  • Page 1 GLACIÄR MIDI Gas Leakage Detector for commercial and industrial applications USER MANUAL...
  • Page 2 Alarm set points ..............................................16 4.6 M ................................17 AGNETIC KEY FOR CONFIGURATION 4.6.1 Bluetooth activation ..........................................17 4.6.2 Alarm/warning management ......................................17 4.7 SAMON GLACIÄR ................................18 APP FEATURES 4.7.1 Connecting the device via Bluetooth ....................................18 4.8 M ® ....................................21...
  • Page 3 FURTHER INFORMATION ................................32 6.1 S ..................................32 ENSOR OPERATING PRINCIPLE 6.1.1 Semiconductor sensors .......................................... 32 6.1.2 Electrochemical sensors ......................................... 32 6.1.3 Pre-calibrated sensors and devices .............................. 32 6.2 G ......................................33 AS DETECTED 6.3 T ................................... 34 ECHNICAL SPECIFICATIONS 6.3.1 Mechanical specification ........................................

  • Page 4: Product Description

    The change in status is signalled via the RS485 Modbus® output Furthermore, the “SAMON GLACIÄR” app, available in both App Store and Play Store, can be used to access the device. The GLACIÄR MIDI series detectors enable compliance with refrigeration safety standards (e.g., EN 378, ASHRAE 15) through alarms to alert personnel in the event of a refrigerant leakage.

  • Page 5: Physical Dimensions

    2.2 Physical dimensions Built-in version Remote version...

  • Page 6: General Information

    CAUTION: THERE IS NO GENERAL RULE for establishing the appropriate number of sensors and their location for each application. Therefore, the guidelines described below are intended as support for installers, and not as rules in their own right. SAMON accepts no liability for the installation of the gas detectors.
  • Page 7 3.2.4 Chillers Measuring leaks on outdoor chillers is generally more difficult, given the highly variable air flow. Generally, it is recommended to install the gas detectors near the compressor, as this is the place where refrigerant leaks are most likely to occur. In particular, check if it is possible to install the gas detector inside the closed unit near the compressor, where gas is more likely to stagnate.
  • Page 8 • Open the cover of the GLACIÄR MIDI, fit the cable glands and make the required electrical connections. The plug-in terminals can be removed from the device to facilitate wiring. • Power the device on and complete the settings using the rotary switch, as described in the following paragraphs, or using the app, as described below or through the Modbus connection.
  • Page 9 Electrical connection Analogue output Analogue output reference Shielded RS485 cable GND for RS485 Tx + / Rx + for RS485 Tx- / Rx- for RS485 For Vac power supply, connect the second transformer wire Vac/dc +24 V For Vdc power supply, connect one of the two power wires, the device automatically recognizes whether this AC/DC is + or GND.

  • Page 10: Additional Installation Notes

    Secure the detector cover with the four screws. • Power the device on and set the parameters using the “SAMON GLACIÄR” app (see the relevant chapter) if the settings were not previously made using the rotary switch. 3.4 Additional installation notes Before commencing electrical installation and wiring, carefully read the following notes: •...
  • Page 11 4.2 Device operating states The GLACIÄR MIDI series gas detectors provide visual indications of their current operating status, in addition to the relay outputs. Visual indication of device operating status is provided by three LEDs (green/red/orange). Device status and the corresponding outputs are shown in the following table: Status Warning/Fault relay Alarm relay...
  • Page 12 4.3 Setup of the device using the rotary switch The rotary switch (R1) is located inside the device, on the electronic board . The basic configuration can be performed using the rotary switch, following the instructions described below. To complete the configuration, a digital multimeter is required, with the test leads connected to connector J6. In this way, the tester will show a voltage between 0 and 10 Volts, indicating the value selected by the rotary switch.
  • Page 13 Description of the rotary switch LEDs The table below shows the value of the selected parameter and the corresponding voltage value. Each LED corresponds to a different parameter. The default parameter values are saved to permanent memory. LED W1 Not used LED W2 Warning level.
  • Page 14 J6 voltage value conversion table / selected function Service W2 / W3 wheel LED Full scale Full scale Full scale Full scale 1000 4000 10000 Voltage [V] [ppm] [ppm] [ppm] [ppm] [--] [--] [--] [--] 1000 1000 1000 9600 8N1 1100 1100 1200...

