Assembly Guide for Projector leg lock PLL-50/70
An example of installing PLL-50/70 and projector on a pedestal
Assembly components:
PLL-50/70 - 4 pcs
1
Mounting kit included in
the PAP package:
Steel Cup, (SG-50 or SG-70) - 4 pcs
2
Screw M10 - 4 pcs
3
Washer - 4 pcs
4
Nut - 4 pcs
5
www.mnmounting.com
info@mnmounting.com
2 Merezhna str., Bila Tserkva,
Kyiv region, 09100, Ukraine
Assembly Guide
PLL-50/70
SAFETY INSTRUCTIONS
1. Entrust mounting equipment only to experienced
professionals and strictly follow the providedv safety
instructions. Improperly installed equipment may result
in property damage, personal injury and/or liability for
the installing contractor.
2. Only use appropriate fastening hardware.
3. Always make sure to securely use and lock all
mounting bolts. Loose bolts may become unscrewed
over time due to vibration which will then create a safety
hazard.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Mounting Solutions PLL-50/70
Summary of Contents for Mounting Solutions PLL-50/70
- Page 1 Assembly Guide PLL-50/70 Assembly Guide for Projector leg lock PLL-50/70 An example of installing PLL-50/70 and projector on a pedestal Assembly components: PLL-50/70 - 4 pcs SAFETY INSTRUCTIONS 1. Entrust mounting equipment only to experienced Mounting kit included in professionals and strictly follow the providedv safety the PAP package: instructions.
- Page 2 Assembly Guide PLL-50/70 Assembly Instructions: 2. Install the lower parts of the disassembled PLLs and cups from the PAP kit (SG-50 or SG-70) in the corresponding holes of the upper plate of the pedestal according to the legs 1. Disassemble all PLLs required for of your projector and screw them kit installation (3 or 4 pcs.)
