Summary of Contents for Crown Micro Xavier-1200VA-MPPT
- Page 1 USER MANUAL Xavier-1200VA-MPPT /Xavier-2400VA-MPPT MPPT SOLAR INVERTER V. 1.0...
-
Page 2: Table Of Contents
Table of Contents 1. Introduction ..............................1 2. Important Safety Warning (SAVE THESE INSTRUCTIONS) ..............1 3. Product Overview ............................3 4. Installation ..............................3 5. Operation ............................... 6 6. Trouble Shooting ............................15 7. Specifications ............................. 16... -
Page 3: Introduction
1. Introduction Thank you for purchasing this solar inverter. This simple solar inverter is designed to power your home appliances or precious 3C electronics. It also can handle motor-type loads with high surge power such as vacuums, small freezers, or drills. With built-in MPPT solar charger, it can convert solar power to battery power and provide continuous power to connected equipment during night time. - Page 4 CAUTION! Have plenty of fresh water and soap nearby in case battery acid contacts skin, clothing, or eyes. CAUTION! NEVER smoke or allow a spark or flame in vicinity of a battery. CAUTION! If a remote or automatic generator start system is used, disable the automatic starting circuit or disconnect the generator to prevent accident during servicing.
-
Page 5: Product Overview
3. Product Overview Power switch Status indicator Charging indicator Fault indicator Function buttons (Please see the Operation section for the details) LCD display AC input AC output terminals Input circuit breaker 10. External battery connectors 11. Solar connector 12. DC fuse 4. - Page 6 1) Single battery connection: When using a single battery, its voltage must be equal to the Nominal DC Voltage of the unit Breaker 2) Multiple batteries in series connection(Refer to Fig. 3): All batteries must be equal in voltage and amp hour capacity.
- Page 7 PV module numbers in Parallel: Total PV module numbers / Maximum PV module numbers in series Take Xavier-1200VA-MPPT inverter as an example to select proper PV modules. After considering Voc of PV module not exceeds 80Vdc and max. Vmpp of PV module close to 15Vdc or within 15Vdc ~ 18Vdc, we can choose PV module with below specification.
-
Page 8: Operation
Connect to the Load Remove insulation sleeve 10mm for three conductors. And shorten phase L and neutral conductor N 3 mm. Insert AC output wires according to polarities indicated on terminal block and tighten the terminal screws. Be sure to connect PE protective conductor ( ) first. - Page 9 Fault: Lighting with fault code Output Information Indicates the output voltage, output frequency, load percent, load in VA, load in Watt, main board firmware version and SCC firmware version Battery Information Indicates the Battery level by 0-24%, 25-49%, 50-74% and 75-100% in battery mode, charging status in line mode.
- Page 10 13.0V to 14.6V for 12Vdc model and increment of each click is 0.1V. Setting range is from 26.0V to 29.2V for 24Vdc model and increment of each click is 0.2V. Xavier-1200VA-MPPT default setting: 9.9V Low DC cut-off voltage...
- Page 11 Xavier-2400VA-MPPT default setting: 19.8V Setting range is from 9.9V to 12.0V for Xavier-1200VA-MPPT model and increment of each click is 0.1V Setting range is from 19.8V to 24.0V for Xavier-2400VA-MPPT model and increment of each click is 0.2V. Low DC cut-off voltage will be fixed to setting value no matter what percentage of load is connected.
- Page 12 22.0V 22.5V 23.0V (default) 23.5V 24.0V 24.5V 25.0V 25.5V Available options in Xavier-1200VA-MPPT model: Battery fully 12.0V 12.3V charged 12.5V 12.8V 13.0V 13.3V 13.5V (default) 13.8V 14.0V Setting voltage point back to battery mode when selecting “SBU Available options in Xavier-2400VA-MPPT model: priority”...
- Page 13 Return to default If selected, no matter how users switch display screen, display screen it will automatically return to default display screen (default) (Input voltage /output voltage) after no button is Auto return to pressed for 1 minute. default display screen Stay at latest screen If selected, the display screen will stay at latest screen...
- Page 14 Display Setting The LCD display information will be switched in turns by pressing “SCROLL” key. The selectable information is switched as below order: input voltage, input frequency, PV voltage, charging current, battery voltage, output voltage, output frequency, load percentage, load in Watt, load in VA, load in Watt, DC discharging current, main CPU Version and second CPU Version.
- Page 15 Secondary CPU version 00003.03 Battery voltage=25.5V Secondary CPU Battery voltage version checking Output frequency=50Hz Output frequency Operating Mode Description Operation mode Description LCD display Charging by utility and PV energy. Standby mode Utility input bypass to Charging by utility. Note: output, charger *Standby mode: The inverter is available, LCD backlight...
- Page 16 Operation mode Description LCD display Power from battery and PV energy. The unit will provide Battery Mode output power from Power from battery only. battery and PV power. Fault Reference Code Fault Code Fault Event Icon on Fault Code Fault Event Icon on Output short circuit Main relay stick...
-
Page 17: Trouble Shooting
6. Trouble Shooting Use the table below to solve minor problems. Problem LCD/LED/Buzzer Explanation / Possible cause What to do Charge the unit at least 8 Battery voltage is too low. hours. When power fails, Battery low alarm the backup time is Battery capacity is not full even Check the date code of the issue quickly. -
Page 18: Specifications
7. Specifications MODEL Xavier-1200VA-MPPT Xavier-2400VA-MPPT CAPACITY 1200VA/900W 2400VA/1600W INPUT Voltage 230 VAC Voltage Range 90-280 VAC Nominal Operating Frequency 50/60Hz Maximum Input Current OUTPUT Nominal Output Voltage 230 VAC Voltage Regulation (Batt. Mode) +/-10% Output Frequency Range 50/60Hz Nominal Output Current 5.2A...
