Summary of Contents for Lenovo Legion S7
- Page 1 User Guide Lenovo Legion S7 (16″, 7)
- Page 2 • Setup Guide First Edition (March 2022) © Copyright Lenovo 2022. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-...
-
Page 3: Table Of Contents
The FnLock switch ... . Call Lenovo ....Before you contact Lenovo .. - Page 4 User Guide...
-
Page 5: About This Guide
About this guide • This guide applies to Lenovo product model(s) listed below. Illustrations in this guide may look slightly different from your product model. Model name Machine type (MT) Legion S7 16IAH7 82TF Lenovo Legion S7 16IAH7 Legion S7 16ARHA7... - Page 6 User Guide...
-
Page 7: Chapter 1. Meet Your Computer
• The antennas are not visible from the outside of the computer. • If the location of the antennas is close to the user’s body (< 20 cm), you can find the Specific Absorption Rate (SAR) values in the Setup Guide that comes with your computer. © Copyright Lenovo 2022... -
Page 8: Base
Base 1. Power button/Fingerprint reader • Press the button to turn on the computer or put the computer into sleep mode. • Fingerprint reader is available on power button. Enroll and read your fingerprint for user authentication. Note: You can turn on the computer by flipping open the LCD screen if Flip to Boot is enabled. -
Page 9: Left
Left 1. Ventilation slots (outlet) Maintain the outgoing airflow to dissipate internal heat. Attention: Do not block the ventilation slots. Otherwise, the computer may overheat. ™ 2. Thunderbolt 4 port/Multi-function USB This port varies by model and is either a Thunderbolt 4 (2a) or multi- ®... -
Page 10: Right
Right 1. Combo audio jack Connect to headphones or headsets with a 3.5 mm (0.14 inch), 4-pole plug. Note: This jack does not support standalone external microphones. If you use headsets, choose one with a single plug. 2. Camera switch Disable or re-enable the camera. -
Page 11: Rear
Rear Figure 1. Legion S7 16IAH7 and Lenovo Legion S7 16IAH7 Figure 2. Legion S7 16ARHA7 and Lenovo Legion S7 16ARHA7 1. Ventilation slots (outlet) Maintain the outgoing airflow to dissipate internal heat. Attention: Do not block the ventilation slots. Otherwise, the computer may overheat. -
Page 12: Bottom
Bottom 1. Ventilation slots (inlet) Maintain the incoming airflow to dissipate internal heat. Attention: Do not block the ventilation slots. Otherwise, the computer might overheat. 2. Novo button hole Press the Novo button to open the Novo Button menu. From the menu, you can choose to open the UEFI/BIOS setup utility, the Boot menu, or the Windows startup options screen. -
Page 13: Features And Specifications
Features and specifications Dimensions • Width: Approximately 357.7 mm (14.08 inches) • Depth: Approximately 260.0 mm (10.24 inches) • Thickness – Thinnest: Approximately 16.9 mm (0.67 inches) – Thickest: Approximately 21.0 mm (0.83 inches) ac power adapter • Input: 100 V ac–240 V ac, 50 Hz–60 Hz •... - Page 14 • Combo audio jack • HDMI 2.1 connector • USB Standard-A connector × 3 (for Legion S7 16IAH7 and Lenovo Legion S7 16IAH7) – Supports SuperSpeed USB 5 Gbps and backwards compatible with USB 2.0 – Supports SuperSpeed USB 10 Gbps; backwards compatible with SuperSpeed USB 5 Gbps and USB 2.0...
-
Page 15: Statement On Usb Transfer Rate
Statement on USB transfer rate Depending on many factors such as the processing capability of the host and peripheral devices, file attributes, and other factors related to system configuration and operating environments, the actual transfer rate using the various USB connectors on this device will vary and will be slower than the data rate listed below for each corresponding device. - Page 16 User Guide...
