JNS Aquaria FR-1ES Installation Manual

Fluidized GFO and Carbon Filter Media Reactor
Installation Guide
Recommendations
1.
While we take great care to keep any contaminates away from our products
during assembly, please take a moment to clean the reactor and plumbing
before attaching to your tank. Only clean your reactor with warm water. Never
clean Acrylic with alcohol based products. Use caution when handling as
acrylic scratches easily.
2.
Please keep in mind that a media reactor is intended to be a bypass filter, and
is not designed to handle the complete flow and pressure requirements of a
large aquarium system.
3.
Some media (such as phosphate control products) is not designed to be
aggressively fluidized in a reactor – please read the instructions on your media
carefully.
4.
The reactor should be cleaned out every time that the media is replaced
ensuring that there is no media below the bottom plate.
FR-1ES / FR-1E / FR-2E / FR-2ED
Includes:
FR-1E / FR-2E / FR-2ED
3/4" (20 mm) hose barbs
FR-1ES
1/2" (13 mm) hose barbs
Main Body *1
Accessories:
- FR-1ES:
*2 *2
*1
- FR-1E / FR-2E: *2 *2 *1
- FR-2ED: *4
*4 *2
Filling Your Media
1
Loosen the thumb screws. Turn lid counterclockwise to release.
2
( Only if you need to switch the hosebarbs from 20 mm to 13 mm)
The included hosebarbs could be switched from 3/4" to 1/2", just unscrewing the
hosebarbs' fasteners from beneath the lid, then pressing the hosebarb upward
out of their hexagonal recess.
Multiple ways to set!
One and Only
Unique design of inlet and outlet could be set in multiple ways, could be
suitable for any tubing.
O-ring
Don't forget
to switch
the O-rings!
