Page 4
Betriebsanleitung | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N Beachten Sie die dem Gerät beiliegenden Sicherheitshinweise! Diese sind auch unter der folgenden Internetadresse abrufbar: https://download.axing.com/BAs/Sicherheitshinweise_9sprachig.pdf Benutzen Sie das Gerät ausschließlich wie in dieser Betriebsanleitung beschrieben und insbesondere nach dem Stand der Technik.
Die MIE-Kopfstellen bestehen aus einer Grundeinheit mit Spannungsversorgung. Die Grundeinheit ist entweder mit einem oder zwei Modulen bestückt. Die MIE 8-00N, MIE 16-00N, MIE 4-02N und MIE 3-02N enthalten ein Modul A. Modul A Die MIE 32-00N, MIE 8-02N und MIE 6-02N enthalten zwei Module A und B.
1.4. Anzeigeelemente und Anschlüsse • Die MIE 8-00N, MIE 16-00N, MIE 4-02N und MIE 3-02N enthalten ein Modul A. • Die MIE 32-00N, MIE 8-02N und MIE 6-02N enthalten zwei separate Module A und B. 1.4.1. Anzeigeelemente Die LEDs zeigen den Zustand der Ausgangsmodulatoren an •...
1.5. Anwendungsbeispiel Beide Geräte werden über zwei redundante IPTV-Quellen versorgt. Eine ist an den Port IPTV IN1 und eine ist an den Port IPTV IN2 angeschlossen. Die Verbindung zum Conditional-Access-Simulcrypt-Server wird über den CAS-Port hergestellt. Der Control-Port dient zum einen als Konfigurationsschnittstelle, zum anderen für das Monitoring des Backupgeräts. Die in der Kopfstelle verschlüsselten Programme können von angeschlossenen Teilnehmern mit passenden CA-Modulen/Smartcard entschlüsselt werden.
Betriebsanleitung | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 1.6. SMARTPortal Das AXING SMARTPortal verbindet jede AXING-Kopfstelle mit einem Cloud-basierten Portal und verschafft dadurch weltweiten Zugriff auf die Geräte. Die Verbindung ist passwortgeschützt und verschlüsselt. Voraussetzungen vor Ort ist lediglich eine Internetverbindung für die Kopfstelle über die Konfigurationsschnittstelle.
2. Montage und Anschluss Montage und Anschluss sind nur von autorisierten Elektrofachkräften durchzuführen. Das Gerät darf nur in Innenräumen betrieben werden. Vor Montage und Anschluss Netzstecker ziehen! Das DVB-C/T/T2-Verteilnetz muss gemäß EN 60728-11 aufgebaut und entsprechend geerdet werden. 2.1.
Die MIE ist modular aufgebaut. Jedes Modul hat eigene Schnittstellen. Schließen Sie die jeweils benötigten Schnittstellen mit Class 5/6 Ethernet-Kabel mit RJ-45-Steckern z.B. an einem Switch an. Die MIE 8-00N, MIE 16-00N, MIE 4-02N und MIE 3-02N enthalten ein Modul A. Modul A Die MIE 32-00N, MIE 8-02N und MIE 6-02N enthalten zwei Module A und B.
Betriebsanleitung | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 2.5. IPTV-Eingänge Die Kopfstellen verfügen über zwei redundante IPTV Eingänge IPTV IN1 und IPTV IN2. Wenn für eine gewisse Zeit keine Eingangs-Transportstreams mehr an IPTV IN1 anstehen, dann schaltet die MIE auf diesen redundanten Eingang um.
2.7. Modul-Redundanz (mit MIS 1-11) Die Modul-Redundanz bietet die Möglichkeit, ein Modul der MIE z. B. bei Ausfall durch ein anderes Modul zu ersetzen. Wenn bestimmte konfigurierbare Bedingungen eintreffen (Eingangsfehler, Ausgangsfehler, Fehler der Betriebsspannung etc.), dann wird auf das Backup-Modul umgeschaltet. Beim Backup-Modul sind zunächst die Ausgangsmodulatoren deaktiviert. Wenn auf das Backup-Gerät umgeschaltet wird, dann werden dessen Ausgangsmodulatoren aktiv und liefern das Ausgangssignal.
