EN
WINE CABINET - INSTRUCTION MANUAL
Models: WSD49, WSD70, WCS15, WCD30-700, WCD30,
WCD30-800, WCS30PS-700, WCD30-780, WCD40-700,
WCD40-800, WCED40PRP-780, WCD50-700, WCD60-700, WCD60,
WCD60-800, WCD60P-700, WCD60P, WCDD60, WCED60PRP-780,
WCED187, WE2D60, WCS60PS-700, WCD60-780, WCD187H, WKES23P,
WKED25P, WKED25PRP, WKD25, WKD49, WKD70, WKED112P,
WKED112PRP, WSTO78T, WSTO82, WSTO126, WSTO215, WSTO226,
VCS154, VCS156, VCS200, VCS204, VCS240, VCS273, VCS280
Please read this manual carefully before installing and starting up, and store it in a safe place. If
you pass on the product to another person, hand over this instruction manual along with it.
Lindström & Sondén AB, Havsbadsvägen 1, 262 63 Ängelholm, Sweden
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for mQuvee WSD49
Summary of Contents for mQuvee WSD49
- Page 1 WINE CABINET - INSTRUCTION MANUAL Models: WSD49, WSD70, WCS15, WCD30-700, WCD30, WCD30-800, WCS30PS-700, WCD30-780, WCD40-700, WCD40-800, WCED40PRP-780, WCD50-700, WCD60-700, WCD60, WCD60-800, WCD60P-700, WCD60P, WCDD60, WCED60PRP-780, WCED187, WE2D60, WCS60PS-700, WCD60-780, WCD187H, WKES23P, WKED25P, WKED25PRP, WKD25, WKD49, WKD70, WKED112P, WKED112PRP, WSTO78T, WSTO82, WSTO126, WSTO215, WSTO226, VCS154, VCS156, VCS200, VCS204, VCS240, VCS273, VCS280 Please read this manual carefully before installing and starting up, and store it in a safe place.
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. IMPORTANT SAFEGUARDS 1.1 For your safety 2. DISPOSAL 3. CONNECTION TO THE MAINS SUPPLY 4. PRODUCT FEATURES 5. INSTALLATION 5.1 Before using your appliance 5.2 Installation of your appliance 5.3 Electrical connection 5.4 Installing the handle 5.5 Reversing the door hinge 5.6 Anti-tip bracket installation 5.7 Securing the appliance... -
Page 3: Important Safeguards
1. IMPORTANT SAFEGUARDS When using an electrical appliance, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1.1 For your safety Read all instructions carefully, even if you are quite familiar with the appliance. •... - Page 4 • The use of attachments not recommended by the manufacturer may be hazardous. • Place the unit on a dry level surface. • Do not operate if the housing is removed or damaged. • A loose fit between the AC outlet (receptacle) and plug may cause overheating and a distortion of the plug.
- Page 5 • CAUTION! Please keep the products away from the fire or similar glowing substance before you dispose the appliance. • WARNING! Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance. • WARNING! When position the appliance, ensure the supply cord is not trapped or damaged.
-
Page 6: Disposal
• Replace all panels after service before operating. • WARNING! Glass breakage. Danger of injury from broken glass. If installed at altitudes above 1500m there is a risk of the glass in the door breaking because of changes in air pressure. -
Page 7: Connection To The Mains Supply
themselves in the appliance during play (risk of suffocation) or endangering their lives in any other way. DO NOT dispose of the appliance in landfill as the insulation (Cyclopentane) and refrigerant gas (R600a) contained in these appliances are flammable. Disposal instructions: •... -
Page 8: Product Features
YELLOW wire is the EARTH and must be connected to the terminal which is marked with or coloured GREEN or GREEN/YELLOW. the letter ‘E’ or by the earth symbol The BLUE wire is the NEUTRAL and must be connected to the terminal which is marked with the letter ‘N’... -
Page 9: Installation
• Automatic defrosting with defrost water evaporation. • Reversible tempered double/triple pane gray glass door protects your wine from UV light and creates an attractive display with minimal condensation and low noise. • Black coated matte steel outer frame and black plastic interior liner offer lifetime performance and stability. - Page 10 • WARNING! Do no install the appliance in the laundry. Avoid locating the unit in damp areas. • Place your appliance on a floor/surface that is strong enough to support it when it is fully loaded. To level your unit, adjust the front leveling leg at the bottom of the unit. •...
- Page 11 NOTE! When pushing the appliance into the niche, make sure that the mains cable does not get trapped. A (mm) B (mm) C (mm) D (mm) 15 cm wide 455/440 75/115 30 cm wide 440/460 115 40 cm wide 50 cm wide 60 cm wide 440/460 115 NOTE!
- Page 12 5.2.2 FULLY INTEGRATED BUILT-IN-COLUMN INSTRUCTIONS RISK OF DAMAGE! The wine cabinet has an elongated glass door and must not be set down vertically at any time! DESIGN 1 – The unit door seals the installed unit almost completely, so an air vent must be provided in the base of the housing.
