- Page 1 Cybex 19040/19050 Power Rack ® Owner’s Manual Strength Systems Part Number 19040-999-4 www.cybexintl.com...
- Page 3 Cybex logo are registered trademarks of Cybex International, Inc. DISCLAIMER: Cybex International, Inc., makes no representations or warranties regarding the contents of this manual. We reserve the right to revise this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such revisions or changes.
-
Page 5: Table Of Contents
Table of Contents Safety Safety ........7 Safety Guidelines and Practices ....8 Warning/Caution Decals . -
Page 7: Safety
Make sure that each machine is set up and operated on a solid level surface. Do not install • equipment on an uneven surface. CAUTION: Cybex is not responsible for the actual anchoring of equipment. Consult with a professional contractor. -
Page 8: Safety Guidelines And Practices
SECURING EQUIPMENT: The machine has holes in the feet, which allow for ease in anchoring to the floor. Cybex strongly recommends that, to eliminate rocking, tipping or falling over due to incorrect usage and misuse,... - Page 9 MAINTENANCE: Preventative maintenance allows proper equipment operation and reduces the risk of injury. Perform the maintenance requirements as specified in the manual. STANDARD COMPLIANCE: Cybex products meet or exceed applicable ASTM and EN Standards.
-
Page 10: Warning/Caution Decals
Cybex 19040/19050 Power Rack Owner’s Manual Warning/Caution Decals Warning decals indicate a potentially hazardous situation, which, if not avoided, could result in death or serious injury. Caution decals indicate a potentially hazardous situation, which, if not avoided, could result in minor or moderate injury. -
Page 11: Regular Maintenance Activities
Cybex 19040/19050 Power Rack Owner’s Manual Regular Maintenance Activities Preventative maintenance activities must be performed to maintain normal operation of this equipment. Keeping a log sheet of all maintenance actions will assist you in staying current with all preventative maintenance activities. - Page 12 Cybex 19040/19050 Power Rack Owner’s Manual...
-
Page 13: Exercise
Cybex 19040/19050 Power Rack Owner’s Manual Exercise Intended Use The intended use of this equipment is to aid or improve general physical fitness and exercise. For Comercial use. Before you workout Prior to starting a training program, get a complete physical exam to make sure your physician agrees that you are ready. - Page 14 Cybex 19040/19050 Power Rack Owner’s Manual...
-
Page 15: Customer Service
Hours of phone service are Monday through Friday from 8:30 a.m. to 6:00 p.m Eastern Standard Time. For Cybex customers living in the USA, contact Cybex Customer Service at 888-462-9239. For Cybex customers living outside the USA, contact Cybex Customer Service at 508-533-4300 or fax 508-533-5183. Find information on the web at www.cybexintl.com... -
Page 16: Return Material Authorization (Rma)
Provide the model and serial number of your Cybex equipment. At Cybex’s discretion, the technician may request that you return the problem part(s) to Cybex for evaluation and repair or replacement. The technician will assign you a RMA number and will send you an ARS label. -
Page 17: Damaged Parts
Cybex 19040/19050 Power Rack Owner’s Manual Damaged Parts Materials damaged in shipment should not be returned for credit. Shipping damages are the responsibility of the carrier (UPS, Federal Express, trucking companies, etc.) Apparent Damage - Upon receipt of your shipment, check all items carefully. Any damage seen with a visual check must be noted on the freight bill and signed by the carrier’s agent. - Page 18 Cybex 19040/19050 Power Rack Owner’s Manual...
-
Page 19: Assembly
W x L - 70” (177 cm) W x 74” (188 cm) L Height - 19040 - 109” (277 cm); 19050 - 97.5” (248 cm) Weight - 19040 - 900 lbs (409 kg); 19050 - 895 lbs (407 kg) NOTE: Three people will be required for this procedure. - Page 20 Cybex 19040/19050 Power Rack Owner’s Manual WARNING: Use extreme caution when removing from pallet. Failure to do so could result in injury. Move to desired location and unpack. Remove items from pallet in the order shown on the following diagram Carefully handle parts to prevent damage to paint or frame.
- Page 21 Cybex 19040/19050 Power Rack Owner’s Manual Assemble Rack in area it will be used.. Attach Upper Side to both sides. Attach bottom cross to both sides. Using a step ladder, carefully attach Upper Cross to both sides. Carefully attach Upper Handle Bar to both sides.
- Page 22 Cybex 19040/19050 Power Rack Owner’s Manual Attach Spotter Stands to Bottom Cross. Securely tighten all screws to 450 - 500 inch/ pounds. With Out (4x) Optional Platform F, G, H (4x) (4x) F, G, H (1x) (2x) (4x) Spotter Stand...
- Page 23 Attach Adjustable Bar Stops (D) to desired position. Attach each Bar Catch (I and J) to desired position. Securely anchor machine to the floor using the anchor holes provided in each machine. CAUTION: Cybex is not responsible for the actual anchoring of equipment. Consult with a professional contractor. WARNING: Use fasteners having a minimum of 500 lbs. tensile capacity (3/8’’ grade 2 bolts or better).
- Page 24 Cybex 19040/19050 Power Rack Owner’s Manual...
-
Page 25: Maintenance
Maintenance All preventive maintenance activities must be performed on a regular basis. Performing routine preventive maintenance actions can aid in providing safe, trouble-free operation of all Cybex Strength Systems equipment. NOTE: Cybex is not responsible for performing regular inspection and maintenance actions for your machines. - Page 26 Cybex 19040/19050 Power Rack Owner’s Manual decals. Replace all worn labeling immediately.
- Page 28 10 Trotter Drive Medway, MA 02053 508-533-4300 FAX 508-533-5183 • • www.cybexintl.com • techhelp@cybexintl.com...