Betriebsanleitung | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 2.8. Verbindung mit einem CAS-Server (mit MKS 1-02) Die Kopfstelle kann mit einem CAS-Server verbunden werden. Wenn die Kopfstelle mit dem CAS-Server verbunden und korrekt konfiguriert ist, dann kann sie Programme verschlüsseln. Die verschlüsselten Programme können von angeschlossenen Teilnehmern mit passenden CA-Modulen/Smartcards entschlüsselt...
2.9. Upgrade 2.9.1. Softwareerweiterung Die MIE 8-00N kann mit der MIS 8-16-Softwareerweiterung von 8 auf 16 Ausgangsmodulatoren erweitert werden (siehe 3.8 Lizenzen für Software-Erweiterungen auf Seite 53). 2.9.2. Hardwareerweiterung Die MIE 8-00N, MIE 16-00N, MIE 4-02N und MIE 3-02N können um ein weiteres Hardwaremodul erweitert werden.
Betriebsanleitung | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 3. Konfiguration Die Konfiguration der Geräte erfolgt über die grafische Benutzeroberfläche der integrierten Webschnittstelle. Für den Zugriff auf die Benutzeroberfläche benötigen Sie einen handelsüblichen PC/Laptop inklusive Netzwerkschnittstelle und die aktuelle Version des installierten Webbrowsers.
3.1. An- und Abmelden Die Benutzeroberfläche ist gegen unbefugten Zugriff geschützt. Beim Zugriff auf die Benutzeroberfläche erfolgt als erstes die Passwortabfrage. Geben sie das werksseitig eingestellte Passwort ein: Ramsen8262 Klicken Sie auf ENTER PASSWORD. Sollten sie nicht automatisch zu der Startseite weitergeleitet werden, klicken Sie anschließend auf OPEN PAGE.
Betriebsanleitung | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 3.2. Startseite 3.2.1. Eingang Die Datenrate des IPTV-Eingangs wird angezeigt. Eingangs-Redundanz Wenn die CAS-Schnittstelle als redundanter IPTV-Eingang verwendet wird und die MIE auf diesen Eingang umgeschaltet hat, dann wird dies auf der Startseite angezeigt (CAS-Port verwendet).
3.2.3. Geräte-Redundanz Das Backup-Gerät zeigt den Status aller überwachten Geräte auf der Startseite an. Wenn bei Geräten Fehler auftreten, dann wird dies in der Spalte Status angezeigt. Beim Backup-Gerät werden keine Datenraten für Eingänge und Ausgänge angezeigt. Die Initialisierungsseiten (Phase 1 – Phase 3) sind nicht verfügbar.
3.3.2. Einen oder mehrere Streams hinzufügen Klicken Sie auf Stream hinzufügen. Der Dialog zum Hinzufügen von Eingangsstreams wird geöffnet. Geben Sie die IP-Adresse und den Port des neuen Streams ein. Klicken Sie OK, der Stream wird hinzugefügt und gescannt .. Mehrere Streams hinzufügen: ...
Betriebsanleitung | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 3.3.3. Eingangs-Transport-Streams direkt einem Modulator zuordnen Mit dem Modus „Passthrough“ können die Programme eines Eingangs-Transportsreams 1:1 zu einem Modulator durchgeleitet werden.
3.4. Initialisierung - Phase 2 Klicken Sie auf PHASE 2, um zur Programmauswahl zu gelangen. Die TS-IDs (Transportstream-IDs), die Netzwerk-ID und der Netzwerkname können geändert werden. Wenn Sie mehrere MIE in einem Netzwerk verwenden, dann müssen die Netzwerk-IDs gleich sein und auch der Netzwerkname sollte gleich sein. Transportstream-IDs hingegen dürfen jeweils nur einmal im Netzwerk vergeben werden.
3.4.4. PID Filtering Die Transportströme bestehen aus Paketen, die durch PIDs (Packet IDentifier) gekennzeichnet sind. Einzelne Pakete können bei Bedarf aus dem Transportstrom gefiltert werden. Klicken Sie auf eines der Programme. Die Tabelle mit den im Programm enthaltenen Paketen wird geöffnet. ...
Manuelles Remappen Sollen Pakete eine bestimmte OUT PID erhalten, dann kann diese manuell eingegeben werden. Klicken Sie beim entsprechenden Programm in die Spalte OUT PID. Geben Sie die PID mit der Tastatur ein oder erhöhen/verringern Sie die PID mit den Pfeiltasten. ...
