings to fac- • Table of settings in the center display Related information tory default.
Page 135 . Others Vehicle Wi-Fi Hotspot are global, which means that they are not linked to a driver profile. Vehicle Modem Internet Route and Guidance My Car Volvo On Call Traffic Sub-categories Volvo Service Networks Media Displays Sub-categories Climate...
Page 136 DISPLAYS AND VOICE CONTROL Driver profiles System Keyboard layout is an example of a global setting. If driver profile X is used to add additional key- Many of the vehicle's settings can be custom- Sub-categories board languages, these languages will also be ized to the driver's personal preferences and Driver Profile available for driver profile Y.
Page 137 DISPLAYS AND VOICE CONTROL Selecting a driver profile Changing a driver profile's name 3. Select desired driver profile. When the center display starts up, the selected It is possible to change the names of the differ- Confirm 4. Tap driver profile will be shown at the top of the ent driver profiles used in the vehicle.
Page 138 DISPLAYS AND VOICE CONTROL Protecting a driver profile Linking a remote key to a driver Related information profile • Driver profiles (p. 134) It may not always be desirable to store settings made in the vehicle to the active driver profile. In A remote key can be linked to a driver profile.
Page 139 DISPLAYS AND VOICE CONTROL Resetting driver profile settings 6. Tap System Driver Profiles. 2. Tap > The key used is now linked to the driver Settings that have been saved for one or more 3. Mark the desired profile. The display will profile and will remain so as long as the driver profiles can be reset when the vehicle is Guest...
Page 140 DISPLAYS AND VOICE CONTROL Messages in the center display Handling messages in the center than messages shown in the status bar and display require acknowledgment/action before they dis- The center display shows messages in certain appear. circumstances to inform or assist the driver. Messages in the center display are handled in the center display's views.
Page 141 DISPLAYS AND VOICE CONTROL Handling messages saved from the Handling new messages 2. Tap a message to expand/minimize it. center display For messages with buttons: > More information about the message will appear in the list and the image to the left Messages saved from the instrument panel and Tap the button to perform the action or let –...
Page 142 DISPLAYS AND VOICE CONTROL Head-up display* NOTE The head-up display is a complement to the The driver's ability to see information in the instrument panel and projects information from head-up display may be impeded by the instrument panel onto the windshield. The •...
Page 143 DISPLAYS AND VOICE CONTROL Activating and deactivating the Related information The snowflake symbol will illuminate if head-up display* there is a risk of slippery conditions. • Activating and deactivating the head-up dis- play* (p. 141) The head-up display can be activated and deac- tivated when the vehicle has been started.
Page 144 DISPLAYS AND VOICE CONTROL Head-up display settings* Adjusting brightness and height Lowering position position Adjusting settings for the head-up display. Confirm Settings can be adjusted when the vehicle is The brightness of the graphic is automatically started and a projected image is displayed on the adapted to the light conditions in its background.
Page 145 Activating and deactivating the head-up dis- tion may need to be calibrated. Calibration means Bluetooth-connected phone, the climate system play* (p. 141) that the projected image is rotated clockwise or and the Volvo navigation system*. • Driver profiles (p. 134) counterclockwise. •...
Page 146 DISPLAYS AND VOICE CONTROL Using voice commands ses from the system. The voice control system To change the audio volume of the system, turn uses the same microphone as devices connected the volume knob while the voice is speaking. It is with Bluetooth, and the voice control system possible to use other buttons while voice com- Press the button for voice con-...
Page 147 DISPLAYS AND VOICE CONTROL Settings Voice control for cellular phones Commands for specific functions, such as phone 1. Tap in the Top view. and audio, are described in the sections related Call a contact in the phone book, have a text System Voice Control 2.
Page 148 DISPLAYS AND VOICE CONTROL Related information Voice control for radio and media • " " - starts playback from USB. • Voice control (p. 143) iPod • Voice commands for the radio and media play- " " - starts playback from iPod. ers are shown below.
Page 149 DISPLAYS AND VOICE CONTROL Related information Voice control settings • Voice control (p. 143) Settings for the voice control system are made here. • Using voice commands (p. 144) • Voice control for cellular phones (p. 145) Settings System Voice Control •...
Page 151 LIGHTING...
Page 152 High beams can be activated. NOTE High beam flash can be used. Volvo recommends use of Daytime Running Lights in the US. Its use is mandatory in Can- Lighting ring position. ada. When the vehicle's ignition is in mode II, the...
Page 153 LIGHTING Adjusting light functions via the • Using turn signals (p. 156) WARNING center display • Using high beam (p. 154) The vehicle lighting system cannot in all situa- A number of light functions can be adjusted and tions determine when the daylight is too weak •...
Page 154 LIGHTING Adjusting the headlight pattern Parking lights deactivated. In weak daylight or dark conditions, the parking lights and low beams will be illumi- The headlight pattern can be reset from right- The parking lights can be used to help other nated.
Page 155 Canadian models: With the lighting ring in the position, the daytime running lights will be on. NOTE Volvo recommends use of Daytime Running Lights in the US. Its use is mandatory in Can- ada. Lighting ring in AUTO position. WARNING With the steering wheel lever's lighting ring in the The system is an energy saving aid –...
Page 156 LIGHTING Low beams Using high beam Related information • Lighting control and panel (p. 150) High beam is operated via the left-hand steering When driving with the lighting ring in the wheel lever. High beam is the vehicle's strongest • Ignition modes (p.
Page 157 LIGHTING Active high beam High beams Activating active high beams The high beams can be activated when the Active high beams can be activated and deacti- Active high beams is a function that uses cam- vated by turning the lighting ring on the right-side lighting ring is in mode era sensors in the upper edge of the windshield Activate high beams by moving the steering...
Page 158 LIGHTING Using turn signals active high beams become available again, or the NOTE windshield sensors are no longer blocked, the The vehicle's turn signals are controlled using • This automatic flashing sequence can be message will disappear and the symbol will the left-side steering wheel lever.
Page 159 LIGHTING Front fog lights/cornering Active Bending Lights* The function is only active in weak daylight or illumination* dark conditions and only when the vehicle is mov- Active Bending Lights (ABL) are designed to ing and the low beams are on. help provide maximum illumination in curves and The front fog lights have a stronger beam than intersections.
Page 160 LIGHTING Rear fog light wheel lever lighting ring is in position NOTE The rear fog light is considerably brighter than Regulations concerning fog light use vary ordinary taillights and should only be used to from country to country. help other road users see the vehicle when visi- NOTE bility is reduced by conditions such as fog, Cornering illumination*...
Page 161 LIGHTING Brake lights Emergency brake lights Hazard warning flashers The brake lights are automatically illuminated The emergency brake lights are activated to Hazard warning flashers warn other road users when braking. warn following vehicles of hard braking. by all of the vehicle's turn signals being activated at the same time.
Page 162 LIGHTING Using home safe lighting Welcome Light Interior Lighting Some of the exterior lights remain on to illumi- Approach lighting is activated when the vehicle The interior is equipped with several different nate the area around the vehicle. This is called is unlocked and can be used to provide light as types of lighting to improve the experience.
Page 163 LIGHTING Rear roof lighting Courtesy lighting auto switch Briefly press the button on the light to turn on or off the reading lights. To adjust the brightness, Reading lights are located in the rear section of Reading light right side press and hold the button.
Page 164 LIGHTING Adjusting interior lighting Mood lighting* Changing the brightness Settings The vehicle is equipped with LEDs that provide 1. Tap in the Top view in the center Illumination in the vehicle varies depending on faint lighting in various colors. This lighting is on display.
Page 165 WINDOWS, GLASS AND MIRRORS...
Page 166 WINDOWS, GLASS AND MIRRORS Windows, glass and mirrors Pinch protection for windows and • Using the windshield and headlight washers sun curtains (p. 177) The vehicle is equipped with controls for win- dows, glass and mirrors. Some of the windows •...
Page 167 Operating the power windows (p. 166) • Using sun curtains* (p. 167) The power windows have pinch protection. If there is any problem with the pinch protection, a rest procedure can be tested. An authorized Volvo workshop is recommended. * Option/accessory.
Page 168 WINDOWS, GLASS AND MIRRORS Operating the power windows WARNING All power windows can be operated using the Children, other passengers or objects can be control panel in the driver's door. The control trapped by the moving parts. panels in the other doors can be used to oper- •...
Page 169 WINDOWS, GLASS AND MIRRORS Using sun curtains* • Keyless locking and unlocking* (p. 245) WARNING There is a sun curtain in the parcel shelf in the • Locking and unlocking using the remote key Make sure that no child or other passenger rear window.
Page 170 WINDOWS, GLASS AND MIRRORS Rearview/door mirrors Adjusting the rearview mirror • Storing positions for seats, mirrors and head- dimming function up display* (p. 182) The rearview mirror and door mirrors can be used to improve the driver's visibility behind the Bright light entering the vehicle from behind, e.g.
Page 171 WINDOWS, GLASS AND MIRRORS Adjusting the door mirrors 3. Press the L or R button again. The light in which work together to identify and eliminate glare. The forward-pointing sensor monitors the button will go out. To improve visibility to the rear, the door mirrors ambient light, while the rearward-pointing sensor need to be adjusted to the driver's height and Automatically folding door mirrors*...
Page 172 WINDOWS, GLASS AND MIRRORS Panoramic roof* Automatic folding when the vehicle is Tilting when parking locked* The door mirrors can be tilted down to help give The panoramic roof is divided into two glass the driver a better view along the sides of the The door mirrors can automatically fold in when sections.
Page 173 WINDOWS, GLASS AND MIRRORS Operating the panoramic roof* Wind blocker WARNING The panoramic roof and sun curtain are oper- Children, other passengers or objects can be ated using a control in the ceiling panel, and trapped by the moving parts. both are equipped with pinch protection.
Page 174 WINDOWS, GLASS AND MIRRORS Opening and closing ventilation direction opposite that of the current direction of CAUTION movement. position • Remove ice and snow before opening the The panoramic roof and sun curtain are also panoramic roof. Be careful not to scratch equipped with pinch protection.
Page 175 WINDOWS, GLASS AND MIRRORS Fully opening and closing the Auto operation • Keyless locking and unlocking* (p. 245) panoramic roof with the control in the 1. To open the sun curtain to the fully open • Locking and unlocking using the remote key ceiling position, pull the control backward to the (p.
Page 176 WINDOWS, GLASS AND MIRRORS Wiper blades and washer fluid Auto closing the panoramic roof* • Locking and unlocking using the remote key sun curtain (p. 232) The wipers and the washer fluid are used to improve visibility and the headlight pattern. With this function, the sun curtain closes auto- matically 15 minutes after the vehicle has been Washer fluid direct from the wiper blades and...
Page 177 WINDOWS, GLASS AND MIRRORS Using the windshield wipers Using the rain sensor Continuous wipers Move the lever upward for the wipers to The windshield wipers clean the windshield. The The rain sensor monitors the amount of water on operate at normal speed. right-side steering wheel lever is used to adjust the windshield and automatically starts the wind- windshield wiper settings.
Page 178 WINDOWS, GLASS AND MIRRORS Using the rain sensor's memory Related information Activate the rain sensor by pressing the rain sen- function • Using the windshield and headlight washers sor button (p. 177) The rain sensor monitors the amount of water on Move the lever downward for an extra wiper the windshield and automatically starts the wind- •...
Page 179 WINDOWS, GLASS AND MIRRORS Using the windshield and headlight CAUTION washers Avoid activating the washer system when it is The windshield and headlight washers clean the frozen or the fluid reservoir is empty. Other- windshield and headlights. Use the right-side wise, there is a risk of damaging the pump.
Page 181 SEATS AND STEERING WHEEL...
Page 182 SEATS AND STEERING WHEEL Manual front seats • Adjust lumbar support* by pressing the but- Front seat massage* settings (p. 184) ton up/down/forward/rearward The power front seats can be adjusted in a num- • Adjusting front seat side bolster settings* ber of different ways for optimal comfort and (p.
Page 183 SEATS AND STEERING WHEEL Power* front seats Adjusting the power* front seats • Adjusting front seat massage settings* (p. 185) The power front seats can be adjusted in a num- Set the desired seating position using the con- ber of different ways for optimal comfort and trols on the front seat cushion.
Page 184 SEATS AND STEERING WHEEL Storing positions for seats, mirrors 2. Press and hold the M button. The indicator Raise/lower the seat by moving the control and head-up display* up/down. light in the button will illuminate. Move the seat forward/rearward by moving Adjustment settings for the power* seat, door 3.
Page 185 SEATS AND STEERING WHEEL Using stored positions for seats, • Adjusting the passenger seat from the driv- Front door closed mirrors and head-up display* Press and hold one of the memory buttons 1 er's seat* (p. 188) – ) or 2 ( ) until the seat, door mirrors •...
Page 186 SEATS AND STEERING WHEEL Front seat massage* settings • Restarting the massage function Adjusting the power* front seats (p. 181) The massage function turns off automatically The settings for the multifunctional seats can be • Storing positions for seats, mirrors and head- after 20 minutes.
Page 187 SEATS AND STEERING WHEEL Adjusting front seat massage Adjusting* front seat cushion length 3. Select massage settings by tapping the cen- settings* ter display or by moving the cursor up/down Depending on the selected equipment level, the using the multifunction control's upper length of the seat cushion can either be The settings for the multifunctional seats can be adjusted using either the mutifunction control on...
Page 188 SEATS AND STEERING WHEEL Adjusting front seat side bolster Cushion extension 2. Select • in the seat set- Adjusting the power* front seats (p. 181) settings* tings view. • Storing positions for seats, mirrors and head- up display* (p. 182) Enhance comfort in the front seat by adjusting •...
Page 189 SEATS AND STEERING WHEEL Adjusting front seat lumbar Side bolsters 2. Select Lumbar support is adjusted using the multifunc- in the seat settings support* tion control in vehicles with four-way lumbar sup- view. port*, or the round button in vehicles with two- Use the control on the side of the seat cushion •...
Page 190 SEATS AND STEERING WHEEL Adjusting the passenger seat from Lumbar Related information 2. Select in the seat settings view. the driver's seat* • Manual front seats (p. 180) Press the round button up /down • The front passenger seat can be adjusted from •...
Page 191 SEATS AND STEERING WHEEL Folding down the rear seat • Adjusting front seat side bolster settings* backrests* (p. 186) • Adjusting front seat lumbar support* (p. 187) The rear seat backrest is split into two sections. The two sections can be folded forward individu- ally.
Page 192 SEATS AND STEERING WHEEL Folding up the backrest CAUTION To fold up the backrest to the upright position The armrest* in the center seat must be manually: raised before the seat backrest is folded 1. Move the backrest upward/rearward. down. 2.
Page 193 SEATS AND STEERING WHEEL Adjusting the rear seat head restraints Adjust the center head restraint in the rear seat to the seat occupant's height. Fold down the outboard head restraints* to improve rear visibil- ity. Adjusting the center seat head restraint Headrest Fold To lower the restraint, push and hold the button Tap the...
Page 194 SEATS AND STEERING WHEEL Steering wheel controls and horn Related information Horn • Folding down the rear seat backrests* The steering wheel has a horn and controls for (p. 189) e.g. driver support systems and voice control. The horn is located in the center of the steering wheel. Related information •...
Page 195 SEATS AND STEERING WHEEL Adjusting the steering wheel The steering wheel can be adjusted to various positions. Steering wheel adjuster lever. 1. Move the lever forward to release the steer- ing wheel. 2. Adjust the steering wheel to the desired The steering wheel's reach and height can be adjusted.
Page 197 CLIMATE CONTROL...
Page 198 CLIMATE CONTROL Climate Climate zones Climate control sensors The vehicle is equipped with electronic climate The vehicle is divided into climate zones to make The climate system has a number of sensors to control. The climate system cools, heats and it possible to set different temperatures for dif- help regulate the climate settings in the vehicle.
Page 199 CLIMATE CONTROL Perceived temperature Climate control system voice On vehicles equipped with the Interior Air Quality commands System*, there is also an air quality sensor in the The climate control system regulates the climate climate system's air intake. in the passenger compartment based on per- Voice commands can be used for the climate ceived temperature, not actual temperature.
Page 200 Turn steering wheel heat on Turn • " "/" Use Volvo-recommended cleaning agents and steering wheel heat off " - activates/deac- car care products to clean the interior. tivates heated steering wheel*. Air filtering systems...
Page 201 CLIMATE CONTROL Clean Zone* Clean Zone Interior Package* • The blower is activated. The Clean Zone function monitors the condi- • Air recirculation is deactivated. Clean Zone Interior Package (CZIP) is a series tions affecting good air quality in the passenger of modifications that filters even more allergy and compartment and indicates whether they are ful- asthma-inducing substances from the passenger...
