- Page 1 USER MANUAL MODEL: SLX-PS PUMP FED SANITIZER - SINGLE STATION English (Original Instructions) Updated: 02/23/22...
-
Page 2: Table Of Contents
PROTECT THE ENVIRONMENT Please dispose of packaging materials, old machine components, and hazardous fluids in an environmentally safe way according to local waste disposal regulations. Always remember to recycle. SLX-PS Pump Fed Sanitizer User Manual Page 2 of 11 Updated: 02/23/22... -
Page 3: System Requirements
Always test prior to normal operation to ensure facility requirements are met for cleaning procedures. More Information Please contact Clean Logix at: (616)-438-9200 or sales@clean-logix.com SLX-PS Pump Fed Sanitizer User Manual Page 3 of 11 Updated: 02/23/22... -
Page 4: Installation
HOSE WAND Notes: POLYPROPYLENE (DEFAULT) • Backflow prevention required - consult local codes. OPTIONAL STAINLESS STEEL UPGRADE AVAILABLE • System may vary depending on model and optional upgrades. SLX-PS Pump Fed Sanitizer User Manual Page 4 of 11 Updated: 02/23/22... -
Page 5: Operation
4. Fully open pump supply valve. • The spray wand will slowly begin discharging water until pressure is established. Fig. 5.1: Water supply ball valves closed. Fig. 5.2: Spray wand with open valve. SLX-PS Pump Fed Sanitizer User Manual Page 5 of 11 Updated: 02/23/22... -
Page 6: General Use
SDS recommendations. 2. Open the enclosure door. 3. Loosen the tri-clamp fitting to disconnect the upper pump fed body and lower sanitizer body. Fig. 6.2: Tri-clamp open SLX-PS Pump Fed Sanitizer User Manual Page 6 of 11 Updated: 02/23/22... - Page 7 11. Close enclosure door and lock if necessary. O-Ring 12. Follow initial setup procedures to test insert and spray quality before resuming normal operation. Fig. 7.3: Replacing insert SLX-PS Pump Fed Sanitizer User Manual Page 7 of 11 Updated: 02/23/22...
-
Page 8: Maintenance
Check that tri-clamp is seated properly and tighten till secure. • Replace discharge hose (and wand if necessary) • Replace insert More Information Please contact Clean Logix at: (616)-438-9200 or sales@clean-logix.com SLX-PS Pump Fed Sanitizer User Manual Page 8 of 11 Updated: 02/23/22... -
Page 9: Troubleshooting
Open sanitizer body and check for build-up. Remove and formed in the sanitizer body blocking the fluid path. clean with water or descaling acid (insert is PVC). Replace as necessary. For Technical Support: SLX-PS Pump Fed Sanitizer User Manual Page 9 of 11 Updated: 02/23/22... -
Page 10: Parts Call Out
P2450 Poly: M2254 (Shown) Stainless: M2221 M2239 F1252 P2484 M2243 M2441 P2292 M2322 M2258 Poly: M2256 (POLY BODIED Stainless: M2223 UNITS ONLY) P2449 M2269 M2422 M2334 P2471 M2218 SLX-PS Pump Fed Sanitizer User Manual Page 10 of 11 Updated: 02/23/22... - Page 11 NOZZLE, AXIAL FAN SPRAY, 1/2 NPT, 304SS, 80 DEG, 15 GPM @ 40 PSI, 80150 P2484 O-RING, SLX BODY, VITON, BROWN More Information Purchase Replacement Parts: Please contact Clean Logix at: (616)-438-9200 or sales@clean-logix.com SLX-PS Pump Fed Sanitizer User Manual Page 11 of 11 Updated: 02/23/22...