Page 30
Betriebsanleitung | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N Im nachfolgenden Beispiel werden zwei Programme konfiguriert. Beim einen werden nur die Deutschen, beim anderen die französischen Audio-Streams an den Ausgangsmodulator übertragen.
3.4.7. NIT-Version „einfrieren“ Klicken Sie auf ERWEITERTE OPTIONEN. Ein Dialog mit zusätzlichen Optionen wird geöffnet. Öffnen Sie die Option NIT. Wenn sich Programme eines Transponders ändern, dann wird die NIT neu erstellt. In der Regel merkt der Endanwender davon nichts, weil die Receiver die neue NIT automatisch einlesen.
Betriebsanleitung | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 3.4.8. OTA-Upgrade Damit ein Over-the-Air-Upgrade möglich ist, stehen in der Konfiguration zwei Funktionen zur Verfügung: • Nicht referenzierte PIDs können manuell an die Ausgangsmodulatoren weitergeleitet werden •...
Page 33
Dieselbe Eingangs-PID kann bei Bedarf zu mehreren Ausgangsmodulatoren weitergeleitet werden. Der Ausgangs-PID-Wert kann für jeden Ausgang separat eingegeben werden. Im folgenden Beispiel wird PID 7496 aus dem Eingangsstrom 239.0.0.0.1:1234 an drei Modulatoren weitergeleitet. Klicken Sie anschließend auf SPEICHERN. Die Eingaben werden erst dadurch in der Kopfstelle gespeichert. Einträge editieren oder löschen ...
Page 34
Betriebsanleitung | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N Benutzerdefinierte Deskriptoren zur NIT hinzufügen Klicken Sie in PHASE 2 auf ERWEITERTE OPTIONEN. Öffnen Sie die Option NIT.
3.4.9. Einstellmöglichkeiten für die TDT und TOT Die Time and Date Table (TDT) enthält die augenblickliche Uhrzeit im UTC-Format. Die Time Offset Table (TOT) enthält sowohl die Uhrzeit in UTC als auch den Versatz zur lokalen Zeitzone. Beide werden innerhalb des Transportstroms in dafür bestimmten Paketen an die Receiver der Endgeräte übertragen.
Betriebsanleitung | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 3.4.10. EIT-Konfiguration Wenn die SPTS/MPTS-Eingangsströme nicht alle EIT-Informationen enthalten (Event Information Table), dann kann die EIT aus einer alternativen EIT-Quelle bereitgestellt werden.
Initialisierung - Phase 3 Klicken Sie auf PHASE 3, um zur Modulator-Konfiguration zu gelangen. • Bei den MIE 8-00N, MIE 16-00N und MIE 32-00N kann in der Wartung zwischen DVB-C und DVB-T umgeschaltet werden (siehe 4.2 auf Seite 46). •...
Durch Änderung des FEC-Faktors wird der Anteil der FEC-Daten im Verhältnis zu den Nutzdaten geändert. Ein höherer Anteil an FEC-Daten bedeuten eine höhere Redundanz bei der Übertragung. Dadurch wird jedoch die Bandbreite für die Nutzdaten gesenkt. Mit einer FEC von 7/8 erreichet man die höchste Nutzdatenrate und die geringste Redundanz bei der Übertragung.
Page 40
Betriebsanleitung | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N Hinweis: Eine Änderung der Norm folgt den folgenden Regeln: • CCIR -> Australien: Die Bandbreite aller Modulatoren wird auf 7 MHz geändert •...
Hinweis Einige Konfigurationsmöglichkeiten sind von einander abhängig. In diesem Fall werden auswählbare Werte weiß, nicht auswählbare Werte grau hinterlegt. 3.5.4. MIE 3-02N und MIE 6-02N (DVB-T2) Modulator-Konfiguration Auswahl eines Modulators Wählen Sie links aus MODULATOR 1 bis MODULATOR 3 einen Modulator aus. ...
Page 42
Betriebsanleitung | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N FEC Coderate Mit Hilfe der Fehlerkorrektur können durch störungsreiche Übertragungsstrecken entstandene (Vorwärtsfehlerkorrektur) Fehler durch das Wiederherstellen von Daten ausgeglichen werden. Die für die Wiederherstellung des Signals benötigten Daten sind in den übertragenen FEC-Bits enthalten.