-
Page 17: Chapter 2. Get Started With Your Computer
If night light mode is turned on, you can adjust the color temperature of the temperature screen. Note: Selected Lenovo computers are low blue light certified using night light mode and color temperature settings available in the pre-installed operating system. These computers are tested with night light turned on and color temperature set to 48 or greater. -
Page 18: Lenovo Vantage And Lenovo Pc Manager
To open it, type its name in the Windows Search box and select the matched result. If neither of the apps is pre-installed, you may install one on your own. Lenovo Vantage is available for download free of charge from the Microsoft Store. -
Page 19: Hotkeys
Switch display devices. Turn airplane mode on and off. Display an app launcher for quick access to Lenovo apps and services. Note: For some models, you may need to connect to the Internet and complete system update for this function to take effect. -
Page 20: The Fnlock Switch
Key combination Hidden function Fn + K ScrLk Fn + Q Switch operation modes Fn + R * Adjust display refresh rate Fn + U Turn the rear port LED on and off * for selected models The FnLock switch The FnLock is a switch that reverses the default and hidden function of a hotkey. -
Page 21: Chapter 3. Explore Your Computer
To extend your battery’s lifespan, the battery may optimize its full charge capacity based on your usage. After prolonged periods of limited use, full battery capacity may not be available until you discharge to as low as 20% and recharge completely. For more information, refer to the power section of Lenovo Vantage. -
Page 22: Set Power Button Behavior
CAUTION: When purchasing third-party USB Type-C chargers for use with the computer, choose a product that is safety approved or certified. A disqualified charger may cause damage to your computer or pose an electrical hazard. In many countries and regions, manufacturers or importers of electric chargers can submit their products to a certification authority or approved and recognized testing laboratories. -
Page 23: What Is Uefi/Bios Setup Utility
Ctrl key. For example, you can press either Ctrl + A or Fn + A to select all text in a text editing application. Enable or disable always-on For some Lenovo computers with always-on connectors, the always-on function can be enabled or disabled in the UEFI/BIOS setup utility. -
Page 24: Set Administrator Password
Attention: If you forget the administrator password, a Lenovo authorized service personnel cannot reset your password. You must take your computer to a Lenovo authorized service personnel to have the system board replaced. Proof of purchase is required and a fee will be charged for parts and service. -
Page 25: Set User Password
Lenovo authorized service personnel cannot reset your password or recover data from the hard disk. You must take your computer to a Lenovo authorized service personnel to have the hard disk drive replaced. Proof of purchase is required and a fee will be charged for parts and service. -
Page 26: Change Or Remove Hard Disk Password
Change or remove hard disk password Step 1. Open the UEFI/BIOS setup utility. Step 2. Select Security. Step 3. Change or remove the hard disk password. To change or remove master password, select Change Master Password and press Enter. Note: If you remove the master hard disk password, the user hard disk password is also removed. To change user password, select Change User Password and press Enter. -
Page 27: Chapter 4. Help And Support
Where can I get the latest device • Lenovo Vantage or Lenovo PC Manager drivers and UEFI/BIOS? • Lenovo Support Web site at https://support.lenovo.com... -
Page 28: What Is A Cru
If you intend to install a CRU, Lenovo will ship the CRU to you. You might be required to return the defective part that is replaced by the CRU. When return is required: (1) return instructions, a prepaid shipping label, and a container will be included with the replacement CRU;... -
Page 29: Crus For Your Product Model
Call Lenovo If you have tried to correct the problem yourself and still need help, you can call Lenovo Customer Support Center. Before you contact Lenovo Record product information and problem details before you contact Lenovo. -
Page 30: Purchase Additional Services
• Lenovo hardware repair - If the problem is determined to be caused by Lenovo hardware under warranty, trained service personnel are available to provide the applicable level of service. -
Page 31: Appendix A. Notices And Trademarks
Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead. - Page 32 Actual results may vary. Users of this document should verify the applicable data for their specific environment. This document is copyrighted by Lenovo and is not covered by any open source license, including any Linux agreement(s) which may accompany software included with this product. Lenovo may update this document at any time without notice.
