Page 1
Voorraadvat Storage tank Ballons de stockage ST - 400/500/600/750/1000 Installatie-, Gebruikers- en Servicehandleiding Installation, User and Service Manual Notice d’installation, Mode d’emploi, Notice d’entretien Innovation has a name.
Page 2
Uw Installateur / Your Installer / votre installateur A.O. Smith Hoofdkantoor Europa, De Run 5305, 5503 LW Veldhoven www.aosmith.nl, 0800-AOSMITH (2676484) A.O. Smith UK, Unit B8 Amstrong Mall, Southwood Business Park, Farnborough, Hampshire GU14 0NR www.aosmith.co.uk A.O. Smith France, 14, allée Charles Pathé, 18000 Bourges...
Page 3
Inhoudsopgave / Table of contents / Table des matières Deze handleiding bestaat uit 3 talen. 1 - NL Handleiding ST 400 t/m 1000 ..................5 2 - EN Manual ST 400 trough 1000 ................... 21 3 - FR Notice ST 400 à 1000 ..................... 37 This manual consists of 3 languages.
Page 4
Installatie-, Service- en Gebruikershandleiding...
Page 5
A.O. Smith Water Products Company. A.O. Smith Water Products Company behoudt zich het recht voor de specificaties zoals vermeld in deze handleiding te wijzigen.
Page 6
Installatie-, Service- en Gebruikershandleiding...
Technische specificaties 1.1 Vloerbelasting Houd in verband met het gewicht van het toestel rekening met de maximale vloerbelasting, zie de tabel (1.6 "Algemene gegevens"). 1.2 Watersamenstelling Het toestel is bedoeld om drinkwater op te warmen. Het drinkwater moet voldoen aan de regelgeving voor drinkwater voor menselijke consumptie.
Installatie 2.1 Aansluitschema De figuur geeft het aansluitschema weer. Dit schema wordt gebruikt in de paragrafen waarin het eigenlijke aansluiten wordt beschreven. Installatie Schema Legenda 2. inlaatcombinatie (verplicht) 3. T&P-ventiel (aanbevolen) 4. afsluiter (aanbevolen) 5. terugslagklep (verplicht) 6. circulatiepomp (optioneel) A.
Page 14
Let op Een inlaatcombinatie is verplicht. Monteer deze zo dicht mogelijk bij het toestel. Waarschuwing Tussen inlaatcombinatie en het toestel mag nooit een afsluiter of terugslagklep geplaatst worden. 2.2.2 Warmwaterzijdig Zie (B) in het aansluitschema (2.1 "Aansluitschema"). Opmerking Isolatie van lange warmwaterleidingen voorkomt onnodig energieverlies. 1.
Vullen en aftappen Installatie Schema Legenda 2. inlaatcombinatie (verplicht) 3. T&P-ventiel (aanbevolen) 4. afsluiter (aanbevolen) 5. terugslagklep (verplicht) 6. circulatiepomp (optioneel) A. koudwatertoevoer B. warmwaterafvoer C. circulatieleiding IMD-0545 R1.0 3.1 Vullen Om het toestel te vullen gaat u als volgt te werk: 1.
1. Sluit de afsluiter in de warmwaterleiding. 3.2 Aftappen 2. Sluit de toevoerkraan van de inlaatcombinatie (2). 3. Open de aftapkraan. 4. Belucht het toestel (of installatie) zodat het helemaal kan leeglopen. Installatie-, Service- en Gebruikershandleiding...
Onderhoud Let op Onderhoud mag alleen door een erkend service- en onderhoudsmonteur worden uitgevoerd. Bij elke onderhoudsbeurt dient het voorraadvat waterzijdig onderhouden te worden. Het onderhoud dient in de volgende volgorde te worden uitgevoerd. 1. Onderhoud voorbereiden 2. Waterzijdig onderhoud 3.
Page 18
Werkvolgorde: 1. Draai de bouten van de reiningsopening los. 2. Verwijder de deksel en de pakking. 3. Inspecteer de tank en verwijder de losse kalkaanslag en verontreinigingen. 4. Indien de kalkaanslag niet handmatig verwijderd kan worden, dient ontkalkt te worden met een ontkalkingmiddel. Neem contact op met de leverancier/fabrikant voor een advies over het te gebruiken ontkalkingmiddel.
