Attention
Installer:
Give this manual to
the homeowner.
Important Information to
keep for Service
Model # ___________________
Serial # ____________________
Install Date ________________
The Hayward HeatPro Heat Pump is listed by ETL as complying with the latest edition of the "UL Standard for Safety for
Heating and Cooling Equipment", UL1995 and CSA C22.2 No. 236.
All Hayward HeatPro Heat Pumps must be installed in accordance with all applicable National and Local codes. In the absence
of local codes, refer to the latest edition of the National Electric Code (NEC) in the United States and the Canadian Electric
Code (CEC) in Canada
Basic safety precautions should always be followed, including the following: Failure to follow instructions can cause severe
injury and/or death.
This is the safety-alert symbol. When you see this symbol on your equipment or in this manual, look for one of the
following signal words and be alert to the potential for personal injury.
WARNING
warns about hazards that could cause serious personal injury, death or major property damage and if
ignored presents a potential hazard.
CAUTION
warns about hazards that will or can cause minor or moderate personal injury and/or property damage
and if ignored presents a potential hazard. It can also make consumers aware of actions that are unpredictable and unsafe.
The NOTICE label indicates special instructions that are important but not related to hazards.
Models: HP20654T, HP20654BT, HP20854T,
HP20854BT and HP21104T
OWNERS OPERATION & PARTS MANUAL
SAVE THIS OWNERS MANUAL
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
Pomona, CA Clemmons, NC Nashville, TN
HP13023772 Rev: E
Tel: 908.351.5400
www.haywardpool.com
Advertisement
Table of Contents
Related Manuals for Hayward Pool Products HeatPro HP20654BT
Summary of Contents for Hayward Pool Products HeatPro HP20654BT
- Page 1 HP13023772 Rev: E Models: HP20654T, HP20654BT, HP20854T, HP20854BT and HP21104T OWNERS OPERATION & PARTS MANUAL Attention Installer: Give this manual to the homeowner. Important Information to keep for Service Model # ___________________ Serial # ____________________ Install Date ________________ SAVE THIS OWNERS MANUAL The Hayward HeatPro Heat Pump is listed by ETL as complying with the latest edition of the “UL Standard for Safety for Heating and Cooling Equipment”, UL1995 and CSA C22.2 No.
- Page 2 Page 2 of 22 HP13023772 Rev: E HEATPRO HEAT PUMP IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS IN THIS OWNER’S MANUAL AND ON EQUIPMENT. Before servicing this electrical equipment, turn power supply OFF. KEEP ALL LABELS IN GOOD CONDITION AND REPLACE IF MISSING OR DAMAGED. WARNING –...
- Page 3 Page 3 of 22 HP13023772 Rev: E HEATPRO HEAT PUMP Dual suction fittings shall not be located on seating areas or on the backrest for such seating areas. The maximum system flow rate shall not exceed the flow rating of any listed (per current revision of ASME/ANSI A112.19.8) suction outlet cover installed.
-
Page 4: General Information
For weekend use, it is more economical to maintain the pool water temperature at the desired temperature. Hayward Pool Products offers the following recommendations to help conserve energy and minimize the cost of operating the heat pump. - Page 5 Page 5 of 22 HP13023772 Rev: E HEATPRO HEAT PUMP The following table lists the minutes it will take to heat a pool 1°F, based on gallons. This is an approximation only. Model HP20654T & HP20654BT HP20854T & HP20854BT HP21104T Pool Size in Gallons 80°F...
-
Page 6: How A Heat Pump Works
Page 6 of 22 HP13023772 Rev: E HEATPRO HEAT PUMP How a Heat Pump Works WATER HEAT FROM COLD WATER WATER HEAT EXCHANGER (CONDENSER) COMPRESSOR AIR COIL (EVAPORATOR) The heat pump takes heat from the environment and uses it to heat the pool water. During heat pump operation, high temperature, high-pressure sub cooled liquid Refrigerant (A) is throttled by Metering Device (TXV) and turned into low temperature, low-pressure saturated liquid (B). - Page 7 Page 7 of 22 HP13023772 Rev: E HEATPRO HEAT PUMP High / Low Refrigerant Pressure Switches • The high-pressure switch senses the refrigerant pressure in the sealed refrigeration system and turns the heat pump off if the operating pressure exceeds the acceptable range. The heat pump will automatically reset the switch after the system pressure returns to normal operating conditions.
- Page 8 Page 8 of 22 HP13023772 Rev: E HEATPRO HEAT PUMP Clearance A minimum of 2 feet (.6 m) of clearance from walls, shrubbery, equipment, etc. is required around the entire heat pump. This allows for ample air intake. A minimum of 6 feet (2 m) of clearance above the heat pump is required to prevent re-circulation of air.
- Page 9 Page 9 of 22 HP13023772 Rev: E HEATPRO HEAT PUMP NOTICE Make sure there are no sprinkler heads near the heat pump that will spray on or into the unit. Sprinkler damage is not covered under the warranty agreement. Make sure that sprinklers are placed at a sufficient distance away, so that normal wind will not carry the mist to the heat pump.
