- Page 1 USER MANUAL ENGLISH VT202 - 4K-HDMI/USB KVM Fibre Extender Set (TX/RX) Product code: 101242 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
- Page 2 VT202 - 4K-HDMI/USB KVM Fibre Extender Set (TX/RX) Preface Thank you for purchasing this DMT product. The purpose of this user manual is to provide instructions for the correct and safe use of this product. Keep the user manual for future reference as it is an integral part of the product. The user manual shall be stored at an easily accessible location.
-
Page 3: Table Of Contents
VT202 - 4K-HDMI/USB KVM Fibre Extender Set (TX/RX) Table of contents Introduction ................................3 Before Using the Product ..........................3 Intended Use ............................... 3 Product Lifespan ..............................3 Text Conventions ..............................3 Symbols and Signal Words ..........................4 Symbols on the Information Label ........................4 Safety .................................. -
Page 4: Introduction
VT202 - 4K-HDMI/USB KVM Fibre Extender Set (TX/RX) Introduction Before Using the Product Important Read and follow the instructions in this user manual before installing, operating or servicing this product. The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual. -
Page 5: Symbols And Signal Words
VT202 - 4K-HDMI/USB KVM Fibre Extender Set (TX/RX) Symbols and Signal Words Safety notes and warnings are indicated throughout the user manual by safety signs. Always follow the instructions provided in this user manual. Indicates an imminently hazardous situation which, if not avoided, will result in DANGER death or serious injury. -
Page 6: Safety
VT202 - 4K-HDMI/USB KVM Fibre Extender Set (TX/RX) Safety Important Read and follow the instructions in this user manual before installing, operating or servicing this product. The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual. -
Page 7: Requirements For The User
VT202 - 4K-HDMI/USB KVM Fibre Extender Set (TX/RX) Attention This device shall be used only for the purposes it is designed for. This device is designed to be used as an HDMI fibre-optic extender. Any incorrect use may lead to hazardous situations and result in injuries and material damage. -
Page 8: Description Of The Device
VT202 - 4K-HDMI/USB KVM Fibre Extender Set (TX/RX) Description of the Device The DMT VT202 - KVM HDMI/USB Fibre Extender Set enables sending HDMI and USB signals over long distances. The set consists of a transmitter and a receiver that communicate through a fibre-optic cable. -
Page 9: Product Specifications
VT202 - 4K-HDMI/USB KVM Fibre Extender Set (TX/RX) Product Specifications Model: VT202 - 4K-HDMI/USB KVM Fibre Extender Set (TX/RX) Electrical (TX/RX): Input voltage: 5 V DC Input current: Power consumption: 3,2 W Physical (TX/RX): Dimensions: 108 x 77 x 27 mm (L x W x H) -
Page 10: Dimensions
VT202 - 4K-HDMI/USB KVM Fibre Extender Set (TX/RX) Dimensions Transmitter (TX) Receiver (RX) Fig. 08 Installation and Setup Warnings and Precautions Attention Connect all data cables before supplying power. Disconnect power supply before connecting or disconnecting data cables. Installation Site Requirements The device must be installed only indoors. -
Page 11: Mounting
VT202 - 4K-HDMI/USB KVM Fibre Extender Set (TX/RX) Mounting The devices can be placed on a flat surface or mounted to a display or a monitor. The devices are supplied with a set of 2 mounting brackets. You need a Phillips screwdriver. -
Page 12: Setup Example
VT202 - 4K-HDMI/USB KVM Fibre Extender Set (TX/RX) Setup Example This a typical setup of a VT202 - 4K-HDMI/USB KVM Fibre Extender Set (TX/RX) and external devices. Fig. 11 To connect the extender set (transmitter and receiver) to other devices in a setup, follow the steps below: Connect the input device (a personal computer or a laptop) to the HDMI signal connector IN (01) or the USB-B connector (02) on the transmitter. -
Page 13: Connecting To Power Supply
VT202 - 4K-HDMI/USB KVM Fibre Extender Set (TX/RX) Connecting to Power Supply Attention Incorrect handling of the AC power adapter may result in hazardous situations This device is delivered with an AC power adapter. Incorrect handling of the AC power adapter may result in hazardous situations. -
Page 14: Troubleshooting
VT202 - 4K-HDMI/USB KVM Fibre Extender Set (TX/RX) Troubleshooting This troubleshooting guide contains actions which can be carried out by the user. The device does not contain user-serviceable parts. Unauthorized modifications to the device will render the warranty void. Such modifications may result in injuries and material damage. -
Page 15: Deinstallation, Transportation And Storage
VT202 - 4K-HDMI/USB KVM Fibre Extender Set (TX/RX) Deinstallation, Transportation and Storage ● Disconnect power supply before deinstallation. ● Use the original packaging to transport the device, if possible. ● Always observe the handling instructions printed on the outer carton box, for example: “Handle with care”, “This side up”, “Fragile”. - Page 16 ©2023 DMT...