3.5.5. Füllstand Die Datenrate der Eingangs-Streams kann abhängig vom Bildinhalt und Übertragungsqualität variieren. Um den störungsfreien Empfang zu gewährleisten ist unbedingt eine Reserve einzuhalten. Wir empfehlen einen maximalen Füllstand von maximal 90%. Wird der maximale Füllstand überschritten kann es zu Bildstörungen wie z. Bsp. Mosaikbilder kommen. Liegt die Netto-Datenrate des Signales oberhalb der maximalen Netto-Datenrate des Ausgangskanals kommt es im Modulator zu einem Überlauf.
Wir empfehlen zum leichteren Handling und Überblick das AXING SMARTPortal. Download Sie finden Software-Updates zum Download, indem Sie auf www.axing.com im Suchfeld den Artikel eingeben. Laden Sie die aktuelle Version auf Ihren PC herunter und entpacken Sie diese. Update Unter SOFTWARE-DATEI kann eine neue Software für die Oberfläche installiert werden.
4.3. System 4.3.1. Ändern der IP-Adressen Unter dem Menüpunkt WARTUNG > SYSTEMOPTIONEN werden die Netzwerkoptionen konfiguriert. Sie finden dort folgende Registerkarten: • Control: IP-Adresse der Konfigurations-Schnittstelle • IPTV 1: IP-Adresse der IPTV-Schnittstelle • IPTV 2: IP-Adresse der IPTV-Schnittstelle • CAS: IP-Adresse der Schnittstelle für den CASimulcrypt-Server Dynamische IP-Adresse ...
Klicken Sie auf BESTÄTIGEN & NEUSTART. Das Modulationsverfahren wird geändert. Die verbleibende Zeit wird angezeigt. Anschließend wird das Gerät automatisch neu gestartet und der Anmeldedialog angezeigt. Geben Sie das Passwort erneut ein Prüfen Sie insbesondere die Modulatoreinstellungen und deren Füllstand. 4.4.
Betriebsanleitung | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 4.4.3. Initialisierungsdaten laden Unter EINSTELLUNGEN DER INITIALISIERUNG AUS DATEI LADEN können Sie die gespeicherten Einstellungen der Initialisierungsphasen 1 bis 3 in ein Gerät laden.
Verbindungsdaten anpassen (siehe 3.7.3 auf Seite 47). Wählen Sie im Feld Status die Option Aktiviert. Aktivieren Sie, wenn gewünscht, die Option AXING Support zulassen. Geben Sie im Feld Standort eine Bezeichnung des Standorts des Geräts ein. Diese Bezeichnung erscheint später im SMARTPortal und hilft Ihnen dabei das Gerät zu identifizieren.
4.9.1. Lizenzen erwerben Eine Lizenz können Sie erwerben, in dem Sie die entsprechende Software-Erweiterung bei AXING kaufen. Beim Kauf müssen Sie die Seriennummer der Kopfstelle angeben. Passend zu genau dieser Seriennummer wird eine Lizenzdatei für Sie generiert. Wichtig: Die Lizenz ist an die Seriennummer gebunden und nicht auf andere Geräte übertragbar! 2023-06-15 | Technische Verbesserungen, Änderungen im Design, Druckfehler und Irrtümer vorbehalten | BA_MIE-N.pdf...
Betriebsanleitung | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 4.9.2. Upload der Lizenzdatei Lizenzen können auf verschiedene Arten in die Kopfstelle hochgeladen werden: Durch den AXING-Support per Fernwartungssoftware (z. B. TeamViewer): ...
4.10. CASSimulcrypt (mit MKS 1-02) Die Einrichtung eines Conditional-Access-Systems setzt die Installation und Konfiguration eines CAS-Servers, der unter anderem ECMs und EMMs generiert, voraus. Die Einrichtung eines CAS-Servers wird in diesem Dokument nicht beschrieben. Um die Einstellungen für die Kopfstelle vornehmen zu können, benötigen Sie eine entsprechende Lizenz (siehe 3.8 auf Seite 53). Wenn diese Lizenz in der Kopfstelle aktiviert ist, können unter CAS die nötigen Einstellungen vorgenommen werden.
Betriebsanleitung | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 4.10.3. Scrambling Control Groups (SCG) Diese Tabelle listet alle verwendeten Scrambling Control Groups auf. Programme, die mit demselben SCG verbunden sind, werden zur gleichen Zeit mit demselben Control Word (Schlüssel) verschlüsselt.