Page 202 CLIMATE CONTROL Activating and deactivating the air Interior Air Quality System* • Clean Zone Interior Package* (p. 199) quality sensor* Interior Air Quality System (IAQS) is a fully auto- • Passenger compartment air filter (p. 201) matic air quality system that removes gases and The air quality sensor is part of the fully automa- particles to reduce odors and contaminants in ted Interior Air Quality System (IAQS).
Page 203 To maintain the high performance of the climate also be controlled manually. control system, the filter must be replaced regu- larly. Follow Volvo's service schedule for recom- Adjustable air vents mended replacement intervals. When driving in Certain air vents in the vehicle are adjustable, areas with a lot of smog, dust, etc., the filter may...
Page 204 CLIMATE CONTROL Adjusting air distribution Opening, closing and directing air vents Air distribution can be adjusted manually if nee- ded. Some of the air vents in the passenger compart- ment can be individually opened, closed and directed. Misting can be eliminated by directing the outer air vents towards the door windows.
Page 205 CLIMATE CONTROL Related information • Air distribution (p. 201) • Adjusting air distribution (p. 202) • Air distribution options (p. 204)
Page 206 CLIMATE CONTROL Air distribution options Air distribution can be adjusted manually if nee- ded. The following options are available. Air distribution Purpose If all air distribution buttons are deselected in manual mode, the climate control system will revert to automatic mode. Main airflow from defroster vents.
Page 207 CLIMATE CONTROL Air distribution Purpose Main airflow from defroster and dashboard vents. Some airflow Provides a comfortable climate in warm and dry weather. from other vents. Main airflow from defroster and floor vents. Some airflow from Provides a comfortable climate and effective defogging in cold and other vents.
Page 208 CLIMATE CONTROL Related information • Air distribution (p. 201) • Opening, closing and directing air vents (p. 202) • Adjusting air distribution (p. 202)
Page 209 CLIMATE CONTROL Climate system controls Main climate In addition to the functions in the climate bar, The climate system functions are controlled from other main climate system functions can be con- physical buttons on the center console, the cen- Main climate trolled from the tab.
Page 210 CLIMATE CONTROL Activating and deactivating power Blower control. • Setting the blower speed for the front seats front seats* (p. 214) AUTO - Automatic climate control. • Synchronize temperature (p. 216) The seats can be heated for added comfort for the driver and passengers in cold weather.
Page 211 CLIMATE CONTROL Activating and deactivating the Activating and deactivating the Activating and deactivating front heated front seat* heated rear seats* seat ventilation* The seats can be heated for added comfort for The seats can be heated for added comfort for The seats can be ventilated to provide increased the driver and passengers in cold weather.
Page 212 CLIMATE CONTROL Activating and deactivating the Activating and deactivating Related information heated steering wheel* automatic steering wheel heating* • Climate system controls (p. 207) The steering wheel can be heated for added The steering wheel can be heated for added comfort in cold weather.
Page 213 CLIMATE CONTROL Activating auto climate control Activating and deactivating Related information recirculation • Climate system controls (p. 207) If auto climate control is activated, several cli- mate system functions are controlled automati- The climate system's recirculation function helps cally. shut out smog, smoke, exhaust fumes, etc. by reusing the air in the passenger compartment.
Page 214 CLIMATE CONTROL Activating and deactivating the Activating and deactivating max Related information recirculation timer setting defroster • Climate system controls (p. 207) The climate system's recirculation function helps Max defroster is used to quickly remove conden- • Activating and deactivating the recirculation shut out smog, smoke, exhaust fumes, etc.
Page 215 CLIMATE CONTROL Activating and deactivating the heated rear window and door mirrors The heated rear window and door mirrors are 2. Tap used to quickly remove condensation and ice > The max defroster is activated/deacti- from the glass. vated and the button lights up/goes out. Activating and deactivating the heated Related information rear window and door mirrors from the...
Page 216 CLIMATE CONTROL Automatically activating and Setting the blower speed for the Activating and deactivating the heated deactivating the heated rear window rear window and door mirrors from the front seats and door mirrors center display The blower can be set to several different auto- The heated rear window and door mirrors are matically controlled speeds for the front seat.
Page 217 CLIMATE CONTROL Setting the temperature for the CAUTION front seats The air conditioning will not engage if the The temperature can be set to the desired num- blower is turned off completely, which may ber of degrees for the front seat climate zones. cause fogging on the inside of the windows.
Page 218 CLIMATE CONTROL Synchronize temperature Activating and deactivating air Related information conditioning • Climate system controls (p. 207) The temperature in the different climate zones of the vehicle can be synchronized with the tem- The air conditioning cools and dehumidifies perature set for the driver's side. incoming air as needed.
Page 219 CLIMATE CONTROL Parking climate Preconditioning NOTE Parking climate is an umbrella term for various Preconditioning is a climate function that, if pos- The air conditioning cannot be activated when functions that improve the passenger compart- sible, attempts to achieve a comfortable tem- the fan speed is set to ment climate when the vehicle is parked, e.g.
Page 220 Starting from app* preconditioning for each function. Related information A device with the Volvo On Call* app can be used Preconditioning 4. Tap • Parking climate (p. 217) to start preconditioning or check settings.
Page 221 CLIMATE CONTROL Preconditioning timer Adding and editing timer settings Related information for preconditioning • Parking climate (p. 217) The timer can be set to finish preconditioning at a predetermined time. The preconditioning timer can store up to 8 pre- • Preconditioning (p.
Page 222 CLIMATE CONTROL Activating and deactivating Date Related information 4. Tap to set a time for a specific date. preconditioning timer • Preconditioning (p. 217) Days to set a time for one or more days Timer settings in the preconditioning timer can •...
Page 223 CLIMATE CONTROL Deleting preconditioning timer Related information • Adding and editing timer settings for precon- settings ditioning (p. 219) • Preconditioning (p. 217) • Deleting preconditioning timer settings A preconditioning timer setting that is no longer • Preconditioning timer (p. 219) (p.
Page 224 CLIMATE CONTROL Climate comfort retaining function Starting and switching off the NOTE climate retaining function when The climate in the passenger compartment can Climate comfort maintenance will be deacti- parking be maintained when the vehicle is parked, e.g. if vated if the vehicle is locked from the outside the engine is turned off but the driver or passen- The climate retaining function maintains the cli- in order to avoid using residual engine heat...
Page 225 Parking climate symbols and Messages related to parking climate can also be messages displayed in a device that has the Volvo On Call* app. A number of symbols and messages related to parking climate may be displayed in the instru- ment panel.
Page 226 CLIMATE CONTROL Heater Parking heater Additional heater The heater has two sub-functions that help warm The parking heater heats the passenger com- The auxiliary heater helps heat the passenger the passenger compartment or engine in various partment as needed before driving if precondi- compartment and engine while driving.
Page 227 CLIMATE CONTROL Activating and deactivating the auxiliary heater The auxiliary heater helps heat the passenger compartment and engine while driving. It is possible to set whether automatic start for the auxiliary heater should be activated or deacti- vated. Settings 1. Tap in the Top view in the center display.
Page 229 KEY, LOCKS AND ALARM...
Page 230 KEY, LOCKS AND ALARM Lock indication Lock and alarm indicators on the Lock button indicators dashboard The turn signals will flash when the vehicle is Front door locked or unlocked. Exterior confirmation Locking • The turn signals will flash once and the door mirrors will fold in to confirm the vehicle is locked.
Page 231 KEY, LOCKS AND ALARM Lock confirmation settings Related information Rear door* • Lock indication (p. 228) Settings for how the vehicle confirms locking and unlocking can be adjusted in the center dis- play's Settings menu. To change the locking response settings: Settings 1.
Page 232 KEY, LOCKS AND ALARM Remote key Remote key buttons the trunk lid mechanically due to the preloa- ded springs. The remote key is used to lock and unlock doors Panic alarm - Used to attract attention in and the trunk lid. The remote key must be in the vehicle in order to start the engine.
Page 233 – pref- vehicle is locked using Volvo On Call, and when servicing your vehicle. For more infor- erably no closer than 10-15 cm (4-6 in.).
Page 234 Move closer to the vehicle and try to unlock it vehicle, it will be deactivated even if the again. vehicle is locked using Volvo On Call, and will be reactivated when the vehicle is If the remote key is not working to lock or unlock unlocked using Volvo On Call or another the vehicle, its battery may be discharged.
Page 235 KEY, LOCKS AND ALARM Settings for remote and inside door Unlocking the trunk lid using the 2. With the optional power trunk lid* - unlock remote key Hold and press (about 1.5 seconds) the Several different sequences are available for The remote key can be used to unlock only the button on the remote key.
Page 236 KEY, LOCKS AND ALARM Remote key range Replacing the remote key's battery approx. 1.5 meter (5 feet) along the sides of the vehicle or approx. 1 meter (3 feet) from the trunk In order to function correctly, the remote key The battery in the remote key must be replaced lid.
Page 237 Hold the remote key with the front side The cover will loosen and can be (with the Volvo logo) facing up and move the removed from the key. button on the key ring section to the right.
Page 238 KEY, LOCKS AND ALARM Use a screwdriver or similar object to turn The battery's positive side (+) faces upward. Insert a new battery with the positive side (+) the battery cover counterclockwise so the Carefully pry out the battery as shown in the facing upward.
Page 239 KEY, LOCKS AND ALARM NOTE CAUTION Volvo recommends that batteries used in the Be sure to dispose of end-of-life batteries in remote control key satisfy UN Manual of Test a way that protects the environment. and Criteria, Part III, sub-section 38.3. The...
Page 240 Two remote keys are provided with the vehicle. A Red Key makes it possible for the vehicle Volvo recommends that you order a new or One Key Tag is also included if the vehicle is owner to set limitations for certain vehicle prop- duplicate remote control key from an author- equipped with keyless locking/unlocking*.
Page 241 One or more Red Key can be ordered from a • Setting interval: 0-250 km/h (0-160 mph) Max Speed Limit • Volvo retailer. A total of twelve keys can be pro- • Increments: 1 km/h (1 mph) Speed Limit Warning grammed and used for the same vehicle. Up to •...
Page 242 • Red Key - restricted remote key* (p. 238) A Volvo workshop can provide you with the key blade's unique code, which is recommended in case you need to order a new key blade. Using the detachable key blade...
Page 243 KEY, LOCKS AND ALARM Locking and unlocking with Lock the door in the same way, but turn the key detachable key blade 45 degrees counterclockwise in step (3). The detachable key blade can be used to unlock Turning off the alarm the vehicle from the outside, e.g.
Page 244 KEY, LOCKS AND ALARM Locking Remove the detachable key blade from the • Remote key (p. 230) – remote key. Insert the key blade into the The vehicle can also be locked using the remote opening for the lock mechanism and push key's detachable key blade, e.g.
Page 245 Volvo retailer for more information and assistance This device complies with part 15 of the FCC activating the system. rules. Operation is subject to the following two conditions: Only certain markets and in combination with Volvo On Call. * Option/accessory.
Page 246 Canada license-exempt RSS standards. Operation is sub- ject to the following two conditions: Volvo Standard Key IC: 4008C-HUF8423 (1) This device may not cause harmful interfer- Volvo Tag ID IC: 4008C-HUF8432 ence, and (2) this device must accept any inter-...
Page 247 KEY, LOCKS AND ALARM Keyless locking and unlocking* Pressure-sensitive surfaces Trunk lid handle The trunk lid handle has a rubberized pressure With keyless locking and unlocking, touching the Door handle plate that can only be used for unlocking. pressure-sensitive indentation on the door han- There are indentations on the outside of the dle will lock or unlock the vehicle.
Page 248 KEY, LOCKS AND ALARM Keyless unlock settings* Keyless locking Several different sequences are available for All of the doors have to be closed before the keyless unlocking. vehicle can be locked. However, the trunk lid can be open when a door handle is used for locking. To change this setting: Touch the marked area on the outside of one –...
Page 249 KEY, LOCKS AND ALARM Keyless trunk lid unlock* 2. Lift the outer handle to open the trunk lid. Hands-free opening of the trunk lid is also possi- ble using a foot movement under the rear With keyless locking/unlocking, touching the bumper.
Page 250 KEY, LOCKS AND ALARM Antenna locations for the start and NOTE WARNING lock system Please note that the system could be inadver- Individuals with an implanted pacemaker The antennas for the keyless start system and should not allow the pacemaker to come tently activated in a car wash or similar if the keyless locking system* are integrated in the closer than 22 cm (9 in.) to the Keyless sys-...
Page 251 KEY, LOCKS AND ALARM Locking and unlocking from inside Locking using the front door buttons Alternative unlocking method the vehicle – Press the button (both front doors must The doors and trunk lid can be locked and be closed). unlocked from inside the vehicle using the cen- >...
Page 252 KEY, LOCKS AND ALARM Unlocking the trunk lid from inside Opening the trunk lid from inside Related information the vehicle the trunk • Settings for remote and inside door unlock (p. 233) The trunk lid can be unlocked from the inside The vehicle is equipped with a fluorescent han- using the button on the dashboard.
Page 253 KEY, LOCKS AND ALARM Activating and deactivating child WARNING safety locks • Lock the doors and trunk lid when the The child safety locks help prevent the rear vehicle is parked and keep the remote doors from being able to be opened from the keys out of reach of children.
Page 254 KEY, LOCKS AND ALARM 2. Press the button on the driver's door control NOTE Symbol Message Meaning panel. • The door's knob control only locks that Rear child The child safety Rear child lock Activated > The message specific door, not both rear doors simulta- lock Acti- locks are acti- will be shown in the instrument panel and...
Page 255 KEY, LOCKS AND ALARM Automatic locking when driving Private Locking Activating and deactivating private locking The doors and trunk lid will automatically lock The trunk lid and rear seat backrests can be when the vehicle begins to move. locked using the private locking function, e.g. Private locking is activated using the function when the vehicle is left at a workshop or with a button in the center display and a PIN code.
Page 256 2. Enter the desired security code and press If the vehicle is unlocked using Volvo On Call or Confirm Confirm the Volvo On Call app, private locking will be >...
Page 257 Contact a workshop - an authorized Volvo When armed, the alarm will be triggered if: workshop is recommended. • the hood, trunk lid or any door is opened.
Page 258 KEY, LOCKS AND ALARM Arming and disarming the alarm Disarming the alarm 3. Turn the start knob clockwise and release. Unlock and disarm the vehicle alarm by > The alarm will be disarmed. The alarm is armed when the vehicle is locked. •...
Page 259 KEY, LOCKS AND ALARM Related information • Alarm (p. 255)
Page 261 DRIVER SUPPORT...
Page 262 DRIVER SUPPORT Driver support systems Speed-dependent steering wheel • BLIS* (p. 321) resistance The vehicle is equipped with a number of driver • Cross Traffic Alert* (p. 325) support systems that can provide the driver with Speed-dependent power steering increases the •...
Page 263 DRIVER SUPPORT Electronic Stability Control WARNING WARNING The Electronic Stability Control (ESC ) function If the temperature rises too high, the power • The function is supplementary driver sup- helps the driver avoid skidding and improves the steering may be forced to switch off com- port intended to facilitate driving and help vehicle's directional stability.
Page 264 Engine Drag Control Trailer Stability Assist is included if the vehicle is equipped with a Volvo original towbar. Trailer Stability Assist Electronic Stability Control Trailer Stability Assist * Option/accessory.
Page 265 DRIVER SUPPORT Activating/deactivating Sport mode • Cruise control for Electronic Stability Control • Adaptive Cruise Control* The stability system (ESC ) is always activated • Pilot Assist and cannot be switched off. However, the driver Related information can select Sport mode, which offers more active •...
Page 266 DRIVER SUPPORT Electronic Stability Control symbols Some examples of symbols and messages are and messages shown in the table below. A number of symbols and messages related to Electronic Stability Control (ESC ) may be dis- played in the instrument panel. Symbol Message Meaning...
Page 267 A text message can be erased by briefly pressing button in the center of the right-side steering wheel keypad. If the message persists: Contact a workshop ‒ an authorized Volvo workshop is recommended. Related information • Electronic Stability Control (p. 261)
Page 268 DRIVER SUPPORT Cruise control : Reduces the set speed WARNING Cruise Control (CC ) can help the driver main- Marker for set speed • The function is supplementary driver sup- tain an even speed to provide a more relaxing port intended to facilitate driving and help driving experience on highways and long, The vehicle's current speed make it safer –...