  • Page 15: Analogue Output

    Service W2 / W3 wheel LED Full scale Full scale Full scale Full scale 1000 4000 10000 Voltage [V] [ppm] [ppm] [ppm] [ppm] [--] [--] [--] [--] 6400 6500 6600 6700 6800 6900 7000 19200 8E1 7100 7200 7300 7400 7500 7600 7700...

  • Page 16: Alarm Management

    4.5 Alarm management The alarms are activated when the set thresholds are exceeded. The alarm threshold value must always be greater than the warning value. The alarm and warning thresholds must be less than or equal to the full-scale range and must be greater than or equal to the allowed limit.

  • Page 17: Bluetooth Activation

    4.6 Magnetic key for configuration The device is supplied with a magnet for configuration. By placing it in the slot provided, the following functions can be managed: 4.6.1 Bluetooth activation After 5 seconds of exposing the magnet to the magnetic sensor, Bluetooth mode is activated. If Bluetooth is already on, after 5 seconds of exposure Bluetooth is deactivated.
  • Page 18 4.7 SAMON GLACIÄR app features The “SAMON GLACIÄR” app lets users fully exploit the potential of the new GLACIÄR MIDI series gas detectors, allowing simple and intuitive interaction with the gas detector. This simplifies configuration by using a smartphone to interface with the GLACIÄR MIDI gas leakage detectors.
  • Page 19 Home screen PARAMETERS screen From the home screen, it is possible to display the current This screen displays the sensor parameters. concentration level measured by the sensor, with the corresponding It is also possible to select the type of gas to be detected, from those alarm and warning thresholds.
  • Page 20 MODBUS SETUP screen Test mode screen If enabled, the following functions can be activated in test mode, i.e. The following parameters can be set: not corresponding to the behaviour of the device, rather for • Modbus address debugging: • Baud rate •...

  • Page 21: Modbus® Network

    4.8 Modbus® network For the Modbus RS485 network, use a shielded 3-wire cable. Recommended: Belden 3106A (or equivalent). The Modbus communication parameters can only be set using the SAMON GLACIÄR app or the rotary switch on the device’s electronic board.
  • Page 22 4.9 Table of Modbus variables ® Function 04 Read Input Registers Address Register Short Medium Long Unit of Modbus Modbus Default name description description description value value meas. Bit pos. length value Concentrat Concentration Sensor Sensor 6553 concentration concentration in “units” in “units”...
  • Page 23 Function 06 Write Single Register & Function 03 Read Holding Registers Address Register name Short Medium Long description Unit of Modbus Modbus Default description description value value meas. Bit pos. length value LimitAlarm Alarm limit Alarm threshold Alarm threshold 10000 0 Delay Delay Delay before...
  • Page 24 Input register 102 : bits Description Long description Fault Service Port Error Code No reply from SM No reply from sensor Preheating From sensor, 1 during preheating Reserved Internal use only Over range Over range from sensor Under range Under range from sensor Reserved For internal use only Reserved...