4.10.4. ECM Generators Der ECM-Generator wird vom CAS-Lieferanten bereitgestellt, um ECM-Nachrichten zu erzeugen. • Name: Wird nur in der Web-Schnittstelle verwendet, um ECMG-Server leicht zu unterscheiden. • Channel ID <optional>: ‘ECM_channel_id’ Wird bei der Kommunikation mit dem ECMG verwendet. Einige ECMGs verlangen einen bestimmten Wert für diese ID (Info ggf.
Betriebsanleitung | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 4.10.6. EMM Configuration EMM enthält Informationen von CAS-Lieferanten, die z.B. die Berechtigungsstufen von Abonnenten oder Gruppen von Abonnenten angeben. Der EMM-Generator ist ein externer Server des CAS-Anbieters, der EMM-Nachrichten erzeugt und diese wiederholt an die Kopfstelle sendet.
4.10.7. Programm Verschlüsselung in Phase 2 Die Programme werden in Phase 2 mit den SCGs verbunden, um sie zu verschlüsseln: Klicken Sie auf das gewünschte Programm, um dessen Details anzuzeigen. Wählen Sie ein Simulcrypt-SCG aus der Dropdown-Liste (es werden alle konfigurierten SCGs angezeigt). Standardmäßig werden alle Video- und Audio-PIDs des Programms für die Verschlüsselung ausgewählt.
4.12. NMS (mit MIS 1-11) Ein Gerät kann bis zu fünf weiteren Geräten überwachen und als Backup-Gerät für diese Geräte dienen. Wenn bestimmte konfigurierbare Bedingungen zutreffen (Eingangsfehler, Ausgangsfehler, Fehler der Betriebsspannung etc.), dann wird auf das das Backup-Gerät umgeschaltet. Das Umschalten erfolgt nur, wenn am Backup-Gerät nicht ebenfalls Fehler aufgetreten sind. Ein Umschalten erfolgt z.B. nicht, wenn der IPTV-Eingang bei beiden Geräten fehlt oder beide an die gleiche ausgefallene Spannungsquelle angeschlossen sind.
Page 62
Betriebsanleitung | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N In einer Tabelle sind die Geräte aufgelistet, die sich im selben Sub-Netz befinden (im Beispiel 192.168.0.xxx) Wählen Sie die Geräte aus, die überwacht werden sollen, in dem Sie auf Monitor klicken.
4.13. Network Information Table (NIT) Die NIT– Network Information Table überträgt im digitalen Datenstrom eine Reihe von Parametern, die für einen Suchlauf bei den Endgeräten hilfreich sind. Die spezifischen Parameter innerhalb der NIT, wie ONID – Original Network ID und TS-ID – Transmitting Subscriber ID, können jeweils konfiguriert werden.
Betriebsanleitung | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 4.13.4. NIT überprüfen Werte, die sich überschneiden Werte, die sich ggf. überschneiden werden rot dargestellt. Diese Fehler müssen vor dem Hochladen bereinigt werden.
4.13.6. Hochladen der NIT Wählen Sie die Geräte aus, in die die NIT hochgeladen werden soll. Klicken Sie auf HOCHLADEN. Die Daten werden hochgeladen und in der Kopfstelle gespeichert. 4.13.7. NIT zurücksetzen Das Zurücksetzen der NIT ist unter bestimmten Umständen nötig. Beispiel: Es werden drei Geräte verwendet.
MIE 4-02N MIE 8-02N MIE 3-02N MIE 6-02N Betriebstemperaturbereich –10°C…+50°C (gemäß EN 60065) Lagertemperaturbereich (gemäß EN 60065) –20 °C…+80 °C Maße (B × H × T) ca. 480 × 43 × 275 mm Gewicht 3,15 kg 3,67 kg 3,15 kg 3,15 kg Anmerkungen * nur mit Softwareerweiterung MKS 1-02...
Page 74
Operation instructions | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N Observe the safety instructions enclosed with the unit! These are also available at the following Internet address: https://download.axing.com/BAs/Sicherheitshinweise_9sprachig.pdf...
The MIE head-end units are housed in a 19" housing with 1 RU. The MIE headends consist of a basic unit with power supply. The basic unit is equipped with either one or two modules. The MIE 8-00N, MIE 16-00N, MIE 4-02N and MIE 3-02N contains one module A: Module A The MIE 32-00N, MIE 8-02N and MIE 6-02N contains two modules A and B.
