Cooper Lighting Metalux T5 Specifications

D I M E N S I O N S
T5
focus beam 1 or 2 lamp
X
1-31/32" [51mm]
3-9/32"
[84mm]
1"
[26mm]
X=2-11/16"
4-5/16"
[69mm]
[110mm]
task beam 1 or 2 lamp
X
1-31/32" [51mm]
3-9/32"
[84mm]
1-7/16"
[37mm]
X=2-11/16"
4-5/16"
[69mm]
[110mm]
normal beam 1 or 2 lamp
X
1-31/32" [51mm]
3-9/32"
[84mm]
1-3/16"
[31mm]
X=2-11/16"
4-5/16"
[69mm]
[110mm]
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : M B - 1 5 4 T 5 - 1 2 0 V - E B T 1
Tandem
Blank=4' Length
8T=8' Length
Series
MB= T5 Micro-Bay
Number of Lamps
(Not included)
1=1 Lamp
2=2 Lamps
Lamp Types
54T5=54W T5/HO (4' Unit)
32=32WT8
Reflector
FB=Focus Beam
TB=Task Beam
NB=Normal Beam
(1)
NOTES: Products also available in non-US voltages and frequencies for international markets.
For complete product data, reference the Fluorescent Specification binder. Specifications & dimensions subject to change without notice. Consult your Cooper Lighting
Representative for availability and ordering information.
COOPER LIGHTING - METALUX
T8
focus beam 1 or 2 lamp
X
3-5/32" 29/32"
[81mm]
[24mm]
X=2-11/16"
7-3/16"
[69mm]
[183mm]
task beam 1 or 2 lamp
X
3-5/32"
29/32"
[81mm] [24mm]
X=2-11/16"
7-9/16"
[69mm]
[193mm]
normal beam 1 or 2 lamp
X
3-5/32"
29/32"
[81mm] [24mm]
X=2-11/16"
7-3/32"
[69mm]
[181mm]
Voltage
UNV=Universal
Voltage 120-277
Options
(1)
Ballast Type
EB8 = T8 Electronic Instant Start.
Total Harmonic Distortion < 10%
No. of Ballast
1, 2 or 3
EB8 /PLUS= T8 Electronic Instant Start.
High Ballast Factor >1.13. Total
No. of
Harmonic Distortion < 20%
Ballast
1, 2 or 3
ER8 = T8 Electronic Program Rapid Start.
Total Harmonic Distortion < 10%
No. of Ballast
1, 2 or 3
EBT =T5 Linear Electronic Program Rapid
Start. Total Harmonic Distortion < 10%
No. of Ballast
1 or 2
DIM=Dimming
DLS=Digital Lighting System Dimming
(For complete details on generic or to specify
manufacturer's ballast see pg. 469)
D E S C R I P T I O N
The MB Series is a functional
and multi-purpose narrow
profile fluorescent High-Bay
that incorporates premium
performance and construction
durability. Designed for both
T5 and T8 fluorescent lamp
technology, the MB Series
offers both high performance
and application versatility.
The MB Series is ideal for
lighting in narrow aisle
applications. The MB Series
can be the illumination solution
in commerical, industrial and
retail applications. Fixtures can
be used in warehouses and
retial store distribution centers.
Options Packaging
(See Options & U=Unit Pack
Accessories
PAL=Pallet Pack
Section)
®
F-BAY MB
SERIES
4 ' O R 8 ' S T R I P
1 O R 2 L A M P
T 5 O R T 8 M I C R O - B AY
• Available in a 1or 2 lamp
version using T5 or T8
lamps
• Specular MIRO 4 reflectors
for precise light control
• Three optical distribution
patterns available: Focus
Beam, Task Beam and
Normal Beam
• White enamel finish
improves efficiency and
protects from corrosion
• Easily suspended and
adjusted with various cable
mounting methods
• Ideal for continuous row
mounting in narrow aisle
applications (available with
long connector for row
alignment)
• Occupancy sensor is
available to instantly turn
lights on and off. Saves
more energy!
• UL/CUL Listed. Suitable for
damp locations
COOPER LIGHTING
449