Page 269 DRIVER SUPPORT Activating and starting Cruise To disengage CC: 30 km/h (20 mph) or higher. The lowest speed Control that can be set is 30 km/h (20 mph). Press the accelerator pedal about halfway – down and then release it. The Cruise Control (CC ) function must be To start Cruise Control:...
Page 270 DRIVER SUPPORT Deactivating and putting Cruise Related information Standby mode due to action by the driver Control in standby mode Cruise Control will be temporarily deactivated and • Cruise control (p. 266) put in standby mode if: Cruise Control (CC ) can be temporarily put •...
Page 271 DRIVER SUPPORT Reactivating Cruise Control from Switching off Cruise Control To start Cruise Control from standby mode: standby mode Cruise control (CC ) can be turned off. – Press the button on the steering wheel Cruise Control (CC ) can be temporarily put (2).
Page 272 DRIVER SUPPORT Distance Alert* Distance Alert is active at speeds above 30 km/h 3. Press the (2) button on the steering (20 mph) and only reacts for vehicles ahead mov- wheel keypad again. The Distance Alert function can help the driver ing in the same direction as your vehicle.
Page 273 DRIVER SUPPORT Activating/deactivating Distance Distance Alert limitations • Set time interval for driver support (p. 292) Alert • Collision risk warning from driver support Distance Alert functionality may be reduced in (p. 290) certain situations. The function is only available Distance Alert can be turned off.
Page 274 DRIVER SUPPORT Adaptive Cruise Control* WARNING WARNING Adaptive Cruise Control (ACC ) helps the • The function is supplementary driver sup- • The function is supplementary driver sup- driver maintain a constant speed with a set time port intended to facilitate driving and help port intended to facilitate driving and help interval to the vehicle ahead.
Page 275 Passing assistance (p. 295) snow, in poor visibility, on winding roads, : Increases the set speed or on on/off ramps. Depending on market, this function can be either standard or optional. Adaptive Cruise Control An authorized Volvo workshop is recommended. * Option/accessory.
Page 276 DRIVER SUPPORT Activating and starting Adaptive Related information : Reduces the set speed Cruise Control* • Adaptive Cruise Control* (p. 272) Increases the time interval to the vehicle Adaptive Cruise Control (ACC ) must first be ahead activated and then started before it can regulate Reduces the time interval to the vehicle speed and distance.
Page 277 DRIVER SUPPORT Deactivating/reactivating Adaptive Starting/activating Adaptive Cruise ACC will only regulate the time Cruise Control* Control interval to the vehicle ahead when the distance symbol To start ACC: Adaptive Cruise Control (ACC ) can be tempo- shows two vehicles. rarily put into standby mode and then reactiva- •...
Page 278 DRIVER SUPPORT To temporarily deactivate Adaptive Cruise Control Temporarily increasing speed using the accelera- • the driver opens the door. and put it in standby mode: tor pedal, e.g. when passing another vehicle, will • the driver unbuckles the seat belt. not affect the setting.
Page 279 DRIVER SUPPORT Switching between Cruise Control Adaptive Cruise Control* limitations To reactivate ACC from standby mode: and Adaptive Cruise Control* Adaptive Cruise Control (ACC ) may have lim- – Press the button on the steering wheel In vehicles equipped with Adaptive Cruise Con- ited functionality in certain situations.
Page 280 DRIVER SUPPORT Cruise Control Switching from CC to ACC 2. Tap the button in the center display's Function view. The button's indica- To do so: tor will change from GRAY to GREEN. 1. Press the button on the steering wheel >...
Page 281 DRIVER SUPPORT Symbols and messages for The previous illustration shows that Adaptive Adaptive Cruise Control* Cruise Control is set to maintain a speed of 110 km/h (68 mph) and that there is no target A number of symbols and messages relating to vehicle ahead to follow.
Page 282 Adaptive Cruise Contr. Adaptive Cruise Control is in standby mode. Unavailable The symbol is GRAY. The system is not functioning as intended. Contact a workshop ‒ an authorized Volvo workshop is Adaptive Cruise Contr. recommended. Service required The symbol is GRAY.
Page 283 DRIVER SUPPORT Pilot Assist The driver sets the desired speed and distance to The color of the steering wheel the vehicle ahead. Pilot Assist monitors the dis- symbol indicates the current Pilot Assist helps the driver keep the vehicle in tance to the vehicle ahead and the traffic lane's status of steering assistance: the current traffic lane by providing steering...
Page 284 • If Pilot Assist does not position the vehicle there are great differences in speed between appropriately in the lane, the driver should vehicles or if the vehicle ahead brakes suddenly. An authorized Volvo workshop is recommended.
Page 285 DRIVER SUPPORT Pilot Assist controls and display turn off Pilot Assist or switch to Adaptive : Reduces the set speed Cruise Control. A summary of how Pilot Assist is controlled Increases the time interval to the vehicle using the right-side steering wheel keypad and Related information ahead how the function is shown in the display.
Page 286 DRIVER SUPPORT Activating and starting Pilot Assist Instrument panel 2. Press the button on the steering wheel (2). Pilot Assist must first be activated and then started before it can help regulate speed and > Pilot Assist will start and the current distance and provide steering assistance.
Page 287 DRIVER SUPPORT Deactivating/reactivating Pilot Press the ◀ button on the steering wheel (3). If Pilot Assist detects that the – Assist driver's hands are not on the > Pilot Assist is turned off and Adaptive steering wheel, a symbol and Cruise Control will go into active mode.
Page 288 DRIVER SUPPORT Standby mode due to action by the driver • your vehicle's speed goes under 5 km/h WARNING (3 mph) and the vehicle ahead turns so that Pilot Assist will be temporarily deactivated and With automatic standby mode, the driver is Pilot Assist no longer has a vehicle to follow.
Page 289 DRIVER SUPPORT Pilot Assist limitations WARNING WARNING Pilot Assist functionality may be reduced in cer- A noticeable increase in speed may follow In some situations, Pilot Assist may have trou- tain situations. ble helping the driver properly or may be when the speed is resumed with the deactivated automatically –...
Page 290 DRIVER SUPPORT Pilot Assist* symbols and messages The driver is responsible for ensuring that tain the correct time interval to the vehicle ahead the vehicle maintains a suitable distance when driving down steep hills. The driver should A number of symbols and messages relating to from such obstacles.
Page 291 DRIVER SUPPORT Several examples are provided below. The previous illustration shows that Pilot Assist The previous illustration shows that Pilot Assist is set to maintain a speed of 110 km/h (68 mph) is set to maintain a speed of 110 km/h (68 mph) The previous illustration shows that Pilot Assist and is following a target vehicle ahead that is...
Page 292 DRIVER SUPPORT Collision risk warning from driver light and audible warning signal will be activated support to alert the driver that immediate action is required. The driver support systems Pilot Assist and Adaptive Cruise Control* can help alert the WARNING driver if the distance to the vehicle ahead sud- denly decreases to an unsafe distance.
Page 293 DRIVER SUPPORT Switching target vehicles with driver NOTE WARNING support Visual warnings on the windshield may be dif- When driver support follows another vehicle at At certain speeds, vehicles with automatic trans- speeds over approx. 30 km/h (20 mph) and ficult to notice in cases of strong sunlight, missions and the driver support functions Adap- changes target vehicle –...
Page 294 DRIVER SUPPORT Set time interval for driver support In order to help your vehicle follow the vehicle NOTE ahead as smoothly and comfortably as possible, The time interval to the vehicle ahead can be set When the symbol in the instrument panel Adaptive Cruise Control allows the time interval for the functions Adaptive Cruise Control* shows two vehicles, ACC is following the vehi-...
Page 295 DRIVER SUPPORT Drive mode for driver support Adjusting set speed for driver Related information support • Driver support systems (p. 260) The driver can choose different drive modes to determine how driver support should maintain a It is possible to adjust set speeds for the Speed •...
Page 296 DRIVER SUPPORT Auto-hold braking with driver Pilot Assist can provide steering assistance from Change a set speed by pressing the – support near-stationary speeds up to 140 km/h (2) buttons briefly or by pressing and (87 mph). Pilot Assist and Adaptive Cruise Control* holding them: The lowest speed that can be set is 30 km/h (ACC...
Page 297 DRIVER SUPPORT Passing assistance This occurs if the function is keeping the vehicle NOTE stationary using the brakes and: Passing assistance can assist the driver when Driver support can keep the vehicle stationary passing other vehicles. The function can be •...
Page 298 DRIVER SUPPORT Using passing assistance Related information Situations of this type can be avoided by tempo- rarily putting Adaptive Cruise Control or Pilot • Driver support systems (p. 260) Several conditions must be met for passing Assist in standby mode. assistance to be possible.
Page 299 DRIVER SUPPORT Radar sensor Radar sensor type approval • Recommended camera and radar sensor maintenance (p. 304) The radar sensor is used by several driver sup- The type approval for the vehicle radar sensor in port systems to detect other vehicles. •...
Page 300 DRIVER SUPPORT Radar sensor in ACC and PA environment. This equipment should be installed Ce dispositif de radiocommunication de catégorie USA & Canada: and operated with minimum distance of 20 cm II respecte la norme CNR-310 d’Industrie between the radiator and your body. Canada.
Page 301 DRIVER SUPPORT Camera Related information • Driver support systems (p. 260) The camera is used by several driver support systems to e.g. detect lane marker lines or road • Camera/radar sensor limitations (p. 300) signs. • Recommended camera and radar sensor maintenance (p.
Page 302 DRIVER SUPPORT Camera/radar sensor limitations The camera is located on the upper interior sec- The following table shows some of the situations tion of the windshield along with the radar sen- that can cause the message to be displayed, and The camera and radar sensor used by several of sor.
Page 303 There is dirt between the inside of the windshield and the camera/ Consult a workshop to have the area of the windshield on the inside of the camera's radar sensor. casing cleaned. An authorized Volvo workshop is recommended. Bright sunlight. No action. The camera/radar sensor will reset automatically when lighting conditions improve.
Page 304 DRIVER SUPPORT Limited field of vision between your vehicle and the vehicle directly tems that depend on the camera or cause these ahead. systems to temporarily stop functioning. The radar sensor has a limited field of vision. In some situations, it may detect a vehicle later than Small vehicles, such as motorcycles, or vehi- Strong sunlight, reflections from the road surface, expected or not at all.
Page 305 DRIVER SUPPORT Park Assist Camera* Defective camera image may vary slightly. Poor lighting conditions may result in reduced image quality. If a camera sector is dark and Blind sectors contains this symbol, this indi- Rear Park Assist Camera cates that the camera is not functioning properly.
Page 306 Wash gently to avoid scratching the lens. CAUTION Maintenance of driver support components Location of the Park Assist sensors. may only performed by a workshop Related information • Camera (p. 299) • Radar sensor (p. 297) An authorized Volvo workshop is recommended. * Option/accessory.
Page 307 DRIVER SUPPORT City Safety™ changes in the traffic ahead and driver distraction WARNING could lead to an incident. City Safety can alert the driver with light, • The City Safety auto-brake function can sound and pulsations in the brake pedal to help The function assists the driver by automatically prevent a collision or reduce collision the driver detect pedestrians, cyclists, large ani-...
Page 308 DRIVER SUPPORT City Safety parameters and sub- • City Safety and delayed evasive maneuvers WARNING functions (p. 314) • The function is supplementary driver sup- • City Safety in crossing traffic (p. 311) City Safety can help avoid a collision with a vehi- port intended to facilitate driving and help cle, cyclist or large animal ahead by reducing the •...
Page 309 DRIVER SUPPORT Large animals City Safety carries out three steps in the follow- NOTE ing order: If there is a risk of colliding with a large animal, Visual warnings on the windshield may be dif- City Safety can help reduce your vehicle's speed 1.
Page 310 DRIVER SUPPORT Setting a warning distance for City 3 - Auto-brake When City Safety applies the brakes, a text mes- Safety sage will appear in the instrument panel to notify The automatic braking function is activated at the the driver that the function is/was activated. last moment.
Page 311 DRIVER SUPPORT Detecting obstacles with City Safety Late warning distance setting should there- NOTE fore only be used in exceptional cases, such as City Safety can help the driver detect other vehi- The warning with direction indicators for Rear when a more dynamic driving style is preferred. cles, cyclists, large animals and pedestrians.
Page 312 DRIVER SUPPORT Pedestrians and lower body in combination with normal WARNING human movements. City Safety is supplementary driver support, If large portions of the cyclist's body or the bicy- but it cannot detect all pedestrians in all sit- cle itself are not visible to the function's camera, uations and, for example, cannot see: it will not be able to detect a cyclist.
Page 313 DRIVER SUPPORT City Safety in crossing traffic Large animals City Safety can detect large animals even in dark conditions if they are illuminated by the vehicle's City Safety can assist the driver when turning in headlights. the path of an oncoming vehicle in an intersec- tion.
Page 314 DRIVER SUPPORT Limitations of City Safety in Related information WARNING crossing traffic • City Safety™ (p. 305) The driver support system only issues a warn- In certain situations, it may be difficult for City • Limitations of City Safety in crossing traffic ing for obstacles detected by its radar sensor Safety to help the driver avoid a collision with (p.
Page 315 DRIVER SUPPORT City Safety steering assistance for tion also helps stabilize the vehicle after it has NOTE evasive maneuver passed the obstacle. The function uses the vehicle's camera and City Safety steering assistance can help the City Safety steering assistance can detect: radar sensor, which has certain general limita- driver steer away from a vehicle/obstacle when it tions.
Page 316 DRIVER SUPPORT City Safety steering assistance City Safety and delayed evasive Related information limitations during evasive maneuvers • City Safety™ (p. 305) maneuvers City Safety can assist the driver by automatically • City Safety steering assistance limitations braking the vehicle when it is not possible to City Safety steering assistance may have limited during evasive maneuvers (p.
Page 317 DRIVER SUPPORT City Safety braking for oncoming Related information However, if City Safety determines that an eva- vehicles sive maneuver would not be possible due to traf- • City Safety™ (p. 305) fic in the adjacent lane(s), the function can assist City Safety can help you apply the brakes for an •...
Page 318 DRIVER SUPPORT City Safety limitations • your lane must have clear side lane markings WARNING • your vehicle must be positioned straight in City Safety functionality may be reduced in • The function is supplementary driver sup- your lane certain situations. port intended to facilitate driving and help •...
Page 319 Driver intervention • Warnings for stationary or slow-moving Backing up vehicles and large animals can be disen- City Safety is temporarily deactivated when the gaged due to darkness or poor visibility. vehicle is backing up. An authorized Volvo workshop is recommended.
Page 320 DRIVER SUPPORT Related information • Warnings and brake interventions for pedestrians and cyclists are disengaged • City Safety™ (p. 305) at vehicle speeds over 80 km/h • Limitations of City Safety in crossing traffic (50 mph). (p. 312) • Do not place, affix or mount anything on •...
Page 321 When City Safety is braking or has activated the automatic braking function, one or more symbols may illuminate in the instrument panel and a text message may be displayed. Automatic intervention The system is not functioning as intended. Contact a workshop ‒ an authorized Volvo workshop is recommended. City Safety Reduced functionality Service...
Page 322 DRIVER SUPPORT Rear Collision Warning Rear Collision Warning limitations NOTE In some situations, it may be difficult for Rear The Rear Collision Warning (RCW) function The warning with direction indicators for Rear Collision Warning (RCW) to warn the driver of a can help the driver avoid rear-end collisions from Collision Warning is deactivated if the colli- collision risk.
Page 323 DRIVER SUPPORT BLIS* The BLIS function is designed to help provide assistance in heavy traffic with several lanes moving in the same direction by helping the driver to detect the presence of vehicles in the "blind spot" area behind and to the side of the vehicle.
Page 324 DRIVER SUPPORT Activating or deactivating BLIS given, the indicator light will become brighter and NOTE begin flashing. The BLIS function can be activated or deacti- The function uses the vehicle's camera and vated. radar sensor, which has certain general limita- NOTE tions.
Page 325 DRIVER SUPPORT BLIS limitations If BLIS is deactivated when the engine is turned WARNING off, it will remain off the next time the engine is BLIS functionality may be reduced in certain • BLIS does not work in sharp curves. started and the indicator lights will not illuminate.
Page 326 Some examples of symbols and messages are shown in the table below. Message Meaning The system is not functioning as intended. Contact a workshop ‒ an authorized Volvo workshop is recommended. Blind spot sensor Service required Blind spot system off BLIS and CTA have been deactivated because a trailer has been connected to the vehicle's electrical system.
