FORWARD Thanks for your purchasing of Prodriver Function Card HD-PFT-A researched and developed by Hpmont independently. This product is cost-efficient to control small auto-equipment and its volume is small. This user manual describes product specification, characteristic and use method. It is for your reference.
Page 3
Version and Revision Records Version time: July, 2018 Version: V1.1 Chapter Revised Contents Chapter 2 • Add CAN communication selection jumper J12, see section 2.3 • Add temperature control input terminal (PT100) wiring, see section 2.4.4 Chapter 3 • Modify the instruction set (logical and functional instructions), see section 3.3 •...
Page 5
4.4 Temperature Control Use ....................... 28 4.5 Power-down Save Data Usage ...................... 29 4.6 Program Protection ......................... 29...
Shenzhen Hpmont Technology Co., Ltd. Chapter 1 Safety Information and Precautions Chapter 1 Safety Information and Precautions 1.1 Design Precautions Make sure to have safety circuits outside of the PFC to ensure safe system operation even during external power supply problems or PFC failure. Otherwise, malfunctions may cause serious accidents.
Shenzhen Hpmont Technology Co., Ltd. Chapter 2 Product Introduction Chapter 2 Product Introduction HD-PFT-A (FPC) features are as below: HD-PFT-A • Programmable memory is used to store instructions such as data processing, sequential control, timing, counting and logic operations. And control various types of devices and production process via digital, analog input and output ports.
Shenzhen Hpmont Technology Co., Ltd. Chapter 2 Product Introduction Terminals Description Programmable / HMI MOD2+, MOD2- Programming interface / HMI communication interface communication port CAN+, CAN- CAN communication CAN communication with the host computer, function development Note: If the relay terminal is connected to the AC 220V voltage signal, it must be limited to 3A.
Chapter 2 Product Introduction Shenzhen Hpmont Technology Co., Ltd. Jumper and DIP Switch Description CAN communication matching resistor selection: When 1,2pin is shorted, no matching resistor is used (factory setting); When 2,3pin is shorted, match resistor is used. SEL short selection: When 1,2pin is shorted, SEL is shorted to P24 (factory setting);...
Page 12
Shenzhen Hpmont Technology Co., Ltd. Chapter 2 Product Introduction Source (Drain) Mode Use the source and drain connections of the external power supply, as shown in Figure 2 - 2. (Remove the shorting cap between the SEL and P24 terminals)
Chapter 2 Product Introduction Shenzhen Hpmont Technology Co., Ltd. 2.4.2 Relay Output Terminal (Y) Wiring Y0 and Y1 are transistor outputs, the output voltage range is 0 - 30VDC, and the maximum output current is 50Ma. You can use the internal 24V power supply of the driver or use an external power supply.
Shenzhen Hpmont Technology Co., Ltd. Chapter 2 Product Introduction For inductive loads connected to the AC loop, the external circuit should consider the RC instantaneous voltage sink circuit; for the inductive load of the DC loop, consider adding a freewheeling diode, as shown in Figure 2 - 6.
Chapter 2 Product Introduction Shenzhen Hpmont Technology Co., Ltd. 2.4.4 Temperature Control Input Terminal (PT100) Wiring PTA/PTB is temperature input, supports two independent PT100 temperature acquisition, input temperature range is -150 - 250°C, control accuracy±2°C, resolution 0.1°C. The two-wire PT100 input wiring is shown in Figure 2 - 9. If you are using a three-wire PT100, please refer to the two-wire system for wiring.
Shenzhen Hpmont Technology Co., Ltd. Chapter 3 Functions Name Function Available Devices Step RST reset Keep clearing action and clear storer Y,M,S,T,C,D,V,Z PLS rising edge Rising edge Y,M (except of special M) PLF failing edge Failing edge Y,M (except of special M)
Page 19
Chapter 3 Functions Shenzhen Hpmont Technology Co., Ltd. Rotation and Shift Symbols Functions Symbols Functions Symbols Functions Rotation right SFTR (Bit) shift right SFWR Shift register write Rotation left SFTL (Bit) shift left SFRD Shift register read Rotation right WSFR...
