Sport Camera – V35
User Manual
CAUTIONS
- This is a ultra HD action camera, It is normal for the housing to exert heat under use.
- Don' t expose the product directly to high temperatures over 45°C.
- Please properly protect well the lens and screen of camera after using.
- Keep it safe from falling and dropping.
- Keep it distance from any strong magnetic interference objects like electrical machine to avoid
strong radio waves that might be damaging the product and affect the sound or image quality.
- In case of overheating, unwanted smoke from the device, unplug it immediately from the power
outlet to prevent hazardous fire.
- Keep it safety from children while on charging.
- Stored the device in a cool, dry and dust free location.
- Do not modify the camera it in any way,if the camera has been detached,the warranty will be
void.
THE BASIC
1 - Lens
2 - 1.4 inch Front Screen

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V35 and is the answer not in the manual?

Questions and answers

Related Manuals for tekkiwear V35

Summary of Contents for tekkiwear V35

  • Page 1 Sport Camera – V35 User Manual CAUTIONS - This is a ultra HD action camera, It is normal for the housing to exert heat under use. - Don' t expose the product directly to high temperatures over 45°C. - Please properly protect well the lens and screen of camera after using.

  • Page 2: Getting Started

    3 - 2.0 inch Screen / Beauty Button 4 - Charging Indicator 5 - Working Indicator 6 - Micro USB Port 7 - HD Output Port 8 - Micro SD Card Slot 9 - DC2.5 External microphone 10 - UP / Wi-Fi / Zoom in Button 11 - Down / Remote / Zoom out Button 12 - Speaker 13 - Mode / Power Button...

  • Page 3: Powering On/Off

    NOTES: - Please format the micro SD, micro SDHC and micro SDXC memory card on the camera before using. - Please insert the memory card in correct way if not , the card slot maybe damage, by the wrong way. - To keep your micro SD card in good condition, reformat it on a regular basis.

  • Page 4: Osd Description

    3) Turn on the camera and verify the camera is in Video Mode: - Swipe up quickly on the touch screen to switch fast to the Video Setting Mode, to exit, tap the icon 'X' on the top right corner of the screen , as shown below: - Swipe down quickly on the touch screen to switch fast to the Vid.

  • Page 5: Video Setting

    Playback & Setting Mode will cycle in following order: VIDEO SETTING Button Operation: Verify the camera is in Video Setting Mode, press the Shutter button to enter the Video Settings menu. Then press the UP or Down button repatedly to cycle through the options, and press the Shutter button to select the desired option To exit, press the Mode button again.

  • Page 6: Slow Motion

    This camera is equipped EIS function with 6-axis gyroscope to detect motion changes. When the camera tilts, moves, shakes, the sensor use image cross-border compensation algorithm to compensate the change and produce stable videos, especially in activities with relatively small angle (about 6 degrees) but fast motion including cycling, motorcycling, and hand-held uses.

  • Page 7: Photo Setting

    - If you select Slow Motion, EIS, Time-Lapse Video and Fast Motion will not be available automatically. Fast Motion Off / 2x / 4x / 6x / 10x /15x Action that appears to move faster than normal on the screen, accomplish by filming the action at less than normal speed in the camera and then projecting it at normal speed.
  • Page 8 Photo Settings: - Photo Resolution: 20M / 14M / 10M / 8M Default setting is 12M - ISO: Auto / 100 / 200 / 400 / 800 / 1600 / 3200 Default setting is Auto. ISO determines the camera' s sensitivity to light, and creates a trade-off between brightness and resulting image noise.

  • Page 9: System Settings

    - Date Stamp: Off / Date / Date & Time If you turn on Stamp, this camera adds stamp to the photos you take. If you tum off Stamp, this camera will not add stamp to the photos you take. SYSTEM SETTING Button Operation: Verify the camera is in System Setting Mode, press the Shutter button to enter the System...
  • Page 10 - Snorkeling mode provides color correction while capturing footage in blue water or clear freshwater at depths of 5 to 33ft (1.5 to 10m) - Snow mode can suppress overexposure in high-brightness environments such much snow field or beach. Effect: standart / black and white / natural / negative / retro. Default setting is Normal.

  • Page 11: Video Mode

    the mode button to enter system setting, then press down button several times to enter Format > Format Card? > YES. - Reset Yes/No This option resets all settings to their default values. - Version : Mod. / Version / Number / Dated You can check the model, software version and updated time of your camera.

  • Page 12: Adjusting The Zoom Level

    PHOTO To capture photo, verify the camera is in desired Photo Setting option and set the desired photo resolution, if the photo icon in your camera' s LCD is not showing, press the Mode Button repeatly to the Photo Setting menu and select the desird option such as Time-lapse Photo / Burst Photo / Delay Timer / Long Exposure, etc.

  • Page 13: Playing Back On Tv

    PLAYBACK PLAYING BACK ON CAME. 1 . Enter Video or Photo playback mode. If the SD card contains a lot of content, it might take a minute for it to Ioad. 2 . Press the Up / Down Button to scroll through the video or photo files. 3 .

  • Page 14: Battery Storage And Handling

    2. Press the Up or Down Button to locate the file you want to delete. 3. Press and hold the Up Button for seconds. The screen shows " Delete File" . 4. Press the Up or Down Button to locate the desired option: "Single File- or "All Files" then Press Shutter Button to select the desired option.
  • Page 15 Notes: - Charging time: 4-hours for 5V 1A power supply - Please make sure the camera is shuttled down while charging. •Remove the battery before using as a dash camera and use 5V/1A brand-name car charger. • MAXIMIZING BATTERY LIFE If the battery reaches 0% while recording, the camera saves the file and powers off.
  • Page 16 2. Turn on the camera, then press Up Button for seconds to turn on Wi-Fi; the WiFi name and password information will appear on the display, Press Up Button for seconds again if you want to turn off Wi-Fi 3. Turn on Wi-Fi Setting of your mobile device, connect to the Wi-Fi SSID "iSmart DV" 4.
  • Page 17 - When the phone and camera connect through Wi-Fi, the power of the camera will increase. The camera's temperature will rise rapidly, and the consumption of camera batteries will also increase. This is a normal phenomenon. - Since many kinds of phones in the market, and the phone system is constantly updated, iSmart DV app needs time to synchronize timely updates, if iSmart DV app can not be compatible to your phone, please tell us your phone' s model and system version information, we will in the first time synchronize your phone.

  • Page 18: Waterproof Case

    Step 1: Use a 1.84 mm tip screwdriver (not included) to remove the 4 screws on the back cover, allowing you to open it. Step 2: Remove another 4 screws on PCB board. Step 3: Lift the PCB board and slide out the battery, as shown in the picture. Step 4: Instal the new battery, keeping the + pole facing up.

  • Page 19: Mounting Your Camera

    1) Please close the back door of the case. 2) Pull down the latch and lock it to the back door. 3) Press down the buckle. Tips: 1. Please tear the protective films on the waterproof case lens before shoot/record; 2.
  • Page 20 Attach your camera to helmets, gear and equipment. The following assembly methods are for reference only! Notes: - Our standard accessories are the basic version. If you need different types of accessories, you need to purchase them separately. - With different types of accessories, the camera can be used in different occasions. Please purchase different types of accessories kit according to actual needs.