Page 327 DRIVER SUPPORT Cross Traffic Alert able, the auto brake function will intervene CTA is only active when the vehicle is moving backward or if reverse gear is engaged. to stop the vehicle and a text will be shown Cross Traffic Alert(CTA) is a supplementary on the instrument panel to explain why the If CTA detects that something is approaching driver support system to BLIS...
Page 328 DRIVER SUPPORT Activating/deactivating Cross Traffic Cross Traffic Alert limitations WARNING Alert function with auto brake may have The CTA • The function is supplementary driver sup- The driver can select to switch off the warning limited functionality in certain situations. Auto- port intended to facilitate driving and help –...
Page 329 DRIVER SUPPORT "see" and brake for e.g. stationary obstacles, a cyclists or a pedestrian. • Dirt, ice and snow covering the sensors may reduce functionality and prevent the system from providing warnings. • CTA is automatically deactivated if a trailer, bicycle holder or similar is connected to the vehicle's electrical system.
Page 330 Some examples of symbols and messages are shown in the table below. Message Meaning The system is not functioning as intended. Contact a workshop ‒ an authorized Volvo workshop is recommended. Blind spot sensor Service required Blind spot system off BLIS and CTA have been deactivated because a trailer has been connected to the vehicle's electrical system.
Page 331 DRIVER SUPPORT Road Sign Information* WARNING The Road Sign Information (RSI ) function can • The function is supplementary driver sup- help the driver observe speed-related road port intended to facilitate driving and help signs. make it safer – it cannot handle all situa- tions in all traffic, weather and road condi- tions.
Page 332 DRIVER SUPPORT Activating/deactivating Road Sign Road Sign Information and sign • Road Sign Information with speed warning Information* displays* and settings* (p. 331) • Road Sign Information with speed camera The Road Sign Information (RSI ) function is Road Sign Information (RSI ) displays road information* (p.
Page 333 DRIVER SUPPORT Road Sign Information and Sensus Road Sign Information with speed Signs for "School" and "Children Navigation* warning and settings* playing" If the warning sign "School" The Road Sign Information (RSI ) sub-function If the vehicle is equipped with Sensus or "Children playing"...
Page 334 DRIVER SUPPORT When Speed Warning is acti- Please note that the set warn- To adjust the audible alert settings: vated, the symbol for the cur- ing limit will not be used when Settings My Car IntelliSafe 1. Select rent speed limit in the instru- a speed camera symbol is dis- Road Sign Information in the center...
Page 335 DRIVER SUPPORT Activating/deactivating Speed Road Sign Information with speed NOTE Warning in Road Sign Information camera information* • For an audible alert to be provided if the Vehicles equipped with Road Sign Information Speed Limit speed is exceeded, the Speed Limit Warning To activate the sub-func- (RSI...
Page 336 DRIVER SUPPORT Driver Alert Control Road Sign Information* limitations NOTE The Driver Alert Control (DAC) function is Road Sign Information (RSI ) functionality may The function uses the vehicle's camera and designed to help capture the driver become be reduced in certain situations. radar sensor, which has certain general limita- aware of erratic behavior, e.g.
Page 337 DRIVER SUPPORT A camera monitors the traffic lane's marker lines WARNING WARNING and compares the direction of the road with the Driver Alert Control must not be used to An alarm from Driver Alert Control should be driver's movements of the steering wheel. extend a period of driving.
Page 338 DRIVER SUPPORT Activating/deactivating Driver Alert Selecting guidance to a rest area if Driver Alert Control limitations Control the Driver Alert Control warning has Driver Alert Control (DAC) functionality may be been given The Driver Alert Control (DAC) function can be reduced in certain situations.
Page 339 DRIVER SUPPORT Lane Keeping Aid Depending on the settings used, Lane Keeping Aid functions in different ways: Lane Keeping Aid (LKA ) is designed to actively steer the vehicle on freeways, highways Assist • enabled: When the vehicle and other major roads to help the driver reduce approaches a lane marker line, the function the risk of the vehicle unintentionally veering out will actively steer the vehicle back into the...
Page 340 DRIVER SUPPORT Steering assistance with Lane Lane Keeping Aid does not intervene WARNING Keeping Aid • The function is supplementary driver sup- Steering assistance with Lane Keeping Aid port intended to facilitate driving and help (LKA ) only functions if the driver's hands are make it safer –...
Page 341 DRIVER SUPPORT Activating/deactivating Lane Selecting type of assistance for Lane Keeping Aid limitations Keeping Aid Lane Keeping Aid In certain demanding driving conditions, Lane The driver can determine what types of assis- Keeping Aid (LKA ) may not be able to properly The Lane Keeping Aid (LKA ) function is assist the driver.
Page 342 DRIVER SUPPORT Related information • Lane Keeping Aid (p. 337) • Speed-dependent steering wheel resistance (p. 260) • Camera/radar sensor limitations (p. 300)
Page 343 Some examples of symbols and messages are shown in the table below. Symbol Message Meaning The system is not functioning as intended. Contact a workshop ‒ an authorized Volvo work- Driver support system shop is recommended. Reduced functionality Service required Windscreen sensor The camera's ability to detect the lane in front of the vehicle is reduced.
Page 344 A text message can be erased by briefly pressing button in the center of the right-side steering wheel keypad. If the message persists: Contact a workshop ‒ an authorized Volvo workshop is recommended. Related information • Lane Keeping Aid (p. 337) •...
Page 345 DRIVER SUPPORT Lane Keeping Aid symbols in the Related information Unavailable instrument panel • Lane Keeping Aid (p. 337) Lane Keeping Aid (LKA ) uses symbols in the instrument panel for various situations. Some examples of symbols and descriptions of the situations in which they might appear are provided below.
Page 346 DRIVER SUPPORT Steering assistance at risk of • Run-Off Mitigation with steering assistance WARNING collision levels (p. 345) • The function is supplementary driver sup- Collision avoidance assistance • Steering assistance during collision risks lim- function port intended to facilitate driving and help itations (p.
Page 347 DRIVER SUPPORT Activating/deactivating steering Run-Off Mitigation with steering NOTE assistance during collision risks assistance levels Collision avoidance assistance When the The steering assistance function is optional – the This function has two activation levels for inter- function is deactivated, all subfunctions of the driver can choose to have it activated or deacti- vention: following are deactivated:...
Page 348 DRIVER SUPPORT Run-Off Mitigation with steering Steering assistance with braking WARNING assistance • The function is supplementary driver sup- Steering assistance has several sub-functions. port intended to facilitate driving and help Run-Off Mitigation with steering assistance can make it safer – it cannot handle all situa- help the driver and reduce the risk of the vehicle tions in all traffic, weather and road condi- inadvertently running off the road by actively...
Page 349 DRIVER SUPPORT Steering assistance during collision If your vehicle is starting to veer from your own WARNING risks from oncoming traffic lane and a vehicle is approaching from the oppo- • The function is supplementary driver sup- site direction, this function can help the driver Steering assistance has several sub-functions.
Page 350 DRIVER SUPPORT Steering assistance during collision NOTE risks limitations The function uses the vehicle's camera and The function may have limited functionality in radar sensor, which has certain general limita- certain situations and not intervene, e.g.: tions. • for smaller vehicles such as motorcycles Related information •...
Page 351 A text message can be erased by briefly pressing button in the center of the right-side steering wheel keypad. If the message persists: Contact a workshop ‒ an authorized Volvo workshop is recommended. Related information • Steering assistance at risk of collision...
Page 352 DRIVER SUPPORT Park Assist* Audible signals for obstacles in front and to the WARNING sides of the vehicle are active when the vehicle is The Park Assist function can help the driver • The parking sensors have dead/blind moving but will cease after the vehicle has been when maneuvering in tight spaces by indicating spots where objects cannot be detected.
Page 353 DRIVER SUPPORT Park Assist front, rear and sides* Related information NOTE • Driver support systems (p. 260) Park Assist behaves differently depending on The Parking Assist system is deactivated which part of the vehicle is approaching an • Park Assist front, rear and sides* (p. 351) when the parking brake is used or when P is obstacle.
Page 354 When reversing with e.g. a trailer or bike car- tion using this button in the approx. 90 cm (3 ft) diagonally behind or in front rier on the trailer hitch – without Volvo original center display's Function view. of the vehicle can be detected.
Page 355 DRIVER SUPPORT Park Assist limitations CAUTION NOTE Park Assist may not be able to detect all condi- Objects such as chains, thin and glossy poles When a trailer hitch is configured with the tions in all situations and functionality may there- or low obstacles may end up in the "signal vehicle electrical system, the trailer hitch pro- fore be limited in certain cases.
Page 356 One or more of the sensors are blocked. Check and clean/remove the obstacle as soon as pos- sible. Sensors blocked, cleaning nee- The system is not functioning as intended. Contact a workshop ‒ an authorized Volvo workshop Park Assist System is recommended.
Page 357 DRIVER SUPPORT Park Assist Camera* Towbar* - activate/deactivate trajectory lines for towbar* The Park Assist Camera can help provide the driver when maneuvering in tight spaces by alert- CTA* - activate/deactivate Cross Traffic Alert ing the driver to obstacles using the camera Objects/obstacles may be closer to the vehicle screen and graphics in the center display.
Page 358 DRIVER SUPPORT Park Assist Camera* views • Camera/radar sensor limitations (p. 300) WARNING • PAC can display a 360° panoramic view as well Park Assist* (p. 350) • The function is supplementary driver sup- as separate views for each of the other cameras: •...
Page 359 DRIVER SUPPORT Park Assist 360° view* Front camera If the vehicle is equipped with System *, the distance to detected obstacles will be illustrated by fields in different colors. The cameras can be activated automatically or manually. Back The front Park Assist Camera is located in the grille. The location of the cameras and their approximate fields of vision.
Page 360 DRIVER SUPPORT Park Assist Camera trajectory lines* Side cameras help simplify parallel parking, backing into tight spaces or attaching a trailer. The Park Assist Camera uses trajectory lines and fields on the screen to indicate the vehicle's The lines on the screen are projected as if they position in relation to its immediate surround- were painted lines on the ground behind the ings.
Page 361 DRIVER SUPPORT Trajectory lines in 360° view* Trajectory lines for a towbar* CAUTION • Bear in mind that when the rearward camera view is selected, the screen only shows the area behind the vehicle – pay attention to the sides and front of the vehicle when steering while reversing.
Page 362 DRIVER SUPPORT Sensor field from Park Assist for Towbar 1. Tap The front and rear fields change colors (from (1). Park Assist Camera YELLOW to ORANGE to RED) as the vehicle > The trajectory line for the towbar's antici- moves closer to an obstacle. pated path toward the vehicle will appear If the vehicle is equipped with Park Assist, dis- and the vehicle's trajectory lines will dis-...
Page 363 DRIVER SUPPORT Starting the Park Assist Camera Side sensor fields The color of the side field changes as the vehicle moves closer to the object – from YELLOW to Warning signals vary depending on the vehicle's The Park Assist Camera starts automatically RED.
Page 364 DRIVER SUPPORT Camera view when backing up When reverse gear is engaged, the screen shows the rear view Camera view when manually starting the camera Start the Park Assist Camera using this button in the center display's Function view. The screen will first show the most recently used camera view.
Page 365 One or more of the sensors are blocked. Check and clean/remove the obstacle as soon as possible. Sensors blocked, cleaning needed The system is not functioning as intended. Contact a workshop ‒ an authorized Volvo workshop is Park Assist System recommended.
Page 366 DRIVER SUPPORT Park Assist Pilot* WARNING NOTE Park Assist Pilot (PAP ) can help the driver • The function is supplementary driver sup- The PAP function measures the space and maneuver the vehicle when parking. The function port intended to facilitate driving and help steers the vehicle –...
Page 367 DRIVER SUPPORT Types of parking with Park Assist Related information Perpendicular parking Pilot* • Park Assist Pilot* (p. 364) Park Assist Pilot (PAP ) can be used for the • Leaving a parallel parking space with Park following types of parking. Assist Pilot* (p.
Page 368 DRIVER SUPPORT Parking with Park Assist Pilot* NOTE Park Assist Pilot (PAP ) helps the driver park The distance between the vehicle and parking using three different steps. The function can also spots should be 0.5–1.5 meters (1.6–5.0 ft) help the driver pull out of a parking space. when the function is looking for parking.
Page 369 DRIVER SUPPORT Park In 1. Tap Backing into a parking space 2. Back up slowly and carefully without touch- in Function view or in Camera ing the steering wheel and do not exceed a view. speed of 7 km/h (4 mph). >...
Page 370 DRIVER SUPPORT Leaving a parallel parking space Positioning the vehicle in the parking space To do so: with Park Assist Pilot* 1. Move the gear selector to the gear instructed Park Out function can help the driver to pull by the system. Wait until the steering wheel out of a parking space when the vehicle is paral- turns and then drive slowly forward.
Page 371 DRIVER SUPPORT Park Assist Pilot* limitations 3. Be prepared to stop the vehicle when WARNING instructed to do so by a graphic and mes- Park Assist Pilot (PAP ) may not be able to • The function is supplementary driver sup- sage in the center display.
Page 372 DRIVER SUPPORT The driver should be aware of the following limi- There are a number of things to keep in mind CAUTION tations for Park Assist Pilot: when parking, including: Under certain circumstances, the function • The driver is always responsible for determin- The parking sequence is cancelled may not be able to find parking spaces –...
Page 373 Switching to another approved wheel and/or tire dimension could change the tire circum- ference, which would then require the system to be updated. Consult a workshop – an authorized Volvo workshop is recommended. Related information • Park Assist Pilot* (p. 364) •...
Page 374 One or more of the sensors are blocked. Check and clean/remove the obstacle as soon as possible. Sensors blocked, cleaning needed The system is not functioning as intended. Contact a workshop ‒ an authorized Volvo workshop is recommended. Park Assist System...
Page 375 HYBRID INFORMATION...
Page 376 If the vehicle does not have electrical current handled by trained and qualified Volvo service ing, e.g. electric power only or, if more power is and both the electric motor and the gasoline technicians.
Page 377 The hybrid battery can be recharged using the sumption. charging cable stored in a storage space in the trunk. WARNING If the hybrid battery needs to be replaced, this may only be done by a Volvo retailer or authorized Volvo workshop.
Page 378 HYBRID INFORMATION Charging using the gasoline engine Related information • Charge cable (p. 377) • Charging current (p. 377) • Opening and closing the charging socket cover (p. 380) • Initiating hybrid battery charging (p. 380) • Stopping hybrid battery charging (p. 386) •...
Page 379 Always interrupt charging first • Charging status in the instrument panel chased from a Volvo retailer. and then disconnect the charging cable – first (p. 384) from the vehicle's charging socket and then •...
Page 380 120/240 V outlet could be damaged in such repaired by a workshop – an authorized not be rinsed or immersed in water. circumstances. Always interrupt charging first Volvo workshop is recommended. and then disconnect the charging cable – first • Always position the charging cable so...
Page 381 Maintenance or replacement of the hybrid electrical circuit's capacity. Using a charge battery may only be performed by a level that exceeds the electrical circuit's or trained and qualified Volvo service techni- Charge module electrical outlet's capacity may start a fire or cian.
Page 382 Never connect the charging cable if there is a have the charging cable and the vehicle's risk of a thunderstorm or there is lightning. charging system inspected by a trained and qualified Volvo service technician. Related information • Charge cable (p. 377) Press in the rear edge of the charger door and release.
Page 383 A damaged or mal- functioning charging cable may only be repaired by a workshop – an authorized Volvo workshop is recommended. • Always position the charging cable so that it will not be driven over, stepped on, tripped over or otherwise damaged, or cause personal injury.
Page 384 HYBRID INFORMATION Charging status in the vehicle's Related information 2. The charging cable handle will lock into charging socket place and charging will begin within • Charging the hybrid battery (p. 375) 5 seconds. When charging starts, the green The charging status is indicated by an LED light •...
Page 385 If the red warn- ing light continues to flash or glows steadily, a fault has been detected and the charger will not deliver power to the vehicle. Contact a Volvo retailer or a certified Volvo service technician.
Page 386 HYBRID INFORMATION Charging status in the instrument information is displayed as long as the instru- panel ment panel is active. Charging status is indicated in the instrument panel using both graphics and messages. This Graphic Message Meaning Fully charged at: [Time] displayed along with an animated blue puls- Charging is in progress and the approximate time at which the ing light through the charging cable.
Page 387 HYBRID INFORMATION NOTE If the instrument panel is not used, it will go dark after a period of time. To reactivate the display: • depress the brake pedal, • open one of the doors, or put the ignition in mode I by turning the •...