Chapter 3 Functions Shenzhen Hpmont Technology Co., Ltd. 3.4 Special Address 3.4.1 Special M Address RUN input STOP M8000 RUN monitor (a contact) M8001 RUN monitor (b contact) One scan period M8002 Initial pulses (a contact) M8003 Initial pulses (b contact)
Shenzhen Hpmont Technology Co., Ltd. Chapter 3 Functions RS485 Communication M8123 Finished receiving data Programming Port Baud Rate Selection OFF: 19200bps (default) M8124 ON: 9600bps CAN Communication flag M8152 CAN communication completion flag M8155 CAN communication error flag Up/Down Counter Control...
Page 23
Chapter 3 Functions Shenzhen Hpmont Technology Co., Ltd. Special D Address Y000 cumulative pulse Y000 cumulative pulse Y001 cumulative pulse D8140 D8141 D8142 number (low) number (high) number (low) D8143 Y001 cumulative pulse D8144 Y000 high speed pulse D8145 Y001 high speed pulse duty number (high) duty cycle (unit 0.1%, 0 -...
Chapter 4 Usage 4.1 Modbus Communication The HD-PFT-A provides two RS485 communication interfaces (MOD1/MOD2). • MOD1 communicates in MODBUS RTU mode. Can act as a slave or host. • MOD2 can be used as a programming port or MODBUS slave interface (supports 19200bps and 9600bps, 1-8-1 has no parity, and cannot be set to 0x85, 0x82, 0x05, 0x02 four station addresses).
Chapter 4 Usage Shenzhen Hpmont Technology Co., Ltd. Address Specification Communication error code. Receive error code, unsupported operation (no support for attributes, Meaningless, initial value factory values, upper and lower limits, etc.) Receive error code, request frame Normal communication register...
Shenzhen Hpmont Technology Co., Ltd. Chapter 4 Usage 4.1.3 Communication Address Bit Component Address Number (16 digits) Register Address Number (16 digits) M0 - M1535 0x0000 - 0x05FF D0 - D7999 0x0000 - 0x1F3F M8000 - M8255 0x1E00 - 0x1EFF...
Page 27
Chapter 4 Usage Shenzhen Hpmont Technology Co., Ltd. TO: Write only, support command words 0x05, 0x06, 0x0, 0x10. Command input Operand Type Content Data Type High eight-bit command word (component length 1 defaults to 0x06, greater than 1 defaults to 0x10)
Chapter 4 Usage 4.2 CAN Communication Use HD-PFT-A provides one CAN communication interface. 120Ω matching resistors are connected to the CAN interface. When wiring, only CAN+ and CAN- of two cards can be connected to each other for CAN communication.
Chapter 4 Usage Shenzhen Hpmont Technology Co., Ltd. CAN Expansion Terminal Scanning Address Description CAN expansion terminal scanning period (ms) • When there are multiple expansion terminal cards, wait for this time between each card, ie scan cycle = D8110 D8110 * Total number of cards used.
Shenzhen Hpmont Technology Co., Ltd. Chapter 4 Usage 4.2.3 CAN Expansion Terminal Card Scanning The process card supports up to 5 cards from the card to automatically expand the XY input and output points through CAN communication, and the first card also supports the expansion of two-way AI and two-way AO.
Chapter 4 Usage Shenzhen Hpmont Technology Co., Ltd. 4.2.4 CAN Communication Protocol Standard Data Frame The card CAN communication uses the 11-bit identifier flag frame format. Date frame Frame space Arbitration field Control field Data field CRC field Frame end...
Shenzhen Hpmont Technology Co., Ltd. Chapter 4 Usage 4.3 Analog Usage Address The analog address is read and written directly to the operation of the special address. Category Terminal Address High Correction Value Low Correction Value D8240 D8170 D8171 D8241...
Page 33
Chapter 4 Usage Shenzhen Hpmont Technology Co., Ltd. 4.4 Temperature Control Use Item Celsius Input Signal Sensor Current Rated Temperature Effective Digital Resolution Comprehensive Accuracy The PFT-A supports two PT100 temperature measurements using a two-wire connection. When using, connect the two pins of different colors of PT100 to PTA and GND or PTB and GND respectively. For the three-wire connection, the other pin of the PT100 is left unconnected.
Page 34
Shenzhen Hpmont Technology Co., Ltd. Chapter 4 Usage 4.5 Power-down Save Data Usage The battery needs to be installed when using power-down save. The power-down storage range is divided into: fixed power-down storage area, and power-down storage area can be set.
