- Page 1 Midtown Installation Manual Model: 54211 Fresh White 54212 Matte Nickel Fan weight ±2 lbs: 19.3 lbs (8.8 kg) ©2019 Hunter Fan Co. PG3771 r060619...
- Page 2 - All wiring must be in accordance with national and local electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualified electrician. c.2 - Use only Hunter replacement parts. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 We recommend that you pull everything out of the box and lay it out. We have grouped the drawn components below with the hardware you’ll need for those Hunter Pro Tip: parts. The screws below are drawn to scale to make it easier to identify what piece of hardware is needed to install each component.
-
Page 4: Choosing The Right Installation Location
A little more information on Angled Mounting: For optimum performance and appearance, a longer downrod should be used with your Hunter ceiling fan when installing on high or angled ceiling. If your ceiling is angled greater than 34° you will also need an Angled Mounting Kit. -
Page 5: Installing The Ceiling Bracket
You have two options for installation. Pick which one works best for your location. Remove any existing Hunter Pro Tip: bracket prior to installation. Only use the provided Hunter ceiling bracket that came in your fan’s box. The machine screws are the ones that came with your outlet box. -
Page 6: Hanging The Fan
1886 Hanging the Fan NOTICE To prevent damage to fan, ALWAYS lift holding either the fan housing or the downrod. Place the downrod ball into the slot in the ceiling bracket. Progress Check: Your fan should look like this. Ceiling Bracket Downrod Hanging Fan Wiring... -
Page 7: Wiring The Fan
Follow these steps to get your fan wired quickly and safely. Follow the route below that best matches your wall switch setup. If you are unfamiliar with wiring or uncomfortable doing it yourself, please contact a qualified electrician. Hunter Pro Tip: Here is how to connect the wires: Push the bare metal ends of the wires together and slide a wire nut over them. -
Page 8: Installing The Canopy
Canopy Screw Lift the canopy into place so that the screw holes are aligned. Hunter Pro Tip: Let the tool do the work! A magnetic screwdriver will give you more visibility when securing the canopy. -
Page 9: Assembling The Light Kit
1886 Assembling the LIght Kit 2 of 3 Light Kit Screw Feed the 9-pin plug connector coming Align the keyhole slots in the top of the light kit from the bottom of the motor housing assembly with the partially installed assembly Partially install two light kit through the center hole in the light kit screws. -
Page 10: Preparing The Remote
1886 Preparing the Remote The remote control is already paired for use. For your convenience, a remote function card is packed in with your remote. To access the battery compartment, remove the small Phillips head screw that Battery secures the battery door to Door the transmitter assembly. -
Page 11: Limited Lifetime Warranty
Hunter instructions, accidental damage caused by the fan owner or related parties, Please do not ship your fan or any fan parts to Hunter. Delivery will be refused. modifications to the fan, improper or incorrectly performed maintenance or repair,... -
Page 12: Troubleshooting
“How do I properly install multiple remote-controlled fans?” for information on how to correct this issue. Hunter Pro Tip: Cleaning the Fan Use soft brushes or cloths to prevent scratching. Cleaning products may damage the finishes.
