Whirlpool ADP 8454 Quick Reference Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
GB
ADP 8454
Programme selector
Start button
Indicator lamp lit while the dishwasher is operating.
Flashes when a fault occurs.
Switches off at the end of the programme.
Programme Symbol
and Temperature
Crockery to be washed later.
Pre-wash
Lightly soiled crockery with no dried-on food.
Rapid 40° C
2)
Normally or heavily soiled crockery with dried-on food.
Bio- Eco 50° C
Recommended programme for heavily soiled crockery,
Intensive 70° C
especially pots and pans.
1)
Values may vary in relation to usage, e.g.: different loads, water temperatures
(above or below 15° C), water hardness and power supply voltage, etc.
2)
Programme recommended when using detergents of type B (enzyme-based detergents).
Reference programme for energy label.
Quick Reference Guide
Further indications are given in the pages to follow and in the user instructions.
Programme selection and
recommended load type
Place the detergent in the:
small compartment large compartment
-
-
-
X
X
X
X
X
(We reserve the right to make technical modifications)
1)
Consumption
Normal load
Water
Energy
Time
(Litres)
(kWh)
(Min.)
8.0
0.02
12
15.0
0.85
31
19.0
1.05
120
24.0
1.90
111
5019 100 91382

Advertisement

loading

Related Manuals for Whirlpool ADP 8454

Summary of Contents for Whirlpool ADP 8454

  • Page 1 Quick Reference Guide ADP 8454 Further indications are given in the pages to follow and in the user instructions. Programme selector Start button Indicator lamp lit while the dishwasher is operating. Flashes when a fault occurs. Switches off at the end of the programme.
  • Page 2 Upper and lower rack How to use the dishwasher 1. After loading the dishwasher, close the 6. Once the Start indicator lamp has Glass holder Lower rack door properly and open the water switched off, turn the programme • can be moved sideways. supply tap.
  • Page 3 Troubleshooting Guide Tips and advice • Before starting a wash programme, Crockery still dirty after washing make sure that the spray arms can turn • Arrange crockery so that items do not • Was the crockery loaded properly? AFTER-SALES freely and are not impeded by crockery touch each other.
  • Page 4 Dishwasher loading instructions UPPER RACK LOWER RACK Depending on the model, rack features may vary (see “Upper and lower rack” description).

  • Page 5: Table Of Contents

    CONTENTS BEFORE USING THE DISHWASHER PAGE PROTECTING THE ENVIRONMENT PAGE PRECAUTIONS AND GENERAL RECOMMENDATIONS PAGE CONNECTIONS PAGE HOW TO FILL THE SALT CONTAINER PAGE HOW TO FILL THE RINSE AID DISPENSER PAGE HOW TO FILL THE DETERGENT DISPENSER PAGE CARE AND MAINTENANCE PAGE To make the most of your new dishwasher, please read these user instructions and the quick reference guide carefully.

  • Page 6: Before Using The Dishwasher

    BEFORE USING THE DISHWASHER Removing the packaging and check 2. Water and electrical connections • All water and electrical connections must be carried out by a qualified technician in After unpacking, make sure that the compliance with the manufacturer's dishwasher is undamaged and that the door instructions (refer to the enclosed installation closes correctly.

  • Page 7: Connections

    CONNECTIONS Do not use the dishwasher if it has been damaged in transit. Consult your local retailer or our After-Sales Service. (Refer to the separate installation instructions booklet) Water inlet and drain: • Observe any special regulations issued by your local Water Board. •...

  • Page 8: How To Fill The Salt Container

    HOW TO FILL THE SALT CONTAINER From a water hardness category of 1-2 (average), before using the dishwasher, fill the salt container with regeneration salt (to find out the hardness level of water in your area, contact your local Water Board or check the last bill you received).

  • Page 9: How To Fill The Rinse Aid Dispenser

    HOW TO FILL THE RINSE AID DISPENSER The rinse aid facilitates drying and prevents the formation of unsightly spots and streaks on crockery. Before using the dishwasher for the first time, fill the rinse aid dispenser. How to fill the rinse aid dispenser: Only use rinse aids recommended for use in domestic dishwashers.

  • Page 10: How To Fill The Detergent Dispenser

    HOW TO FILL THE DETERGENT DISPENSER A small compartment and a large compartment are provided for the detergent. The use of detergent in excess of the recommended dosage may cause pollution. The recommended dosage varies for different brands. If you use detergents in pellet form, follow the manufacturer’s directions for use.

  • Page 11: Care And Maintenance

    CARE AND MAINTENANCE Before cleaning or carrying out maintenance, switch off the appliance and turn off the water tap. Cleaning the outside of the appliance: To clean the outside of the appliance, use a neutral detergent and a damp cloth. Do not use abrasive detergents.
