LG XH-T5020X Service Manual page 48

11. ES6698FD VIDEO OUTPUT WAVEFORMS
1) Full colorbar signal(COMPOSIT)
Copyright © 2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes
FIG 10-2(CD)
FIG 11-1
3-19
CD_DVDCT(IC501 PIN 169)
TRO(IC501 PIN 210)
TR-(IC401 PIN 12)
TR+(IC401 PIN 11)
(IC501 PIN 134)
