4. Timer
■ Timer functions are different by each remote controller.
■ For details on how to operate the remote controller, refer to the appropriate operation manual included with each remote controller.
4.1. For wireless remote controller
ON/OFF
MODE
CHECK
TEST RUN
SET
5. Emergency Operation for Wireless Remote-controller (option)
HEAT
6. Care and Cleaning
► C leaning the filters
• Clean the filters using a vacuum cleaner. If you do not have a vacuum
cleaner, tap the filters against a solid object to knock off dirt and dust.
• If the filters are especially dirty, wash them in lukewarm water. Take
care to rinse off any detergent thoroughly and allow the filters to dry
completely before putting them back into the unit.
Caution:
• Do not dry the filters in direct sunlight or by using a heat source,
such as an electric heater: this may warp them.
• Do not wash the filters in hot water (above 50°C), as this may warp
them.
• Make sure that the air filters are always installed. Operating the
unit without air filters can cause malfunction.
Caution:
• Before you start cleaning, stop operation and turn OFF the power
supply.
• Indoor units are equipped with filters to remove the dust of sucked-in
air. Clean the filters following the procedures below.
10
Ⓒ
Ⓓ
Ⓑ
Ⓐ
TEMP
FAN
AUTO STOP
①③
VANE
AUTO START
LOUVER
h
②
min
RESET
CLOCK
AAA
AAA
ON/OFF
①
②
COOL
1) Set the current time
① Press the CLOCK button using a thin stick and blink the time Ⓐ .
h
min
② Press the
and
button to set the current time.
③ Press the CLOCK button using a thin stick.
2) Set the time to start the unit as follows
① Press the
AUTO START
button.
• Time can be set while the following symbol is blinking.
On time: Ⓑ START is blinking.
• The start times is displayed at Ⓐ .
h
min
② Use the
and
buttons to set the desired time.
③ To cancel the ON timer, press the
3) Set the time to stop the unit as follows
AUTO STOP
① Press the
button.
• Time can be set while the following symbol is blinking.
Off time: Ⓒ STOP is blinking.
• The stop times is displayed at Ⓓ .
② Use the
h
min
and
buttons to set the desired time.
③ To cancel the OFF timer, press the
4) Changing the set times
AUTO START
AUTO STOP
Press the
or
to cancel the timer and repeat from 2) or 3).
① ON/OFF lamp (lit when unit is operating; unlit when unit is not
operating)
② Emergency operation
In cases where the remote control unit does not operate properly, use
either the
COOL or
HEAT button on the wireless remote control
signal receiver to toggle the unit on or off. On cooler only units,
pushing the
HEAT button toggles the fan on and off.
Pressing the
COOL or
HEAT button selects the following settings.
Operation mode
Preset temperature
24 °C/75 °F
Fan speed
► Filter removal
Caution:
• In removing the filter, precautions must be taken to protect your
eyes from dust. Also, if you have to climb up on a stool to do the
job, be careful not to fall.
• When the filter is removed, do not touch the metallic parts inside
the indoor unit, otherwise injury may result.
Ⓑ
Ⓓ
• While lifting the filter knob, pull it.
Ⓐ Air intake
Ⓑ Air outlet
AUTO START
button.
AUTO STOP
button.
COOL
HEAT
24 °C/75 °F
High
High
Ⓐ
Ⓒ
Ⓓ
Ⓒ Filter
Ⓓ Knob