Page 388 HYBRID INFORMATION Stopping hybrid battery charging To stop charging of the hybrid battery, unlock the vehicle, unplug the charging cable from the vehicle's charging socket and then unplug the cable from the 120/240 V outlet (alternating current). CAUTION Before the charging cable is removed from the vehicle's charging socket, the vehicle Unlock the vehicle with the remote key.
Page 389 HYBRID INFORMATION Twin Engine symbols and messages ment panel. They may also appear in combina- in the instrument panel tion with general indicator and warning symbols and disappear when the necessary action has A number of symbols and messages relating to been taken.
Page 390 Displayed when the driver again attempts to start the vehicle with the charging cable connected. Disconnect the charging cable or verify that the cable is completely disconnected and the charger Removed? Turn and hold start knob cover is closed. An authorized Volvo workshop is recommended. Related information • Initiating hybrid battery charging (p. 380) •...
Page 391 HYBRID INFORMATION Long-term storage of vehicles with 2. If the vehicle is not driven for more than 6 hybrid batteries months or the hybrid battery's charge level is noticeably below the 25% mark, charge the To help minimize degradation of the hybrid bat- battery to about 25% to help compensate for tery if the vehicle is not driven for a prolonged the natural battery discharge that occurs in...
Page 393 STARTING AND DRIVING...
Page 394 2. Press and hold down the brake pedal as far • Volvo's floor mats are specially manufac- as possible. tured for your vehicle. They must be prop- 3. Turn the start knob clockwise and release.
Page 395 STARTING AND DRIVING Vehicle key not found In some situations, such as in cold weather or if If the message is shown WARNING the hybrid battery's charge level is too low, the in the instrument panel at start, place the remote Never remove the remote control key from gasoline engine will start instead.
Page 396 STARTING AND DRIVING Switching off the vehicle • Selecting ignition mode (p. 396) CAUTION The vehicle can be switched off using the start • When starting in cold weather, the auto- knob in the tunnel console. matic transmission may shift up at slightly higher engine speeds than normal until the automatic transmission fluid reaches normal operating temperature.
Page 397 STARTING AND DRIVING Ignition modes Mode Functions Mode Functions The vehicle's ignition can be put in various • The odometer, clock and tem- • The headlights illuminate. modes (levels) to make different functions availa- perature gauge are illuminated • ble. Warning/indicator lights illumi- nate for 5 seconds.
Page 398 STARTING AND DRIVING Selecting ignition mode Brake functions Ignition mode I – Turn the start knob clock- • wise and release it. The control will automati- The vehicle's ignition can be put in various The vehicle's brakes are used to reduce speed cally return to the original position.
Page 399 STARTING AND DRIVING Brakes After the vehicle is started, a brief test of the This function is active at speeds in the range of ABS system is automatically performed when the 150-5 km/h (93-3 mph). When braking at The brake pedal is used to apply the vehicle's driver releases the brake pedal.
Page 400 Braking force can be increased up to the point at vehicle's regular brake system is tem checked - an authorized Volvo work- which the ABS intervenes. The function is deacti- still working, but without the ABS shop is recommended.
Page 401 To keep the vehicle as safe and reliable as possi- This may also occur after washing the vehicle. It an extra large safety distance to the vehicle ble, follow the Volvo service schedule specified in will then be necessary to apply greater pressure ahead. Make sure to also: the Warranty and Maintenance Records Informa- to the brake pedal.
Page 402 STARTING AND DRIVING Parking brake Activating and deactivating the Related information parking brake • Activating and deactivating the parking brake The parking brake helps keep the vehicle sta- (p. 400) tionary by mechanically locking two wheels. Use the parking brake to help keep the vehicle stationary when it is parked.
Page 403 STARTING AND DRIVING Symbol in the instrument panel Emergency braking Deactivating automatically In an emergency, the parking brake can be acti- 1. Start the vehicle. Symbol Meaning vated when the vehicle is moving by pulling and 2. Depress the brake pedal firmly. Move the The symbol will be illuminated holding up the control.
Page 404 Heavy load uphill the rear brake pads must be replaced by a work- Heavy loads, such as a trailer, could cause the shop. An authorized Volvo workshop is recom- vehicle to roll backward when the parking brake mended. is released automatically on steep uphill gradi- ents.
Page 405 When the vehicle stops, the brakes are activated • Volvo's service program (p. 556) automatically. The function can use either the normal brakes or the parking brakes to keep the vehicle stationary and works on flat surfaces or hills.
Page 406 STARTING AND DRIVING Activating and deactivating Auto- Symbols in the instrument panel • The function will remain off until it is reactiva- hold at a standstill ted. Symbol Meaning The Auto-hold brake function at a standstill is • When Auto-hold is switched off, Hill Start This symbol illuminates when the activated with the button in the tunnel console.
Page 407 STARTING AND DRIVING Hill Start Assist Braking assist after a collision Related information • Rear Collision Warning (p. 320) The function for assisting when starting the vehi- In a collision in which the activation level is reached for the pyrotechnic seat belt tensioners cle on inclines (HSA ) helps prevent the vehicle •...
Page 408 STARTING AND DRIVING Transmission Gear selector positions for Symbol Meaning automatic transmissions The transmission is part of the vehicle's driveline Information and messages related (power transmission) between the engine and In vehicles with an automatic transmission, the to the transmission. Follow the rec- the drive wheels.
Page 409 STARTING AND DRIVING Select P when the vehicle is parked or when star- To park a vehicle with an unbuckled seat belt and open door – end P mode by shifting to R or D ting the engine. The vehicle must be stationary when Park is selected.
Page 410 STARTING AND DRIVING Using the steering wheel paddles* Brake - B To shift manually to a higher gear, the vehicle to shift must be equipped with steering wheel paddles*. The steering wheel paddles are a supplement to Push the gear selector forward to return to D •...
Page 411 STARTING AND DRIVING Shiftlock Turning off Start/Stop The automatic transmission's shiftlock function Manual deactivation in gear D and B helps prevent inadvertently moving the gear Deactivate the paddles by pulling the right – selector between different positions. paddle (+) toward the steering wheel and holding it until the number of the current gear is no longer displayed in the instrument Automatic shiftlock...
Page 412 The kickdown function All Wheel Drive (AWD) Drive systems Kickdown can be used when maximum accelera- Volvo Twin Engine combines a combustion All-wheel drive (AWD ), also called four-wheel tion is needed, e.g. when passing. engine for the front wheels and an electric motor drive, means that power is distributed to all four for the rear wheels.
Page 413 STARTING AND DRIVING Starting and stopping the Can provide the combustion engine with combustion engine in Twin Engine extra electrical current. vehicles Electric motor - Powers the vehicle using electricity. Can provide extra torque and An advanced control system determines the dis- power during acceleration.
Page 414 STARTING AND DRIVING Drive modes Available drive modes reduced and affect how often the combustion engine automatically starts. Drive modes affect the vehicle's driving charac- WARNING teristics in different ways to enhance and sim- Emission control system plify the driving experience in certain types of sit- Keep in mind that the vehicle does not emit To help ensure that the emission control system uations.
Page 415 STARTING AND DRIVING Hybrid ence. When faster acceleration is requested by The instrument panel also shows how the driver, the electric driveline will be utilized to much current is being restored to the • This is the default mode in which the electric help provide maximum additional power.
Page 416 STARTING AND DRIVING Power This drive mode is optimized for maximum driving control, stability and traction, e.g. on slippery drive mode is always available regardless distance with electric propulsion and is primarily roads or when towing a heavy trailer or another of the hybrid battery's charge status.
Page 417 STARTING AND DRIVING Presets Individual 3. Under , select one of the following Pure Hybrid drive modes as a basis: • Customizes drive mode to personal preferen- Power ces. Select one of the drive modes as a basis and The following settings can be modified: adjust the settings to achieve your preferred driv- Driver Display •...
Page 418 STARTING AND DRIVING Changing drive mode Related information Related information • Changing drive mode (p. 416) • Drive modes (p. 412) Select the drive mode that is best suited to the current driving conditions. • Economical driving (p. 420) • Energy distribution in hybrid mode using map The drive mode is changed using the control in data* (p.
Page 419 STARTING AND DRIVING Energy distribution in hybrid mode Related information The greatest fuel savings are achieved when using map data* • Drive modes (p. 412) • the trip begins on a highway Hybrid drive mode is the vehicle's default • Economical driving (p.
Page 420 Volvo recommends that shock absorber adjust- absorbers are adapted to the selected drive particular road surfaces. ments are performed by an authorized Volvo mode and the current vehicle speed. The shock The settings can be adjusted for driving on workshop.
Page 421 Stop safely Suspension A fault has occurred. If the message appears while driving, contact a workshop Slow down Vehicle too high An authorized Volvo workshop is recommended. Related information • Leveling control settings* (p. 420) •...
Page 422 STARTING AND DRIVING Economical driving Leveling control settings* while the vehicle is parked. If possible, park the vehicle in a climate-controlled garage. Turn off leveling control before lifting the vehicle Drive economically and more environmentally with a jack to help avoid problems with the conscious by thinking ahead and avoiding rapid •...
Page 423 STARTING AND DRIVING Factors affecting electric motor Driving increases fuel consumption and carbon diox- range Pure ide emissions. • Choose the drive mode to help mini- mize electric power consumption. • In a cold climate, reduce heating of the wind- A number of factors affect the electric motor's shield/rear window, mirrors, seats and the driving range.
Page 424 STARTING AND DRIVING Factors the driver cannot control Factors the driver can control NOTE There are several outside conditions that affect The driver should be aware that the following fac- • The values shown in the table refer to a range to varying degrees: tors help conserve energy and improve driving new vehicle.
Page 425 STARTING AND DRIVING Hold and Charge functions Charge Engine charges hybrid In certain situations, it can be useful to control battery the hybrid battery's charge level while driving. Hold Charge This is possible with the func- This function charges the tions.
Page 426 Preparing for a long trip Winter driving Slippery driving conditions For optimal traction and roadholding, Volvo rec- It is important to have the vehicle's systems and It is important to check the vehicle before driving ommends using snow tires on all wheels when-...
Page 427 Have the the water at its deepest point before driving vehicle towed on the bed of a tow truck to a through it. Be particularly careful when driv- workshop - an authorized Volvo workshop is ing through flowing water. recommended. •...
Page 428 STARTING AND DRIVING Refueling 2. After refueling, press the fuel filler door lightly to close it. The fuel tank is equipped with a fuel filling sys- tem without a cover. Related information • Refueling (p. 426) Refueling the vehicle at a service station 1.
Page 429 STARTING AND DRIVING Instructions for fueling: 4. Avoid overfilling the tank. Do not press the WARNING handle on the filler nozzle again after it has 1. Turn off the engine and open the fuel filler California Proposition 65 initially stopped pumping. door.
Page 430 STARTING AND DRIVING Fuel the emission control system and could result in Volvo permits the use of the following "oxygen- loss of emission warranty coverage. State and ated" fuels. However, the specified octane ratings Volvo recommends the use of detergent gaso- local vehicle inspection programs will make must still be met.
Page 431 TOP TIER Detergent Gasoline been strongly linked to certain forms of cancer. Volvo endorses the use of "TOP TIER Detergent Many fuels contain benzene as a solvent. Gasoline" where available to help maintain Unburned benzene has been strongly linked to engine performance and reliability.
Page 432 Excessive starter cranking (in excess of one partment is ventilated, and immediately return minute), or an intermittently firing or flooded the vehicle to a trained and qualified Volvo service technician for correction. engine can cause three-way catalytic con- verter or exhaust system overheating.
Page 433 STARTING AND DRIVING Overheating of engine and or location or removing components, and/or the vehicle safely and letting the engine idle transmission repeated use of leaded fuel. for a few minutes to let the transmission cool. In certain driving conditions, such as driving in NOTE mountainous areas or hot weather, there is a risk •...
Page 434 Related information 12 V Battery Fuse failure If a fuse has blown, • Start battery (p. 574) Service required will be displayed in the instru- • Ignition modes (p. 395) ment panel. Volvo recommends contacting an authorized Volvo workshop.
Page 435 STARTING AND DRIVING To avoid short circuits or other damage, the fol- 9. Make sure the jumper cables are securely 12. Remove the jumper cables in the reverse order ‒ first the black cables and then the lowing steps are recommended when jump star- attached to help prevent sparks while jump ting the battery: starting.
Page 436 STARTING AND DRIVING Driving with a trailer • If contact occurs, flush the affected area NOTE immediately with water. Obtain medical There are a number of things to consider when If the starter battery has been discharged to help immediately if eyes are affected. towing a trailer, such as the towbar, the trailer the extent that the vehicle does not have nor- •...
Page 437 Consult fore be reduced. The weight of the vehicle The specified maximum trailer weights are your nearest authorized Volvo retailer for and trailer must be decreased by 10% for those permitted by Volvo. National vehicle correct installation.
Page 438 STARTING AND DRIVING Trailer Stability Assist* The automatic transmission selects the optimal ments. If swaying is detected, the brakes are gear for the current load and engine speed. applied individually on the front wheels, which has Trailer Stability Assist (TSA ) is a function a stabilizing effect on the vehicle and trailer.
Page 439 STARTING AND DRIVING Checking trailer lights When Trailer Stability Assist is fog lights when driving with a trailer to help activated, the ESC symbol is ensure safe operation. When connecting a trailer, make sure that all of displayed in the instrument the lights on the trailer are functioning before Checking trailer lights* panel.
Page 440 STARTING AND DRIVING Towing using a towline Related information Disabling the automatic check The automatic light check can be disabled in the • Attaching and removing the towing eyelet This section refers to one vehicle being towed center display. (p. 439) behind another using a towline.
Page 441 STARTING AND DRIVING Attaching and removing the towing 3. Screw the towing eyelet into place as far as eyelet possible. Use the towing eyelet to tow another vehicle. Screw the towing eyelet securely into place in the threaded outlet behind the cover on the right-hand side of the rear bumper.
Page 442 STARTING AND DRIVING ® Recovery ® HomeLink HomeLink is delivered integrated in the rearview ® mirror. The HomeLink panel consists of three ®15 This section refers to transporting the vehicle HomeLink is a programmable remote control, programmable buttons and an indicator light in with a tow truck or similar vehicle.
Page 443 STARTING AND DRIVING ® ® Programming HomeLink 1. Point the remote control at the HomeLink button to be programmed and hold it about Follow these instructions to program 2-8 cm (1-3 inches) from the button. Do not ® HomeLink , reset all programming, or program ®...
Page 444 STARTING AND DRIVING ® Programming individual buttons Using HomeLink WARNING ® To program an individual HomeLink button: ® Once HomeLink is programmed, it can be ® • If you use HomeLink to open a garage used instead of the separate remote controls. 1.
Page 445 STARTING AND DRIVING ® Compass* Type approval for HomeLink • 869.70MHz-870.00MHz <25mW E.R.P. Certificate holder address: Gentex Corporation, An integrated compass in the upper right cor- FCC (USA) and IC (Canada) 600 North Centennial Street, Zeeland MI 49464, ner of the rearview mirror shows the direction This device complies with FCC rules part 15 and the vehicle is traveling.
Page 446 STARTING AND DRIVING Activating and deactivating the Calibrating the compass* compass* The globe is divided into 15 magnetic zones. An integrated compass in the upper right cor- The compass should be calibrated if the vehi- ner of the rearview mirror shows the direction cle is driven from one zone to another.
Page 447 STARTING AND DRIVING 7. Vehicles with heated windshields*: If shown in the display when the windshield heating function is activated, perform step 6 above with the heating function on. 8. Repeat the above procedure as needed. Related information • Compass* (p. 443) •...
Page 449 AUDIO, MEDIA AND INTERNET...
Page 450 AUDIO, MEDIA AND INTERNET Audio, media and Internet Sound settings Related information • Media player (p. 470) The audio and media system consists of a media The sound system is precalibrated for optimal player and a radio. A cellular phone can also be sound reproduction, but these settings can be •...
Page 451 AUDIO, MEDIA AND INTERNET Sound experience* Premium Sound* (Bowers & Wilkins) • Voice control settings (p. 147) Tone • - setting for e.g. bass, treble, equalizer, • Phone settings (p. 492) Sound experience is an app that provides etc. access to additional sound settings. •...
Page 452 AUDIO, MEDIA AND INTERNET Apps High Performance Pro* (Harman Kardon) The App view contains applications (apps) that Seat Optimization • - the sound can be opti- provide access to certain vehicle services. Driver Rear mized for Swipe the center display screen from right to Surround •...
Page 453 AUDIO, MEDIA AND INTERNET Download apps Start an app by pressing the app in the center 3. Tap on the row for an app in order to expand display's app view. in the list and get more information about the New apps can be downloaded when the vehicle app.
