- Page 1 System ® lEctro trainEr Operation Manual Models: ES-200-PS / ES-150-PS (888) 384-8881 support@electrosea.com (952) 475-8084 www.electrosea.com...
-
Page 2: Table Of Contents
No part of this publication may be reproduced, translated, stored in a retrieval system, or transmitted in any form or by any means electronic, mechanical, photocopying, recording, or otherwise without the prior written consent of ElectroSea, LLC. Every precaution has been taken in the preparation of this manual to ensure its accuracy. ElectroSea assumes no responsibility for errors and omission. Neither is any liability assumed for damages resulting from the use of this product and information contained herein. -
Page 3: Electrosea And Electrostrainer System
With more than 100 issued U.S. patents and 350+ foreign patents in advanced technologies, our executive management team has been developing innovative solutions for more than 50 years. With an expert team of “old salts” who eat, sleep, and breathe boating, ElectroSea will improve your time on the water. -
Page 4: System Features
System Features User Interface Features and Functions Power ON ElectroStrainer. The Control Unit will complete a diagnostic self-test, and then the green “POWER” light will be illuminated. The main status screen will be displayed. Programming Menu Operating Mode Selection Buttons Flow Rate Circuit Breaker USB Port... -
Page 5: Operating Modes And Feature Overview
• Default Update: This process is used to restore ElectroStrainer to its original factory default settings or to update the ElectroStrainer Control Unit firmware using a USB memory drive supplied by ElectroSea. Safety Considerations WARNING Indicates a hazardous situation that, if not avoided, could result in death or serious injury. - Page 6 System Features Power ON and Start-Up Delay Power ON the ElectroStrainer System. The Control Unit will complete a diagnostic self-test, and then the green “POWER” LED will be illuminated. “START-UP” will be displayed for 30 seconds. Cleaning Mode During normal operation the Control Unit will flash “CLEANING,” and the green Cleaning LED will be illuminated. This indicates the ElectroStrainer System is electrochemically generating chlorine to prevent biofouling.
-
Page 7: Inhibit Mode, Pump Mode And Time
System Features Inhibit Mode Inhibit Mode: The ElectroStrainer System can receive a signal from (1) 24-VDC or 12-VDC and/or (1) 240-VAC or 120-VAC input from equipment, such as a baitwell or reverse osmosis (RO) water system, that are incompatible with chlorine. These wired inputs trigger the ElectroStrainer to “inhibit” (stop) generating chlorine. ElectroStrainer will flash the word “INHIBIT”... - Page 8 System Features Pump Mode and Time The Pump Mode should be set up during the installation process. Refer to the table below to verify the Pump Mode is set correctly. Use the Up or Down arrow to select Pump Mode. Wiring Mode Description...
-
Page 9: Optimal Performance And Strainer Flow Alert
System Features Optimal Performance Constant Chlorinated Seawater Flow: The ElectroStrainer System should be powered ON and have seawater flowing through it whenever possible. This provides the vessel’s seawater circuit with constant chlorinated seawater to prevent unwanted marine growth. Intermittent or stagnant seawater that is not continuously electrochemically treated allows growth of marine microorganisms. -
Page 10: Electrostrainer Maintenance
ElectroStrainer Maintenance Canister Assembly Access Before accessing the Canister Assembly, power OFF the ElectroStrainer Control Unit. To Access the Canister Assembly: Power OFF the ElectroStrainer Control Unit. Turn OFF ALL seacock valves in the seawater circuit at or below the waterline. This includes any output seacocks to prevent back siphoning. - Page 11 ElectroStrainer Maintenance ElectroStrainer Maintenance Loosen the pressure ring by turning the wing Remove the pressure ring. Remove the Cell Assembly. Lift straight up by nuts counterclockwise. the black plastic cover. Do not lift or pull on the cable. Set the Cell Assembly aside in a safe location.
