* Le produit réel peut varier en apparence en fonction du modèle. Warranty Registration and Inquiry For product warranty registration, TOTO U.S.A. Inc. recommends online warranty registration. Please visit our web site http://www.totousa.com. If you have questions regarding warranty policy or coverage, please contact TOTO U.S.A.
Warranty......................11 THANKS FOR CHOOSING TOTO! The mission of TOTO is to provide the world with healthy, hygienic and more comfortable lifestyles. We design every product with the balance of form and function as a guiding principle. Congratulations on your choice.
BEFORE INSTALLATION Read these instructions thoroughly before beginning work. Please leave instructions for customers. These instructions contain maintenance and warranty information. If necessary, remove the existing toilet and if new construction, purge the supply line. NOTICE Due to the powerful performance of our Tornado, G-Max, E-Max and Power The only means of installing these toilets in a back-to-back situation is when builder or contractor prior to this installation.
INSTALLATION PROCEDURE ill.1 Wax seal Follow the Installation instruction to complete the installation (ill. 1). 2. Place the template into position and follow its instructions to prepare for installing the toilet bowl. Screw NOTICE In on the Floor Flange after Washer wax seal is set.
Page 5
7/8” Ballcock Thread seen at the bottom of toilet tank (Ill. 7). Tighten this HAND TIGHTEN ONLY connection finger tight. The water supply hose must be connected NOTICE installation. TOTO recommends using a...
Page 6
INSTALLATION PROCEDURE ill.8 Fill Valve Nut Flush Valve Nut tower nut (ill. 8). While pressing down, spread the gasket over the nut until the gasket touches the bottom of the tank. A slight gap between the tank bottom and the gasket is allowable. 10.
MAINTENANCE INSTRUCTIONS Replacing the Flush Tower Turn off water supply and flush the toilet. 2. Remove the tank lid and place it upside down on a clean surface. Remove the remain- ing water from tank with a sponge. 3. Pull the clip on top of trip lever gear box as shown.
CARE AND CLEANING Use a detergent or non-abrasive toilet cleaner and a soft bristled plastic brush to clean your toilet. To remove hard water stains, use vinegar or lime dissolving cleaner and a non-scratch scour pad made for porcelain. Allow a little contact time to allow the cleaner to dis- solve the buildup.
SERVICING THE FILL VALVE NOTE: Due to water conditions in your area, the strainer may require periodic clean- ing. An indication that the strainer 1. Snap off the top cover by pulling from under the tab (ill. 1). 2. Pinch the tabs of the lever arm to allow its removal (ill. 2). 3.
TOTO product in pristine condition. No CEFIONTECT® NOTE: For best results to keep your TOTO product with CEFIONTECT® clean: • Lavatory: Use a mild dish detergent with a clean, soft cloth. • Toilet: Use a gel based cleaner with a soft bristled-plastic brush.
