  • Page 1 REV 2017-1 SWIMMING POOL HEAT PUMP UNIT Installation & Instruction Manual Models HP40A HP50A HP80A Hayward Pool Products Canada, Inc. 2880 Plymouth Dr., Oakville, ON L6H 5R4 Haywardpool.ca / 1.888.238.7665...

  • Page 2: Table Of Contents

    CONTENTS 1. Preface 2. Specifications 2.1 Performance Data of Swimming Pool Heat Pump Unit 2.2 Dimensions for Swimming Pool Heat Pump Unit 3. Installation and Connection 3.1 Installation of System 3.2 Swimming Pool Heat Pumps: Location 3.3 How Close to your Pool? 3.4 Swimming Pool Heat Pumps: Plumbing 3.5 Swimming Pool Heat Pumps: Electrical Connection 3.6 Initial Start-Up of the Unit...

  • Page 3: Preface

    1. PREFACE In order to provide our customers with quality, reliability and versatility, this product has been made to strict production standards. This manual contains installation, service and maintenance. Please read this manual carefully before you open or maintain the unit. The manufacturer of this product will not be held responsible if someone is injured or the unit is damaged as a result of improper installation, service or unnecessary maintenance.

  • Page 4: Specifications

    2. SPECIFICATIONS 2.1 Performance Data of Swimming Pool Heat Pump Unit *** REFRIGERANT: R410A Unit Model HP40A HP50A HP80A Heating Power Input 1.87 2.68 Running Current 8.22 Power Supply V/Hz 208-230V~/60Hz 208-230V~/60Hz 208-230V~/60Hz Compressor Quantity Compressor(s) Rotary Rotary Rotary Fan Quantity...

  • Page 5: Dimensions For Swimming Pool Heat Pump Unit

    2. SPECIFICATIONS 2.2 Dimensions (mm/inches) for the Swimming Pool Heat Pump Unit Model: HP40A Model: HP50A...
  • Page 6 2. SPECIFICATIONS 2.2 Dimensions (mm/inches) for the Swimming Pool Heat Pump Unit Model: HP80A...

  • Page 7: Installation And Connection

    3. INSTALLATION AND CONNECTION 3.1 Installation Illustration...

  • Page 8: Swimming Pool Heat Pumps: Location

    3. INSTALLATION AND CONNECTION 3.2 Swimming Pool Heat Pumps: Location 3.3 How Close To Your Pool? Normally, the pool heat pump is installed within 24.6ft (7.5 metres) of the pool. The longer the distance from the pool, the greater the heat loss from the piping.

  • Page 9: Swimming Pool Heat Pumps: Plumbing

    3. INSTALLATION AND CONNECTION 3.4 Swimming Pool Heat Pumps: Plumbing The titanium heat exchanger requires no special plumbing except bypass (please set the ow rate according to the nameplate). The water pressure drop is less than 1.5psi (10KPa) at maxi- mum ow rate.

  • Page 10: Swimming Pool Heat Pumps: Electrical Connection

    3. INSTALLATION AND CONNECTION 3.5 Swimming Pool Heat Pumps: Electrical Connection 3.6 Initial Start-Up...

  • Page 11: Water Flow Setting

    3. INSTALLATION AND CONNECTION 3.7 Water Flow Setting While the heat pump is running and the water inlet and outlet valves are open, adjust the by- pass valve to obtain a difference of 2ºC between the water inflow and outflow temperatures (see Functional Diagram Section 3.1).

  • Page 12: User Interface

    4. USER INTERFACE 4.1 Overview...
  • Page 13 4. USER INTERFACE (continued) OFF Mode When the heat pump is on standby (OFF Mode), the time and operating mode are displayed on the control screen.

  • Page 14: Setting The Clock

    4. USER INTERFACE (continued) 4.2 Setting the Clock 4.3 Setting the Timer Function...

  • Page 15: Choice Of Operating Mode

    4. USER INTERFACE (continued) 4.4 Choice of Operating Mode: Heating, Cooling or Automatic...

  • Page 16: Settings And Viewing The Set Point

    4. USER INTERFACE (continued) 4.5 Settings and viewing the set point (Desired water temperature) 4.6 Locking and unlocking the touch screen 4.6 Locking and unlocking the touch screen 4.7 Temperature Display Change...