Extension module for MIE 4-02N or MIE 4-02N/48 for extension to 2 × 512 input streams and 2 x 4 DVB-T2 output channels. MIS 8-16 Software extension for MIE 8-00N or MIE 8-00N/48, from 8 to 16 x DVB-C (J.83 Annex A/C) or from 6 to 12 x DVB-T output channels. MIS 1-11 Software extension for MIE device redundancy Offers the possibility to replace a device with another device, e.g.
1.4. Display elements and connectors • The MIE 8-00N, MIE 16-00N, MIE 4-02N and MIE 3-02N come with one module A. • The MIE 32-00N, MIE 8-02N and MIE 6-02N come with two separate modules A and B. 1.4.1. Display elements The LEDs show the state of the output modulators: •...
1.5. Application example Both devices have two redundant IPTV sources, one connected to the IPTV IN1 port, and one connected to the IPTV IN2 port. The connection to the Conditional Access Simulcrypt server is implemented via the CAS port. The Control port is used as a configuration interface on the one hand and for the monitoring of the backup unit on the other. The programs scrambled in the headend can be descrambled by connected subscribers with suitable CA modules/smart cards.
2. Mounting and Installation Installation must be performed by authorized and skilled electricians only. Before mounting and installation, pull the mains plug! The DVB-C/T/T2 distribution network must be installed and connected to the equipotential bonding according to EN 60728- ...
Operation instructions | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 2.2. Equipotential bonding The device must be connected to the equipotential bonding according to EN 60728-11. Use the equipotential bonding connection at the device.
Connect the IPTV input to an Ethernet switch connected to the IPTV source. Use Class 5/6 Ethernet cables with RJ-45 connectors. The MIE 8-00N, MIE 16-00N, MIE 4-02N and MIE 3-02N contains one module A: Module A The MIE 32-00N, MIE 8-02N and MIE 6-02N contains two modules A and B. Each module has its own IPTV address:...
Operation instructions | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 2.5. IPTV inputs The headends have two redundant IPTV inputs IPTV IN1 and IPTV IN2. If there are no more input transport streams at IPTV IN1 for a certain time, the MIE switches to this redundant input. The head-end then receives its input transport streams from this interface.
2.7. Module redundancy (with MIS 1-11) Module redundancy offers the possibility to replace a module of the MIE with another module, e.g. in case of failure. If certain configurable conditions occur (input error, output error, operating voltage error, etc.), then the system switches to the backup module.
Operation instructions | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 2.8. Connecting to a CAS server (with MKS 1-02) The headend can be connected to a CAS server.
2.9. Upgrading 2.9.1. Software extension The MIE 8-00N can be expanded from 8 to 16 output modulators with the MIS 8-16 software extension (see 3.8 Licenses for Software Extensions on page 53). 2.9.2. Hardware extension The MIE 8-00N, MIE 16-00N, MIE 4-02N and MIE 3-02N can be extended with an additional hardware module.
Operation instructions | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 3. Configuration The device is configured via the graphical user interface of the integrated web interface. To access the user interface, you need a standard PC/laptop with a network interface and the actual version of the installed web browser.
3.1. Login and logout The web-based user interface is protected against unauthorized access. When accessing the user interface, the first thing is the password request. Enter the default password: Ramsen8262 Click ENTER PASSWORD. If you are not automatically forwarded to the start page, click OPEN PAGE.
Operation instructions | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 3.2. Front page 3.2.1. Input The data rate of the IPTV- input is shown. Input port redundancy If the CAS interface is used as a redundant IPTV input and the MIE has switched to this input, this is displayed on the front page (CAS port used).
3.2.3. Device Redundancy The backup device shows the status of all monitored devices on the front page. If there are failures on devices, then this is displayed in the Status column. No data rates for inputs and outputs are displayed for the backup device. The initialisation pages (Phase 1 – Phase 3) are not available.
3.3.2. Add one or multiple input streams Click Add Input. The Add input streams dialog opens. Enter the IP address of the stream and its port. Click OK, the stream will be added and scanned. To add multiple streams: ...
Operation instructions | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 3.3.3. Assigning input transport streams directly to a modulator With the "Passthrough" mode, the programs of an input transport stream can be forwarded 1:1 to a modulator.
