IMPORTANT – READ CAREFULLY – RETAIN FOR FUTURE REFERENCE
A) WARNING – The upper bed of bunk beds are not suitable for children under
six years old due to the risk of injury from falls.
B)
WARNING – Bunk beds can present a serious risk of injury from
strangulation if not used correctly. Never attach or hang items to any part of the
bunk bed that are not designed to be used with the bed, for example, but not
limited to ropes, strings, cords, hooks, belts and bags.
C)
WARNING – children can become trapped between the bed and the wall, a
roof pitch, the ceiling, adjoining pieces of furniture (e.g. cupboards) and the like.
To avoid risk of serious injury the distance between the top safety barrier and the
adjoining structure shall not exceed 75mm or shall be more than 230mm.
D) WARNING – Do not use the bunk bed if any structural part is broken or
missing.
E)
Always follow the manufacturer's instruction.
F)
Recommended size of mattress: upper bed: 90 x 190cm and lower bed: 90
x 190cm
G)
Maximum thickness of mattress
H)
Periodically check and ensure that the guardrails, ladder, and other
components are in their proper position, free from damage. Also, make sure the
connectors are tight and secure.
I)
Ventilation of the room is necessary in order to keep the humidity low and
to prevent mould in and around the bed
J)
This item meets the
cm.
test standards

Advertisement

loading

Summary of Contents for Bedkingdom Flair Tetrad

  • Page 1 IMPORTANT – READ CAREFULLY – RETAIN FOR FUTURE REFERENCE A) WARNING – The upper bed of bunk beds are not suitable for children under six years old due to the risk of injury from falls. WARNING – Bunk beds can present a serious risk of injury from strangulation if not used correctly.
  • Page 2 P 01...
  • Page 3 EXPLODED VIEW P 02...
  • Page 4 HARDWARE B x40 C x44 E x2 M6x90 Φ8x30 M6x70 F x8 G x15 H x2 J x4 Φ3.5 x16 Φ6x 60 Φ4 x25 Φ7x6 0 Φ12x80 L x2 M x4 N x10 P x6 Q x64 M6 x60 M6x5 0 Φ3x 30 M6x30 R x2...
  • Page 5 01-1 C x30 Φ8x30 P 04...
  • Page 6 01-2 C x12 Φ8x30 P 05...
  • Page 7 B x16 M6x9 0 M6x 70 E x2 F x8 Φ3.5x 16 G x3 Φ7x60 P 06...
  • Page 8 B x8 H x2 Φ6x60 M 6x90 B x12 M6x9 0 P 07...
  • Page 9 J x4 Φ4x25 Φ12x 80 P 08...
  • Page 10 G x12 Option A Φ7x60 Option B P 09...
  • Page 11 B x4 C x2 Option A M 6x90 Φ8x30 L x2 M x4 N x4 M6x6 0 M6 x50 P 10...
  • Page 12 B x4 C x2 Option B M 6x90 Φ8x30 L x2 M x4 N x4 M6x6 0 M6 x50 P 11...
  • Page 13 N x6 P x6 M 6x30 P 12...
  • Page 14 Q x64 Φ3x30 P 13...
  • Page 15 S x13 P 14...
