Summary of Contents for Anlapus V2.C.06.A
- Page 1 Security Camera Day/Night V2.C.06.A INSTRUCTION MANUAL...
-
Page 2: Before Installation
Statement Thank you for purchasing this product. Anlapus is committed to providing our customers with a high quality, reliable security solution. Anlapus cannot assume responsibility for any consequences resulting from the use thereof. Before Installation This product require cabling. It is strongly suggested to test all products and parts before installation and cabling. -
Page 3: Product Overview
Product Overview Infra-red LEDs Camera Lens Light Sensor Video Connector Power Connector Mounting Plate Dome Base Dome Cover Dome... -
Page 4: Mounting Plate
Mounting your camera Step 1: Separate the Mounting Plate from Dome Base twisting the Mounting Plate in a counterclockwise motion. Mounting Plate Dome Base... - Page 5 Dome Base. Step 2: Remove the Dome Base Step 3: Remove the Dome Cover Dome Mounting Plate Dome Dome Cover...
- Page 6 Mounting Plate to the ceiling or wall in the Step 4: Install the position with the supplied screws. Mounting Plate Note: The cable should be through the Mounting Plate.
- Page 7 Step 5: Attach the Dome Dome Cover to the Mounting Plate. Mounting Plate Dome Cover Dome...
- Page 8 Dome Base Mounting Plate,then Step 6: Attach the to the twisting Dome Base in a counterclockwise motion until hear the “ lock” sound. Mounting Plate Dome Base Note: The cable should be fixed on the slot hole.
- Page 9 Positioning the cables AUDIO OUT VIDEO IN AUDIO IN ① Connect camera to DVR via BNC cable. ② Connect monitor to DVR via HDMI cable or VGA cable.
- Page 10 ③ Connect DVR to router via Ethernet cable. ④ Connect mouse to USB port on DVR, then power on DVR and cameras. NOTE: The picture shown is for your reference only. Please adhere to the actual product instead. FAQs Q: Video Loss appears where the image from my camera should be displaying on my DVR? A: 1.
- Page 11 E-Mail: anlapus@ansjer.com All rights reserved. No part of this publication may be reproduced by any means without written permission from Anlapus. The information in this publication is believed to be accurate in all respects. Anlapus cannot assume responsibility for any consequences resulting from the use thereof.
