This Operator's Manual is an integral part of the safe operation of this machine and must

be maintained with the unit at all times. READ, UNDERSTAND, and FOLLOW the Safety

and Operation Instructions contained in this manual before operating the equipment. C01-

Cover

BUSH HOG

2501 Griffin Ave.

Selma, AL 36703

334-874-2700

www.bushhog.com

OPERATOR'S MANUAL

CULTIVATOR

MODEL 1RCV

Part No. 50072468

$0.00

Table of Contents

Need help?

Do you have a question about the 1RCV and is the answer not in the manual?

Questions and answers

Summary of Contents for Bush Hog 1RCV

Page 1 CULTIVATOR MODEL 1RCV Published 09/20 Part No. 50072468 OPERATOR’S MANUAL This Operator's Manual is an integral part of the safe operation of this machine and must be maintained with the unit at all times. READ, UNDERSTAND, and FOLLOW the Safety and Operation Instructions contained in this manual before operating the equipment.
Page 2 BEFORE YOU START! Read the safety messages on the implement and shown in your manual. Observe the rules of safety and common sense! For future reference, record your Bush Hog product model number and serial number. Dealer Telephone Model Number...
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY SECTION ......................1-1 General Safety Instructions and Practices ......................1-2 Operator Safety Instructions and Practices ....................... 1-3 Equipment Operation Safety Instructions and Practices ..................1-5 Connecting or Disconnecting Safety Instructions and Practices ................ 1-7 Maintenance and Service Safety Instructions and Practices ................1-7 Storage and Parking Safety Instructions and Practices ..................
Page 5: Safety Section
SAFETY SECTION Safety Section 1-1...
Page 6: General Safety Instructions And Practices
Safety Messages. Always use good common sense to avoid hazards. (SG-2) Si no lee ingles, pida ayuda a alguien que si lo lea para que le traduzca las medidas de seguridad. (SG-3) 1RCV 09/20 Safety Section 1-2 © 2020 Alamo Group Inc.
Page 7: Operator Safety Instructions And Practices
Always read carefully and comply fully with the manufacturer’s instructions when handling oil, solvents, cleansers, and any other chemical agent. (SG-22) KEEP AWAY FROM ROTATING ELEMENTS to prevent entanglement and possible serious injury or death. (SG-24) 1RCV 09/20 Safety Section 1-3 © 2020 Alamo Group Inc.
Page 8 Tractor control failure occur while operating, immediately shut down the Tractor and perform repairs before resuming operation. Serious injury and possible death could occur from not maintaining this Implement and Tractor in good operating condition. (SG-36) 1RCV 09/20 Safety Section 1-4 © 2020 Alamo Group Inc.
Page 9: Equipment Operation Safety Instructions And Practices
Operate the Tractor controls from the tractor seat only. (SG-9) Never allow children or other persons to ride on the Tractor or Implement. Falling off can result in serious injury or death. (SG-10) 1RCV 09/20 Safety Section 1-5 © 2020 Alamo Group Inc.
Page 10 Attacking insects can cause you to lose control of the tractor, which can result in serious injury or death to you or bystanders. Never dismount a moving tractor. (SG-40) 1RCV 09/20 Safety Section 1-6 © 2020 Alamo Group Inc.
Page 11: Connecting Or Disconnecting Safety Instructions And Practices
(SG-14) Never attempt to lubricate, adjust, or remove material from the Implement while it is in motion or while tractor engine is running. (SG-20) 1RCV 09/20 Safety Section 1-7 © 2020 Alamo Group Inc.
Page 12: Storage And Parking Safety Instructions And Practices
(if equipped) or block up securely to prevent falling and possible crushing injury and/or other injury from holding or lifting heavy components. Use the stand to stabilize the implement during storage. (S3PT-3) 1RCV 09/20 Safety Section 1-8 © 2020 Alamo Group Inc.
Page 13: Transporting Safety Instructions And Practices
When operating in traffic always use the Tractor’s flashing warning lights and reduce your speed. Be aware of traffic around you and watch out for the other guy. (SG-19) 1RCV 09/20 Safety Section 1-9 © 2020 Alamo Group Inc.
Page 14: Concluding Safety Instructions And Practices
These parts are made and tested to Bush Hog specifications. Non-genuine "will fit" parts do not consistently meet these specifications. The use of “will fit” parts may reduce equipment performance, void warranties, and present a safety hazard. Use genuine Bush Hog parts for economy and safety.
Page 15: Decal Location
SAFETY Decal Location NOTE: Bush Hog supplies safety decals on this product to promote safe operation. Damage to the decals may occur while in shipping, use, or reconditioning. Bush Hog cares about the safety of its customers, operators, and bystanders, and will replace the safety decals on this product in the field, free of charge (Some shipping and handling charges may apply).
Page 16 LEVEL DESCRIPTION 50057097 CAUTION Read Operator’s Manual 90960BH WARNING Plow Adjustments 00725746 DANGER Translate 50072467 LOGO Model 1RCV 50062087 LOGO Bush Hog SERIAL Serial Number Plate D960 WARNING Proposition 65 1RCV 09/20 Safety Section 1-12 © 2020 Alamo Group Inc.
Page 18: Federal Laws And Regulations