Indien binnen één jaar na de oorspronkelijke installatiedatum van een door A.O. Smith geleverd voorraadvat, na onderzoek en ter uitsluitende beoordeling van A.O. Smith, blijkt dat een deel of onderdeel, met uitzondering van de tank, niet of niet juist functioneert ten gevolge van fabricage- en/of materiaalfouten, zal A.O. Smith dit deel of onderdeel vervangen of repareren.
5.5 Omvang garantie De verplichtingen van A.O. Smith krachtens de gegeven garantie gaat niet verder dan kosteloze levering af magazijn van de te vervangen delen of onderdelen respectievelijk voorraadvat. Vervoers-, arbeids-, installatie- en andere met de vervanging verband houdende kosten komen niet voor rekening van A.O.
Page 21
Liability A.O. Smith Water Products Company accepts no liability for claims from third parties arising from unauthorised use, use other than that stated in this manual, and use other than in accordance with the General Conditions registered at the Chamber of Commerce.
Page 23
Water-side maintenance ..................31 Warranty ........................ 33 General warranty ....................33 Tank warranty ......................33 Conditions for installation and use ................33 Exclusions ....................... 34 Scope of warranty ....................34 Claims ........................34 Obligations of A.O. Smith ..................34 0312731_ST_400-1000_NLENFR_V3.0, 2018-01-04...
Technical specifications 1.1 Floor load Allow for the storage tank's weight and the maximum floor load; refer to the table (1.6 "General specifications"). 1.2 Water composition The storage tank is intended for heating drinking water. The drinking water must comply with the regulations governing drinking water for human consumption. The table gives an overview of the specifications.
1.6 General specifications General specifications Unit ST 400 ST 500 ST 600 ST 750 ST 1000 Contents litres 1055 Empty weight Maximum floor load 1317 Energy Efficiency Class (Energy Label) Heat Loss Maximum operating pressure kPa (bar) 1000 (10) 1000 (10) 1000 (10) 1000 (10) 1000 (10)
Page 27
Front sectional view of the appliance IMD-1294 R0 0312731_ST_400-1000_NLENFR_V3.0, 2018-01-04...
Note These products can be installed as vented and unvented. This manual only discusses unvented installations. For information about vented installations please contact A.O. Smith. Installation Diagram Legend 1. pressure relief valve (mandatory if mains water pressure is too high) 3.
Page 30
2.2.2 Hot Water side See (B) in the installation diagram (2.1 "Installation diagram"). Note Insulating long hot water pipes prevents unnecessary energy loss. Optional: fit a temperature gauge (12) so you can check the temperature of the tap water. Fit the T&P valve (3). Fit a stop valve (11) in the hot water outlet pipe for servicing.
Filling and draining Note These products can be installed as vented and unvented. This manual only discusses unvented installations. For information about vented installations please contact A.O. Smith. Installation Diagram Legend 1. pressure relief valve (mandatory if mains water pressure is too high) 3.
3.2 Draining 1. Close the stop valve (4) between the cold water head tank and the cold water inlet (A). 2. Open the drain valve (9). 3. Bleed the water heater (or installation) so that it drains completely. Installation, Service and User Manual...
Maintenance Warning Maintenance may only be carried out by a competent person. At each service, the storage tank undergoes maintenance on water side. The maintenance must be carried out in the following order. 1. Preparation for maintenance 2. Water-side maintenance 3.
Page 34
Work order: 1. Undo bolts from the cover. 2. Remove cover and the gasket. 3. Inspect the tank and remove the loose scale deposits and contamination. 4. If the scale cannot be removed by hand, descale the storage tank with a descaling agent.
A.O. Smith shall offer to replace the defective storage tank with an entirely new storage tank of equivalent size and quality. The warranty period given on the replacement storage tank shall be equal to the remaining warranty period of the original storage tank that was supplied.
A.O. Smith Water Products Company products. Inspection of the storage tank as referred to in articles 1 and 2 shall take place in one of the laboratories of A.O. Smith. 5.7 Obligations of A.O.
Page 37
Aucune partie de ce document ne peut être copiée, dupliquée et/ou diffusée par impression, photocopie ou tout autre moyen de reproduction, sans l'accord écrit préalable de A.O. Smith Water Products Company. A.O. Smith Water Products Company se réserve le droit de modifier les spécifications de ce manuel d'instructions. Marques de commerce Toutes les marques mentionnées dans ce manuel d'instructions sont des marques...