Page 454 AUDIO, MEDIA AND INTERNET Updating apps Deleting apps Update certain apps Download Center 1. Open the app in App Apps can be updated when the vehicle is con- When the vehicle is connected to the Internet, it view. nected to the Internet. is possible to uninstall apps.
Page 455 AUDIO, MEDIA AND INTERNET Radio Starting the radio • Radio settings (p. 456) The radio can receive broadcasting from the FM • RBDS (p. 457) The radio is started from the center display's waveband with HD Radio™ Technology and App view. •...
Page 456 AUDIO, MEDIA AND INTERNET Changing waveband and radio Genres • Changing waveband and radio station - only plays channels broadcasting the station (p. 454) selected genre or program type, e.g. pop, classi- cal, etc. • Storing radio favorites (p. 455) Instructions for changing wavebands, waveband lists and radio stations in the selected list are •...
Page 457 AUDIO, MEDIA AND INTERNET Searching for a radio station Storing radio favorites Searching for a station manually Radio The radio automatically compiles a list of the It is possible to add a radio station in the favorites radio stations that are sending out the strongest app and in the list of favorites for the signals in the vehicle's current location.
Page 458 AUDIO, MEDIA AND INTERNET Radio settings Related information • Voice control for radio and media (p. 146) • Radio (p. 453) • Radio settings (p. 456) There are a number of different radio functions ® that can be activated and deactivated. •...
Page 459 AUDIO, MEDIA AND INTERNET RBDS HD Radio™ The IBOC system is referred to as a "hybrid" since it is both analog and digital. During hybrid RBDS radio HD Radio is a brand name registered by the DTS, operation, receivers still continue to receive the RBDS (Radio Broadcast Data System) enables analog (non-digital) signal.
Page 460 AUDIO, MEDIA AND INTERNET Activating and deactivating the HD be displayed immediately. Album art is synched • Instead of transmitting one analogue signal, Radio™ with the artist that you are currently listening to. stations send out a bundled signal – both analog and digital.
Page 461 AUDIO, MEDIA AND INTERNET HD Radio™ sub-channels • HD Radio™ limitations (p. 460) If you tap a sub-channel favorite, it may take up to 6 seconds before the channel becomes audi- • Opening contextual setting in the center dis- In many cases, a main HD Radio station (FM ble.
Page 462 AUDIO, MEDIA AND INTERNET ® HD Radio™ limitations SiriusXM Satellite radio* NOTE ® The SiriusXM Satellite system broadcasts from There may be a noticeable difference in Limitations of a number of high elevation satellites in geo- sound quality when a change from analogue Main channel vs.
Page 463 AUDIO, MEDIA AND INTERNET ® ® Using SiriusXM Satellite radio* 2. Open the settings menu for SiriusXM Satel- lite radio. ® SiriusXM Satellite radio offers several features Unsubscribed Services for finding and listening to music, news, sporting 3. Tap events, etc. being broadcast on satellite radio ®...
Page 464 AUDIO, MEDIA AND INTERNET EPG (Electronic Program Guide) iTunes tagging Search SiriusXM Tap the magnifying glass to display a screen On the center display's Home view, tap From the center display's Top view, tap Settings iTunes Tagging where you can enter text using the center dis- information about e.g., when a program is being .
Page 465 AUDIO, MEDIA AND INTERNET ® ® Settings for SiriusXM Satellite JUMP • From the Home screen, tap to activate the Settings for SiriusXM Satellite radio* radio* function. When traffic/weather information is (p. 463) available from the selected city, the radio will •...
Page 466 AUDIO, MEDIA AND INTERNET ® SiriusXM Travel Link Game Alerts Skipped Categories Tap to display a list of sports. Tap to display a list of categories. Tap a category SiriusXM Travel Link is a subscription feature to skip (hide) it. It will not be displayed in the list ®...
Page 467 AUDIO, MEDIA AND INTERNET ® SiriusXM Travel Link 3. Press • SiriusXM Travel Link * - Sports (p. 469) NOTE Subscription Status ® • SiriusXM Travel Link * - Weather (p. 466) Close If the button is used to return to the >...
Page 468 AUDIO, MEDIA AND INTERNET ® SiriusXM Travel Link * - Weather Local 5 days Tap to see weather information for the coming 5 Information from the closest weather station will This SiriusXM Travel Link service provides days. be displayed and the following alternatives are weather-related information near the vehicle, at a available: local ski resort, etc.
Page 469 AUDIO, MEDIA AND INTERNET ® Areas SiriusXM Travel Link the location of the weather problem on a map Areas Notifications and a description of the situation). to display a list of areas/locations in states from the SiriusXM Travel Link database. This SiriusXM Travel Link service provides notifi- If a phone number is available in a notification, a Call...
Page 470 AUDIO, MEDIA AND INTERNET ® SiriusXM Travel Link * - Fuel Search the Sensus Navigation* supplement for additional information about using the navigation system. Tap the magnifying glass icon. If the function is This SiriusXM Travel Link service provides infor- supported in the current context, a keyboard will mation and guidance to service stations near the Recommended...
Page 471 AUDIO, MEDIA AND INTERNET ® SiriusXM Travel Link * - Sports 2. Tap a brand to display a list of service sta- 4. Tap one of the divisions to display: tions affiliated with that brand (BP, Exxon, In progress This SiriusXM Travel Link service provides infor- •...
Page 472 AUDIO, MEDIA AND INTERNET Media player Playing media Related information • Playing media (p. 470) The media player can play audio from the CD The media player is controlled from the center player* and from external audio sources con- display. Several other functions can also be con- •...
Page 473 AUDIO, MEDIA AND INTERNET Related information Bluetooth-connected device 1. Insert a CD. 1. Activate Bluetooth in the media source. • Handling the App menu in the instrument panel (p. 102) 2. Open the app from App view. 2. Connect a media source. •...
Page 474 AUDIO, MEDIA AND INTERNET Controlling and changing media Similar Changing track/song - tap the desired track in - tap the button to use Gracenote to search for similar the center display, or press below Media playback can be controlled using voice music on the USB device and the center display or on the right-side steering commands, the steering wheel keypad or the...
Page 475 AUDIO, MEDIA AND INTERNET ® Media searches Related information Gracenote • Media player (p. 470) Searches can be performed to locate a specific Gracenote identifies artists, albums, tracks and artist, composer, song title, album, video, audio • Internet-connected vehicle* (p. 494) any associated images that can be displayed book or playlist.
Page 476 AUDIO, MEDIA AND INTERNET Video CD player* Updating Gracenote The contents of the Gracenote database are con- The media player can play CDs with compatible The media player can play videos from USB- tinuously updated. For optimal functionality, audio files. connected devices.
Page 477 AUDIO, MEDIA AND INTERNET ® Playing video Video settings Playing DivX ® app in App view is used to play videos. Some video playback settings can be adjusted, The DivX Certified device must be registered to e.g. language. play purchased DivX video-on-demand (VOD) 1.
Page 478 AUDIO, MEDIA AND INTERNET ® ® Playing media via the USB port Streaming media via Bluetooth Connecting a device via Bluetooth ® External audio sources, such as an iPod® or The vehicle's media player is equipped with Connect a Bluetooth device to the vehicle to MP3 player, can be connected to the audio sys- Bluetooth and can play audio files from...
Page 479 AUDIO, MEDIA AND INTERNET Connecting a device via the USB Technical specifications for USB • Technical specifications for USB devices port devices (p. 477) ® ® ® • For the contents of USB devices to be read, the External audio sources, such as an iPod Apple CarPlay * (p.
Page 480 AUDIO, MEDIA AND INTERNET Compatible file formats for media File extension .divx, .avi Format File extension In order to play media, the following file formats Max. file size 4 GB .avi must be used. AVI (DivX) .avi, .divx Audio codec MP3, AC3 Audio files .asf, .wmv...
Page 481 CarPlay is active. An alter- site: www.apple.com/ios/carplay/. Using apps native source must be used to provide an iPhone. In relation to Volvo Cars, you are that are not compatible with CarPlay may some- Internet connection for the vehicle's apps.
Page 482 AUDIO, MEDIA AND INTERNET ® ® Settings for Apple CarPlay 5. Tap the desired app. Communication Apple 2. Proceed to CarPlay. > The app will start up. Settings for an iOS device connected through CarPlay Starting CarPlay 3. Uncheck the box for the iOS device that should no longer start CarPlay automatically CarPlay can be started as follows after an iOS Automatic start...
Page 483 AUDIO, MEDIA AND INTERNET ® ® Tips for using Apple CarPlay ten/dictated, it will be displayed in the iOS Sound System Volumes 2. Tap to change device, but not in the center display. the settings for the following: Here are some useful tips for when you use ®...
Page 484 For third-party apps, see 4. Read the terms and conditions and then tap When you use Android Auto, your car Accept Google Play. Please note that Volvo is not to connect. transfers certain information (including its responsible for the content of Android Auto.
Page 485 AUDIO, MEDIA AND INTERNET Settings for Android Auto* Related information From a previously connected Android device 1. Connect the device to the USB port with the • Android Auto* (p. 482) Settings for Android devices initially connected white frame. with Android Auto. •...
Page 486 AUDIO, MEDIA AND INTERNET Phone Tips for using Android Auto* noting if many people share the vehicle, e.g. in a car pool. When the list is full and a new Here are some useful tips for when you use A phone equipped with Bluetooth can be wire- device is connected, the oldest one will be Android Auto.
Page 487 AUDIO, MEDIA AND INTERNET Connecting a phone to the car via Overview • Connecting a phone to the car via Bluetooth Bluetooth for the first time automatically (p. 487) • Connecting a phone to the car via Bluetooth Pair a Bluetooth-enabled phone to the vehicle to manually (p.
Page 488 AUDIO, MEDIA AND INTERNET Option 1 - searching for the phone from Option 2 - searching for the vehicle NOTE the vehicle from the phone • The message function must be activated 1. Make the phone discoverable/visible using 1. Open the phone tile in the center display. in certain phones.
Page 489 AUDIO, MEDIA AND INTERNET Connecting a phone to the car via • Disconnecting Bluetooth-connected devices • Ignition modes (p. 395) Bluetooth automatically (p. 489) • Settings for Bluetooth devices (p. 493) A phone can be automatically connected to the vehicle via Bluetooth. The phone must have first •...
Page 490 AUDIO, MEDIA AND INTERNET Connecting a phone to the car via Disconnecting a Bluetooth- Switch between phones connected Bluetooth manually connected phone via Bluetooth A phone can be manually connected to the vehi- A Bluetooth-connected phone can be discon- It is possible to switch between Bluetooth-con- cle via Bluetooth.
Page 491 AUDIO, MEDIA AND INTERNET Disconnecting Bluetooth-connected Handling phone calls Calls can also be made from the list of recent devices calls using the app menu, which can be opened Handling phone calls in the vehicle for a using the button on the right-side steering Phones or other devices in the list of registered Bluetooth-connected cellular phone.
Page 492 • Managing the phone book (p. 492) • The center display's keyboard cannot be used. • Handling text messages (p. 490) • Sound settings (p. 448) Only applies to certain markets. Contact a Volvo retailer for more information.
Page 493 AUDIO, MEDIA AND INTERNET Text message settings Message alert Sending text messages in the center Alerts can be activated and deactivated in the display Settings for handling text messages received text message settings. 1. It is possible to reply to text messages or through a connected phone can be personal- create a new message.
Page 494 AUDIO, MEDIA AND INTERNET Managing the phone book Phone settings name or last name. This is adjusted in your cellu- lar phone settings. When a phone is connected with Bluetooth to When the phone is connected to the car, the fol- the vehicle, contacts can be managed directly in lowing settings can be made: Related information...
Page 495 AUDIO, MEDIA AND INTERNET Settings for Bluetooth devices Canada • Head-up display* (p. 140) Settings for Bluetooth-connected devices. • Sound settings (p. 448) This device complies with Industry Canada license-exempt RSS standard(s). Operation is Settings 1. Tap in the Top view. subject to the following two conditions: Communication Bluetooth...
Page 496 Deleting Wi-Fi networks (p. 499) • Wi-Fi technology and security (p. 499) NOTE • Volvo ID (p. 26) When using Android Auto, it is possible to • Terms of use and data sharing (p. 500) connect the vehicle to the Internet using Wi-Fi, Bluetooth or the vehicle's modem.
Page 497 AUDIO, MEDIA AND INTERNET Connecting the vehicle to the Connecting the vehicle to the 6. If a different connection is being used, con- Internet via a Bluetooth-connected Internet via a phone (Wi-Fi) firm the connection change. phone > Your vehicle is now connected to the Establish an Internet connection using Wi-Fi Internet via your Bluetooth-connected through Internet sharing (tethering) from a phone...
Page 498 (P-SIM). be saved for future use. To display a list of saved > The vehicle will connect to the network. networks or to manually delete saved networks, Vehicles equipped with Volvo On Call will use the Settings Communication Wi-Fi Related information...
Page 499 AUDIO, MEDIA AND INTERNET Vehicle modem settings Sharing Internet from the vehicle via Send request code • - used to e.g. download Wi-Fi hotspot (tethering) or check the balance remaining on a prepaid Your vehicle is equipped with a modem that can phone card.
Page 500 AUDIO, MEDIA AND INTERNET No or poor Internet connection Connected devices to see a list of cur- Communication Vehicle Wi-Fi 2. Tap rently connected devices. Hotspot. Factors affecting the Internet connection. Network name Related information 3. Tap to assign a name to the The amount of data transmitted depends on the hotspot.
Page 501 AUDIO, MEDIA AND INTERNET Deleting Wi-Fi networks Wi-Fi technology and security Restarting the phone If you experience any Internet connection prob- Networks that are not needed can be deleted. Networks must meet certain criteria in order for lems, it may help to restart your phone. the vehicle to connect.
Page 502 Settings The aim is to inform the user about Volvo's terms 1. Tap capacity and how much space is used for instal- in the Top view in the center of use and data sharing policy. By accepting data led apps.
Page 503 Theater video files up to 576p (includ- tions specified in the agreement. The following ing .avi, .divx). Download free software at texts are Volvo's agreements with manufactur- www.divx.com to create, play and stream digital ers/developers. video.
Page 504 AUDIO, MEDIA AND INTERNET Portions of the content are copyright © of these restrictions. If your license terminates, you additional data types or categories that Grace- Gracenote or its providers. agree to cease any and all use of the Gracenote note may provide in the future and is free to dis- Data, the Gracenote Software, and Gracenote continue its services at any time.
Page 505 AUDIO, MEDIA AND INTERNET source code must retain the above copyright This software is based in part on the work of the SILICON GRAPHICS, INC. BE LIABLE FOR ANY notice, this list of conditions and the following Independent JPEG Group. CLAIM, DAMAGES OR OTHER LIABILITY, disclaimer.
Page 506 AUDIO, MEDIA AND INTERNET The website provides the Source Code "As Is" PARTICULAR PURPOSE ARE DISCLAIMED. IN the above copyright notice(s) and this permission and without warranty of any kind. NO EVENT SHALL NTT BE LIABLE FOR ANY notice appear with all copies of the Data Files or DIRECT, INDIRECT, INCIDENTAL, SPECIAL, Software, (b) both the above copyright notice(s) By downloading Source Code, you expressly...
Page 507 AUDIO, MEDIA AND INTERNET dealings in these Data Files or Software without prior written authorization of the copyright holder. FCC CAUTION Declaration of Conformity Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equip- ment.
Page 508 AUDIO, MEDIA AND INTERNET Country/ Area Brazil: Este equipamento opera em caráter secundário isto e, náo tem direito a protecão contra interferéncia prejudicial, mesmo tipo, e não pode causar interferéncia a sistemas operando em caráter primário. Para consultas, visite: www.anatel.gov.br Manufacturer: Mitsubishi Electric Corporation Sanda Works 2-3-33, Miwa, Sanda-city.
Page 509 AUDIO, MEDIA AND INTERNET Country/ Area Kazakh- stan Model name: NR-0V Manufacturer: Mitsubishi Electric Corporation Export country: Japan...
Page 510 AUDIO, MEDIA AND INTERNET Country/ Area China: ■ 使用频率 2.4 - 2.4835 GHz ■ 等效全向辐射率(EIRP) 天线增益 10dBi 时 ≤100 mW 或≤20 dBm ① ■ 最大率谱密度天线增益 10dBi 时 ≤20 dBm / MHz(EIRP) ① ■ 载频容限 20 ppm ■ 帯外发射率(在 2.4-2.4835GHz 頻段以外) ≤-80 dBm / Hz (EIRP) ■...
