Summary of Contents for Ocean Signal EPIRB2
- Page 1 User Manual EPIRB2 Class 2, Category 2 Emergency Position Indicating Radio Beacon with RLS English www.oceansignal.com...
- Page 2 The technical data, information and illustrations contained in this manual were believed to be correct at the time of print. Ocean Signal Ltd reserve the right to change specifica- tions and other information contained in this manual as part of our continual improvement process.
- Page 3 EPIRB2 USER MANUAL IN CASE OF EMERGENCY USE ONLY IN SITUATIONS OF GRAVE AND IMMINENT DANGER MANUAL ACTIVATION 22/06/2023 912S-04391 - 01.00...
-
Page 4: About Your Epirb
Earth orbit (GEO) which form the GEOSAR System The future Cospas-Sarsat System will include a new type of satellite in the medium-al- titude Earth orbit (MEO) which will form the MEOSAR System. The EPIRB2 is fully compatible with the new MEOSAR satellites. -
Page 5: Return Link Service
Galileo Navigation Signal in Space. The RLS feature is an indication on the EPIRB2 that confirms to the User that the distress signal from the EPIRB2 has been localised by the Cospas-Sarsat system and is being sent to the SAR authorities. -
Page 6: Table Of Contents
Warnings What’s in the Box Operating Modes EPIRB2 OVERVIEW INSTALLATION Location Mounting Dimensions Remove the EPIRB2 from the Mounting Bracket Fit the Manual Mounting Bracket Fit the EPIRB2 into the Mounting Bracket OPERATION Manual Release Optical indications on activation Deactivation... -
Page 7: General
RSS-102 (Canada). Warnings It is a legal requirement to register your EPIRB2 with your National Authority. Only use your EPIRB2 in a situation of grave and imminent danger. Deliberately misusing your EPIRB2 or setting it off accidentally may result in prosecution and a fine. -
Page 8: What's In The Box
Your EPIRB2 may be operated in a variety of modes. 2.5.1 Manual Release and Automatic Activation Should the vessel be in danger of sinking the EPIRB2 should be removed from its bracket, the antenna extended and then placed in the sea. Contact with the water will automatically activate the EPIRB2. -
Page 9: Epirb2 Overview
Programming Details Label The lanyard is provided to attach the EPIRB2 to the life raft or your person, once it is activated. Do not use it to attach it to the ship, as this may result in the loss of the EPIRB2 if the vessel sinks. -
Page 10: Installation
Failure to follow the following installation guidelines may cause the EPIRB2 to operate incorrectly. Do not mount the EPIRB2 closer than 1.0 metre to any steering compass as this may affect the accuracy of the compass. Keep the EPIRB2 away from any strong magnetic sources such as loudspeakers, compass compensation magnets, etc. -
Page 11: Remove The Epirb2 From The Mounting Bracket
EPIRB2 USER MANUAL Remove the EPIRB2 from the Mounting Bracket Prior to installation the EPIRB2 must be removed from the bracket. Fit the Manual Mounting Bracket Using the dimensions shown, use the three No.6 x 3/4” Countersunk screws supplied to secure the mounting bracket to a suitable bulkhead in a position that will allow easy access in the event of abandoning the vessel. -
Page 12: Operation
The EPIRB2 is designed for best operation while floating in water. If used in other situations ensure that the EPIRB2 is placed in the open, clear of any cover and kept upright. Do not place the EPIRB2 close to large structures or under cover. - Page 13 EPIRB2 USER MANUAL 5.1.2 Fully extend the antenna 5.1.3 Break off the red protective tab 5.1.4 Lift the yellow flap up to expose the Red ON/OFF button. 22/06/2023 912S-04391 - 01.00...
- Page 14 – as indicated on the top of the EPIRB2. A lanyard is provided to tether the EPIRB2 to the lifeboat or life raft to ensure that it does not drift away. Make sure this is firmly attached.