-
Page 10: Start-Up Procedures
Page 10 of 22 HP13023772 Rev: E HEATPRO HEAT PUMP Operating the HeatPro Heat Pump NOTICE- Do not use this heat pump if any part has been flooded or submerged in water. Immediately call a qualified technician to inspect and replace any damaged part of the heat pump. Control System components must be replaced if submerged in water. - Page 11 Page 11 of 22 HP13023772 Rev: E HEATPRO HEAT PUMP Becoming Familiar with HeatPro Heat Pump Controls Up Arrow Button Display Window Down Arrow Button Spa Button (Optional) Pool Button Run Light Heat Pump Control Panel Display Window (All Models) When power is supplied to the unit, the display will either show temperature (in degrees F or C), diagnostic code (such as “rhd”), or scrolling dots.
-
Page 12: Control Operation
Page 12 of 22 HP13023772 Rev: E HEATPRO HEAT PUMP Control Operation Dual Thermostat (Models HP20654T, HP20654BT, HP20854T, HP20854BT & HP21104T) This control does not have a true on/off feature. The unit uses standby mode On/Off: instead. Scrolling dots in the display indicate standby. Standby mode serves two functions. -
Page 13: Maintenance
Page 13 of 22 HP13023772 Rev: E HEATPRO HEAT PUMP Changing Temperature Display (All Models): The control will display temperatures in either degrees Fahrenheit or Celsius. To change the temperature display, place the heat pump in “Stand-By” mode so that the scrolling dots appear on the screen. Press and hold both the pool button and the down arrow button for two seconds and release. - Page 14 Page 14 of 22 HP13023772 Rev: E HEATPRO HEAT PUMP Owner Inspection Hayward recommends that you inspect your heat pump on a seasonal basis and especially after significant weather events. Refer to the sections of this Manual: “Clearance”, “Roof Run-Off”, “Drainage and Condensation”...
- Page 15 Page 15 of 22 HP13023772 Rev: E HEATPRO HEAT PUMP Some heat pump owners desire their pool to be heated during the winter months. This is possible when daytime temperatures are above 50°F [10°C] for most of Hayward’s heat pumps. If temperatures fall below freezing, be certain to keep the pool filter pump operating continuously to prevent freeze damage.
- Page 16 Page 16 of 22 HP13023772 Rev: E HEATPRO HEAT PUMP 6. Ensure that the pump and skimmer baskets are clean; also ensure that the pool filter is clean and supplying proper water flow to the heat pump. 7. If the heat pump is not able to maintain the desired temperature, depending on the time of the year, it may be necessary to adjust your pool filtration systems hours of operation (increase run time).
-
Page 17: Troubleshooting
Page 17 of 22 HP13023772 Rev: E HEATPRO HEAT PUMP Troubleshooting Circuit Breakers: If it is suspected that a circuit breaker is tripped, turn the breaker to the “Off” position and then back to the “On” position. NOTICE: Service to be conducted ONLY by an EPA Certified Service Technician. General Troubleshooting Guide for Hayward HeatPro Heat Pump Problem Possible Cause... - Page 18 Page 18 of 22 HP13023772 Rev: E HEATPRO HEAT PUMP Display Diagnostic Codes - Troubleshooting Guide for Hayward HeatPro Heat Pump Display Problem Possible Cause Solution No power to heat Tripped circuit breaker/ Check breaker and ensure that the unit is properly pump no power supply installed.
- Page 19 Page 19 of 22 HP13023772 Rev: E HEATPRO HEAT PUMP Heat Pump Replacement Parts Diagram CONTROL BOX FOR: HP2654T, HP20654BT, HP2854T, HP20854BT & HP21104T USE ONLY HAYWARD GENUINE REPLACEMENT PARTS Pomona, CA Clemmons, NC Nashville, TN Tel: 908.351.5400 www.haywardpool.com...
- Page 20 Page 20 of 22 HP13023772 Rev: E HEATPRO HEAT PUMP Heat Pump Replacement Parts List Item Part description HP20654T HP20654BT HP20854T HP20854BT HP21104T FAN TOP HPX01023502 HPX01024821 HPX01023502 HPX01024821 HPX01023502 SIDE PANEL HPX01023503 HPX01024822 HPX01023503 HPX01024822 HPX01023503 CONTROL BOX COVER HPX01023504A HPX01023504B HPX01023504A HPX01023504B HPX01023504A CONTROL BOX HPX01023505...
- Page 21 God. There are no implied warranties of merchantability or fitness for a particular purpose that apply to this product. These warranties apply to units shipped after October 1, 2008 Hayward Pool Products, Inc. 620 Division Street Elizabeth, NJ 07207...
- Page 22 Page 22 of 22 HP13023772 Rev: E HEATPRO HEAT PUMP ▼ DETACH HERE: Fill out bottom portion completely and mail within 10 days of purchase/installation. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS Pomona, CA Clemmons, NC Nashville, TN Tel: 908.351.5400 www.haywardpool.com...