  • Page 17: Parameter Table

    4. USER INTERFACE (continued) 4.8 Parameter Table...

  • Page 18: Maintenance And Inspection

    5. MAINTENANCE AND INSPECTION 5.1 Maintenance • Check the water supply device and the release often. You should avoid the condition of no water or air entering into the system as this will influence the unit’s performance and reliability. You should clear the pool/spa filter regularly to avoid damage to the unit as a result of a clogged filter.

  • Page 19: Winterization

    5. MAINTENANCE AND INSPECTION 5.3 Winterization...

  • Page 20: Appendix

    6. APPENDIX 6.1 Connection of PCB Illustration...

  • Page 21: Wiring Diagram

    6. APPENDIX 6.2 Wiring Diagram - HP40A...
  • Page 22 6. APPENDIX 6.2 Wiring Diagram - HP50A...
  • Page 23 6. APPENDIX 6.2 Wiring Diagram - HP80A...
  • Page 24 6. APPENDIX 6.3 Exploded View and Spare Parts - HP40A...
  • Page 25 6. APPENDIX 6.3 Spare Parts List & Spare Parts - HP40A Part Code Part Name Part Number 32012-210584 Chassis HPX32012-210584 20000-220188 Fan net HPX20000-220188 32012-220071 Front panel HPX32012-220071 3500-2701 Axial flow fan HPX3500-2701 32012-210597 Left connecting plate HPX32012-210597 32012-210585 Left side panel...
  • Page 26 6. APPENDIX 6.3 Exploded View and Spare Parts - HP50A...
  • Page 27 6. APPENDIX 6.3 Spare Parts List & Spare Parts - HP50A Part Code Part Name Part Number 32012-120037 Evaporator HPX32012-120037 20000-220188 Fan Net HPX20000-220188 20000-330124 Fan Motor HPX20000-330124 3500-2701 Axis Blower Fan HPX3500-2701 2001-1418 4 Way Valve HPX2001-1418 20000-110041 Compressor HPX20000-110041 20000-360005 Water Flow Switch...
  • Page 28 6. APPENDIX 6.3 Exploded View and Spare Parts - HP80A...
  • Page 29 6. APPENDIX 6.3 Spare Parts List & Spare Parts - HP80A Part Code Part Name Part Number 20000-220169 Fan protection grille HPX20000-220169 32009-22059 Front panel HPX32009-22059 20000-330124 Motor HPX20000-330124 3500-2701 Fan blade HPX3500-2701 32009-210339 Motor support HPX32009-210339 32009-210338 Electrical box cover HPX32009-210338 32009-210340 Middle pannel...

  • Page 30: Warranty

    6. APPENDIX 6.4 Warranty...
  • Page 31 THERMOPOMPE POUR PISCINE Manuel d’instructions et d’installation Modèle HP40A HP50A HP80A Hayward Pool Products Canada, Inc. 2880 Plymouth Dr., Oakville, ON L6H 5R4 Haywardpiscine.ca / 1.888.238.7665...
  • Page 32 SOMMAIRE 1. Préface 2. Caractéristiques techniques 2.1 Données techniques de la pompe à chaleur 2.2 Dimensions 3. Installation et raccordement 3.1 Illustration de lìnstallation 3.2 Thermopompe 3.3 A quelle distance de la piscine l’installer 3.4 Installation des conduites 3.5 Raccordement électrique 3.6 Premier démarrage 3.7 Réglage du debit d’eau 4.

  • Page 33: Préface

    1. PREFACE...

  • Page 34: Caractéristiques Techniques

    2. CARACTERISTIQUES TECHNIQUES 2.1 Données techniques de la thermopompe *** REFRIGERANT: R410A Unit Modèle HP40A HP50A HP80A Puisssance calorifique à l’entrée 1,87 2,68 Courant de fonctionnement 8,22 Alimentation électrique V/Hz 208-230V~/60Hz 208-230V~/60Hz 208-230V~/60Hz Nombre de compresseurs Type de compresseur Rotatif...

  • Page 35: Dimensions

    2. CARACTERISTIQUES TECHNIQUES 2.2 Dimensions (mm / po) Modèle : HP40A Modèle : HP50A...
  • Page 36 2. CARACTERISTIQUES TECHNIQUES 2.2 Dimensions (mm / po) Modèle: HP80A...