-
Page 15: Optical Indications On Activation
EPIRB2 USER MANUAL Optical indications on activation • The green LED will illuminate (blue if RLS is enabled) for 1 second. • The strobe light will start flashing. • Within 1 minute of activation, the indicator LED will flash a quick burst of 5 indicating 406MHz transmission. -
Page 16: Deactivation
1 to 2 seconds the ON/OFF key. It is not possible for the user to replace the red protective cover. Return the EPIRB2 to an Ocean Signal authorised service centre for checking and replacement. -
Page 17: Nfc And Mobile App
NFC technology allows communication between two electronic devices over a distance of 4cm (1.5”) or less. The benefit of using NFC in the EPIRB2 is that the power used for communication comes from the mobile device and not the beacon. -
Page 18: Beacon Test
Beacon Test Ensure the antenna is fully deployed and above the EPIRB2 before commencing the test. Rewind the antenna before placing the EPIRB2 back in its bracket. Because the test transmits a short burst on the aircraft distress frequency of 121.5MHz, please only carry out this test in the first five minutes of each hour. - Page 19 EPIRB2 may not have sufficient energy to operate for the specified 48-hour period. Battery replacement is recommended. NOTE: The flash sequence will be repeated after a short pause and then the EPIRB2 will automatically power off. 22/06/2023 912S-04391 - 01.00...
-
Page 20: Gnss Test
If there are 10 or more tests remaining then the LED will flash 10 times only (repeated). The EPIRB2 has the capacity to carry out 60 GNSS tests within the lifetime of the battery. If there are no tests remaining immediately after the current test, the LED will flash green... -
Page 21: Beacon Registration
EPIRB2 USER MANUAL BEACON REGISTRATION It is the owner’s responsibility to register this beacon with the appropriate National Authority before operation. Documentation is provided within the packaging with information regarding registration with the relevant body to comply with the required configuration of the beacon. -
Page 22: Unregistered Beacon
Ensure the antenna is clean and not permanently bent. Ensure free movement of the antenna winding mechanism. Should the EPIRB2 turn on during cleaning, make sure it is turned off as quickly as possible by pressing and holding the ON/OFF Key until the LED flashes red twice and release. -
Page 23: Batteries
The EPIRB2 contains Lithium iron batteries for long operating life. The battery must be replaced either prior to the expiry date or after the EPIRB2 has been used, even if only activated for a short period of time. The battery condition can be determined by carrying out the Self Test procedure shown in section 7 of this manual. -
Page 24: Transport
IATA packing instruction 970 section II. If you are hand carrying your EPIRB2 on an aircraft please contact your airline for advice. Safety Data sheets for all Ocean Signal products can be found on the Ocean Signal website: www.oceansignal.com/safety-data-sheets/ 912S-04391 - 01.00... -
Page 25: Specifications
EPIRB2 USER MANUAL Specifications 406MHz Transmitter Transmit Power (EIRP) Frequency 406.031 MHz ±1KHz Modulation Phase ±1.1 Radians (16K0G1D) Encoding Biphase L Rate 400 bps 121.5MHz Transmitter Transmit Power (PERP) 50mW±3dB Frequency 121.5 MHz Modulation Duty Cycle >35% Modulation Factor 0.85 to1.00 Frequency Stability ±50ppm... -
Page 26: Approvals
In addition to Cospas Sarsat Type Acceptance, the EPIRB2 complies with the following National Approvals: 9.6.1 European Union Hereby, Ocean Signal Ltd. declares that the radio equipment type EPIRB2 is in compliance with Radio Equipment Directive 2014/53/EU. The DoC can be found at the following website link: https://oceansignal.com/approvals-documents/... -
Page 27: 10. Warranty Information
Proof of purchase shall be required in order for a warranty claim to be valid from the original purchaser. All claims shall be made in writing to Ocean Signal or an approved service dealer or distributor. - Page 28 Ocean Signal Ltd. Unit 4, Ocivan Way Margate CT9 4NN United Kingdom info@oceansignal.com www.oceansignal.com...