3.4. Initialization - phase 2 Click on PHASE 2, to select programs. The TS IDs (transport stream IDs), the Network ID and the Network Name can be changed. If you use several MIE in a network, then the network IDs must be the same and the network name should also be the same. Transport stream IDs, on the other hand, may only be assigned once in the network.
3.4.4. PID Filtering The transport streams consist of packets that are identified by PIDs (Packet Identifier). Individual packets can be filtered from the transport stream if required. Click on one of the programs. The table with the packages contained in the program is opened. ...
Operation instructions | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 3.4.5. PID-Remapping Automatic PID remapping If several programs within an output modulator contain packets that have the same PID, this can cause interferences. Therefore these PIDs are re-mapped automatically.
Re-mapping PIDs by hand If packets should get a very specific OUT PID, this can be entered manually. Click in the OUT PID column of the program. Enter the PID with the keyboard or increase/decrease the PID with the arrow keys. ...
Page 100
Operation instructions | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N In the following example two programs are configured. In one, only the German audio streams are transmitted to the output modulator, in the other the French audio streams.
3.4.7. "Freeze" NIT version Click on ADVANCED OPTIONS. A dialog with options will open. If programs change, then the NIT is recreated. In most countries, the end user does not notice, because the receivers automatically read in the new NIT. However, in some countries (e.g. France) end users are asked to start a channel search. If it comes to the case that one or more stations are weak to receive, then the NIT changes frequently and the end users are always unnecessarily prompted to start a channel search.
Operation instructions | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 3.4.8. OTA upgrade To enable an Over-the-Air upgrade, two functions are available in the configuration: • Non-referenced PIDs can be manually added to the output modulators •...
Page 103
The same input PID can be added to multiple outputs if needed. Output PID value can be set separately for each output. In the example below, PID 7496 from the input stream 239.0.0.1:1234 is added to three outputs. Click SAVE after completing the entries. This saves the entries in the headend.
Page 104
Operation instructions | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N Add custom descriptors to NIT Click in PHASE 2 on ADVANCED OPTIONS. A dialog with options will open.
3.4.9. Setting options for TDT and TOT The Time and Date Table (TDT) contains the current time in UTC format. The Time Offset Table (TOT) contains both the time in UTC and the offset to the local time zone. Both are transmitted within the transport stream to the receivers of the mobile devices in packets intended for this purpose.
Operation instructions | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 3.4.10. EIT configuration If the SPTS/MPTS input streams do not contain all the EIT information (Event Information Table), then the EIT can be provided from a alternative EIT source.
Initialization - phase 3 Click on PHASE 3, to modify the setting of the modulators. • The MIE 8-00N, MIE 16-00N and MIE 32-00N can be changed between DVB-C and DVB-T in maintenance (see 4.2 on page 46). •...
DVB-T FEC Coderate Thanks to the error correction, errors resulting from high-disturbed transmission routes can be (forward error correction) balanced by restoring data. The data required to restore the signal are included in the transmitted FEC bits. Changing the FEC factor modifies the part of the FEC data in relation to the application data. A higher part of FEC data means an higher transmission redundancy.
Page 110
Operation instructions | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N Parameters: Common Output level The Common Output Level option include a general attenuation of all modulator outputs. The highest output level is reached with a setting of 20 dB, the lowest level with a setting of 0 dB.
Note Some configuration options are dependent on each other. In this case, selectable values are highlighted in white, non-selectable values in grey. 3.5.4. MIE 3-02N and MIE 6-02N (DVB-T2) Configuration of the modulators Select a modulator Select a modulator from MODULATOR 1 to MODULATOR 3 on the left. ...
Page 112
Operation instructions | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N FEC Code rate Thanks to the error correction, errors resulting from high-disturbed transmission routes can be balanced by restoring data. The data required to restore the signal are included in the transmitted FEC bits.
3.5.5. Fill level The data rate of the sender may vary depending on the image contents and on the transmission quality. To ensure an undisturbed reception, a reserve must absolutely be observed. We recommend you to set the maximal fill level to 90%. If the current fill level exceeds the maximal fill level, it may cause image disturbances, e.g.
Operation instructions | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 4. Maintenance The menu entry MAINTENANCE enables software updates, changing the IP address, changing the password, restarting the device and much more.
We recommend the AXING SMARTPortal for easier handling and overview. Download You can find software updates by entering the article in the search field at www.axing.com. Download the current version of the file to your computer and unpack it.