  • Page 25: Calibration Procedure

    MAINTENANCE 5.1 Calibration procedure The calibration procedure is performed periodically and involves introducing a known gas concentration at the sensor inlet, using the calibration kit. The need to perform calibration is signalled by a specific variable on the supervisor. Each type of device has a different calibration interval, as described in the technical specifications table.
  • Page 26 5.3 Calibration via app Before connecting to the device via the SAMON GLACIÄR app, first make sure that the BLUETOOTH connection and GEOLOCATION are enabled on the smartphone used. Make sure that the Bluetooth mode on the GLACIÄR MIDI has been activated using the magnetic latch as described in the previous chapters.
  • Page 27 Supply the gas at the known concentration using the Click Span Calibration to set the calibration calibration kit. concentration. Wait about 1 minute until the gas concentration stabilises. Enter the room temperature and relative humidity. Verify the summary screen, checking that all the These values will be entered on the calibration certificate to information has been entered correctly before indicate the environmental conditions during calibration.
  • Page 28 Save the calibration report. Use File manager to share the calibration report via email. 5.4 Calibration via Modbus communication ® Place the sensor in clean air and wait for the warm-up phase to be completed at the end of the start-up phase. Enter the Technician password to access the device (2222 to register 205).
  • Page 29 5.4.1 Diagram of the calibration procedure...
  • Page 30 5.4.2 Operation of the registers for calibration...

  • Page 31: Sensor Replacement Procedure

    5.5 Sensor replacement procedure When the need for replacement is signalled via Modbus communication (coil 311 SensorExpired), proceed as follows: • Acquire a pre-calibrated sensor module with the same part number as the one mounted on the detector. • Disconnect power Built-in version •...

  • Page 32: Cleaning The Device

    5.6 Cleaning the device Clean the detector with a soft cloth using water and a mild detergent. Rinse with water. Do not use alcohol, degreasers, sprays, polishes, detergents, etc. FURTHER INFORMATION 6.1 Sensor operating principle 6.1.1 Semiconductor sensors Semiconductor or metal-oxide-semiconductor (MOS) sensors are very versatile and can be used in a wide range of applications: they can measure both gases and vapours at low ppm and combustible gases at higher concentrations.
  • Page 33 6.2 Gas detected Register 117 group Gas group Technology Default GAS Gas calibration Infrared Electrochemical R32 mix Type 1 Semiconductor HFC/HFO Type 2 Semiconductor R134a R134a HC Type 3 Semiconductor R290 R290 Sensor module group Range of measurement. GasType register value R-1150 0-4000 ppm R-1233zde...

  • Page 34: Technical Specifications

    6.3 Technical specifications Technical specifications Semiconductor version Electrochemical version Infrared version Power supply voltage ** 24VDC/AC +/- 20%, 5W , 50/60Hz User interface App with Bluetooth Analogue output: 4-20mA / 0-10V / 1-5V / 2-10V selected via software Serial communication: Modbus®...

  • Page 35: Disposal Of The Device

    Common house- hold appliances can be disposed of via special collection and recycling sites. However, this device has not been registered for home use. Therefore, it must not be disposed of using these services. Do not hesitate to contact SAMON if you have any further questions on this topic. 6.4.2 Disposal of the sensors Dispose of the sensors in accordance with local laws.

  • Page 36: Order Information

    ORDER INFORMATION 7.1 Gas Detector GLACIÄR MIDI series part numbers Part number Description Sensor Range 31-210-32 GLACIÄR MIDI IR CO2 0-10000 ppm 10000 ppm 31-510-32 GLACIÄR MIDI Remote IR - Remote 0-10000 ppm IR CO2 10000 ppm 31-210-33 GLACIÄR MIDI IR CO2 0-50000 ppm 50000 ppm 31-510-33...
  • Page 37 7.2 Sensor module spare part numbers Part number Description Sensor Range SEN-41032 Sensor module IR CO2 0-10000ppb 10000ppm SEN-41036 Sensor module IR CO2 0-50000ppm 50000ppm SEN-42012 Sensor module SC HFC/HFO Group 1 0-1000ppm HFC/HFO Group 1 1000ppm SEN-42017 Sensor module SC HFC/HFO Group 2 0-1000ppm HFC/HFO Group 2...
  • Page 40 Manufactured by: Samon AB Modemgatan 2 S-235 39 Vellinge, Sweden www.samon.se...