Page 511 AUDIO, MEDIA AND INTERNET Country/ Area B 급 기기 (가정용 방송통신기자재) Korea: 이 기기는 가정용(B 급) 전자파적합기기로서 주로 가정에서 사용하는 것을 적으로 하며, 든 지역에서 사용할 수 있습니다. 해당 무선설비는 전파혼신 가능성이 있으므로 인명안전과 관련된 서비스는 할 수 없습니다. Malaysia This device has been certified under the Communications &...
Page 512 AUDIO, MEDIA AND INTERNET Country/ Area Mexico: 低功率電波輻射性電機管理辦法 Taiwan: 第十二條經型式認證合格之低功率射頻電機，非經許可，公司商號或使用者均不得擅自變更頻率加大功率或變更原設計之特性及功能第十四條低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立停用，改善至無干擾時方得繼續使用前項合法通信，指依電信法規定作業之無線電通信低功率射頻電機須忍受合法通信或工業科學及醫療用電波輻射性電機設備之干擾 Related information • Audio, media and Internet (p. 448) • Internet-connected vehicle* (p. 494) • Media player (p. 470) ®...
Page 513 WHEELS AND TIRES...
Page 514 Recommended tires bination designed to provide maximum dry pavement performance with consideration for On delivery, the car is equipped with Volvo origi- The tires significantly influence the vehicle's driv- hydroplaning resistance. They may be more nal tires that have the VOL marking on the side ing characteristics.
Page 515 If you have any questions regarding tread depth, Volvo recommends consulting an authorized • Correct front wheel alignment is very impor- Volvo workshop. If significant differences in wear tant. (> 1 mm difference in tread depth) between the • Unbalanced wheels impair tire economy and tires have already occurred, the least worn tires driving comfort.
Page 516 NOTE Tires with tread designed to roll in only one • The wheel and tire sizes for your Volvo Use tires of the same type, dimensions and direction are marked with an arrow on the side- are specified to meet stringent stability make (manufacturer) on each axle.
Page 517 Recommended tire inflation pressure: • capability. wear indicator. Replace the tire as soon as possi- inflation pressure, established by Volvo, Extra load: A class of P-metric or Metric • ble. Tires with low tread offer very poor traction in which is based on the type of tires that are tires designed to carry a heavier maximum rain or snow.
Page 518 WHEELS AND TIRES Tire sidewall designations perature is normally reached after the vehicle NOTE has been parked for at least 3 hours. The following information can be found on a Please be aware that the following tire desig- tire's sidewall. Related information nation is an example only and that this par- •...
Page 519 This limit is set rain, AS = All Season • The wheel and tire sizes for your Volvo by the tire manufacturer. 8. U.S. DOT Tire Identification Number are specified to meet stringent stability Speed Symbol (TIN): This begins with the letters "DOT"...
Page 520 WHEELS AND TIRES Uniform Tire Quality Grading Related information WARNING • Tires (p. 512) ALL PASSENGER VEHICLE TIRES MUST The traction grade assigned to this tire is CONFORM TO FEDERAL SAFETY REQUIRE- • Tire sidewall designations (p. 516) based on braking (straight-ahead) traction MENTS IN ADDITION TO THESE GRADES.
Page 521 , at least once a month and before long trips. to drive longer than that to inflate the tires, check Volvo recommends buying a reliable air pressure and record the inflation pressure of the tires first gauge, as the automatic gauges provided at serv- and inflate accordingly when you arrive at the ice stations may be inaccurate.
Page 522 WHEELS AND TIRES Adjusting tire pressure 3. Screw the valve cap back on. NOTE Tire pressure decreases over time, which is nor- If you have overfilled the tire, release air by NOTE mal. The tire pressure must therefore be pushing on the metal stem in the center of adjusted to maintain the recommended tire pres- •...
Page 523 WHEELS AND TIRES Recommended tire pressure Tire pressure monitoring system* ted to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or The tire pressure placard on the driver's side B The tire pressure monitoring system provides a tire inflation pressure label.
Page 524 WHEELS AND TIRES To keep in mind pressure telltale. When the system detects a mal- • Action when warned of low tire pressure function, the telltale will flash for approximately (p. 525) • Always save the new inflation pressure in the one minute and then remain continuously illumi- system after changing a tire or adjusting the •...
Page 525 (over 160 km/h (100 mph)), tire Storing pressure should be adjusted to the Volvo-recom- > If storing cannot be performed, pressure unsuccessful. Try again. mended tire pressure values. The system should...
Page 526 WHEELS AND TIRES Viewing tire pressure status in the • Action when warned of low tire pressure Status indicator light center display* (p. 525) • Tire pressure monitoring system* (p. 521) With the system for tire pressure monitoring tire pressure status can be viewed in the center display.
Page 527 3. Inflate the tire to the correct inflation pres- caused by gravel, dirt, etc. An authorized Volvo workshop is recommended. sure; see the tire pressure placard on the • Use plastic valve caps only. Metal caps...
Page 528 If you change to tires of another dimension, con- • Inflate tires with the compressor included in tact an authorized Volvo workshop to update the the tire sealing system (p. 539) vehicle's software. A software update may be necessary when changing to tires of larger/ smaller dimensions or when changing to or from snow tires.
Page 529 Only use rims that have been tested and pension, it must be turned off before the vehicle approved by Volvo and are included in Volvo's is lifted on a jack. original product range.
Page 530 WHEELS AND TIRES Removing a wheel Related information WARNING • Removing a wheel (p. 528) Wheel changes must always be carried out cor- • Apply the parking brake and put the gear rectly. The following instructions show how to • Installing a wheel (p.
Page 531 WHEELS AND TIRES 1. Turn on the vehicle's hazard warning flashers 5. Using the lug wrench, screw the towing eye 8. When hoisting the vehicle, it is important that if a wheel change must be performed in an into place as far as possible according to the the jack or garage lift arms are positioned on area with traffic.
Page 532 WHEELS AND TIRES Installing a wheel 10. Crank it up until it is properly aligned and it is WARNING in contact with the vehicle's jack attachment Instructions for installing a wheel during a wheel • Apply the parking brake and put the gear point.
Page 533 Related information • When changing wheels (p. 526) If the spare wheel is damaged, a new one can be purchased from a Volvo retailer. • Hoisting the vehicle (p. 564) • Jack* (p. 527) WARNING •...
Page 534 WHEELS AND TIRES Handling spare tires WARNING CAUTION Follow these instructions regarding handling the • The vehicle must never be driven with The vehicle must not be driven with wheels of spare wheel. more than one "Temporary Spare" tire different dimensions or with a spare tire other mounted.
Page 535 • Tread wear indicator (p. 515) model and the tire and wheel sizes. Only one- Contact a Volvo dealer for advice on the best sided snow chains are permitted. choice of rims and tires. If uncertain about snow chains, Volvo recom-...
Page 536 NOT be used. odically. WARNING • Only put snow chains on the front wheels Consult a Volvo retailer for more information California Proposition 65 (also applies to all-wheel drive vehicles). about snow chains. Operating, servicing and maintaining a pas- •...
Page 537 (p. 539) NOTE • Tires (p. 512) The compressor is intended for temporary tire sealing and is approved by Volvo. Location The tire sealing system is located in a foam block under the floor of the trunk. Electrical cable...
Page 538 WHEELS AND TIRES Sealing compound bottle • Inhalation: Move the exposed person to WARNING fresh air. If irritation persists, get medical Switch Please keep the following points in mind attention. when using the tire sealing system: • Ingestion: Do NOT induce vomiting Connecting •...
Page 539 WARNING The bottle and the bottle holder are equip- the tire. Volvo recommends an authorized ped with catches to help prevent the sealing Never leave children unattended in the vehicle workshop.
Page 540 Volvo recommends driving to the nearest author- 15. Rechecking the inflation pressure screw the valve cap back on. ized Volvo workshop to have the tire replaced/ Connect the hose to the tire's valve and repaired. Inform the workshop that the tire con-...
Page 541 WHEELS AND TIRES Inflate tires with the compressor WARNING CAUTION included in the tire sealing system After using the tire sealing system, the vehicle Risk of overheating. The compressor should The vehicle's original tires can be inflated using should not be driven farther than approxi- not be running for longer than 10 minutes at the compressor in the tire sealing system.
Page 542 WHEELS AND TIRES Determining the vehicle's permitted Related information Steps for Determining Correct Load weight Limit • Recommended tire pressure (p. 521) 1. Locate the statement "the combined weight Properly loading your vehicle will provide maxi- • Using the tire sealing system (p. 535) of occupants and cargo should never exceed mum return of vehicle design performance.
Page 543 GVW rating. Use only tires with the correct load carrying capacity. Consult your Volvo retailer for information. Related information • Loading recommendations (p. 551)
Page 545 LOADING, STORAGE AND PASSENGER COMPARTMENT...
Page 546 LOADING, STORAGE AND PASSENGER COMPARTMENT Passenger compartment interior Rear seat Related information • Electrical outlets (p. 546) Overview of the passenger compartment interior and storage spaces. • Using the glove compartment (p. 549) • Sun visors (p. 550) Front seats •...
Page 547 LOADING, STORAGE AND PASSENGER COMPARTMENT Tunnel console CAUTION The tunnel console is located between the front Keep in mind that glossy surfaces can be seats. easily scratched by e.g. metal objects. Do not place keys, phones or similar items on sensi- tive surfaces.
Page 548 12 V electrical outlet* in the trunk/cargo compartment. If a problem occurs with an electrical socket, contact a workshop - an authorized Volvo work- shop is recommended. 12 V outlets 12 V outlet in the tunnel console, rear seat.
Page 549 LOADING, STORAGE AND PASSENGER COMPARTMENT Status indicator light Cause Action Steady green light The outlet is providing electrical current to a connected device. None. Flashing orange light The outlet's voltage converter is too hot (e.g. if the device draws too much cur- Unplug the device, let the voltage converter cool rent or if the temperature in the passenger compartment is very high).
Page 550 Accessories connected to the electrical out- Do not attempt to alter or repair the high-volt- is not in use or left unattended. age outlet on your own. Volvo recommends lets can be activated even when the vehicle contacting an authorized Volvo workshop.
Page 551 LOADING, STORAGE AND PASSENGER COMPARTMENT Using the glove compartment WARNING The glove compartment is located on the pas- • Only use accessories that are not dam- senger side. The glove compartment can be aged or malfunctioning. The accessories used to store the Owner's Manual, maps, etc. must be CE marked, UL marked or have There is also room for a pen and a card holder.
Page 552 LOADING, STORAGE AND PASSENGER COMPARTMENT Sun visors In the ceiling in front of the driver's and front passenger's seats, there are sun visors that can be lowered and angled to the side as necessary. The illustration is generic – the design may vary. The illustration is generic –...
Page 553 LOADING, STORAGE AND PASSENGER COMPARTMENT Cargo compartment Loading recommendations WARNING Loads can be secured in the trunk to keep them There are a number of things that are important In a head-on collision at a speed of 50 km/h in place while driving. to consider when carrying loads in or on the (30 mph), an unsecured object weighing vehicle.
Page 554 • Weights (p. 617) loading*. If the rear seat backrests are folded Volvo load carriers are specially designed to help down, make sure that no objects loaded into the prevent damage to your vehicle and help ensure vehicle prevent the WHIPS system for the front maximum safety while driving.
Page 555 LOADING, STORAGE AND PASSENGER COMPARTMENT Grocery bag holders Load anchoring eyelets Under the parcel shelf* Grocery bag holders (hooks) help keep shop- The load anchoring eyelets in the cargo com- ping bags in place and prevent them from falling partment can be used to secure objects with over and spilling their contents in the cargo straps, a net, etc.
Page 556 LOADING, STORAGE AND PASSENGER COMPARTMENT Rear seat ski hatch* The hatch in the rear seat backrest can be opened to transport long, narrow objects such as skis. The illustration is generic - details may vary according to vehicle model. 1. In the cargo compartment, grasp the ski hatch handle and pull it down.
Page 557 MAINTENANCE AND SERVICE...
Page 558 For more infor- • New Vehicle Limited Warranty nician. To keep your Volvo in top condition, spec- mation go to www.P65Warnings.ca.gov/ ify time-tested and proven Genuine Volvo Parts •...
Page 559 OBD II to inspections and services necessary for inspection? reach readiness. Your Volvo retailer can pro- the proper function of your vehicle and Your vehicle can fail OBD II emission inspection vide you with more information on planning a...
Page 560 Check cold tire pressure in all tires. Inspect • Vehicle status (p. 560) the tires for wear. Volvo workshops have a designated Wi-Fi net- • Scheduling service and repairs (p. 561) work for secure data transfer between your vehi- •...
Page 561 MAINTENANCE AND SERVICE Download Center Handling system updates via WARNING Download Center With the vehicle connected to the Internet The vehicle may not be driven when it is con- Functions for Internet-connected vehicles and updates for a number of the vehicle's systems nected to the workshop's networks and sys- infotainment can be updated via Download Cen- can be downloaded from the center display.
Page 562 MAINTENANCE AND SERVICE Vehicle status Note that only a download can be cancelled. An NOTE installation cannot be cancelled once it has The vehicle's general status can be displayed in Data downloading can affect other services begun. the center display along with the option to such as transfer data, e.g.
Page 563 5. Make sure your preferred is cor- • Scheduling service and repairs (p. 561) • Create a Volvo ID and register it to the vehi- rect. cle. • Sending vehicle information to the workshop Tap to write information to the 6.
Page 564 Navigating in the center display's views (p. 113) The appointment request contains information about your vehicle that helps the workshop plan • Volvo ID (p. 26) Car Status 1. Open the app from App view in for your visit. •...
Page 565 MAINTENANCE AND SERVICE Vehicle information can be accessed by any retailer if they are provided with your vehicle iden- tification number (VIN Vehicle information contents The most recently saved vehicle-related informa- tion will be sent (the last time the vehicle was turned on).
Page 566 Volvo recommends only using the jack jack is positioned on the designated points intended for your specific vehicle model. If a under the vehicle. jack other than that recommended by Volvo is used, follow the instructions included with the Leveling Control For vehicles with *: If the vehi- equipment.
Page 567 MAINTENANCE AND SERVICE The triangles in the plastic covering indicate where the jack attachment points/lifting points (red areas) are located. Related information • Removing a wheel (p. 528) • Jack* (p. 527) • Leveling control settings* (p. 420) * Option/accessory.
Page 568 The air conditioning system contains a fluores- Volvo recommends contacting an authorized cent tracer substance. Ultraviolet light is used to Volvo workshop for assistance replacing the search for leaks in the system. windshield. The correct type of replacement windshield must be used in order for the head-up Volvo recommends contacting an authorized display to function properly.
Page 569 Door and seat belt reminders (p. 51) NOTE If the warning symbol is illuminated or an audible warning signal sounds even though the hood is securely closed, consult a work- shop - an authorized Volvo workshop is rec- Hood not completely closed. ommended.
Page 570 Exercise caution when Always entrust engine washing to a workshop accessing the engine compartment and only – an authorized Volvo workshop is recom- touch what is required for normal maintenance. mended. If the engine is hot, there is a risk of fire.
Page 571 Volvo recommends entrusting oil changes to an authorized Volvo workshop. Volvo uses different systems to warn if the oil level is too low/high or the oil pressure is low. On engine variants with an oil pressure sensor, a...
Page 572 Service required , visit a workshop Status 2. Tap to display the oil level. – an authorized Volvo workshop is recommended. The oil level may be too high. Engines with an electronic oil level sensor do not have a dipstick.
Page 573 MAINTENANCE AND SERVICE Refilling coolant NOTE Coolant helps keep the combustion engine at If the conditions for measuring oil level are the right operating temperature. The heat trans- not properly fulfilled (time after engine shut- ferred from the engine to the coolant can be down, vehicle inclination, ambient tempera- used to warm the passenger compartment.
Page 574 For information on lights not mentioned in the Unscrew the expansion tank cap and fill Owner's Manual, contact a Volvo dealer or a • Never run the engine unless the cooling coolant as needed. The level should not certified Volvo service technician.
Page 575 MAINTENANCE AND SERVICE NOTE Bulbs for active curve lighting* contain traces of mercury and should therefore always be submitted to a certified Volvo service techni- cian. * Option/accessory.
Page 576 The battery terminals on the car's start battery in engine is running. the luggage/cargo area must not be used. • Make sure the cables to the start battery are correctly connected and the clamps are securely tightened. An authorized Volvo workshop is recommended.
Page 577 MAINTENANCE AND SERVICE CAUTION CAUTION Only a modern battery charger with controlled Failure to observe the following could cause charge voltage should be used to charge the the infotainment energy save mode to tempo- starter battery. The rapid charging function rarily stop working and/or a message in the should not be used as this could damage the driver's display regarding the state of charge...