Page 39
Entretien côté eau ....................47 Garantie ......................... 49 Garantie générale ....................49 Garantie sur la cuve ....................49 Conditions d'installation et d'utilisation ..............49 Exclusions ....................... 50 Portée de la garantie ....................50 Réclamations ......................50 Obligations de A.O. Smith ..................50 0312731_ST_400-1000_NLENFR_V3.0, 2018-01-04...
Spécifications techniques 1.1 Charge maximale au Tenez compte de la charge maximale exercée sur le sol par le poids de l'appareil, sol de l'appareil voir le tableau (1.6 "Données générales"). 1.2 Composition de l'eau L'appareil est destiné à réchauffer de l'eau potable. L'eau potable doit être conforme aux régulations d'eau potable pour la consommation humaine.
1.6 Données générales Données générales Unité ST 400 ST 500 ST 600 ST 750 ST 1000 Capacité 1055 Poids à vide Charge maximale au sol de l'appareil 1317 Class Efficacité Énergétique (Étiquette d’Énergie) Consommation d’entretien Pres. de fonctionnement max. kPa (bar) 1000 (10) 1000 (10) 1000 (10)
Page 43
Vue de frontale des appareils IMD-1294 R0 0312731_ST_400-1000_NLENFR_V3.0, 2018-01-04...
Installation 2.1 Schéma de raccor- Cette illustration représente le schéma de raccordement. Ce schéma est utilisé dans dement les paragraphes suivants contenant une description du raccordement proprement dit. Schéma de raccordement Légende 2. groupe de sécurité (obligatoire) 3. soupape thermique (recommandée) 4.
Page 46
Attention Un groupe de sécurité est obligatoire. Montez-le le plus près possible de l'appareil. Avertissement Entre la combinaison d'entrée et l'appareil, vous ne pouvez jamais monter de vanne d'arrêt ou de clapet anti-retour. 2.2.2 Côte eau chaude Voir (B) du schéma de raccordement (2.1 "Schéma de raccordement"). Note L'installation des longues conduites d'eau chaude évite les pertes énergétiques inutiles.
Remplissage é Vidange Schéma de raccordement Légende 2. groupe de sécurité (obligatoire) 3. soupape thermique (recommandée) 4. vanne d'arrêt (recommandée) 5. clapet anti-retour (obligatoire) 6. circulateur de bouclage (option) A. alimentation en eau froide B. sortie d'eau chaude C. conduit de circulation bouclage ECS IMD-0545 R1.0 3.1 Remplissage...
Page 48
3.2 Vidange Fermez la vanne d'arrêt dans la conduite d'eau chaude. 1. Fermez le robinet d'arrivée du groupe de sécurité (2). 2. 10.Ouvrez le robinet de vidange. 3. Purgez l'appareil (ou l'installation) pour qu'il (elle) puisse se vider complètement. Notice d’installation, Mode d’emploi, Notice d’entretien...
Effecteur l'entretien Attention L'entretien ne peut entré effectué que par un professionnel de la maintenance ou de l'entretien agréé. A chaque entretien, l'appareil doit être contrôlé côté eau et côté gaz. L'entretien doit s'effectuer dans l'ordre suivant. 1. Préparer l'entretien 2.
Page 50
Ordre du travail: 1. Faites tourner les boulons de l’ouverture de nettoyage. 2. Éliminez le couvercle et le joint. 3. Inspectez le réservoir. Éliminez la couche de calcaire accumulée et les saletés. 4. Si la couche de calcaire ne peut être éliminée manuellement, il convient de retirer le calcaire avec un détartrant.
Si, moins de trois ans après la date initiale de l'installation d'un chauffe-eau livré par cuve A.O. Smith, après examen par et sur l'appréciation exclusive de A.O. Smith, la cuve en acier thermo vitrifié présente des fuites suite à une formation de rouille ou de corrosion du côté...
5.5 Portée de la garantie Les obligations de A.O. Smith conformes à la garantie accordée se limite à la livraison gratuite de l'entrepôt des pièces ou parties à remplacer ou de l'appareil à...
