McElroy DataLogger DL3 Quick Reference Card

DataLogger DL3
®
Quick Reference Card
Connect Pressure Transducer to Fusion Machine with a proper
hydraulic quick disconnect.
Multifunction Switch
1. Turns on the DataLogger ® if it is off (both LED's off). Once
turned on, the DataLogger ® will remain on for 2 minutes
if there is no communication activity. Otherwise, the
DataLogger ® will stay on as long as there is communication
between it and a Recon. Every time this switch is pressed, it
adds another 2 minutes to the on time.
2. Takes temperature reading if the DataLogger
data logging mode. For as long as this switch is held, the
temperature will be displayed on the Recon screen.
3. Stops logging if the DataLogger is in data logging mode.
®
This switch must be held for longer than 3 seconds to turn off
logging.
Note: The DataLogger
® turns itself off, therefore, it does not have an
OFF switch.
LED's
Solid Orange LED on DataLogger® indicates it is initializing.
Flashing Green LED on the DataLogger® indicates it is operating
normally.
Flashing Red LED on the DataLogger® indicates it is logging data.
Holding the DataLogger® button for 3 seconds stops logging.
Wired
Flashing Blue LED indicates Wired DataLogger is communicating
with Recon.
Wireless
Flashing Blue LED indicates Bluetooth® radio is in standby mode.
Solid Blue LED indicates DataLogger® is communicating with
Recon.
Recon
Turn on the Recon by pressing the Power button. Turn on the
DataLogger® by pushing the multifunction switch.
Turn off the Recon by pressing the Power button if it is on. Note:
it is best to disconnect (or stop communications) between the Recon
and DataLogger® before turning off the Recon. The DataLogger®
cannot be turned off, especially while logging data. The
is on but not in
®
DataLogger® will automatically turn itself off if not logging data or 2
minutes elapsed since the Recon last communicated with it.
Reset: To reset a Recon, hold down the Power button for 5 seconds
Date and Time: To set date and time: Tap Start > Settings. Tap
the System tab. Tap Clock & Alarms. Select the respective time
and date field by tapping on it and adjust the values accordingly.
For example to change the hour field, tap on it and then use the up
and down arrow keys to adjust the number up or down. [For more
details, refer to the Setting Time and Date section in the operator's
manual to check and set the correct date and time. It is very
important to set the correct time and date because joint reports
are time stamped using the Recon's clock.]