4.3. System 4.3.1. Changing the IP addresses The network options are configured under the menu item MAINTENANCE> SYSTEM OPTIONS. There you will find the following tabs: • Control: IP address of the Configuration interface • IPTV 1: IP address of the IPTV input interface •...
Operation instructions | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 4.3.2. Changing the password The default password is: Ramsen8262. The default password should be changed right after commissioning the device.
The changing of the modulation standard begins the remaining time is shown as a countdown. The device will be automatically rebooted, the enter password dialog will be displayed. Enter the password again. Check especially the modulator settings and their fill level. 4.4.
Operation instructions | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 4.4.3. Upload initialization data In the section UPLOAD SYSTEM INITILIZATION DATA FROM FILE you can upload the initialization data from a file to the module.
In the State field, select Enabled. Activate, if required, the option AXING support allowed. In the field Location, enter a name for the location of the device. This name will appear later in the SMARTPortal to help you identify the device.
Operation instructions | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 4.7. SNMP 4.7.1. SNMP (Simple Network Management Protocol) The Simple Network Management Protocol (SNMPv1 or SNMPv2c) is supported. With the help of a Network Management Station (NMS) information can be read or alarms can be received.
Purchase licenses You can purchase a license by ordering the appropriate software extension from AXING. When ordering, you must provide the serial number of the headend. A license file will be generated for you to match exactly this serial number. Important: The license is bound to the serial number and is not transferable to other devices! 2023-06-15 | Technical improvements, changes in design, printing- and other errors reserved.
4.10. CASimulcrypt (with MKS 1-02N) The setup for the conditional access system requires the installation and configuration of a CAS server, which generates ECMs and EMMs, among other things. Setting up a CAS server is not described in this document. To configure the settings for the headend unit, you must have a corresponding licence (see 3.8 on page 53).
Operation instructions | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 4.10.3. Scrambling Control Groups (SCG) This table lists all Scrambling Control Groups used in the device. Programs connected to the same SCG are scrambled at the same time with the same control word (encryption key).
4.10.4. ECM Generators ECM generator is provided by CAS supplier to produce ECM messages. • Name: Only used in web interface to easily identify separate ECMG servers • Channel ID <optional>: ‘ECM_channel_id’ used when communicating with ECMG. Some ECMGs require a specific value for this ID (info if necessary, from the CAS supplier).
Operation instructions | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N 4.10.6. EMM Configuration EMM contains CAS supplier private information which for example specifies the authorization levels of subscribers or groups of subscribers.
4.10.7. Program Scrambling at Phase 2 Programs will be connected to SCGs at Phase 2: Click the desired program to view its details. Select a Simulcrypt SCG from the drop-down list (it shows all configured SCGs). By default, all video and audio PIDs for the program are selected for the scrambling. ...
4.12. NMS (with MIS 1-11) A device can monitor up to five other devices and serve as a backup device for these devices. If certain configurable conditions apply (input error, output error, operating voltage error, etc.), then the backup device is switched to. Switching is only done if the backup device does not also fail.
Page 132
Operation instructions | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N A table lists the devices that are in the same subnet (in the example 192.168.0.xxx) Select the device to be monitored.
Note: Only with the software extension MKS 1-00 can the type be set to Manual and a Network Information Table (NIT) be read from the devices, edited, and uploaded back to the devices. The MKS 1-00 must be installed by AXING support (for this purpose, a connection with the Internet is necessary).
Operation instructions | MIE 8-00N | MIE 16-00N | MIE 32-00N | MIE 4-02N | MIE 8-02N | MIE 3-02N | MIE 6-02N Note: If necessary, you must reset the NIT before importing (see „Reset the NIT“ on page 65).
4.13.6. Upload NIT to the devices Select the devices you want to upload to. Click UPDATE. The data is uploaded and stored in the headend. 4.13.7. Reset the NIT Resetting the NIT is necessary in certain circumstances. Example: Three devices are used.
3.150 kg 3.670 kg Comments * with software extension MKS 1-02 only ** encrypted, cloud-based application for configuration, monitoring and remote maintenance 5.1.1. Deviating data MIE 8-00N/48, MIE 16-00N/48 | MIE 32-00N/48 Type MIE 8-00N/48 MIE 16-00N/48 MIE 32-00N/48 Operation voltage 36…60 VDC...
