- Page 1 RW-2502V VHF WIRELESS MICROPHONE SYSTEM USER’S MANUAL...
- Page 2 The receiver unit, features with quartz controlled fixed frequency VHF high band, is compatible with our wireless microphone series for dual or multi channels use. This series applies tone code squelch design to avoid interference from outside signal and noise.
- Page 3 (1) Power Switch (2) CH-A Volume Control (3) CH-B Volume Control 2. Back Panel 8 ( ) (7) DC Power Input (8) Unbalanced Output (9) Balanced Output 2. Microphone Parts （1） （2） （3） （4） （5） U H F V H F （1）Mesh...
- Page 4 1.Frequency Range: VHF 170~250 MHZ; UHF 400~500 MHZ. 2.Frequency Stability: ±0.005% quartz oscillation controlled, with temperature stabilizer. 3.Modulation (Max): ±15KHZ. 4.Frequency Response: 50Hz~18KHz±3dB. 5.Hum & Noise: 100dB min. 6.Dynamic Range: 100dB min. 7.Distortion: less than 0.5%. 1.Antenna: built-in with noise terminator circuit. 2.Battery: DC9V.
- Page 5 5、 Insert attached 9 V battery into wireless microphone's battery compartment, and then close the cover. 6、 Turn on microphone power switch (2), power LED indicator (3) will light, low battery LED indicator (4) will flash once then off , this indicates that microphone is ready to use.
- Page 6 One receiver cannot receive signal from two same frequency microphones simultaneously. Other microphone with different frequency or brand cannot be used for this receiver. To prevent hurt from heavy article dropping, do not put heavy article on the top of this equipment.
- Page 7 17202 Marquardt Ave., CA 90703 www.mediasynccorp.com Tel: 562)404-9950 Fax: 562)404-9951...