- Page 12 ElectroStrainer Maintenance ElectroStrainer Maintenance Remove the strainer basket from the Canister. Spray the strainer basket with fresh water to remove any mud, seaweed, or debris caught in the strainer pores. Spray the internal surfaces of the Canister with fresh water. After the strainer basket and Canister are clean, place the strainer basket back into the Canister.
- Page 13 ElectroStrainer Maintenance ElectroStrainer Maintenance Spray the plastic screen that covers the Cell Assembly. If there is excessive mud or debris, the plastic screen can be removed from the Cell. It is NOT necessary to remove the plastic screen from the Cell if debris rinses off and the plastic screen and Cell appear clean.
- Page 14 ElectroStrainer Maintenance ElectroStrainer Maintenance 9. Insert the strainer basket into the Canister. Align the flat edge of the basket with the flat edge of the Canister. 10. Confirm the gasket is in the top of the Canister. Flat Edge 11. The Canister and lid are keyed and can be inserted in only one direction.
- Page 15 ElectroStrainer Maintenance ElectroStrainer Maintenance Reconnect the Cell Cable between the Control Unit and the Canister. Open the seacocks and check for any leaks. Turn the seawater intake pumps on. The seawater intake pumps must be on and pumping seawater at normal flow rates for the ElectroStrainer System to operate. NOTICE Any air trapped in the Canister must be bled out.
-
Page 16: Cell Indicator
When the ElectroStrainer Cell has reached the end of its useful life, it can no longer generate chlorine. The Cell life is dependent on flow rate, hours of use, seawater quality, and other factors. RESOLUTION: Contact your ElectroSea dealer. U.S. Patent No. 11,027,991 and 11,345,621, Foreign Patent No. I782112 and other U.S. and Foreign Patents Pending... -
Page 17: System Updates
OK to Exit 2. Update: This allows the user to update the firmware using a USB memory drive supplied by ElectroSea. To perform a firmware update Insert the ElectroSea USB memory drive. Go to the Update menu. Line 1 displays the current firmware version of the unit. Line 2 displays the available firmware version that is on the USB memory drive. -
Page 18: Inspection
Inspection Periodic Inspection The ElectroStrainer should be viewed during regular inspection of the vessel’s engine room. During normal operation, the ElectroStrainer status screen will flash the message “CLEANING,” and the green LED will be illuminated. This indicates the ElectroStrainer System is generating a safe and effective low level of chlorine to prevent unwanted marine growth, barnacles, and biofilm in the strainer and seawater lines. -
Page 19: Important Information
Important Information Specifications ElectroStrainer Model: ES-200 ElectroStrainer Model: ES-150 ElectroStrainer Control Unit 9.96 x 6.75 x 3.25 inches 9.96 x 6.75 x 3.25 inches Dimensions (L x W x H) (252.98 x 171.45 x 82.55 mm) (252.98 x 171.45 x 82.55 mm) Weight 4 lb 6 oz (1.98 kg) 4 lb 6 oz (1.98 kg) -
Page 20: Modes And Troubleshooting
Modes & Troubleshooting Modes, Descriptions and Actions Mode Description Action The unit is powered ON, but it is in the OFF state. No seawater is flowing This is a normal operating mode, provided there is no seawater flow. through the system. The unit is in the mode for Cleaning and preventing biofouling by Cleaning This is a normal operating mode. - Page 21 RESOLUTION: Contact your ElectroSea dealer. ElectroStrainer internal High Contact your ElectroSea dealer or ElectroSea directly as the Cell may be at the end of its useful life. Temperature temperature is high. U.S. Patent No. 11,027,991 and 11,345,621, Foreign Patent No. I782112 and other U.S. and Foreign Patents Pending...
- Page 22 Notes NOTES: U.S. Patent No. 11,027,991 and 11,345,621, Foreign Patent No. I782112 and other U.S. and Foreign Patents Pending...
- Page 23 Notes NOTES: U.S. Patent No. 11,027,991 and 11,345,621, Foreign Patent No. I782112 and other U.S. and Foreign Patents Pending...
- Page 24 (888) 384-8881 support@electrosea.com (952) 475-8084 www.electrosea.com 750074-001...
