Page 1
LCD TV Operating Instructions 操作手冊 KD-65X8500A / 55X8500A...
Page 2
(c) DTS Licensing Limited and DTS, Inc. 2012. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Sony Corporation is under license. Other trademarks and trade names are those of their respective owners.
Page 3
This television is designed for use in Hong Kong and ensured the usage in Hong Kong only. Location of the identification label Labels for Model No. and Power Supply rating (in accordance with applicable safety regulation) and Manufacturing date are located on the rear of the TV.
Page 4
About this manual (Operating Instructions) This manual explains how to set up your TV. For more information on how to use BRAVIA TV, refer to the “Electronic manual”. Operating Instructions Explains how to set up your TV such as connections, initial set-up, and basic operations.
Table of Contents Getting Started Checking the accessories................. 6 Inserting batteries into the remote control..........6 1: Attaching the Table-Top Stand ............. 7 2: Connections ..................8 3: Preventing the TV from toppling over..........10 4: Bundling the cables ................11 5: Connecting the TV to the Internet............
Getting Started Checking the Inserting batteries accessories into the remote control Remote Control (1) One-touch Remote Control (1) Size AAA batteries (R03 type) (4) Table-Top Stand (1)* Fixing screws for Table-Top Stand (M5 × 12) (4) Active 3D Glasses (Battery included) (4) Operating Instructions (this manual) and other documents * Refer to the supplied Table-Top Stand leaflet to...
1: Attaching the • Ensure that there are no objects in front of the Table-Top Stand 3D Sync Transmitter Refer to the supplied Table-Top Stand leaflet for proper attachment. IR Sensor Place the TV set on the Table-Top Stand. Detaching the Table-Top Stand from the TV To detach the Table-Top Stand from the TV, remove the screws...
14 mm in thickness. • Use an HDMI cable connector within 12 mm (thickness) × 21 mm (width). • Use Sony HDMI cable with “High Speed” indication for HDMI connection. • For more information on connections, refer to the i-Manual.
Page 9
Connecting an antenna (aerial)/cable Connecting audio/video and VCR devices Antenna (aerial) cable (not supplied) AV cable (not supplied) AV cable (not supplied) Antenna (aerial) Antenna (aerial) cable cable (not supplied) (not supplied) Antenna (aerial) cable (not supplied) DVD recorder (Continued)
3: Preventing the Connecting MHL device TV from toppling over Use authorized MHL 2 CABLE Install a machine screw (M4, not supplied) with MHL logo MHL device into the screw hole of the TV and tie with a (not supplied) strong cord (not supplied).
4: Bundling the 5: Connecting the cables TV to the Internet Before bundling the cables, remove the cable holder from the AC cover. Reuse the cable holder to bundle the other cables. When you connect this TV to the Internet, you can enjoy multiple functions.
6: Performing the Preparing a wireless LAN initial set-up The built-in wireless LAN device allows you to access the Internet and your home network. With this feature, you can connect to a wireless LAN and enjoy the benefits of networking in a cable-free environment.
Page 13
Press V/v/B/b to select an item, then press Follow the instructions on the screen. Programme Sorting: Changes the order of analogue channels stored in the TV. Press V/v to select the channel you want to move to a new position, then press Press V/v to select the new position for the channel, then press •...
Using Your BRAVIA TV Watching TV Turn on the TV. Press =/1 on the TV or remote control to turn on the Select a mode. Select a TV channel or select an input. To select digital channels Use 0-9. For channel numbers 10 and above, press the next digit quickly.
Page 15
Watching 3D contents This feature lets you experience powerful 3D entertainment, such as stereoscopic 3D games and 3D Blu-ray Disc. Refer to the i-Manual as well as the instruction manual supplied with the 3D glasses on how to set the 3D settings or watch the 3D contents. Frequently used buttons Subtitle setting You can turn subtitle on/off while watching digital...
Selecting various functions and settings (Home Menu) You can select the features of your TV from the Home menu. Here is an example on how to select an item and modify the TV settings. Press HOME. Press V/v to select “Settings” category.
Page 17
Category list Category The categories are available depending on your TV model, region and country. Featured Provides information on available applications and content. If there is no network connection, or the “Featured Display” setting is set to “Off”, the “Featured” category will not be displayed. History Displays recently viewed items.
Watching Internet Video This feature serves as a gateway to Internet content, delivering a variety of on-demand entertainment straight to your TV. You can enjoy video content, including movies and cartoons. You will need to make a broadband Internet connection. For details, see page 11 (5: Connecting the TV to the Internet).
Looking for Instructions Looking for instructions in the electronic manual (i-Manual) Operating instructions are built into your BRAVIA TV and can be displayed on the screen. To learn more about your TV features, access your i-Manual with the touch of a button. Press i-MANUAL.