Some regulations specify that no one under the age of 16 may operate power machinery. It is your responsibility to know what these regulations are in your own area or situation. (Refer to U.S. Dept. of Labor, Employment Standard Administration, Wage & Home Division, Child Labor Bulletin #102.) 1RCV 09/20 Safety Section 1-14 © 2020 Alamo Group Inc.
Page 19: Introduction Section
INTRODUCTION SECTION Introduction Section 2-1...
Page 20 INTRODUCTION This Cultivator is designed with care and built with quality materials by skilled workers. Proper assembly, maintenance, and operating practices, as described in this manual, will help the owner/operator get years of satisfactory service from the machine. The purpose of this manual is to familiarize and instruct. The Assembly Section instructs the owner/operator in the correct assembly of the Aerator.
Page 21 INTRODUCTION The Bush Hog 1RVC Cultivator is ideal for aerating, stirring and pulverizing the soil to remove weeds, prepare the ground before planting, or loosen the soil after the crop has begun to grow. The 1RVC has 6 shanks with replaceable tips and is designed for 25-45 HP tractors with Cat l Standard and Quick Hitch.
Page 22 INTRODUCTION Attention Owner/Operator BEFORE OPERATING THIS MACHINE: 1. Carefully read the Operator’s Manual, completely understand the Safety Messages and instructions, and know how to operate correctly both the tractor and implement. 2. Fill out the Warranty Card in full. Be sure to answer all questions, including the Serial Number of the implement.
Page 23 2. If the unit has been subjected to misapplication, abuse, misuse, negligence, fire or other accident. 3. If parts not made or supplied by Bush Hog have been used in connection with the unit, if, in the sole judgment of Bush Hog such use affects its performance, stability or reliability.
Page 25: Assembly Section
ASSEMBLY SECTION Assembly Section 3-1...
Page 26: Dealer Set-Up Instructions
ASSEMBLY Dealer Set-up Instructions The Bush Hog 1RCV model cultivator is shipped fully assembled from the factory. Refer to the parts drawing or contact a Bush Hog dealer for further assistance if needed. Always use personal protection devices such as eye, ear and feet protectors during assembly.
Page 27: Operation Section
OPERATION SECTION Operation Section 4-1...
Page 28 OPERATION 1RCV CULTIVATOR OPERATION INSTRUCTIONS Your Cultivator should now be assembled and inspected for any evidence of defective or damaged parts before use. Any evidence of damage should be reported to your dealer immediately. This section of the Operator’s Manual is designed to familiarize, instruct, and educate safe and proper implement use to the operator.
Page 29: Standard Equipment And Specifications
OPERATION Standard Equipment and Specifications DESCRIPTION 1RCV Cultivator Hitch Cat l & Quick Hitch Overall Width 58” Overall Height 41-3/16” Horsepower 25 - 45 Weight (Approximate) 171 lbs.. Shank Size 3/8” x 1-3/4” x 16 Number of Shanks Cutting Point 1/4”...
Page 30: Tractor Requirements
OPERATION DO NOT use drugs or alcohol immediately before or while operating the Tractor and Implement. Drugs and alcohol will affect an operator’s alertness and coordination and therefore affect the operator’s ability to operate the equipment safely. Before operating the Tractor or Implement, an operator on prescription or over-the-counter medication must consult a medical professional regarding any side effects of the medication that would hinder their ability to operate the Equipment safely.
Page 31: Front End Weight
OPERATION 3.3 Front End Weight A minimum of 20% total tractor weight must be maintained on the tractor front end at all times. Front end weight is critical to maintain steering control and to prevent the tractor from rearing up while driving. If the front end is too light, add weight until a minimum of 20% total weight is reached on the front tires.
Page 32: Dismounting The Tractor
OPERATION 4.2 Dismounting the Tractor Before dismounting, park the tractor and implement on a reasonably level surface, apply the parking brake, idle the engine down, disengage the PTO, and lower the implement to the ground. Shut down the tractor engine according to the operator’s manual, remove the key, and wait for all motion to completely stop. Never leave the seat until the tractor, its engine and all moving parts have come to a complete stop.
Page 33: Connecting The Implement To The Tractor
OPERATION Start tractor only when properly seated in the Tractor seat. Starting a tractor in gear can result in injury or death. Read the Tractor operators manual for proper starting instructions. (SG-13) 6. CONNECTING THE IMPLEMENT TO THE TRACTOR Use extreme caution when connecting the implements to the tractor. The implement should be securely resting at ground level or setting on blocks.
Page 34: Pre-Operation Inspection And Service
OPERATION 4. Lift one arm at a time, align arm end hole between the set of holes of A-Frame lift lugs. Insert hitch pin through the lug and arm holes and insert retaining pin into hitch pin. Walk around to opposite side and repeat procedure for remaining lift arm and hitch pin.
Page 35: Tractor Pre-Operation Inspection/Service
