Nitecore EMR06 - Electronic Multipurpose Repeller Manual

Product Introduction

Read all instructions before use.
This product is intended for adult use only. This product is not a toy.

The EMR06 is specially designed for outdoor activities, such as outdoor work, camping, fishing, trekking and more.

Specifications

Note: Mosquito repellent mats are optional.

Charging

Connecting to the External Power
Use the USB cable to connect an external power supply (e.g. a USB adapter, a power bank or other USB charging devices) to the USB charging port to begin the charging process (Input: 5V⎓1A).

• When the EMR06 is off and in charging, the Power Indicator will flash green to inform the user.
• When the EMR06 is fully charged, the Power Indicator will turn green and become steadily turned on.

Note: When using the mosquito repelling function during the charging process, the Power Indicator will turn blue steadily while flashing green to indicate the charging status.

Mosquito Repelling Function

• On: When the EMR06 is off, short press and then long press the Power Button to activate the mosquito repelling function, after which the Power Indicator will turn blue and become steadily turned on.
• Off: When the EMR06 is on, long press the Power Button to turn off the mosquito repelling function, and the indicator will go off.

Power Indication

Double press the Power Button, and the Power Indicator will flash green to indicate the battery voltage (±0.1V). For example, when the battery voltage is at 3.7V, the Power Indicator will flash green 3 times followed by a 1-second pause and 7 more flashes.

Note: When the EMR06 is on, the Power Indicator will flash quickly to indicate the low power.

Using the EMR06

1. When the EMR06 is off, insert 1 repellent mat into the Repellent Mat Placement Area.
2. Short press and then long press the Power Button to activate the mosquito repelling function.
3. The protection zone will be created after 10 minutes.
4. After use, long press the Power Button to turn off the mosquito repelling function. Please store the EMR06 after cooling completely.

Note: NITECORE Mosquito Repellent Mat Size: 34mm x 48mm / 1.34'' x 1.89'' (up to 6 hours each)

Mosquito Repellent Mat Replacement

Make sure the EMR06 is off and cooled. Insert a new repellent mat while pushing out the used one.

EMR06 Placement

• Place the EMR06 upwind of the mosquito repellent area if it is windy.
• DO NOT cover the EMR06 when using it.
• It is recommended to use multiple EMR06 together to create a larger protection zone.

Warnings

1. The product is designed to be used by adults. Please keep it out of reach of children.
2. Children under 16 years old must be under adult supervision when using this product to prevent scalds and accidents.
3. DO NOT leave the product unattended when it is in use. Stop using the product at any sign of malfunction.
4. DO NOT touch the heating area while using the mosquito repelling function.
5. Please store the product in a dry area at room temperature when not in use.
6. Please recharge the product every 3 months when left unused for a prolonged time.
7. DO NOT place the product in water.
8. DO NOT put your fingers, metals, or foreign matters into the product to avoid accidents or damage.
9. DO NOT use the product in a confined space.
10. Stop using the product and dispose of it immediately if there is any leakage, odor, or deformation in the battery.
11. DO NOT expose the product to temperatures above 60°C (140℉) for a long time.
12. DO NOT disassemble or modify the product without authorization, as this will cause the warranty to be nullified. Please check the Warranty Service for details.
13. Dispose of the device/batteries in accordance with applicable local laws and regulations.

Warranty Service

All NITECORE^® products are warranted for quality. Any DOA / defective product can be exchanged for a replacement through a local distributor/ dealer within 15 days of purchase. After that, all defective / malfunctioning NITECORE^® products can be repaired free of charge within 12 months from the date of purchase. Beyond 12 months, the charge for accessories, replacement parts and delivery shall be at your own expenses.

The warranty will be nullified if

1. the product(s) is/are broken down, reconstructed and/or modified by unauthorized parties.
2. the product(s) is/are damaged due to improper use.

For the latest information on NITECORE^® products and services, please contact a local NITECORE^® distributor or send an email to service@nitecore.com.

※ The trademarks and product images specified herein this user manual are for reference purposes only. The copyright belongs to their lawful holders.
※ All images, texts and statements specified herein this user manual are for reference purposes only. Should any discrepancy occur between this manual and information specified on www.nitecore.com, Sysmax Innovations Co., Ltd. reserves the rights to interpret and amend the content of this document at any time without prior notice.

Customer Service Email: service@nitecore.com
www.nitecore.com