- Page 13 Aperture A (mm) B (mm) C (mm) 45 cm H 60 cm H 590-593 68 cm H 680-685 88 cm H 877-880 102 cm H 1033 1020 1022-1025 105 cm H 1055 1048 1050 122 cm H 1234 1224 1226-1230 140 cm H 1411 1398...
-
Page 14: Electrical Connection
5.2.3 BUILT-IN CABINETRY INSTRUCTIONS Make sure your installation does not block the front ventilation grille. And be sure the door will open and close properly in the chosen location. a (mm) b (mm) c (mm) 1476 1768 1768 125S 1820 170S 1820 1820... -
Page 15: Installing The Handle
The appliance must not be connected to an inverter and must not be used with a plug adapter as these can cause damage to the appliance’s electronic unit. The cord must rest securely behind the appliance and not be allowed to lie or hang unprotected. - Page 16 DESIGN 1 – For built-under models 1. Remove the bottom hinge (1) by unscrewing the four lock screws (2). Be careful to hold the glass door firmly after removing the screws. (Fig. 1) 2. Gently pull down to remove the glass door from the right top hinge and place it on a padded surface to avoid the risk of damage.
- Page 17 DESIGN 2 – For fully integrated models 1. Remove the glass door by unscrewing the eight lock screws (3) and (4). Be careful to hold the glass door firmly after removing the screws and place it on a padded surface to avoid the risk of damage.
- Page 18 DESIGN 3 – For tall models 1. Remove the right bottom hinge (2) and/or left bottom hinge (1) by unscrewing the eight lock screws (3). Be careful to hold the door (4) firmly after removing the screws. (Fig. 1) 2. Gently pull down to remove the door from the right top hinge and place it on a padded surface to avoid the risk of damage.
- Page 19 DESIGN 4 – For vertical double door models 1. Remove the right bottom hinge (1) by unscrewing the four screws (2). Be careful to hold the lower glass door (3) firmly after removing the screws. And then gently pull down to remove the lower glass door from the middle hinge and place it on a padded surface to avoid the risk of damage.
- Page 20 10. Recheck and adjust the lower door alignment by loosening the screws (8) & (9) and moving the door adapter (7) & (10). Tighten the screws (8) & (9) after the door is levelled. 11. Transfer the handles and plugs to the opposite positions. DESIGN 5 –...
-
Page 21: Anti-Tip Bracket Installation
DESIGN 6 – For freestanding models 1. Remove the bottom hinge (3) by unscrewing the four lock screws (4). Be careful to hold the glass door firmly after removing the screws. (Fig. 1) 2. Gently pull down to remove the glass door from the right top hinge and place it on a padded surface to avoid the risk of damage. -
Page 22: Securing The Appliance
• Use an 8mm / 5/16” masonry drill bit and insert plastic anchors. • Secure bracket to floor using screws. • Slide appliance into position and make sure the leg engages the anti-tip bracket. NOTE! If the unit is relocated, the bracket must be removed and installed in the new location. -
Page 23: Operating Your Appliance
6. OPERATING YOUR APPLIANCE This appliance is designed for operation at certain ambient temperatures. The climatic class is specified on the rating plate. The appliance may not work properly if it is left for a long period at a temperature outside the specified range. - Page 24 NOTE! Touching any key once can switch off the audible alarm when the alarm is on. LIGHT - To turn the interior light on/off, lightly touch and hold the key for 5 seconds. The interior light indicator will light up or go out to confirm the selection. - Used to increase (warm) the set temperature by 1°C/1°F.
-
Page 25: Use And Control - Single Zone With Lcd Display
6.2 Use and control - single zone with LCD display The Controls of Your Unit Power - To turn the appliance off, lightly touch and hold the key for 5 seconds until temperature display goes out. To turn the appliance on, lightly touch and hold the key for 1 second until temperature display lights up. - Page 26 Multi-key Function To perform the multi-key function, lightly touch and hold the first key, then touch the rest key for at least 5 seconds and then release all the keys. Child Lock (Only for models with outside controls) If in 2 minutes or longer without touching any key, the child lock will be activated automatically.
-
Page 27: Use And Control - Dual Zone With Led Display
• When 00% is selected, the humidity pump will be switched off. The humidity pump increases the energy consumption of the unit. If the function is not necessary, please switch it off. The rated energy consumption is based on the function is switched off. 6.3 Use and control - dual zone with LED display The Controls of Your Unit POWER... -
Page 28: Use And Control - Dual Zone With Lcd Display
• When the unit is plugged in for the first time, the unit will power up automatically to the preset defaults. The preset temperature at the factory for UPPER/LEFT temperature zone is 8°C (46°F) and for LOWER/RIGHT temperature zone is 12°C (54°F). •... - Page 29 DOWN - Used to decrease (cool) the set temperature by 1°C/1°F. Setting Selector - Select the temperature and humidity you want to set. Symbols in the Display Temperature or Error code display for upper/left zone. Temperature or Error code display for lower/right zone. Compressor is ON Heater is ON Defrosting mode...