OPERATION 7.1 Tractor Pre-Operation Inspection/Service Refer to the tractor operator’s manual to ensure a complete pre-operation inspection and scheduled service performed according manufacturers recommendations. The following are some of the items that require daily service and inspection: • Tire condition/air pressure •...
Page 36 OPERATION The operator’s manual and safety signs affixed on the unit contain important instructions on the safe and proper use of the equipment. Maintain these important safety features on the implement in good condition to ensure the information is available to the operator at all times.
Page 37 OPERATION Tractor PRE-OPERATION Inspection Tractor ID#:________________________Make:________________________ Date:______________________________Shift:________________________ Before conducting the inspection, make sure the tractor engine is off, all rotation has stopped and the tractor is in park with the parking brake engaged. Make sure the implement is resting on the ground or securely blocked up and all hydraulic pressure has been relieved.
Page 38 OPERATION CULTIVATOR PRE-OPERATION Inspection Cultivator ID#:____________________Make:__________________________ Date: ___________________________Shift:___________________________ Before conducting the inspection, make sure the tractor engine is off, all rotation has stopped and the tractor is in park with the parking brake engaged. Make sure the cultivator is resting on the ground or securely blocked up and all hydraulic pressure has been relieved.
Page 39: Driving The Tractor And Implement
OPERATION 8. DRIVING THE TRACTOR AND IMPLEMENT Safe tractor transport requires the operator possess a thorough knowledge of the model being operated and precautions to take while driving with an attached implement. Ensure the tractor has the capacity to handle the weight of the implement and the tractor operating controls are set for safe transport.
Page 40: Starting The Tractor
OPERATION 8.1 Starting the Tractor The procedure to start the tractor is model specific. Refer to the tractor operator’s manual for starting procedures for your particular tractor. Consult an authorized dealer if the starting procedure is unclear. Ensure the 3-point control lever is in the lowered position and the PTO is disengaged before starting the tractor.
Page 41: Driving The Tractor And Cultivator
OPERATION 8.3 Driving the Tractor and Cultivator Start off driving at a slow speed and gradually increase your speed while maintaining complete control of the tractor and unit. Moving slowly at first will also prevent the tractor from rearing up and loss of steering control. The tractor should never be operated at speeds that cannot be safely handled or which will prevent the operator from stopping quickly during an emergency.
Page 42: Shutting Down The Implement
OPERATION 10. Shutting Down the Implement To shut down the implement, first bring the tractor to a complete stop. Park the tractor on a level surface, place the transmission in park or neutral and apply the parking brake, lower the attached implement to the ground, shut down the engine, remove the key, before exiting the tractor.
Page 43: Transporting The Tractor And Implement
OPERATION Never allow children to play on or around Tractor or Implement. Children can slip or fall off the Equipment and be injured or killed. Inadvertent contact with controls can cause the Implement to shift or fall crushing themselves or others. (SG-25) 13.
Page 44: Transporting On Public Roadways
OPERATION Before transporting the tractor on a public roadway or boarding a trailer for transport, the tractor brake pedals should be locked together. Locking the pedals ensures that both wheels brake simultaneously while stopping, especially when making an emergency stop. Use extreme caution and avoid hard applications of the tractor brakes when towing heavy loads at road speeds.
Page 45 OPERATION The SMV (Slow-Moving Vehicle) emblem is universal symbol used to alert drivers of the presence of equipment traveling on roadways at a slow speed. SMV signs are a triangular bright orange with reflective red trim for both easy day and night visibility.
Page 46: Hauling The Tractor And Implement
OPERATION 13.2 Hauling the Tractor and Implement Before transporting a loaded tractor and implement, measure the height and width dimensions and gross weight of the complete loaded unit. Ensure that the load will be in compliance with the legal limits set for the areas that will be traveled through.
Page 47: Maintenance Section
MAINTENANCE SECTION Maintenance Section 5-1...
Page 48: General Maintenance
2. Inspect the implement for any worn or damaged parts and replace with a genuine Bush Hog part. 3. Make sure all safety decals are intact and legible. 4. Inspect unit for cracks and chips and repair if necessary. Consult your Bush Hog dealer before any repair is made. Any unauthorized repairs will void the warranty.
Page 51 TO THE OWNER/OPERATOR/DEALER To keep your implement running efficiently and safely, read your manual thoroughly and follow these directions and the Safety Messages in this Manual. The Table of Contents clearly identifies each section where you can easily find the information you need. The OCCUPATIONAL SAFETY AND HEALTH ACT (1928.51 Subpart C) makes these minimum safety...