Page 20
Saving frequently viewed Displaying the page again pages (Bookmark) while operating the TV You can save frequently viewed pages for easy You can switch between the i-Manual screen access anytime. and the TV screen. This feature allows you to refer to the instructions in the i-Manual while To save a page using your BRAVIA TV.
Press "/1 on the TV to turn it off, disconnect the AC power cord (mains lead), and inform your dealer or Sony service centre of how the indicator flashes (number of flashes). When the illumination LED is not flashing, check the items in the table below.
Installing the Accessories (Wall-Mount Bracket) To Customers: For product protection and safety reasons, Sony strongly recommends that installing of your TV be performed by Sony dealers or licensed contractors. Do not attempt to install it yourself. To Sony Dealers and Contractors: Provide full attention to safety during the installation, periodic maintenance and examination of this product.
Page 25
SU-WL500 Mounting Hook * After mounting the TV to the wall, tilt the TV to the front to detach the Stand Cover Screw (+PSW 6 × 16) from the TV. Stand Cover * • Attach the Mounting Hook using the four screws supplied with the Wall-Mount Bracket. •...
Page 26
Screws and Hook locations diagram/table Screw location Hook location Model Name KD- SU-WL500 SU-WL400 SU-WL500 SU-WL400 65X8500A d, g 55X8500A SU-WL500 Screw location Hook location When installing the Mounting Hook on the TV. When installing the TV onto the Base Bracket. SU-WL400 Hook location When installing the TV onto the Base Bracket.
Page 27
TV installation dimensions table SU-WL500 (1) Screen centre point SU-WL400 (2) Screen centre point (Continued)
Page 28
Unit: mm Screen centre Display dimensions Length for mounting Model Name dimension SU-WL500 65X8500A 1,478 SU-WL400 55X8500A 1,259 Figures in the table may differ slightly depending on the installation. When your TV is installed on the wall, the upper side of the TV slightly leans forward. WARNING The wall that the TV will be installed should be capable of supporting a weight of at least four times that of the TV.
AC power outlet shock or damage and/or injuries: (mains socket). Ventilation – Use only Sony supplied AC power • Place the TV set on a stable, level • Never cover the ventilation holes or cords (mains lead), not those of surface to avoid it from falling down insert anything in the cabinet.
• When using headphones, adjust the • Do not place the TV in a humid or Ask your dealer or Sony service centre dusty space, or in a room with oily volume so as to avoid excessive...
Page 31
• If this TV set is used in a cold place, a Optional Equipment smear may occur in the picture or the Keep optional components or any picture may become dark. This does equipment emitting electromagnetic not indicate a failure. These radiation away from the TV set.
Page 32
商標或註冊商標。 DLNA®、DLNA 標誌和 DLNA CERTIFIED® 是 Digital Living Network Alliance 的商標、服務標誌或認證標誌。 由 Dolby Laboratories 授權製造。 “BRAVIA” 是 Sony Corporation 的商標。 TrackID 是 Sony Mobile Communication AB 的商標或註冊商 標。 音樂辨識技術及相關資料由 Gracenote® 提供。Gracenote 是 音樂辨識技術和相關內容傳遞技術的業界標準。請前往 www.gracenote.com 瞭解有關詳情。 Gracenote,Inc. 提供的 CD、DVD、Blu-ray Disc 以及與音樂...
6: 執行初始設定 準備無線 LAN 內置無線 LAN 設備讓您存取網際網絡和您的家庭 網絡。此功能讓您連接無線 LAN 並享受無線網絡 環境的好處。設定電視機的無線 LAN 功能之前, 務必先設定無線 LAN 路由器。 電視機 無線路由器 數據機 網際網絡 將電視機連接至 AC 電源插座。 按電視機上的 "/1。發光 LED 亮起白燈。 在您第一次打開電視機時,螢幕上便會出現 語言選單。 • 當您首次打開電視機,電視機需要進行一些內 部處理以優化後,您才可執行初始設定。那時 將不會有圖像和聲音,而電視機前的發光 LED 閃白燈大約 40 秒。切勿在此過程進行時關閉 電視機。某些電視機在出廠前已經完成此過 程。 • LED 視電視機的狀態亮起不同的顏色。如果 您不要發光...
Page 45
觀看 3D 內容 此功能讓您體驗強勁的 3D 娛樂,如立體的 3D 電玩和 3D Blu-ray Disc。請參閱功能操作教學以及隨 3D 眼鏡提供的使用說明書有關如何設置 3D 設定或觀看 3D 內容。 經常使用的按鈕 字幕設定 您可在觀看數位廣播時開啟 / 關閉字幕。 2 AUDIO 觀看多聲道廣播時,您可選擇副伴音或次要語言。 3 彩色按鈕 當彩色按鈕有效時, 操作指南出現於螢幕上。 4 GUIDE 顯示節目表。 資訊 / 文字 顯示頻道號碼、節目詳情及時鐘。...