Page 578 MAINTENANCE AND SERVICE NOTE WARNING Location If the starter battery becomes discharged too If the starter battery is disconnected, the func- tion for automatic opening and closing must many times, it will shorten its service life. be reset to function correctly. A reset is The service life of the starter battery is affec- required in order for the pinch protection to ted by several factors, such as driving condi-...
Page 579 353×175×190 mm (13.9×6.9×7.5 inches) Capacity (Ah) According to EN standard. Cold Cranking Amperes. Volvo recommends that batteries are replaced by an authorized Volvo workshop. CAUTION If replacing the battery, make sure you replace it with a battery of the same size, cold start capacity and type as the original battery (see the decal on the battery).
Page 580 Specifications for hybrid battery Type: Lithium-ion WARNING Power reserve: 10.4 kWh. Hybrid battery replacement may only be per- formed by a workshop – an authorized Volvo NOTE workshop is recommended. The capacity of the hybrid battery decreases Coolant with age and use, which could result in...
Page 581 Consult a workshop if you are uncertain of how to dispose of this type of waste ‒ an authorized Wear protective goggles. Volvo workshop is recommended. Related information Risk of explosion. • Start battery (p. 574) •...
Page 582 MAINTENANCE AND SERVICE Fuses and fuseboxes Replacing fuses authorized Volvo workshop to have the compo- nent checked. All electrical functions and components are pro- All electrical functions and components are pro- tected by a number of fuses in order to protect...
Page 583 MAINTENANCE AND SERVICE • Fuses in the engine compartment (p. 582) • Fuses under the glove compartment (p. 586)
Page 584 MAINTENANCE AND SERVICE Fuses in the engine compartment The fuses in the engine compartment help pro- tect electrical components such as engine and brake functions.
Page 585 1 for 12 V outlet in trunk/cargo hybrid battery High-voltage coolant heater compartment* control module Coolant pump for electric drive USB ports for iPad holders system – – An authorized Volvo workshop is recommended. * Option/accessory.
Page 586 MAINTENANCE AND SERVICE Function Ampere Function Ampere Function Ampere – – – – Transmission control module; gear selector control module – – – – Engine control module – – Fed when ignition is on: – – Engine control module; trans- –...
Page 587 MAINTENANCE AND SERVICE Function Ampere – – Engine control module Ignition coils; spark plugs – – – – Transmission oil pump control module Vacuum pump control module Transmission actuator – – – – – – LED (Light Emitting Diode) Related information •...
Page 588 MAINTENANCE AND SERVICE Fuses under the glove compartment Fuses under the glove compartment provide pro- tection for e.g. electrical outlets, displays and door modules.
Page 589 Media player Ceiling console display (seat Data link connector OBD-II Instrument panel belt reminder/front passenger side airbag indicator) Center display Center console buttons – – Climate system blower module Sun sensor (front) An authorized Volvo workshop is recommended. * Option/accessory.
Page 590 Fuses in the trunk/cargo com- Front passenger's seat heat- partment Control module for Internet- Coolant pump connected vehicle; Control – – module for Volvo On Call – Power driver's seat* – Active chassis control module* Infotainment control module – –...
Page 591 MAINTENANCE AND SERVICE Fuses in the trunk The fuses in the trunk protect electrical compo- nents such as the power seats*, airbags and seat belt tensioners. * Option/accessory.
Page 592 MAINTENANCE AND SERVICE The fuse box is located on the right-hand side. Fuse pliers are provided on the inside of the fuse There are also spaces for several extra fuses in the distribution box in the engine compart- box cover to assist in removing and inserting ment.
Page 593 (gasoline, certain engine vari- (left side) ants) Park Assist Camera* – – Power trunk release* – – All Wheel Drive (AWD) control Power front passenger seat* module* – – Door module right side, front An authorized Volvo workshop is recommended. * Option/accessory.
Page 594 MAINTENANCE AND SERVICE Function Ampere Heated rear seat (right side)* – – Related information • Fuses and fuseboxes (p. 580) • Replacing fuses (p. 580) * Option/accessory.
Page 595 Cleaning the center display (p. 593) Only use cleaning agents and car care products Marks, stains, finger smudges etc. on the center recommended by Volvo. Clean regularly and display may affect its performance and readabil- • Cleaning fabric upholstery and ceiling liner treat stains immediately for best results.
Page 596 Never use strong stain removers. For difficult CAUTION cleaning conditions, a special cleaning agent can When cleaning the center display, apply only be purchased at a Volvo retailer. light pressure to the screen. Pressing too Related information hard could damage the screen.
Page 597 Use a vacuum to Never scrape or rub a stain, as this could damage ble for purchase at Volvo retailers. Make sure the remove dust and dirt. the upholstery or ceiling liner. Never use strong belt is dry before it is retracted.
Page 598 Leather upholstery* floor. Make sure the floor mat does not Volvo's leather upholstery is treated to protect its impede the movement of the brake pedal original appearance. Over time, sunlight, grease, or accelerator pedal in any way, as this dirt, etc.
Page 599 Cleaning fabric upholstery and ceiling liner leather steering wheel with a plastic protector. (p. 595) 4. Dry the stain using a soft towel and let the Volvo Leather Care Kit 951 0251 and Leather leather dry completely. • Cleaning the seat belt (p. 595)
Page 600 A lightly dampened microfiber cloth is recom- Related information mended for cleaning interior details and surfaces. • Cleaning the exterior (p. 598) These cloths are available for purchase at Volvo retailers. • Polishing and waxing (p. 599) Never scrape or rub a stain. Never use strong •...
Page 601 Only use paintwork treatments recommended This could cause the detergent or wax to dry vehicle paint. by Volvo. Other treatments, such as preserva- out and become abrasive. • Use polish first and then liquid or paste wax.
Page 602 MAINTENANCE AND SERVICE • Wash using a sponge, car washing detergent • Cleaning the wiper blades (p. 602) NOTE and plenty of lukewarm water. • Cleaning exterior plastic, rubber and trim Exterior lighting such as headlights and tail- • Clean the wiper blades with lukewarm soap components (p.
Page 603 Related information damaged. areas of the vehicle. For best results, Volvo rec- • Cleaning the exterior (p. 598) 2. To help prevent damage from the auto-...
Page 604 MAINTENANCE AND SERVICE High-pressure washing Cleaning the wiper blades • Cleaning rims (p. 604) The vehicle should be washed as soon as it The vehicle should be washed as soon as it • Corrosion protection (p. 604) becomes dirty. This makes the vehicle easier to becomes dirty.
Page 605 Exterior plastic, rubber and trim components Related information A special cleaning agent available from Volvo Components that should be washed with a cleaning • Cleaning the exterior (p. 598) product with a pH value between 3.5 and 11.5.
Page 606 In the chassis, exposed components of the wheel Only use rim cleaning products recommended by suspension are made of corrosion-resistant cast Volvo. aluminum. Strong rim cleaning agents could damage the surface and stain the chromed aluminum rims.
Page 607 MAINTENANCE AND SERVICE Paintwork Touching up minor paint damage If the damage has not reached all the way down to the metal, then touch-up paint can be applied The paintwork consists of multiple layers. It is an The paintwork is an important part of the vehi- immediately after the surface has been cleaned.
Page 608 If there is a longer scratch, follow the same pro- cedure as above, but first mask off the surround- ing area to protect the undamaged paint. Touch-up pens/sticks and spray paint are availa- ble at Volvo retailers. NOTE Sample color code (1): Canadian models. Vehicle paint code...
Page 609 MAINTENANCE AND SERVICE Replacing windshield wiper blades Related information 4. Slide in the new wiper blade until it clicks into place. • Using the rain sensor (p. 175) The wiper blades help remove water from the windshield. Along with the washer fluid, they 5.
Page 610 MAINTENANCE AND SERVICE Windshield wipers in the service Activating/deactivating service position Related information position The service position can be activated/deactivated • Using the rain sensor (p. 175) when the vehicle is stationary and the windshield The windshield wiper blades must be in the serv- •...
Page 611 CAUTION anti-freeze should be used in very cold weather (below-freezing temperatures). Use Volvo's original washer fluid or an equiva- lent fluid with the recommended pH value between 6 and 8, diluted as recommended, e.g. in a 1:1 solution with pH-neutral water.
Page 613 SPECIFICATIONS...
Page 614 SPECIFICATIONS Type designations The decals in the vehicle contain information such as chassis number, type designation, color code, etc. Location of decals The illustration is general and details may vary depending on market and model.
Page 615 Vehicle Emission Control Information. US Vehicle Identification Number (VIN). The Federal Motor Vehicle Safety Standards models. Your Volvo is designed to meet all appli- (FMVSS) specifications (USA) and Ministry of VIN plate is located on the top left surface of the Transport (CMVSS) standards (Canada).
Page 616 SPECIFICATIONS Related information • Air conditioning specifications (p. 622) Engine oil. This label contains the recom- mended engine oil specifications. Decal A/C. Refrigerant R134a. NOTE The decals shown in the Owner's Manual do not claim to be exact reproductions of those found in the vehicle.
Page 617 SPECIFICATIONS Dimensions The vehicle's length, height, etc. are shown in the table. Dimensions inches Dimensions inches Dimensions inches Load height 19,1 Load width, floor 34,1 Ground clearance Wheel track, front Width 1850 72.8 Wheelbase 2872 113,1 1603 63.1 1600 63,0 Length 4761 187.4...
Page 618 SPECIFICATIONS Dimensions inches Width incl. rearview 2040 80.3 mirrors Width incl. folded rear- 1916 75.4 view mirrors At curb weight + 2 people. (Varies slightly depending on tire dimensions, chassis, etc.) Including roof antenna, at curb weight. Vehicles with 17-inch wheels. Vehicles with 18/19-inch wheels.
Page 619 SPECIFICATIONS Weights The following table lists important weight data for your vehicle. Category Canada (lbs) (kg) Gross vehicle weight 5490 2490 Capacity weight Permissible axle weights, front 2775 1260 Permissible axle weights, rear 2775 1260 Curb weight 3670–4480 1660–2020 Max. roof load CAUTION •...
Page 620 SPECIFICATIONS Towing capacity and tongue weight Towing capacity and tongue weight are shown in the tables below. Category Canada (lbs) (kg) Without brakes: 1650 Max. trailer weights With brakes: 2000 Max. tongue weight CAUTION • The maximum trailer weights listed are only applicable for altitudes up to 3280 ft (1,000 m) above sea level.
Page 621 SPECIFICATIONS Engine specifications Twin Engine vehicles are powered by both a NOTE gasoline engine and an electric motor (ERAD – Engine specifications (output, etc.) for each Not all engines are available on all markets. Electric Rear Axle Drive). engine variant are shown in the table below. The specifications for Special Edition vehicles may vary.
Page 622 Volvo recommends: Viscosity chart Extreme driving conditions General Volvo's VCC RBS0-2AE/SAE 0W20 oil is recom- mended for extreme conditions. See the Service and warranty booklet for infor- mation about oil change intervals. Oil volume The oil volume for the engine is:...
Page 623 However, it may need force from e.g. pressure on the brake pedal via a not salt water, etc.). Consult a Volvo retailer if to be changed if the vehicle is driven frequently master brake cylinder to one or more slave cylin- you have any questions.
Page 624 SPECIFICATIONS Fuel tank volume Air conditioning specifications WARNING The fuel tank's refillable volume is shown in the The climate system in the vehicle uses a freon- The air conditioning system contains the table below. free R134a refrigerant. For information regarding refrigerant R134a under pressure.
Page 625 The following tire pressures are recommended by Volvo for your vehicle. Refer to the tire infla- Tire dimensions Cold tire pressure for up to five persons...
Page 627 INDEX INDEX Adjusting the steering wheel Antenna 1, 2, 3 ... location Adjustment of headlight pattern Apple CarPlay 479, 481 Airbag activation/deactivation Approach lighting driver's side Apps passenger side 53, 56 Assistance at risk of collision Air bag, see Airbag activating/deactivating Air conditioning at risk of run-off...
Page 628 INDEX Automatic transmission Bluetooth kickdown connect connecting vehicle to Internet Camera sensor Trailer phone see Camera settings Auxiliary heater Camera unit Book service and repair limitations maintenance and cleaning Booster cushions Capacity weight 540, 617 Brake assist after collision Cargo compartment Backrest attachment points Brake energy...
Page 629 INDEX symbols in status bar Child safety Climate views auto-regulation Child safety locks blower control Central locking Circuit breaker parking Change of owner City Safety perceived temperature Changing a wheel braking for oncoming vehicles Sensors crossing traffic temperature control 215, 216 Charge delayed evasive maneuver voice control...
Page 630 INDEX Connecting vehicle to Internet Curb weight limitations No connection or poor connection Set time interval Customer Privacy Policy via a mobile device (WiFi) ® DivX CZIP (Clean Zone Interior Package) via cellular phone (Bluetooth) Door mirrors via vehicle's modem compass 443, 444 Connect phone...
Page 631 INDEX Drive systems Engine automatic start and stop of combustion Driving engine Federal Clean Air Act cooling system overheating with a trailer Ferry transport start Driving economy Flooded road turn off Driving through standing water Fluids, volumes 609, 622 Engine braking 397, 406 driving with a trailer Fluids and oils...
Page 632 INDEX Fuel Gross vehicle weight Heating Travel Link service Seats 208, 209 steering wheel Fuel filling windows Fuel gauge high beams 154, 155 Fuel requirements 428, 429 Handbrake High engine temperature Fuel tank Hand wash Hill Start Assist volume Hard disk Hill Start Assist (HSA) Fuse box space...
Page 633 INDEX Instrument cluster settings IAQS (Interior Air Quality System) Jack Instrument illumination IC (Inflatable Curtain) Jump-start Instrument lighting ID, Volvo Instrument panel Identification number App menu 101, 102 hybrid-related symbols and messages 387 Ignition mode 395, 396 messages Immobilizer settings...
Page 634 INDEX limitations high beams 154, 155 Long-term storage see Lane Keeping Aid home safe lighting Low battery charge level select assistance option in passenger compartment start battery steering assistance low beams Low beams Symbols and messages 341, 343 position lights Low oil level rear fog light Language...
Page 635 INDEX Pilot Assist in cellular phone pulling out of a parking space stability and traction control system in the center display 17, 18 Symbols and messages Messages in display 103, 138 parking handling 104, 138 on hills saved 105, 139 Parking Assist Mileage activating/deactivating...
Page 636 INDEX Passing assistance pinch protection Adaptive Cruise Control resetting Pilot Assist Radar sensor PIN code starting with Pilot Assist see Radar sensor Private locking start with Adaptive Cruise Control Radar unit Polishing personal information (Customer Privacy limitations Position lights Policy) maintenance and cleaning Power type approval...
Page 637 INDEX head restraint connecting to driver profile heating detachable key blade loss Safety Rearview/door mirrors Range pregnancy adjusting door mirrors dimming Remote updates Safety belt, see Seat belt heating Reporting safety defects Safety defects, reporting interior Resetting door mirrors Safety mode Rearview mirror starting/moving Resetting settings...
Page 638 INDEX Security code Ski hatch Starting the engine after a collision Sensors Slippery conditions air quality Start the vehicle Slippery road conditions Camera unit Steering assistance at risk of collision Snow chains climate Steering power level, see Steering wheel Software updates Radar unit resistance Sound experience...
Page 639 INDEX Sun visor Terms and conditions Towing eyelet mirror lighting services TPMS - Tire Pressure Monitoring System users Switching target vehicles Traction control with Adaptive Cruise Control Tire dimensions Traffic information with Pilot Assist when changing wheels Trailer Symbols Tires driving with a trailer dynamic direction of rotation...
Page 640 546, 548 settings socket for connecting media Lighting VOL mark Trunk lid Volvo ID emergency opening create and register locking/unlocking 233, 247 unlocking from inside Vehicle care 598, 599, 601, 602, 603, 604 leather upholstery...
Page 641 INDEX starter battery not charging Wi-Fi WARNING connecting vehicle to Internet delete network Warning sound sharing Internet connection, tethering, parking brake hotspot warning symbols technology and security Warning symbols Windows and glass safety Windshield Warranties projected image 140, 142 Washer Windshield washing Headlights Windshield wipers...
Page 642 INDEX...
Page 644 WARNING California Proposition 65 Operating, servicing and maintaining a passen- ger vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To mini- mize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle in a well ventilated area and wear...
Page 645 TP 28031 (English - USA & Canada), AT 1846, MY19, Copyright © 2000-2018 Volvo Car Corporation...
