Table of Contents

Need help?

Do you have a question about the Asahi/America DataLogger 7 and is the answer not in the manual?

Questions and answers

Summary of Contents for McElroy Asahi/America DataLogger 7

Page 1 ® DataLogger Asahi/America, Inc. ProWeld Equipment ® Powered by Operator’s DLP0857591 Manual Rev 10/20 Original Language: English...
Page 3 If a tool, procedure, work method or operating technique that is not specifically recommended by McElroy is used, you must satisfy yourself that it is safe for you and for others. You should also ensure that the product will not be damaged or be made unsafe by the operation, maintenance or repair procedures that you choose.
Page 4: Table Of Contents
TABLE OF CONTENTS FOREWORD Literature Information ....................................... 1 - 1 Safety ........................................... 1 - 1 Operation........................................... 1 - 1 Patent Information ......................................1 - 1 Replacement Literature ....................................1 - 1 Trademarks ........................................1 - 1 Graphics ..........................................1 - 1 ASTM Standard........................................
Page 5 Replacement Parts and Accessories ................................6 - 1 SPECIFICATIONS Specifications ........................................7 - 1 NOTES Notes ..........................................8 - 1...
Page 6: Literature Information
Operation For more than 30 years, McElroy has been the only pipe fusion machine manufacturer to continuously offer The operation section is a reference for the new advanced training. Course offerings are meant to operator and a refresher for the experienced operator.
Page 7 Equipment held longer than six months without return is held at the renter's risk. Used Equipment Warranty Purchase of refurbished/used equipment carries a 90-day warranty. New Equipment Warranty Purchase of new Asahi/America versions of McElroy equipment carries a 5-year limited warranty. Details can be found here: https://www.mcelroy.com/warranty.htm TX05339-04-18 DataLogger...
Page 8: Safety
Replace any safety message that is damaged, or missing. If a safety message is attached to a part that is replaced, install a safety message on the replacement part. New safety messages can be ordered from McElroy using the part number listed. General Safety Units with Hydraulics Safety is important.
Page 9: Heater Is Hot
Heater is Hot The heater is hot and will burn clothing and skin. Keep the heater in its insulated heater stand or blanket when not in use, and use care when heating the pipe. NOTICE: Use only a clean non-synthetic cloth such as a cotton cloth to clean the heater plates.
Page 10: General Information
GENERAL INFORMATION DataLogger® 7 Hardware Components Front and Back Features Notification LEDs Rear Facing Camera Lens, 16 MP 10 Camera Flash Touchscreen and Display 11 Speaker Protective Over-molded Bumper (all four edges) 12 Battery Door Lock Microphone (one on each side) 13 Battery Compartment, SIM and SD Card Slots Ambient Light Sensor 14 External Device Attachment Point (1 of 3 on the back)
Page 11: Installing The Sim Card And Sd Card (Optional)
You can now use your device. The tablet will include a formatted and installed SD card from McElroy. If a new SD card is installed, you will need to format the card to use with the device. 2. Remove the compartment door (B). Remove the battery.
Page 12: Operation
OPERATION Waking Up DataLogger® App Your device sleeps after a period of inactivity. Connect Pressure To wake up, press the power button and, at the lock screen, Transducer to Fusion drag the lock icon to the other side of the screen. Machine Shutting Down To shut down, press and hold the power button until a menu...
Page 13: Select Software Language
Log into a DataLogger® Vault™ account using a username and password. If you do not have a Vault account, open an internet browser on this tablet and go to vault.mcelroy.com. Create an account and return to the DataLogger 7 App and enter the username and password.
Page 14: Troubleshooting
TROUBLESHOOTING Perform a Hard Reset 1. If the tablet has froze and won’t respond, hold the power key down for 2 to 3 seconds to see if the menu with the “Power off” option appears, then select that operation. If the menu doesn’t appear, hold the power key down for 10 seconds.
Page 15: Maintenance
Calibration Pressure sender must be sent to McElroy or Authorized Service Center every year for certification. A backup pressure sender may be kept on hand to minimize down time.
Page 16 SPECIFICATIONS Specifications DataLogger 7 Specs Model: DLP0857716 Supported Standards: ASTM F3124, ASTM F2620, ISO 21307, GIS/PL2-3-07, Profuse, DS/INF 70-2 PE:HD, WIS 4-32-08, DVS 2207-1 PE-HD, DVS 2207-11 PP, DS/INF 70-2 PP, PPI TR-33, additional standards upon request. See device for latest list of supported standards. Weight: 1.5 - 2.0 lbs.
Page 17 NOTES Notes DataLogger 8 - 1 Notes ®...