-
Page 30: Use And Control - Three Zone With Lcd Display
• Touch the Setting Selector until the temperature you want to set is flashing. Then you can use the UP and DOWN keys to set the internal temperature as required. When you touch either key at the first time, the display will show the last temperature set previously. - Page 31 NOTE! Touching any key once can switch off the audible alarm when the alarm is on. °F/°C SELECTOR - Set the temperature to be displayed in degree Fahrenheit or degree Celsius. LIGHT - To turn the interior light on/off, lightly touch and hold the key for 5 seconds.
-
Page 32: Settings Mode
• The temperature settings of UPPER zone are adjustable with the range 11°-20°C (52°- 68°F ) which is ideal for serving red wine. The preset temperature at the factory is 18°C (65°F ). The temperature settings of MIDDLE zone are adjustable with the range 5°-11°C (41°- •... - Page 33 ºF/ºC Selection • Lightly touch and hold the UP key for 5 seconds to enter Settings mode. • Use the UP and DOWN keys to select the temperature display setting in Fahrenheit or Celsius degree. • Touch and hold the UP key for 5 seconds to confirm the selection. Display Brightness •...
- Page 34 Audible Tones • Lightly touch and hold the UP key for 5 seconds and then touch the POWER key four times. • Use the UP and DOWN keys to select the audible tones. » S0: sensor tone ON, alarm tone OFF »...
- Page 35 The audible alarm will be automatically silenced, the temperature display stops flashing (And the symbols & will go out for models with LCD Display) when the set temperature is reached again. However, if the noise disturbs you, you can switch the audible alarm off before this if you wish by touching the POWER key once.
- Page 36 position, the push piston is flush with the front of cabinet. In order to set the push piston back in its initial position, disconnect the appliance from the mains, wait for approx. 10 seconds and plug it back in again. The push piston will return to its initial position. •...
-
Page 37: Different Modes
6.7 Different modes Dynaclima/silent mode The appliance has two different running modes: DynaClima and Silent mode. This DYNACLIMA (Dynamic Climate) mode enables the relative humidity inside the unit and the temperature to be distributed evenly around the interior so you can store all your wine under exactly the same excellent conditions. -
Page 38: Bottle Loading, Noises And Hygometry
seasons of high humidity, simply switch on the mode. The condensation will disappear shortly. The mode increases the energy consumption of the wine cellar, if this mode is not needed, please switch it off. The switch is located on the control panel. I is ON and O is OFF. - Page 39 • Do not cross contaminate. Store only wine in your unit to ensure that the environment is odor free. • Only store wine in unopened bottles. Storing opened bottles may result in spillage. Operating noises The unit is cooled by a compressor (refrigeration aggregate). The compressor pumps coolant through the cooling system, producing operating noise.
- Page 40 The appliance is not totally sealed: fresh air admission is permitted through the drainpipe and/or air exchange pipe. Air is circulated through the unit by means of a fan / fans and the open shelves. NOTE! Frost may be accumulated on the evaporator if the unit is repeatedly opened in a high heat or high humidity location.
-
Page 41: Care And Maintenance
Fine wines require long and gentle developments and need specific conditions in which to reach their full potential. All wines mature at the same temperature, which is a constant temperature set between 11°C to 14°C. Only the temperature of “dégustation” (wine appreciation) varies according to the type of wines (see the Wine Serving Temperature Chart as above). - Page 42 In order to replace the shelf, align the left and right slide channels with the tracks in the cabinet. Ensuring an even track engagement on both sides, gently push the shelf into the cabinet until the tabs lock into place. NOTE! Make sure the tabs on the full extension shelf guides are fully engaged before loading any bottles.
- Page 43 or from the Spare Parts Department. 1. Remove the shelf in front of the filter. 2. Grip the filter and turn it 90°clockwise or anti-clockwise to remove. 3. Insert the new filter in the vertical position and turn it 90° clockwise or anti-clockwise until it clicks into position.
-
Page 44: Problems With Your Appliance
NOTE! Irrespective of the cause, if you notice either abnormal temperature or humidity levels inside your unit, be reassured that only long and frequent exposure to these abnormal conditions can cause a detrimental effect on your wines. Vacation time • Short holidays: Leave the unit in operation for holidays of less than three weeks. -
Page 45: Troubleshooting Guide
8.1 Troubleshooting guide PROBLEM POSSIBLE CAUSE REMEDY Nothing works. • Appliance is not connected to a power • Connect the appliance. supply. Appliance does not operate. • Switch on the appliance. • The appliance is turned off. • Switch on circuit breaker or •... - Page 46 The appliance seems to make • Thefattling noise may come from the flow of the refrigerant, which is too much noise. normal. As each cycle ends, you may hear gurgling sounds caused by the flow of refrigerant in your appliance. •...
- Page 47 Condensation on outside • High humidity climate. • During periods of surfaces of glass door. high humidity, some condensation may appear on outside surfaces of glass door. It will disappear when humidity levels drop. It is advisable to install the appliance with sufficient ventilation in a dry and/or an air-conditioned place.
-
Page 48: Warranty
9. WARRANTY The statutory warranty period applies. If the product is defective, please contact your local distributor. In case you need any services, please include the following documents when you send in the device: • A copy of the receipt with purchasing date. •...
