OPERATING INSTRUCTIONS
VENEN ENGEL 4
ENGLISH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4 and is the answer not in the manual?

Questions and answers

Related Manuals for Venen Engel 4

Summary of Contents for Venen Engel 4

  • Page 1 OPERATING INSTRUCTIONS VENEN ENGEL 4 ENGLISH...

  • Page 2: Preliminary Remark

    PRELIMINARY REMARK Congratulations on the purchase of this device! You will enjoy your Venen Engel very much! If you are satisfied with your Venen Engel, we would be very pleased if you submitted a review. This guide includes details that should be taken into account by the user, to avoid risks, and to enable the safe use of the device.

  • Page 3: Product Description

    PRODUCT DESCRIPTION The air pressure massager consists of a device with a pump, cuffs, air pressure sensor, etc., which work together as one unit. The device is connected to the cuffs via a series of hoses. The compression massage is done by cyclically inflating and deflating the air chambers. The pressure in the cuff is controlled by a sensor and microprocessor.

  • Page 4: Important Safety Instructions And Warnings

    IMPORTANT SAFETY INSTRUCTIONS AND WARNINGS lt is important that you read all the warnings and precautions in this manual. They are for your safety, to prevent injury and to prevent damage to the unit. Do not use this device if you have a pacemaker, implanted defibrillator or other implanted metallic or electronic device. Such use ●...

  • Page 5: Working Principle

    • lf the unit is not used for a long time or is used at low temperatures, the unit may not be usable. Allow the unit to inflate any cuff 3 to 4 times to the highest pressure level before use...

  • Page 6: Step 1: Before Use

    The zippers on the cuffs must be completely closed to avoid the cuffs from suddenly splitting open and causing possible damage. After plugging it into the power plug, putting on the cuffs, and tightening the zipper, the Venen Engel application controls on the control unit can be adjusted.

  • Page 7: Step 2: Control Unit Operation

    Remote Control Batteries Before the initial use: Remove the battery protection and insert the battery (Type: CR2032; Diameter: 20mm, Height: 2.5mm, Voltage: 3V)! Due to shipping policies, we are not allowed to provide a battery. We kindly ask for your understanding. Warning: Keep the remote control and battery out of reach of children as there is a risk of suffocation.
  • Page 8 STEP 3: ENJOY THE MASSAGE The leg cuff air chambers inflate one by one.This creates an optimal gliding pressure wave massage for a relaxed feeling in both legs. Duration and pressure can be adjusted, even during the massage. Massage programs:...

  • Page 9: Schritt 5: Cleaning And Storage

    STEP 4: COMPLETION & DISMANTLING THE DEVICE After the set time has elapsed, or after pressing the off switch, you can unplug the multi-plug from the device. lf you are not comfortable during the massage, you can also end the massage at any time, as you wish. After that you may open the cuff. To vent the air from the air cushions faster, after application, we recommend pushing the remaining air out of the cuffs with both hands, ensuring that the multi-plug is removed.

  • Page 10: Troubleshooting

    TROUBLESHOOTING THE DEVICE DOES NOT TURN ON lf the device does not turn on, please check (A) whether the power plug has been correctly plugged into the socket and/or whether the device is turned on. lf the unit is still not turning on, unplug the power plug (B) and unscrew the fuse holder with the inscription "FUSE" on the bottom of the unit (see picture on the left) completely (with a screwdriver or small coin) and check that the fuse inside is intact.
  • Page 11 One should be able to talk or relax and chat with another person, without any issues, during the application. lf this is not the case, due to the Venen Engel being too noisy, it is an indication that the transport screw on the bottom of the device has not yet been removed. Open the cover on the bottom and remove the safety screw with the enclosed screwdriver.
  • Page 12 Velcro the strap to the back of the cuff. Step 3 Step 4 Pull the cuff onto your arm and make sure the end is sitting on your shoulder. Run the strap under your other arm and attach it to the front of the cuff.
  • Page 13 Please do not dispose of the product via your general household waste disposal. Alternatively: we are happy to take care of the disposal of your old Venen Engel free of charge. Just send it to:...

  • Page 14: Technical Details

    TECHNICAL DETAILS Programmes Pump output 40l / Min. Number of chambers Fuse T 0,315 A H Weight ca. 3 kg Controller Dimensions 28x28x15 cm Power output 30 W Protection Class II / Mains Frequency 50-60 Hz 10-40 °C Temperature range Voltage 220-240 V (use and storage)

  • Page 15: Package Contents

    PACKAGE CONTENTS Control unit Multi-Plug air hose set Compression boots Power plug The scope of delivery of the boots depends on the set purchased...

  • Page 16: Explanation Of Symbols Used

    EXPLANATION OF SYMBOLS USED Press the button with this symbol to start and pause the Lot number Non-sterile application. Operate only in barometric Press the button with this pressure range from European symbol to switch on the unit. 500hPa to 1060hPa plenipotentiary Operate only in a humidity Directive 2002/96/EG on...
  • Page 17 IMPORTANT INFORMATION REGARDING ELECTROMAGNETIC COMPATIBILITY (EMC) 1) This product needs special precautions regarding EMC and needs to be installed and put into service according to the EMC information provided, and this unit can be affected by portable and mobile RF communications equipment. 1) Do not use a mobile phone or other devices that emit electromagnetic fields, near the unit.
  • Page 18 UT) for 0.5 cycle 40% UT (60% dip in UT) for supply input lines IEC 61000-4- or hospital environment. lf the user of the DEVICE 0.5 cycle 40% UT requires continued operation during power mains...
  • Page 19 IEC 60601 Compliance level Electromagnetic environment - guidance Immunity test test tevel Portable and mobile RF communications Radiated RF IEC 61000-4-3 lOV/m & table 9 l0V/m & table 9 equipment should be used no closer to any part of the Device,...
  • Page 20 NOTE: lf necessary to achieve the IMMUNITY TEST LEVEL, the distance between the transmitting antenna and the ME EQUIPMENT or ME SYSTEM may be reduced to 1 m. The 1 m test distance is permitted by IEC 61000-4-3. For some services, only the uplink frequencies are included.
  • Page 21 Test specifications for ENCLOSURE PORT IMMUNITY to RF wireless communications equipment (Table 9) Service •1 Modulation Test frequency Band •1 Maximum Distance immunity Test Level (MHz) (MHz) power (W) (V/m) 380-390 TETRA400 Pulse modulation 18Hz 430-470 ± GMRS460, FRS 460 SkHz deviation !kHz sine 704-787 LTE Band 13, 17...

  • Page 22: Warranty

    WARRANTY We offer a 24-month warranty on the control unit. In the event of shall be entitled to cancel the purchase or receive a reduction in the malfunction, purchase it may be necessary to send the device back for inspection. Please ensure price.