  • Page 37: Installation Et Raccordement

    3. INSTALLATION ET RACCORDEMENT 3.1 Illustration de l’installation...

  • Page 38: Thermopompe

    3. INSTALLATION ET RACCORDEMENT 3.2 Thermopompe 3.3 A quelle distance de la piscine l’installer ?

  • Page 39: Installation Des Conduites

    3. INSTALLATION ET RACCORDEMENT 3.4 Installation des conduites...

  • Page 40: Raccordement Électrique

    3. INSTALLATION ET RACCORDEMENT 3.5 Raccordement électrique 3.6 Premier démarrage...

  • Page 41: Réglage Du Debit D'eau

    3. INSTALLATION ET RACCORDEMENT 3.7 Réglage du débit d’eau...

  • Page 42: Interface Utilisateur

    4. INTERFACE UTILISATEUR 4.1 Présentation générale...
  • Page 43 4. INTERFACE UTILISATEUR (suite)

  • Page 44: Réglage De L'horloge

    4. INTERFACE UTILISATEUR (suite) 4.2 Réglage de l’horloge 4.3 Réglage de la fonction timer...

  • Page 45: Choix Du Mode De Fonctionnement

    4. INTERFACE UTILISATEUR (suite) 4.4 Choix du mode de fonctionnement : chauffage, refroidissement ou automatique...

  • Page 46: Réglage Et Visualisation Du Point De Consigne

    4. INTERFACE UTILISATEUR (suite) 4.5 Réglage et visualisation du point de consigne (Température d’eau souhaitée) 4.6 Verrouillage et déverrouillage de l’écran tactile 4.6 Verrouillage et déverrouillage de l’écran tactile 4.7 Charger température sur l’affichage 4.7 Charger température sur l’affichage...
  • Page 47 4. INTERFACE UTILISATEUR (suite) 4.8 Table des paramètres...

  • Page 48: Entretien Et Inspection

    5. ENTRETIEN ET INSPECTION 5.1 Entretien 5.2 Guide de dépannage 5.2 Guide de dépannage...

  • Page 49: Hivernage

    5. ENTRETIEN ET INSPECTION 5.3 Hivernage...

  • Page 50: Annexe

    6. ANNEXE 6.1 Schématique de raccordement du PCB...

  • Page 51: Schéma De Câblage

    6. ANNEXE 6.2 Schéma de cablage - HP40A...
  • Page 52 6. ANNEXE 6.2 Schéma de cablage - HP50A...
  • Page 53 6. ANNEXE 6.2 Schéma de cablage - HP80A...
  • Page 54 6. ANNEXE 6.3 Vue éclatée - HP40A...
  • Page 55 6. ANNEXE 6.3 Liste des pièces principales - HP40A Code de la pièce Nom de la pièce Numéro de pièce 32012-210584 Châssis HPX32012-210584 Plastique de protection du 20000-220188 HPX20000-220188 ventilateur 32012-220071 Panneau frontal HPX32012-220071 3500-2701 Ventilateur axial HPX3500-2701 32012-210597 Plaque de raccordement gauche...
  • Page 56 6. ANNEXE 6.3 Vue éclatée - HP50A...
  • Page 57 6. ANNEXE 6.3 Liste des pièces principales - HP50A Code de la pièce Nom de la pièce Numéro de pièce 32012-120037 Evaporateur HPX32012-120037 20000-220188 HPX20000-220188 Plastique de protection du ventilateur 20000-330124 Moteur de ventilateur HPX20000-330124 3500-2701 HPX3500-2701 Ventilateur axial 2001-1418 Vanne 4 voies HPX2001-1418 20000-110041...
  • Page 58 6. ANNEXE 6.3 Vue éclatée - HP80A...
  • Page 59 6. ANNEXE 6.3 Liste des pièces principales - HP80A Code de la pièce Nom de la pièce Numéro de pièce 20000-220169 Fan protection grille HPX20000-220169 32009-22059 Panneau de façade HPX32009-22059 20000-330124 Moteur HPX20000-330124 3500-2701 Pale du ventilateur HPX3500-2701 32009-210339 Soutien du moteur HPX32009-210339 32009-210338 Couvercle de la boîte électrique...

  • Page 60: Garantie

    6. ANNEXE 6.4 Garantie Hayward Pool Products Canada, Inc. 2880 Plymouth Dr., Oakville, ON L6H 5R4 Haywardpiscine.ca / 1.888.238.7665...
